R+T Asia 2019 - IWDS InnovAction Award - Doors & Gates

Shanghai - February 27-28, 2019

ACMI - About us

ACMI (Assocostruttori Chiusure & Meccanismi Italia) is the Italian Association that gathers the manufacturers of doors and shutters for residential and industrial application, as well as of the drive systems, mechanical components and accessories to them integrated. ❖founded in 1996 thanks the initiative of a group of manufactures of industrial and fire resistant doors. ❖in 2012 the association has significantly expanded the number of members refocusing the mission and the objectives ❖the key points of ACMI’s "new way", are the following:

• drive the incoming changes in our market
• open the talks with institutions and market counterparts to agree actions

that can help our companies in the current tough economic situation

• promote a continuous technical-standardization update

R+T Asia 2019 - IWDS InnovAction Award - Doors & Gates

Shanghai - February 27-28, 2019

ACMI - Values

ACMI associates are aware about the relevance of the full implementation of European laws and standards in the Italian doors & drive systems market. ACMI really believes in the culture of Quality, Environmental Sustainability and Safety, supported by these standards. ACMI makes all efforts to spread and share that culture, in cooperation with the European and Italian standardization bodies, the correlated national associations (e.g. building constructors, architects, …) and the end users of doors’ products, solutions and services.

R+T Asia 2019 - IWDS InnovAction Award - Doors & Gates

Shanghai - February 27-28, 2019

ACMI - Mission

ACMI aims to protect the common interests of its members, promoting all actions aimed at creating and enhancing the image of professionalism and high quality of products and services they provide. ACMI, within the European Competition Laws, promotes the cooperation among its members by providing assistance to improve technical and economic aspects of their business. Formally it represents the common instances of its members at the national and international standardization comities.

R+T Asia 2019 - IWDS InnovAction Award - Doors & Gates

Shanghai - February 27-28, 2019

Represents its members at the Authority for Standardization (UNI, CEN, Ministries bodies), test’s Laboratories, other Associations (EDSF, FINCO, ...), for the development and proper interpretation of European and National Standards Supports the harmonization process of European standards by providing the technical documentation in Italian language, the creation of “ad hoc” working groups, the organization of scientific conferences with expert speakers, etc. Promote statistical studies about values and volumes of doors & drive systems market, both with internal actions of investigation, whether through partnerships with specialized institutions (CRESME) Represent the doors industry in national and international fairs, to spread and share the inhouse knowledge with other operators in the market of building components Organize and deliver training courses for installers and maintainers of doors and drive systems

ACMI - Actions & Aims

R+T Asia 2019 - IWDS InnovAction Award - Doors & Gates

Shanghai - February 27-28, 2019

R+T Asia 2019 - IWDS InnovAction Award - Doors & Gates

Shanghai - February 27-28, 2019

ENTER AND MOVE PRODUCTS ACROSS EU MARKET

R+T Asia 2019 - IWDS InnovAction Award - Doors & Gates

Shanghai - February 27-28, 2019

The European Union has regulated the market to allow free trade in goods among the 27 member countries. The regulation consists of European “laws" (Directives) that have value in all countries and that go beyond national laws. The covered economic sectors of our main interest are:

• The Construction Products (Mechanical, Energy, Safety, Durability, ...)
• Construction Products Regulation 305/2011 (CPR)
• The Machines (driven by non-human energy, safety aspects, …)
• Machinery Directive 2006/42/EC (MD)
• The

Electrical Components (low-voltage systems, electromagnetic compatibility, radiofrequency, ….)

• Low Voltage Directive 2014/35/EU (LVD)
• Electromagnetic Compatibility Directive 2014/30/EU (EMC)

ENTER AND MOVE PRODUCTS ACROSS EU MARKET

R+T Asia 2019 - IWDS InnovAction Award - Doors & Gates

Shanghai - February 27-28, 2019

Products “to be placed” on the EU market must satisfy:

• The Basic Requirements related to the safety and protection of end users

(data in terms of performance to be declared by the manufacturer)

• The characteristics, referred to a specific product (for example a door), are

described in European Technical Standards (EN Standards), that specify the basic requirements and combine them with the verification methods (tests, frequencies, etc.). These EN Standards are listed in the Official Journal of European Union with the specific number, date of issue, title and date of entry into force.

TECHNICAL DOORS & ENTRANCE CONTROL EQUIPMENT

Main related EU Standards

R+T Asia 2019 - IWDS InnovAction Award - Doors & Gates

Shanghai - February 27-28, 2019

EN 14351-2 Internal pedestrian doorsets

product standard, performance characteristics

EN 13241 Industrial, commercial, garage doors and gates

product standard, performance characteristics

EN 16361 Power operated pedestrian doors

product standard, performance characteristics pedestrian doorsets, other than swing type, designed for installation with power operation

EN 17352 Power operated pedestrian entrance control equipment

(draft under study)

safety in use - requirements and test methods

EN 16034 Pedestrian doorsets, industrial, commercial, garage doors and openable windows

product standard, performance characteristics, fire resisting and/or smoke control characteristics

DOORS CE MARKING - Manufacturer duties

R+T Asia 2019 - IWDS InnovAction Award - Doors & Gates

Shanghai - February 27-28, 2019

• 1. Define which directives / standards apply
• 2. Perform initial type tests (TT) on the product or family of products with the

same characteristics

Some tests are to be performed at laboratories recognized at EU level

• 3. Implement a factory production control, as described in the applicable

standard, to ensure that all the similar products must have the same characteristics of the sample subjected to the TT

• 4. Execute the risk analysis
• 5. Complementation the technical construction file
• 6. Provide the documentation indicated as mandatory for the product according

the CPR and the applicable EN standards. Declare the value and / or class for each essential characteristics (for some of them is allowed to declare “value not determined”, if not required by the law

• f the country of supply or the intended use)
• 7. Affixing of the CE-marking

DOORS CE MARKING - Documentation to be provided

R+T Asia 2019 - IWDS InnovAction Award - Doors & Gates

Shanghai - February 27-28, 2019

a) Declaration of Performance (DoP) b) CE label to put on the product (in a fixed way) c) Declaration for the Machinery Directive (if motorized product) d) Installation instructions (for professional installer) e) Maintenance instructions (for professional maintenance technician) f) Operating instructions (for non-professional end users)

DOORS CE MARKING - Declaration of Performance

R+T Asia 2019 - IWDS InnovAction Award - Doors & Gates

Shanghai - February 27-28, 2019

Informations required for all products by CPR (art. 6) List of all essential charateristics

• f the products (e.g. Sectional

Industrial Door) with at least one declared value/class Informations required for all products by CPR (art. 6) M A N U A L D O O R S

DOORS CE MARKING – Declaration of Conformity

R+T Asia 2019 - IWDS InnovAction Award - Doors & Gates

Shanghai - February 27-28, 2019

CE Declaration of Conformity

PRODUCER NAME ________________________ The producer XXXXXX Declares, under its own responsibility, that the product Model "xx01 " Product Sectional industrial Door Serial Number yy1234 Year 2018 with performance level as declared in DoP it is compliant with the following directives: Machinery Directive 2006/42/UE Low Voltage Directive 2014/35/UE Electromagnetic Compatibility Directive 2014/30/UE European Standards reference :

• EN 13241:2016

…title…

• EN 12604:2017

…title…

• EN 12453:2017

…title… Other Harmonized European standards applied referred to safety devices : EN 60335-1 Safety of electrical appliances / operators for gates EN 61000-6-3 Electromagnetic compatibility (EMC) - interference EN 61000-6-2 Electromagnetic compatibility (EMC) - interference resistance Date : 11/06/2018 Name, Surname and Position of the Signatory

M O T O R I Z E D D O O R S

DOORS CE MARKING - CE Label

R+T Asia 2019 - IWDS InnovAction Award - Doors & Gates

Shanghai - February 27-28, 2019

Name or Identifying Mark and Registered Address of the Producer Last 2 digits of year in which the marking is affixed Number of EU Standard Descripion of the Product and intended use Identification Number Information on regulated characteristic of the Product CE conformity marking, consisting of the CE symbol given in Directive 93/68/EEC Reference to related Directive

R+T Asia 2019 - IWDS InnovAction Award - Doors & Gates

Shanghai - February 27-28, 2019

The countries that require CE marking are the 31 countries in the European Economic Area which ncludes: Austria, Belgium, Bulgaria, Croatia, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden and the UK.

• Three members of the European Free Trade Association:

Iceland, Liechtenstein and Norway. In addition, Turkey has fully implemented many of the CE marking directives, even though it’s not a member of the EU or the EEA. Switzerland is also not an EU or EEA member. However, it is part of the European Free Trade Association, so accepts CE marking as a presumption of conformity with its own national technical regulations for some products.

DOORS CE MARKING - Countries Requiring CE Marking

R+T Asia 2019 - IWDS InnovAction Award - Doors & Gates

Shanghai - February 27-28, 2019

Manufacturers have a legal responsibility to ensure that all goods they sell have appropriate CE marking Market Surveillance Authorities are nominated public authorities in each member state, and each state has its own way of enforcing the legislation

• nce it has been implemented into national law.

The penalties for not conforming to CE marking legislation can include fines and imprisonment Under these regulations, authorities can enter premises, test products and seize both documentation and goods. Authorities can also force manufacturers to recall or replace faulty items. When products are manufactured overseas, importers are responsible for ensuring compliance with the applicable directives. In these situations, the importer is considered the manufacturer

DOORS CE MARKING - Product that fails CE marking

Innovation in Tradition

Innovation is seeing what everybody else has seen, and thinking what nobody else has thought.

• DR. ALBERT SZENT

NT-GYOR ORGYI Nobel Prize winner in Physiology or Medicine in 1937

G R A Z I E
