R URAL O NTARIO R ESIDENTIAL B ROADBAND P ROJECT #1 D AWN -E UPHEMIA T OWNSHIP O VERVIEW FOR R ESIDENTS K IRBY K OSTER , S ENIOR M ANAGER B ROADBAND P ROGRAMS Overview of the Rural Ontario Residential Broadband Program from CENGN CENGN is a

slide-1
SLIDE 1

RURAL ONTARIO RESIDENTIAL BROADBAND PROJECT#1 DAWN-EUPHEMIA TOWNSHIP OVERVIEW FOR RESIDENTS

KIRBY KOSTER, SENIOR MANAGER BROADBAND PROGRAMS

slide-2
SLIDE 2

Overview of the Rural Ontario Residential Broadband Program from CENGN

  • CENGN is a not-for-profit company out of Ottawa, Ontario.
  • CENGN is funded by the Ontario Government to drive innovative technology

solutions and help fund projects that bring high-speed internet to underserved small Rural and Northern Ontario communities.

  • CENGN is paying 50% of the costs of the radio and optical equipment required for

a local ISP to offer new commercial internet access services to your area.

  • There is no cost contribution required from the Township Council for this

project.

  • Project is committed to a long-term commercial internet access service
  • ffering for the Township of Dawn-Euphemia.
slide-3
SLIDE 3

Who will be the Wireless Internet Service Provider?

Headquartered in Thamesville, Ontario Key Strengths of MPV Wifi for Residents Rural Ontario Community Experience

  • Extensive Experience - installing wireless networks in Rural Ontario
  • Local Internet Service Provider
  • Strong Understanding of Rural and Farming Clients needs
  • Wide Coverage of high-quality wireless internet access for the township
  • Multiple Types of Wireless Services to deal with open spaces or dense

tree cover

  • Unlimited Data Plans – No data cap or unexpected overage charges
  • Wide range of Pricing and Capacity Options for internet access services
  • Already Serving Dawn-Euphemia Township
  • Currently also offers internet access services in

Chatham-Kent, Middlesex County, and Elgin County

  • Over 40 towers in MPV Wifi Network
  • 600 Residential Customers in Southwestern Ontario
slide-4
SLIDE 4

Broadband Project Overview

New Fibre-Optic Internet Connectivity Throughout the Village of Florence

§ High-speed Fibre-To-The Home (FTTH) will be available to all homes and businesses in the village

New Fibre-Speed Fixed Wireless Internet Connectivity in the Hamlet of Shetland

§ High-speed internet access services will be available to all homes and businesses in the hamlet

New High Speed Fixed Wireless Services for a Wide Area of the Township

§ Mix of wireless technologies, and FTTH where it makes sense

New High Speed Fixed Wireless Internet Connectivity for those with Dense Tree Cover

§ Will reduce the need for some residents who currently would require a tower on their property to receive service

New Wide Selection of Different Internet Access Plans with NO DATA CAP

§ Can select from selection of lower cost options § Can select from selection of throughput options

slide-5
SLIDE 5

Overview of New Wireless Internet Access for the Township

  • 5 distribution “tower” sites utilized
  • Two different wireless options for

for wide coverage:

  • Higher capacity 5 GHz radio

technology

  • 5-7 km out from tower
  • Lower capacity 3.65 GHz

technology

  • 7–15 km from tower
  • Better tree foliage

penetration

  • Fibre & Wireless for Florence
  • High-Speed Wireless for Shetland
  • Dual Fibre Backhaul Connections

to the internet for redundancy

  • Multiple Links between towers and

grain elevators for high reliability

slide-6
SLIDE 6

Mix of Grain Elevators & Towers to Get Wireless Services to Residents

Shetland Access Florence Access Florence Fiber Backhaul Tower Cairo Access Newbury Station Access

8547 Bentpath Line ,Newbury, ON N0L 1Z0 1263 Shetland Rd, Florence, ON N0P 1R0 6200 Fansher Rd, Florence, ON N0P 1R0 6213 Mill St, Florence, ON N0P 1R0

7708 Bentpath Line, Bothwell, ON N0P 1CO

Rutherford Access

520 Dawn Mills Rd, Dresden, ON N0P1M0

slide-7
SLIDE 7

Wide Range of Internet Access Options for the Community

Service Options for the Rest of the Township (subject to quality of LOS, and distance to nearest Tower)

slide-8
SLIDE 8

FTTH for the Village of Florence

  • Project will bring improved internet access services to residents
  • f Florence through Fibre-to-the-Home
  • Future-proof Service will support future higher capacity services

with no in-house equipment changes required

  • No damage to driveway or street pavement during installation
  • installation crew will use horizontal boring under driveway
  • r street for fibre installation
  • All homes and businesses could be supported in Village
slide-9
SLIDE 9

What New Services will be Available in the Village of Florence?

slide-10
SLIDE 10

60GHz Wireless Distribution for Hamlet of Shetland

  • Project will bring fibre-like wireless internet access services to

residents of Shetland through 60GHz wireless technology

  • All homes and businesses could be supported in the hamlet
  • Support up to 100 Mbps download speeds per home
  • High Reliability Wireless Service will be backed up second radio

frequency to protect against heavy rain/snow weather impacts

  • Internet Access via Radio on Grain Elevator in Shetland
  • 60GHz Technology ideal for this size of community
slide-11
SLIDE 11

What New Services will be Available in the Hamlet of Shetland?

In the Hamlet of Shetland Only

High Capacity Wireless Services (60 GHz)

In the Hamlet of Shetland & Surrounding Area In the Hamlet of Shetland & Surrounding Area (and areas of moderate to heavy tree cover)

slide-12
SLIDE 12

What New Wireless Services will be Available Across the Township?

Wireless Service Unlimited Data Monthly Charge 10 Mbps Down 1 Mbps Up $70.00 15 Mbps Down 2 Mbps Up $90.00 25 Mbps Down 2 Mbps Up $125.00

Across the Township (and locations where tree cover is a problem)

Range of Wireless Services (3.65 GHz) Wireless Service Unlimited Data Monthly Charge 10 Mbps Down 2 Mbps Up $50.00 15 Mbps Down 5 Mbps Up $90.00 25 Mbps Down* 7 Mbps Up $100.00 50 Mbps Down* 10 Mbps Up $150.00

* Higher Speeds Only Within 3-7 km of Tower Sites

Range of Wireless Services (5 GHz)

slide-13
SLIDE 13

What do I need outside my home if I want either the 3.65GHz or 5GHz service?

  • Mast or Corner Mount
  • Installation Provided
  • For Outdoor Use
  • Pole or Wall Mount
  • Installation Provided
  • For Outdoor Use

Low Gain

Option#2 – Heavy Tree Cover or more than 7 km from Tower Up to 25 Mbps Down / 2 Mbps Up Option#1 – Clear LOS to the Tower

  • r Moderate Tree Cover

Up to 25 Mbps Down / 2 Mbps Up

Optional Roof J-Mount Optional Roof J-Mount

High Gain

3.65 GHz LTE – Wireless Internet Access Service 5 GHz – Wireless Internet Access Service

  • Post, Roof, Eaves, or Tower
  • Installation Provided
  • For Outdoor Use

Dish with J Mount – Clear LOS to the Tower

  • r Light Tree Cover

Up to 50 Mbps Down / 10 Mbps Up

slide-14
SLIDE 14

What do I need outside my home if I live in Shetland and want high-speed service?

Optional Roof J-Mount

60 GHz – High Speed Wireless Internet Access Service

  • Post, Roof, Eaves, or Tower
  • Installation Provided
  • For Outdoor Use

Raydome with L or Straight Mount – Clear LOS to the Tower Up to 100 Mbps Down / 100 Mbps Up

slide-15
SLIDE 15

What do I need outside my home for an optical service if I live in the Village of Florence?

Optional Roof J-Mount Optional Roof J-Mount

Optical – FTTH High Speed Internet Access Service

  • Side of house or basement
  • Installation Provided
  • For Outdoor Use

Small Optical Receiver Box For Fibre-to-the-Home (FTTH) Service Up to 100 Mbps Down / 100 Mbps Up

Fibre Cable will be buried from the road/street to your home.

slide-16
SLIDE 16

What do I need inside my home?

FTTH Optical service Up to 100 Mbps Down and 100 Mbps Up

  • Easy self install
  • Plug and Play

Applies for all the Wireless Service Options Up to 50 Mbps Down and 10 Mbps Up

  • Easy self install
  • Plug and Play

OR

POE Adapter to power the Optical to Electrical Adapter Optical to Electrical Adapter POE Adapter to power the Outdoor radio receiver for the 3.65 GHz, 5 GHz, or 60GHz Service

slide-17
SLIDE 17

Other Indoor Device for all Internet Access Options

  • Router/Switch
  • Integrated Firewall
  • Multiple GbE ports
  • Dual Band WIFI Support
  • USB Access

Ethernet Cable Input from Outdoor Receiver via Power Over Ethernet Adapter Power Over Ethernet Adapter

Ethernet Cable From Outdoor Receiver

(also powers

  • utdoor equipment)

Typical Customer Provided Indoor Router/Switch

Typical Customer Provided Indoor Router/Switch

POE Adapter Provided with Service

slide-18
SLIDE 18

New High Capacity Service Availability Dates

Optical Service Unlimited Data Planned Availability Date 20 Mbps Down 20 Mbps Up October 2020 50 Mbps Down 50 Mbps Up 100 Mbps Down 100 Mbps Up High Capacity Optical Services (FTTH)

In the Village of Florence Only

Wireless Service Unlimited Data Planned Availability Date 20 Mbps Down 20 Mbps Up August 2020 50 Mbps Down 50 Mbps Up 100 Mbps Down 100 Mbps Up High Capacity Wireless Services (60 GHz)

In the Hamlet of Shetland Only

slide-19
SLIDE 19

New Services for Rest of Township Service Availability Dates

Wireless Service Unlimited Data Availability Date 10 Mbps Down 1 Mbps Up October 2020 15 Mbps Down 2 Mbps Up 25 Mbps Down 2 Mbps Up

Rest of Township (and locations where tree cover is a problem)

Range of Wireless Services (3.65 GHz) Wireless Service Unlimited Data Availability Date 10 Mbps Down 2 Mbps Up September 2020 15 Mbps Down 5 Mbps Up 25 Mbps Down* 7 Mbps Up 50 Mbps Down* 10 Mbps Up

* Higher Speeds Only Within 3-7 km of Tower Sites

Range of Wireless Services (5 GHz)

slide-20
SLIDE 20

Key Benefits for the Residents

Fibre to the Home (FTTH) Future-Proof Service to Florence

§ High speed optical service available or alternative fixed wireless service to residents § 20/20, 50/50, and 100/100 optical internet access services

Fibre-like Service using 60GHz Fixed Wireless Service for Hamlet of Shetland

§ High speed 60GHz fixed wireless service to residents § 20/20, 50/50, and 100/100 internet access services

Widely Available 50/10 High Speed Internet Access via 5GHz Fixed Wireless Services

§ Coverage for at least 60% of the residents in the township § 5 towers throughout township to improve coverage

Improved Fixed Wireless Technology Choices for those Residents with Dense Foliage

§ 3.65 GHz LTE technology offered throughout 90% of township to deal with dense foliage § 25/2, 15/2, and 10/1 internet access services without need for customer towers

Low Cost Options for Future Tower Expansion to Expand 50/10 Service Coverage

§ Grain Elevator or Telecommunications Tower Options Available

slide-21
SLIDE 21

Testing Your Internet Access Performance in Dawn-Euphemia

  • CENGN will be paying for an Internet Performance Tool

customized for Dawn-Euphemia Township

  • Offers visual representation of how the existing service is

performing for the community

  • Allows tracking of improvement as more residents get

connected to the new services

  • Monitors connection for up to a year after installation
  • No charge to use of the tool for residents
  • No charge to use the tool for the township

Your Township Logo Here Your Township Displayed Here

slide-22
SLIDE 22

Testing Your Internet Access Performance in Dawn-Euphemia

Before After

slide-23
SLIDE 23

Contact Info

Kirby Koster CENGN Senior Manager, Broadband Programs kirby.koster@cengn.ca 1-613-291-0707 Matthew Vanheule MPV wifi Owner, IT/Network Operations support@mpvwifi.com 1-226-620-0850
