RabbitMQ at Scale, Lessons Learned OpenStack Summit Barcelona Matthew Popow, Weiguo Sun, Wei Tie, Scott Pham, Kerry Miles @mattpopow October 26, 2016 Environment Details Overcloud / Undercloud 800+ Nova Compute Nodes, 700 Routers,

slide-1
SLIDE 1

OpenStack Summit Barcelona

RabbitMQ at Scale, Lessons Learned

Matthew Popow, Weiguo Sun, Wei Tie, Scott Pham, Kerry Miles @mattpopow October 26, 2016

slide-2
SLIDE 2

2

  • Overcloud / Undercloud
  • 800+ Nova Compute Nodes, 700 Routers, 1,000+ networks, 10,000 + ports
  • Each OpenStack service is run on 3 controller VMs
  • Neutron & OVS & L3 agent
  • RabbitMQ Cluster
  • 3 x 4 vCPU 8GB RAM
  • 3 node Active / Active cluster
  • RHEL 7, RabbitMQ 3.3.5-22, ErlangR16B-03.7
  • Icehouse & Juno (OSP)
  • No heartbeat or QoS

Environment Details

slide-3
SLIDE 3

3

When things go astray

slide-4
SLIDE 4
slide-5
SLIDE 5

5

  • nova compute services down/flapping
  • Instances failing to boot, waiting for port binding
  • Neutron agent timeouts
  • RabbitMQ queues growing

Timeout waiting on RPC response - topic: "q-plugin", RPC method: "report_state" info: "<unknown>”

Symptoms of RabbitMQ Issues

slide-6
SLIDE 6

6

Restarting services can compound the issue

slide-7
SLIDE 7

7

OpenStack Configuration Parameters

Neutron & Nova Client Configuration Enlarge rpc pool

  • rpc_thread_pool_size = 2048
  • rpc_conn_pool_size = 60

Extend timeouts

  • rpc_response_timeout = 960 (especially for large neutron stacks)
  • get_active_network_info(), sync_state() (dhcp-agent, l3-agent)
  • performance optimization in Kilo

Add more workers/consumers

  • rpc_workers = 4 (we run 3 neutron controllers)
slide-8
SLIDE 8

8

3 neutron rpc_workers, 10k backlog

slide-9
SLIDE 9

9

18 neutron rpc_workers, 10k backlog

slide-10
SLIDE 10

10

Client disconnect & (404) errors

  • Even with RPC tuning, frequent disconnects / reconnects
  • With reconnect seeing 404
  • Agent restart was needed
  • OVS flows reloaded (pre-Liberty) L

(404) NOT_FOUND - no queue 'q-agent-notifier- network- delete_fanout_a4db343065984f74971fe0080013744e' in vhost '/'

slide-11
SLIDE 11

11

Kombu Driver (Icehouse) / Oslo

  • Race condition with auto-delete queues
  • Before Juno, auto-delete was not configurable for Neutron
  • When reconnect occurs, race with queue declaration and auto-delete
  • Backport Oslo driver
  • Kombu driver improvements for Neutron
slide-12
SLIDE 12

12

neutron/openstack/common/rpc/impl_kombu.py https://bugs.launchpad.net/neutron/+bug/1393391 Ubuntu Cloud Archive Patch

slide-13
SLIDE 13

13

Connection issues?

slide-14
SLIDE 14

14

RabbitMQ Erlang Configuration

RABBITMQ_SERVER_ERL_ARGS="+K true +A128 +P 1048576

  • kernel inet_default_connect_options [{nodelay,true},{raw,6,18,<<5000:64/native>>}]
  • kernel inet_default_listen_options [{raw,6,18,<<5000:64/native>>}]”
  • +K true # sets keepalive
  • +A 128
  • sets Erlang VM I/O Thread Pool Size
  • {raw,6,18,<<5000:64/native>>}
  • Sets TCP_USER_TIMEOUT to 5 seconds, with the idea being to quickly detect

when an established connection fails

  • Common config recommendation
slide-15
SLIDE 15

15

TCP_USER_TIMEOUT notes

  • Note, setting TCP_USER_TIMEOUT will override tcp_keepalive timers if its shorter.
  • Dropping a single TCP keepalive packet could trigger a socket teardown.
  • Can happen between RabbitMQ and Client or between cluster

=ERROR REPORT==== 22-May-2016::08:36:42 === closing AMQP connection <0.24752.1> (10.203.106.41:35234 -> 10.203.108.11:5672): {inet_error,etimedout} RPC QoS added in Liberty: https://bugs.launchpad.net/oslo.messaging/+bug/1531222

slide-16
SLIDE 16

16

Virtualizing Control Plane

  • Default KVM txqueuelen is tiny, 500 packets

# ifconfig tap79920654-fa tap79920654-fa: flags=4163<UP,BROADCAST,RUNNING,MULTICAST> mtu 1500 ether fe:16:3e:71:7c:d3 txqueuelen 10000 (Ethernet) RX packets 8360296 bytes 2076339428 (1.9 GiB) RX errors 0 dropped 0 overruns 0 frame 0 TX packets 5544232 bytes 793456462 (756.6 MiB) TX errors 0 dropped 0 overruns 0 carrier 0 collisions 0

# Add udev rule to Set Tap Interface TX Queue Length KERNEL=="tap*", RUN+="/sbin/ip link set %k txqueuelen 10000”

slide-17
SLIDE 17

17

  • Never Suspend RabbitMQ VM
  • Monitor Hypervisor for issues
  • CPU soft lockup (can trigger partition)
  • Disk / Memory Contention
  • RAID / IO controller resets

Virtualizing Control Plane Cont.

slide-18
SLIDE 18

18

RabbitMQ Configuration

[ {rabbit, [ {cluster_nodes, {['rabbit@rabbitmq-001', 'rabbit@rabbitmq-002', 'rabbit@rabbitmq-003'], disc}}, {cluster_partition_handling, pause_minority}, {vm_memory_high_watermark, 0.4}, {tcp_listen_options, [binary, {packet,raw}, {reuseaddr,true}, #reuse sockets in TIME_WAIT, not safe for NAT {backlog,128}, {nodelay,true}, # disabling Nagle’s Algorithm for increased throughput {exit_on_close,false}, {keepalive,true}]} #enable tcp keepalives ]} ].

slide-19
SLIDE 19

19

RabbitMQ Process Level Tuning

Limit Soft Limit Hard Limit Units Max CPU Time unlimited unlimited seconds Max file size unlimited unlimited bytes Max data size unlimited unlimited bytes Max stack size unlimited unlimited bytes Max core file size unlimited unlimited bytes Max resident set unlimited unlimited bytes Max processes unlimited unlimited processes Max open files 65536 65536 files Max locked memory unlimited unlimited bytes Max address space unlimited unlimited bytes Max file locks unlimited unlimited locks Max pending signals unlimited unlimited signals Max msgqueue size unlimited unlimited bytes Max nice priority unlimited unlimited Max realtime priority unlimited unlimited Max realtime timeout unlimited unlimited us

slide-20
SLIDE 20

20

  • i.e. RHEL/CentOS:
  • cat /proc/$(cat /var/run/rabbitmq/pid)/limits

Verify Process Limits

slide-21
SLIDE 21

21

  • Pause minority vs. autoheal
  • CAP Theorem; Consistency vs. Availability
  • Pause minority require quorum, will pause if only one node is alive
  • Autoheal & pause_minority not perfect
  • Partition monitoring and alerting
  • Automation to restore partition
  • Wipe/var/lib/rabbitmq/mnesia on problem node, restart RabbitMQ

Partition Handling

slide-22
SLIDE 22

22

Queue Mirroring

  • Set by RabbitMQ policy
  • {“ha-mode”:”all”}
  • rabbit_ha_queues = True #depricated
  • Not applicable for RabbitMQ > 3.x
  • Mirroring not needed for RPC, expensive
  • Only mirror billing queues, notification
  • Deployment examples in Liberty without queue mirroring
  • Policy change likely requires cluster restart
slide-23
SLIDE 23

23

  • Default TCP settings are not ideal
  • 2 hours before first TCP probe is sent
  • Then resend probe every 75 seconds
  • No ACK for 9 times, then mark connection as dead
  • Adjusting can help with client failover / reconnection

Operating System Tuning

Parameter Value net.ipv4.tcp_keepalive_time 5 net.ipv4.tcp_keepalive_probes 5 net.ipv4.tcp_keepalive_intvl 1 net.ipv4.tcp_retries2: 3

slide-24
SLIDE 24

24

Monitoring RabbitMQ

  • Health Check / Query each node (rabbitmqadmin)
  • cluster health / partition status
  • erlang mem util vs high-water mark
  • file descriptors used
  • sockets used
  • process utilization
  • system memory
  • disk utilization
  • queues and number of unacked messages
  • total unacked messages
  • rabbitmq.log for alarm sets:

“New connections will not be accepted until this alarm clears”

slide-25
SLIDE 25

25

Monitoring RabbitMQ Cont.

  • Synthetic Tests
  • Boot a VM; Create Router / Network / Ping VM
  • Create Volume
  • Upload Image
  • Failures of synthetic transaction can indicate RabbitMQ issue
slide-26
SLIDE 26

26

  • Rabbitmqadmin vs rabbitmqctl
  • Before 3.6.0 rabbitmqctl list commands did not stream
  • Hang with stuck queues
  • Monitor memory management of stats database
  • rabbitmqctl status
  • rabbitmqctl eval 'exit(erlang:whereis(rabbit_mgmt_db), please_terminate).'
  • Disabling RabbitMQ UI
  • Adjusting collect_statistics_interval, default 5000ms
  • rabbitmqctl eval 'application:set_env(rabbit, collect_statistics_interval, 60000).’

Tips

slide-27
SLIDE 27

27

Tips Cont.

  • Set policy for Queue TTL
  • {“expires”: “#ms”}
  • > rpc_mesage_timeout
  • 0 consumers
  • Don’t use auto-delete queues
  • If lots of reconnect between client / server

investigate rpc tuning & network stack

  • rabbit_hosts=<randomize order>
slide-28
SLIDE 28

28

Architectural Decisions

Nova, Neutron, Glance Cinder

  • Single Cluster vs. Many

Ceilometer, Heat

slide-29
SLIDE 29

29

  • Troubleshooting oslo.messaging /

RabbitMQ issues (Austin 2016)

  • Troubleshooting RabbitMQ and Its

Stability Improvement (Tokyo 2015)

  • rabbitmq-users

Resources

slide-30
SLIDE 30

30

Q&A
