Ali Sanhaji Javier Rojas Balderrama Matthieu Simonin

OpenStack Summit | Berlin 2018

RabbitMQ or Qpid Dispatch Router: Pushing OpenStack to the Edge

Who’s here

Ali Sanhaji Research engineer at Orange, France Javier Rojas Balderrama Research engineer at Inria, France Matthieu Simonin* Research engineer at Inria France

Agenda

• Bringing OpenStack to the edge
• RabbitMQ and Qpid Dispatch Router for OpenStack over a WAN
• Performance evaluation
• Conclusions and next steps

Core Network DC1 DC2 Regional sites Local sites Edge sites

• Scalability
• Locality
• Placement
• Resiliency
• ...

Challenges at the edge

OpenStack to the edge

• For a telco like Orange, pushing OpenStack to the edge is key
• How to deploy OpenStack in small edge sites

(control plane + compute nodes)? ○ Costly and too many control planes to manage and synchronize ○ ⇒ Have a centralized control plane (APIs) and remote compute nodes

• OpenStack scalability (stateless processes)
• OpenStack over a WAN

WAN

Core

Keystone Glance Nova (control) Neutron (control) Horizon

Edge

Edge Deployment:

• Centralized control services
• Remote edge compute nodes

Communication between edge and core

• RPC traffic (periodic tasks, control traffic)
• Rest API calls (e.g., between nova and glance)

Deployment under consideration

Nova (agent) Neutron (agent) Nova (agent) Neutron (agent) Nova (agent) Neutron (agent)

The message bus in OpenStack

• One critical component in OpenStack is the message bus

used for interprocess communication

• Used by processes to send various RPCs:

○ call: request from client to server, client waiting for response ○ cast: request from client to server, no response (direct notification) ○ fanout: request from client to multiple servers, no response (grouped notification)

Nova API Nova compute Nova scheduler Nova conductor

message bus

Neutron server Neutron agent

message bus

Client Server Request Response Client Server RPC Client Server RPC Server Server

Call Cast Fanout

Broker cluster Router topology

The message bus in OpenStack

• Processes use oslo.messaging library to send RPCs

It supports multiple underlying messaging implementations

Nova API Nova compute Nova scheduler Nova conductor

• slo.messaging

Neutron server Neutron agent RabbitMQ (AMQP 0.9.1) QPID Dispatch Router (AMQP 1.0) RabbitMQ (AMQP 0.9.1) QPID Dispatch Router (AMQP 1.0) Client Server Server Client

• slo.messaging

The message bus over a WAN

Central site Regional site 1 Edge site 3 Edge site 1 Edge site 2 Edge site 4 Edge site 5 Edge site 6 Regional site 2

Client 3 Server 3 Client 2 Server 2 Server 1 Client 1 Server 4

Broker cluster

The message bus over a WAN

Central site Regional site 1 Edge site 3 Edge site 1 Edge site 2 Edge site 4 Edge site 5 Edge site 6 Regional site 2

Client 3 Server 3 Client 2 Server 2 Server 1 Client 1 Server 4

Goal

Evaluate the performance of RabbitMQ and Qpid Dispatch Router over a WAN

○ How do they resist to WAN constraints (packet loss, latency, dropouts)? ○ Does a router fit better in a decentralized environment? ○ Are OpenStack operations still robust without a broker retaining messages? ○ Is a broker safer than a router? ○ How RPC communications (RabbitMQ and QDR) behave in a WAN?

What could go wrong in a WAN?

RPC client RPC server

Examples of two possible situations: latency/loss between client and bus

(e.g., nova-conductor sends a boot request to nova-compute)

latency/loss between server and bus

(e.g., nova-compute sends a vm state update to nova-conductor) RPC client RPC server

RPC client

RPC server

1

RPC client

RPC server

2

What could go wrong in a WAN?

In case of latency RPC calls:

• Sender blocks for 2× latency

RPC casts (fire and forget semantics):

• Correct semantic with QDR driver
• Incorrect semantic with RabbitMQ driver
• In 1. Sender waits for 2x latency (acks)
• But higher guarantee on message delivery

Experiments

Context

○ Test plan of massively distributed RPCs

https://docs.openstack.org/performance-docs/latest/test_plans/ massively_distribute_rpc/plan.html

○ Two categories of experiments: 1. Synthetic (rabbitmq/qdr, decentralized configuration) 2. Operational (with OpenStack and centralized bus)

• Network dropout
• Latency and loss

Tools

○ EnOS for OpenStack deployment (virtualization, bare metal) https://github.com/BeyondTheClouds/enos ○ Grid’5000 a dedicated testbed for experiment-driven research

Synthetic experiment recap

OpenStack Summit Vancouver 2018 presentation

• Evaluation of the implemented patterns of RPC messages in OpenStack
• Brokers and routers scalabilities are similar, but router is lightweight and

achieves low latency message delivery especially under high load

• Routers offers locality of the messages in decentralized deployments
• Decentralization need to be applied to APIs and database

Openstack internal messaging at the edge: In depth evaluation

www.openstack.org/summit/vancouver-2018/summit-schedule/events/2100 7/openstack-internal-messaging-at-the-edge-in-depth-evaluation

https://hal.inria.fr/hal-01891567 × 9→17 × 8→27 × 2

WAN

Keystone Glance Nova (control) Neutron (control) Bus (RMQ/QDR)

Operational experiments

× 3 + 1 Edge nodes

Nova (agent) Neutron (agent) Nova (agent) Neutron (agent) Nova (agent) Neutron (agent)

× 100/400 Core node

Software

• OpenStack stable/queens
• Optimised Kolla based deployment
• RabbitMQ version: v3.7.8
• Qpid-Dispatch Router v1.3.0

Infrastructure

• Hardware: Dell PowerEdge C6420 × 20
• 32 cores
• 193 GB RAM
• Virtualized deployment
• Core: 32 cores, 64 GB RAM
• Edge: 2 cores, 4 GB RAM

Network dropout

Configuration

• Iptables on the core nodes

(controller and network nodes)

• Cron to schedule dropouts

○ Frequency: [5m, 10m] ○ Duration: [30s, 60s, 120s]

• Rally

○

constant_for_duration

runner ■ Concurrency 5 ■ Duration 30m

• OpenStack with 100 computes

Full deployment for each combination (set of parameters, bus)

Network dropout: boot_and_delete_servers

Network dropout: boot_and_delete_servers

Latency and Loss

Configuration

• Parameters

○ Latency: [0, 5, 20, 40, 80, 120, 200] s ○ Loss: [0, 0.1, 0.2, 0.4, 0.8, 1.0, 2.0] %

• Rally

○

constant runner

■ Concurrency: 5 ■ Iterations: 100

• OpenStack

○ Computes: [100, 400]

Full deployment for each combination (set of parameters, bus)

100 computes

400 computes

100 computes

Timeline behind the scene of rally benchmarks (multicast/400 computes)

• boot_server_and_attach_interface
• create_and_delete_network
• create_and_delete_port
• create_and_delete_router
• create_and_delete_security_groups
• create_and_delete_subnet
• set_and_clear_gateway

anycast queues

fanout queues

Conclusions

Summary

• In front of WAN latency and loss, the router (no message

retention) is as effective at delivering messages as the broker (message retention)

• Router is less resilient in the case of network dropouts
• QDR consumes way less resources than RMQ

What’s next

• Bring QDR closer to edge sites and to compute nodes in
• rder to leverage routing capabilities
• Bigger scale of compute nodes
• Make OpenStack control plane even more decentralized

if possible (e.g., database)

https://beyondtheclouds.github.io ali.sanhaji@orange.com javier.rojas-balderrama@inria.fr matthieu.simonin@inria.fr
