RASLRES Energy in Wood Seminar John Dolan. Chartered Engineer BEng (Hons) M.Sc. Fire Eng H.Dip CEng MIEI Planning & Building Unit Tullamore www.energyineducation.ie. planning and building unit based in Tullamore sub units

slide-1
SLIDE 1

John Dolan. Chartered Engineer BEng (Hons) M.Sc. Fire Eng H.Dip CEng MIEI Planning & Building Unit Tullamore

www.energyineducation.ie.

RASLRES Energy in Wood Seminar

slide-2
SLIDE 2

planning and building unit

  • based in Tullamore
  • sub units – property management & site

acquisitions, schools capital appraisals, construction & developing areas , forward planning and professional & technical

  • headed by Seán O Foghlu, Assistant Sec Gen
  • 141 staff – 9 managers, 105 admin,

27 professional / technical staff

slide-3
SLIDE 3

energy in school design

  • evolved from energy programme DART

(Design, Awareness, Research & Technology)

  • informed by building unit professional &

technical staff & external partnerships

  • driven by technical guidance documents
slide-4
SLIDE 4

energy in school design

  • updated by continued energy research &

development

  • disseminated by internal / external

publications, conferences & annual report

  • supported by SEAI and cross border co
  • peration projects
  • acknowledged by national &

international energy awards

slide-5
SLIDE 5

issues particular to schools

  • hours of operation
  • schools needs: not same as domestic

market needs

  • technical ability on site
  • energy is not core function
  • solutions must be robust
slide-6
SLIDE 6

50 100 150 200 250

Schools built in 1980's Schools built in 1990's Schools, Best Practice Current school designs based on TGD's

energy usage in new primary schools

Energy used kWhr/m2/year

  • BER requirements are A3 & B1
slide-7
SLIDE 7

50 100 150 200 250

Schools built in 1980's Schools built in 1990's Schools, Best Practice Current school designs based on TGD's Colaiste Choilm

energy usage Energy used kWhr/m2/year

slide-8
SLIDE 8

50 100 150 200 250 Schools built in 1980's Schools built in 1990's Schools, Best Practice CIBSE Current school designs based on TGD's Passive schools

energy usage in primary schools with passive approach

Energy used kWhr/m2/year

slide-9
SLIDE 9

biomass research & demonstration project

  • overview of programme
  • end users feedback
  • fuel supply chain
  • initial findings
  • conclusions to date
slide-10
SLIDE 10

The objectives of the programme

  • to test and evaluate biomass systems
  • reduce energy in use, produce CO2 saving
  • to evaluate the appropriateness & benefits
  • f combining solar hot water & biomass
  • to monitor performance
  • to develop a suite of case studies
  • to develop a best practice design guide
  • evaluate potential for ESCO supply model
slide-11
SLIDE 11
  • CBS Roscommon
  • St Mary’s Boys NS Cavan
  • St Brendans NS Birr
  • Kentstown N.S. Meath
  • Glangelvin N.S. Cavan
  • St Peters Community School Cork
  • Scoil Mhuire Mullingar
  • Scoil Na Naingeal Noafa Boyle
  • St Josephs Junior School Dublin
  • St Josephs Senior School Ballymun
  • Cloghan NS Offaly
  • St Cholmcille NS Donegal
  • Ballyfin N.S. Laois
  • Emo N.S. Laois
slide-12
SLIDE 12

the the numbe numbers

  • 14 sites
  • 15 schools
  • 17 boilers
  • 9 different M&E Consultants
  • 8 different manufacturers
  • 13 different boiler models
  • 13 different contractors
slide-13
SLIDE 13

the stats

  • 2263 kW boiler power
  • carbon reduction pa. ~ 392 tonnes
  • grant aided under the renewable heat

deployment programme by SEAI

slide-14
SLIDE 14

Convent N.S Boyle County Roscommon

slide-15
SLIDE 15

Cloghan N.S County Offaly

slide-16
SLIDE 16

Kentstown NS County Meath

slide-17
SLIDE 17

 educational value

slide-18
SLIDE 18
  • St. Peter's Community School, Passage West, Co. Cork
slide-19
SLIDE 19

biomass biomass St Joseph’s Ballymun

slide-20
SLIDE 20
  • St. Brendan’s Boys P.S. Birr County Offaly
slide-21
SLIDE 21

CBS Mullingar County Westmeath

slide-22
SLIDE 22

Ballyfin N.S County Laois

slide-23
SLIDE 23

biomass research & demonstration project

  • overview of programme
  • end users feedback
  • fuel supply chain
  • initial findings
  • conclusions to date
slide-24
SLIDE 24

end user feedback

  • satisfaction survey with end users
  • 10 statements
  • score 5 = strongly agreed
  • score 1 = strongly disagreed
slide-25
SLIDE 25

1 - The Biomass Installation has benefited the school.

1 2 3 4 5

Strongly Agree Strongly Disagree Small Primary Medium Primary Large Primary Second Level

slide-26
SLIDE 26

2 – We have seen significant benefit in the running cost of the installation

1 2 3 4 5

Strongly Agree Strongly Disagree Second Level Large Primary Medium Primary Small Primary

slide-27
SLIDE 27

3 – The Biomass Plant is Reliable

1 2 3 4 5

Strongly Agree Strongly Disagree Second Level Large Primary Medium Primary Small Primary

slide-28
SLIDE 28

4 – The Biomass Plant is easy to maintain

1 2 3 4 5

Strongly Agree Strongly Disagree Second Level Large Primary Medium Primary Small Primary

slide-29
SLIDE 29

5 – Any boiler warranty / fault issues are dealt with quickly and efficiently

1 2 3 4 5

Strongly Agree Strongly Disagree Second Level Large Primary Medium Primary Small Primary

slide-30
SLIDE 30

6 – The caretaking / allocated staff are correctly

trained and able to carry-out day to day checks

1 2 3 4 5

Strongly Agree Strongly Disagree Second Level Large Primary Medium Primary Small Primary

slide-31
SLIDE 31

7 – Ash removal and disposal is not an issue

1 2 3 4 5

Strongly Agree Strongly Disagree Second Level Large Primary Medium Primary Small Primary

slide-32
SLIDE 32

8 – Fuel supplier can be found easily and reliable

1 2 3 4 5

Strongly Agree Strongly Disagree Second Level Large Primary Medium Primary Small Primary

slide-33
SLIDE 33

9 – there is competition in the choice of fuel supplier

1 2 3 4 5

Strongly Agree Strongly Disagree Second Level Large Primary Medium Primary Small Primary

slide-34
SLIDE 34

10 – Biomass Integration in schools is a significant benefit and should be rolled out through the country

1 2 3 4 5

Strongly Agree Strongly Disagree Second Level Large Primary Medium Primary Small Primary

slide-35
SLIDE 35

Individual average response

1 2 3 4 5

Strongly Agree Strongly Disagree Second Level Large Primary Medium Primary Small Primary

slide-36
SLIDE 36

Overall average response

3.6 3.1 3.0 3.3 2.9 2.8 3.8 3.8 2.9 2.9 0.0 1.0 2.0 3.0 4.0 5.0

The biomass installation has benefited the school we have seen significant benefit in the running cost the biomass plant is reliable the biomass plant is easy to maintain boiler warranty / fault issues are dealt with quickly the caretaking staff are correctly trained and able to carry out day to day checks ash renoval & disposal is not an issue fuel supplies can be found easily and readily there is competition in the choice of fuel supplier biomass integration in schools is of signifficant benefit and should be rolled out throughout the country

Strongly Agree Strongly Disagree

slide-37
SLIDE 37

biomass research & demonstration project

  • overview of programme
  • end users feedback
  • fuel supply chain
  • initial findings
  • conclusions to date
slide-38
SLIDE 38

WOOD PELLET DISTRIBUTORS

(50km delivery radius indicated)

WOOD PELLET MANUFACTURERS IN IRELAND

(100km delivery radius indicated)

DUBLIN BELFAST

KERRY CORK WATERFORD WEXFORD WICKLOW LAOIS CLARE KILDARE GALWAY ROSCOMMON KELLS LOUTH DEPOT DEPOT DEPOT DEPOT DEPOT DEPOT DEPOT DEPOT DEPOT DEPOT DEPOT

km 100 50 miles 60 30

TIMBERPRO MANUFACTURERS

DPELLET,KNOCKTOPHER BALCAS,ENNISKILLEN LAOIS SAWMILLS, PORTLAOISE BALCAS,MALLOW

CLEARPOWER

WOOD PELLET DISTRIBUTORS IN IRELAND

slide-39
SLIDE 39

WOOD CHIP MANUFACTURERS / DISTRIBUTORS IN IRELAND (50km delivery radius indicated)

WOOD PELLET DISTRIBUTORS IN IRELAND

DUBLIN BELFAST

DERRY

km 100 50 miles 60 30

IMPERATIVE ENERGY OTHERS

BAILEY WOODCHIP, BALLACOLLA

RURAL GENERATION

ARDEE ROSCOMMON ENNISKILLEN ECO WOOD LETTERKENNY GLENMORE CARRIGALINE KNOCKNAGASHEL PORTLAOISE

slide-40
SLIDE 40

biomass research & demonstration project

  • overview of programme
  • end users feedback
  • fuel supply chain
  • initial findings
  • conclusions to date
slide-41
SLIDE 41

initial findings

  • mixed feedback on success of applications
  • fuel delivery
  • fuel storage
  • boiler feed systems / manual feed point
  • cleaning and ash
  • minimise heat loss first
  • on site technical capabilities
slide-42
SLIDE 42

initial findings

  • challenge to integrating with existing dated

systems

  • mixed results in energy savings costs
  • paybacks
slide-43
SLIDE 43

initial findings paybacks second level

Savings Paybacks

€ 3,972.50 € 4,658.47 € 2,217.49 500 ,000 ,500 ,000 ,500 ,000 ,500 ,000 ,500 ,000 Savings per annum (€) 23.1 27.8 36.6 10 20 30 40 50 Simple Payback (years)

slide-44
SLIDE 44

initial findings paybacks large primary

Savings Paybacks

€ 8,423.79 € 9,149.04 Savings per annum (€) 18.6 6.5 5 10 15 20 25 Simple Payback (years)

slide-45
SLIDE 45

initial findings paybacks medium primary

Savings Paybacks

8.8 20.7 6.6 12.5 14.5 5 10 15 20 25 Simple Payback (years)

€ 4,927.96 € 2,597.14 € 4,148.81 € 3,334.66 € 3,575.14 500 1,000 1,500 2,000 2,500 3,000 3,500 4,000 4,500 5,000 Savings per annum (€)

slide-46
SLIDE 46

initial findings paybacks small primary

Savings Paybacks

9.7 12.6 11.0 12.7 5 10 15 Simple Payback (years) € 1,489.85 € 1,144.39 € 2,324.76 € 3,695.57 Savings per annum (€)

slide-47
SLIDE 47

initial findings

  • service industry development
  • disruption potential to school management
  • potential educational value
  • reduction in carbon emissions
  • boiler combustion sensitivity
  • controls strategies
  • two may be cheaper than one
slide-48
SLIDE 48

biomass research & demonstration project

  • overview of programme
  • end users feedback
  • fuel supply chain
  • initial findings
  • conclusions to date
slide-49
SLIDE 49

conclusions to date

  • study has succeeded in discovering issues and

challenges for successful integration

  • fuel supply chain is strong
  • some sites inconclusive need further evaluation
  • satisfaction ratings - big concern
  • consumer confidence
  • biomass industry needs to respond nationally
  • next steps
slide-50
SLIDE 50

www.energyineducation.ie
