ProtoDUNE Single Phase Signal Feedthrough Cross Tube Cable Support and Cable Routing Manhong Zhao 4/19/2017 Brookhaven National Laboratory ProtoDUNE Signal Feedthru Cold Cables Signal Feedthru Chimney CE Box APA 2 Cross Tube Cable
SLIDE 2
SLIDE 3
Cross Tube Cable Support
3
SLIDE 4
Cross Tube Cable (CTC) Support
4
CE Flange PD Flange Cryostat Insulation Cross Tube Tee Cable Strain Relief Adjustment Screws for Tube Alignment Hood
SLIDE 5
Cable Strain Relief
5
ProtoDUNE (1 chimney per APA): 22 CE cable bundles (2 for extra) 2 PD cable bundles (10 PD cables + 2 extra) 1 SHV cable bundle (8 SHV cables)
SLIDE 6
Stress Analysis of CTC Support Inner Tube
6
20 kgf force applied on the cable clamping plate along horizontal direction
SLIDE 7
CFD Model of Signal Feedthrough Chimney
7
Outer surfaces 6 W/m2-K @ 293 K Gas outlet: 0.35 g/s Water mass flux from Teflon cable insulation 87.93 K @ LAr/GAr interface
Reference: ProtoDUNE Ullage Space CFD Model, Erik Voirin
GAr temperature in ullage
Liquid Surface Boil Off Flux of ProtoDUNE: 21 g/s from Liquid Model (see Ref)
SLIDE 8
Water release of Teflon wire insulation
8
H2O_Flux = 0.216*sqrt(2.715e-12*exp(-4988[K]/T)) [kg m^-2 s^-1] Assume after 100 days drying
Reference: Mass Transport of Water in Teflon Down to Cryogenic Temperatures; a Transient Numerical Analysis, Erik Voirin
H2O mass flux at Teflon surface
SLIDE 9
Diffusion Coefficient of Water in Argon Gas
9
Diffusion12 T ( ) 1.86 10
3 −
⋅ T
3 2
⋅
kg kmol
M1
kg kmol
M2 + ⋅ P atm 1 2 σ1 σ2 +
( )
2
⋅ 2.6693 10
6 −
⋅ MAr
kg kmol
T ⋅
1 2
⋅
µAr T ( ) Pa s ⋅ σAr Angstrom
2
⋅ ⋅
Reference: Diffusion Coefficients of Water and Oxygen in Argon, Erik Voirin
The curve can be fitted as H2O_Diff = 0.275 [cm^2 s^-1] * (T/300[K])^1.9*(1 [atm] /Pressure)
SLIDE 10
Results: Gas Flow, Temperature and Moisture Diffusion
10
Gas flow in chimney Temperature Moisture Diffusion
Moisture diffused into ullage ~ 9x10-16 g/sec
SLIDE 11
Cable Routing
11
SLIDE 12
Cable Routing
12
PD cables CE cables PD cables CE cables PD cables CE cables
SLIDE 13
Cable Routing
13
SLIDE 14
Cable Routing
14
Differential length stored in this cable tray
SLIDE 15
Cable Routing
15
SLIDE 16
Cable Routing
16
Differential length of PD cables is stored in a cable tray that is installed at the back side of APA.
SLIDE 17
Cable Routing
17
CE cables PD cables
SLIDE 18
Cable Routing
18
