Computer Graphics Course 2006

Rasterization and Clipping

2

Today’s agenda

We will learn about basic low-level algorithms

dealing with rasterization and clipping.

This algorithms will be implemented in most of

the graphics packages you will deal with.

Basic ideas outlined here are important outside

• f the specific domain of the clipping and

rasterization.

The constants hidden in O(n) algorithms are what all

this is about.

3

Today’s agenda

So what is clipping? rasterization? Lets start with the line clipping

4

Line Clipping Algorithms

Goal: avoid drawing primitives that are

• utside the viewing window.

The most common case: clipping line

segments against a rectangular window

5

Line Clipping Algorithms

Three cases:

Segment is entirely inside the window -

Accept

Segment is entirely outside the window -

Reject

Segment intersects the boundary - Clip

6

Point Classification

How can we tell if a point is inside a

rectangular window?

xmin xmax ymax ymin

max min max min

y y y x x x ≤ ≤ ≤ ≤

max min max min

y y y x x x ≤ ≤ ≤ ≤

7

Line Segment Clipping

If both endpoints are inside the window,

the entire segment is inside: trivial accept

If one endpoint is inside, and the other is

• utside, line segment must be split.

What happens when both endpoints are

• utside? In what situation can we claim

for a trivial reject?

8

Cohen-Sutherland Algorithm

Assign a 4-digit binary outcode to each of

the 9 regions defined by the window:

xmin xmax ymax ymin 0000 0010 0001 0110 1010 1000 0100 1001 0101

9

Cohen-Sutherland Algorithm

xmin xmax ymax ymin 0000 0010 0001 0110 1010 1000 0100 1001 0101 bit bit 1 1 2 2 3 3 4 4 condition condition y > y > y ymax

max

y < y < y ymin

min

x > x > x xmax

max

x < x < x xmin

min

10

Cohen-Sutherland Algorithm

Compute the outcodes C1 and C2

corresponding to both segment endpoints.

If ((C1 | C2) = = 0): Trivial Accept If ((C1 & C2) != 0): Trivial Reject Otherwise, split segment into two parts.

Reject one part, and repeat the procedure

• n the remaining part.

What edge should be intersected ?

11

Example

xmin xmax ymax ymin A B C D Outcode(A Outcode(A) = 0000 ) = 0000 Outcode(D Outcode(D) = 1001 ) = 1001 Clip (A,D) with Clip (A,D) with y = y = y ymax

max, splitting it into (A,B) and (B,D)

, splitting it into (A,B) and (B,D) Reject (B,D) Reject (B,D) Proceed with (A,B) Proceed with (A,B) No trivial accept/reject No trivial accept/reject

12

Example

xmin xmax ymax ymin A B C D Outcode(A Outcode(A) = 0100 ) = 0100 Outcode(E Outcode(E) = 1010 ) = 1010 Clip (A,E) with Clip (A,E) with y = y = y ymax

max, splitting it into (A,D) and (D,E)

, splitting it into (A,D) and (D,E) Reject (D,E) Reject (D,E) Proceed with (A,D) Proceed with (A,D) No trivial accept/reject No trivial accept/reject E

13

Example

xmin xmax ymax ymin A B C D Outcode(A Outcode(A) = 0100 ) = 0100 Outcode(D Outcode(D) = 0010 ) = 0010 Clip (A,D) with Clip (A,D) with y = y = y ymin

min, splitting it into (A,B) and (B,D)

, splitting it into (A,B) and (B,D) Reject (A,B) Reject (A,B) Proceed with (B,D) Proceed with (B,D) No trivial accept/reject No trivial accept/reject

14

Example

xmin xmax ymax ymin B C D Outcode(B Outcode(B) = 0000 ) = 0000 Outcode(D Outcode(D) = 0010 ) = 0010 Clip (B,D) with Clip (B,D) with x = x = x xmax

max, splitting it into (B,C) and (C,D)

, splitting it into (B,C) and (C,D) Reject (C,D) Reject (C,D) Proceed with (B,C) Proceed with (B,C) No trivial accept/reject No trivial accept/reject

15

Parametric Line Clipping (Cyrus-Beck Algorithm)

Represent line segment parametrically as Solve the equation

Dt P t P P P t P + = − + =

1

) ( ) ( Dt P t P P P t P + = − + =

1

) ( ) (

( )

) ( = − ⋅ E t P N (

)

) ( = − ⋅ E t P N

( ) ( ) = ⋅ + − ⋅ ⇔ = − + ⋅ ⇔ Dt N E P N E Dt P N ( ) ( ) = ⋅ + − ⋅ ⇔ = − + ⋅ ⇔ Dt N E P N E Dt P N ( )

D N E P N t ⋅ − − ⋅ =

( )

D N E P N t ⋅ − − ⋅ = N N P P0 P P1

1

E E

16

Intersection Classification (Cyrus-Beck Algorithm)

Clip the line to a rectangle. Clip the line to a rectangle. Edges of rectangle are defined by point and normal. Edges of rectangle are defined by point and normal.

p0 p1

N1 N2 N4 N3 E1 E2 E3 E4

17

Intersection Classification (Cyrus-Beck Algorithm)

• The segment is potentially entering

(PE) the clip region. (remember D=P1-P0)

• The segment is potentially leaving

(PL) the clip region. We want the entry with the highest t1 (or zero) and the lowest leaving t2 (or one). Since those t’s will define the smallest segment which is, when valid, fully included in the clipping region. The range [t1, t2] defines the clipped segment.

( )⇒

< ⋅ D Ni

( )⇒

< ⋅ D Ni

( )⇒

> ⋅ D Ni

( )⇒

> ⋅ D Ni

18

Intersection Classification (Cyrus-Beck Algorithm)

p0 p1 N1 N2 N3 N4 E1 E2 E3 E4

PL PL PE PE

Lets consider several cases: t1>t2 - means that on the line P1-P2 we have first left and then entered the clipping

• region. As in

(But this is not the case as in) Such case should be clipped completely. Another case is when the segment is parallel to on of the clipping edges, as in

PL PE PE PL PE

19

Cyrus-Beck Algorithm

t1=-oo t2 = oo

For each edge i with normal Ni and point Ei compute t.

If return NIL else continue ;

If t2=min(t,t2) else t1=max(t,t1)

If (t2 < t1 or t1>1 or t2<0) then return NIL t1=max(t1,0) t2=min(t2,1) Return [t1,t2]

( )

> ⋅ D Ni

( )

> ⋅ D Ni

) ) ( and (

1 /

> − ⋅ = ⋅

i i i

E P N D N ) ) ( and (

1 /

> − ⋅ = ⋅

i i i

E P N D N

20

Today’s agenda

Now lets see how the rasterization of the

simple line is done

21

Rasterization

Clip primitives to viewing window. Transform clipped primitives to device

coordinates

Points: round floating point coordinates to

nearest pixel coordinates.

Lines: determine the coordinates of all pixels

that “lie” on the line.

22

Rasterization

So how would you draw a simple line?

23

An Incremental Algorithm

Input: endpoints and Compute Line equation for x := x1 to x2

y := Round( ax + b ) DrawPixel( x, y )

) , (

1 1 y

x ) , (

2 2 y

x

( ) ( )

1 2 1 2

x x y y a − − =

b ax ax y ax y + = − + = ) (

1 1

24

Incremental Algorithm

Note: when x is incremented by 1, y is

incremented by a

DrawPixel(x1, y1) y := y1 for x := x1+ 1 to x2

y := y + a DrawPixel( x, Round(y) )

So is there something else left to optimize?

25

The Midpoint Algorithm (Bresenham)

Assumption: line has slope ‘a' between 0

and 1

Idea: choose the next pixel by checking if

the midpoint is above or below the line.

) , ( y x ) , ( y x ) , 1 ( y x + ) , 1 ( y x + ) 1 , 1 ( + + y x ) 1 , 1 ( + + y x ) 2 1 , 1 ( + + y x ) 2 1 , 1 ( + + y x

26

The Midpoint Algorithm

Each line can be written using the line

equation:

The relation between any point (x,y) and

the line can be determined by the sign of F(x,y):

F(x,y) = = 0 for points ON the line F(x,y) < 0 for points ABOVE the line F(x,y) > 0 for points BELOW the line

) , ( = + + = C By Ax y x F ) , ( = + + = C By Ax y x F

27

The Midpoint Algorithm

Given a chosen pixel (x,y), the next pixel will

be:

(x+ 1,y) if F(M) < = 0 (denote this pixel by E ) (x+ 1,y+ 1) if F(M) > 0 (denote this pixel by NE )

) , ( y x ) , ( y x ) , 1 ( y x + ) , 1 ( y x + ) 1 , 1 ( + + y x ) 1 , 1 ( + + y x

) 2 1 , 1 ( + + = y x M ) 2 1 , 1 ( + + = y x M NE E

28

The Midpoint Algorithm

For each pixel compute: Make a decision based on sign of d Incrementally update M and d

) , ( y x ) , ( y x ) , 1 ( y x + ) , 1 ( y x + ) 1 , 1 ( + + y x ) 1 , 1 ( + + y x

) 2 1 , 1 ( + + = y x M ) 2 1 , 1 ( + + = y x M

C y B x A d + + + + = ) 2 1 ( ) 1 (

NE E

29

The Midpoint Algorithm

If d < = 0, we choose (x+ 1, y) (E)

M = M + (1,0) = > d = d + A

If d > 0, we choose (x+ 1, y+ 1) (NE)

M = M + (1,1) = > d = d + (A + B)

Each iteration we compute d by adding

either A or (A+ B), based on the sign of d

30

The Midpoint Algorithm

What should the initial value of d be? To avoid division, we’ll multiply everything

by 2, and result with the following algorithm:

) ( ) ( ) , ( ) ( ) ( ) 1 ( ) , 1 (

2 2 1 1 2 1 1 2 1 1 1 2 1 1 1 B B B

A A y x F A C By Ax C y B x A y x F + = + + = + + + + = + + + + = + +

31

The Midpoint Algorithm

Refering to the implicit line equation: y=(dy/dx)x+b => F(x,y) = Ax + By + C == (dy)x - (dx)y + C = 0 , the Midpoint algorithm is as follows: dE = 2*A /* In order to avoid fractions we’ll dNE = 2*(A+B) /* multiply the equations by 2 x = x0, y = y0 d = 2*A+B DrawPixel( x0, y0 ) while ( x < x1 ) { if ( d <= 0 ) { d = d + dE, x++ } else { d = d + dNE, x++, y++ } DrawPixel( x, y ) }

32

Today’s agenda

And now to the polygon filling (it is

REALLY the last one for today)

33

Point-in-polygon test

How do we tell if a point is inside or

• utside a polygon?

34

Point-in-polygon test

Odd-even rule: count the number of

times a line from the point of interest to a point known to be outside crosses the edges of the polygon.

Odd = inside Even = outside

35

Point-in-polygon test

• Non

Non-

• zero winding number rule:

zero winding number rule: Consider the Consider the number of times the polygon edges wind number of times the polygon edges wind around the point of interest (counter around the point of interest (counter-

• clockwise direction).

clockwise direction).

• Define edge direction to be counter

Define edge direction to be counter-

• clockwise.

clockwise.

• Define edge normal as the clockwise normal.

Define edge normal as the clockwise normal.

• Choose a

Choose a “ “far far” ” point, outside polygon, and cast a point, outside polygon, and cast a ray from the point of interest to that point. ray from the point of interest to that point.

• Calculate a winding number: for each edge crossed:

Calculate a winding number: for each edge crossed:

• If

If angle(ray, normal) < 90 angle(ray, normal) < 90

• increase counter by 1.

increase counter by 1.

• If

If angle(ray, normal) > 90 angle(ray, normal) > 90

• decrease the count by

decrease the count by 1. 1.

• If the winding number is non

If the winding number is non-

• zero the point is

zero the point is inside the polygon. inside the polygon.

36

Point-in-polygon test

Which interior corresponds to which rule?

37

Point-in-polygon test

Which interior corresponds to which rule?

Odd-even rule Winding number

38

Scan-Line Polygon Fill

Two scan-line spans:

from x= 2 through 4 from x= 9 through 13

The scanline “span”:

A span is a group of adjacent pixels on a scanline, that are considered to be interior to the polygon.

39

Polygon Fill-

Scan-line algorithm

For each scan-line crossing the polygon, find

intersections with polygon edges, sort from left to right, and fill interior spans.

40

Polygon Fill-

Scan-line algorithm steps

Find the intersection of the scan line with all

edges of the polygon.

Sort the intersections by increasing x

coordinate.

Fill all pixels between pairs of intersections

that lie interior to the polygon, using the odd- parity rule:

Parity is initially even, and each intersection

inverse the parity bit.

Draw when parity is odd. Do not draw when parity is even.

41

Scan-Line Polygon Fill:

span extrema

.

(a) MidPoint algorithm edge pixels: (b) Only Interior pixels.

42

Polygon Fill - scanline algorithm

Special cases

Q: Given an intersection with an arbitrary

fractional x value, which pixel on either side

• f intersection is interior ?

A: If we approach a fractional intersection to

the right and are inside polygon, we round down the x coordinate to be inside polygon; and vice versa.

43

Polygon Fill - scanline algorithm

Special cases

Q: How do we deal with intersection at integer

pixel coordinate (think of 2 polygons sharing such pixel - to whom does it belong) ?

A:

Leftmost pixels of a span are considered to be interior. Rightmost pixels, are considered to be exterior.

44

Polygon Fill - scanline algorithm

Special cases

Q: How do we deal with intersection at integer pixel

coordinate which is also a shared vertex ? A: We will count only the Ymin vertex of an edge in the parity calculation, but not the Ymax.

Q: How do we deal with intersection at integer pixel

coordinate where the vertices also define a horizontal line ? A: We ignore horizontal edges in intersection calculations.

45

Which edges will be drawn in the polygon

below?

46

Scan-Line Coherence

Scan-line coherence means that the interior spans

corresponding to two adjacent scan lines are usually very similar.

We use scan-line coherence in order to compute

these spans incrementally, rather than intersecting each scan line with the polygon.

In particular, if a polygon edge intersects a scan line

y= k at xk, the intersection with y= k+ 1 is

m x x

k k

1

1

+ =

+

m x x

k k

1

1

+ =

+ (where m is the slope of the edge).

47

Scan-Line Algorithm-

Data structures

Edge Table (ET):

An entry for each scan line crossing the polygon. Each entry contains a list of all polygon edges whose

lower end (Ymin) is on this scan line.

For each edge we store the following information:

xmin, ymax, and slope (dx and dy or m).

The edges in each list are sorted from left to right

(according to their xmin).

48

Scan-Line Algorithm-

Data structures

Edge-Table Example:

49

Scan-Line Algorithm-

Data structures

Active Edge Table (AET):

Maintain an Active Edge list that contains only the list

• f edges crossing the current scan line.

Therefore, the edges held by the AET are updated each new scanline.

In this table each edge element holds the following

information: Ymax, slope, (all taken from the ET), and the x coordinate of intersection point between the edge and current scanline (this should be updated for each new scanline).

The edges in this table are sorted by the x coordinate

• f the intersection points (left to right).

50

Scan-Line Algorithm

ET+ AET Example (AET is given for scanlines 9 & 10): AET:

Scanlines 9: 10:

ET:

Note that this AET example is general, and don’t handle special cases (such as the intersection with edge DC, that according to our rules should be taken as x=12 rather than 13).

51

Scan-Line Algorithm steps

Initialize the ET. Set ‘y’ (the current scanline) to the first non-empty

entry in the ET.

Repeat until the AET and ET are empty:

Move new edges from ET to AET: take all edges in entry y of

ET (recall that these edges has ymin = = y).

Update the x coordinate (intersection point with current

scnline) of each edge in the AET.

Re-sort the AET list, if necessary. Fill interior spans according to the edges on the AET list. Remove from AET those edges with ymax = = y (will not

intersect the next scanline).

Increment y by 1 (move to next scanline).

52

Scan-Line Algorithm

Exercise: Run the algorithm to fill the polygon below:

1 2 3 4 5 6 7 8 1 2 3 4 5 6 1 2 3 4 5 6 7 8 1 2 3 4 5 6

Result:
