W I S S E N T E C H N I K L E I D E N S C H A F T Protecting the Control Flow of Embedded Processors against Fault Attacks Mario Werner 1 , Erich Wenger 2 , and Stefan Mangard 1 , 1 Graz University of Technology 2 Infineon

slide-1
SLIDE 1

W I S S E N T E C H N I K L E I D E N S C H A F T www.iaik.tugraz.at

Protecting the Control Flow

  • f Embedded Processors

against Fault Attacks

Mario Werner1, Erich Wenger2, and Stefan Mangard1,

1 Graz University of Technology 2 Infineon Technologies AG, Munich

5th November 2015, Bochum

slide-2
SLIDE 2

www.iaik.tugraz.at

Context and Motivation

Embedded systems are everywhere Assets in malicious environment

System Memory Processor Crypto

Various assets Protecting cryptographic primitives is insufficient

Werner, Wenger, Mangard, 5th November 2015, Bochum 2

slide-3
SLIDE 3

www.iaik.tugraz.at

Do we really care about the Processor?

unsigned pin = read_pin(); bool auth = tpm_check(pin); if( auth ) {

  • pen_door();

} else { alert_police(); } log_event(); read_pin() tpm_check(pin) check if auth == true

  • pen_door()

alert_police() log_event()

Werner, Wenger, Mangard, 5th November 2015, Bochum 3

slide-4
SLIDE 4

www.iaik.tugraz.at

Do we really care about the Processor?

unsigned pin = read_pin(); bool auth = tpm_check(pin); if( auth ) {

  • pen_door();

} else { alert_police(); } log_event(); check condition perform action handle error continue

Werner, Wenger, Mangard, 5th November 2015, Bochum 3

slide-5
SLIDE 5

www.iaik.tugraz.at

Do we really care about the Processor?

check_auth: // auth in R0 (1 if true) LDR R1, #1 CMP R0, R1 BNE not_authenticated authenticated: // open door // ... B next not_authenticated: // alert police next: // log event

Werner, Wenger, Mangard, 5th November 2015, Bochum 3

slide-6
SLIDE 6

www.iaik.tugraz.at

Do we really care about the Processor?

check_auth: // auth in R0 (1 if true) LDR R1, #1 CMP R0, R1 BEQ not_authenticated authenticated: // open door // ... B next not_authenticated: // alert police next: // log event

Werner, Wenger, Mangard, 5th November 2015, Bochum 3

slide-7
SLIDE 7

www.iaik.tugraz.at

Do we really care about the Processor?

check_auth: // auth in R0 (1 if true) LDR R1, #1 CMP R0, R0 BNE not_authenticated authenticated: // open door // ... B next not_authenticated: // alert police next: // log event

Werner, Wenger, Mangard, 5th November 2015, Bochum 3

slide-8
SLIDE 8

www.iaik.tugraz.at

Do we really care about the Processor?

check_auth: // auth in R0 (1 if true) LDR R1, #1 CMP R0, R1 BNE not_authenticated authenticated: // open door // ... B next not_authenticated: // alert police next: // log event

Werner, Wenger, Mangard, 5th November 2015, Bochum 3

slide-9
SLIDE 9

www.iaik.tugraz.at

Goal and Results

Goal: Enforce control-flow integrity Results: Analysis and evaluation of signature functions Detect a faulty instruction with 99.9 % within 3 cycles (arbitrary fault) Resistant against at least 7 precise bit flips injected across two instructions HDL implementation for a Cortex-M3 clone LLVM based toolchain 6.4 % hardware overhead 2 % to 71 % runtime overhead

Werner, Wenger, Mangard, 5th November 2015, Bochum 4

slide-10
SLIDE 10

www.iaik.tugraz.at

Control-Flow Integrity

Execute code as programmed

Perform only intended function calls Traverse control flow graph along programmed edges Execute basic blocks from start to end Preserve instructions and their order

main

read_pin check_pin unlock_door alert_police log_event

Werner, Wenger, Mangard, 5th November 2015, Bochum 5

slide-11
SLIDE 11

www.iaik.tugraz.at

Control-Flow Integrity

Execute code as programmed

Perform only intended function calls Traverse control flow graph along programmed edges Execute basic blocks from start to end Preserve instructions and their order

check auth

  • pen_door()

alert_police() log_event()

Werner, Wenger, Mangard, 5th November 2015, Bochum 5

slide-12
SLIDE 12

www.iaik.tugraz.at

Control-Flow Integrity

Execute code as programmed

Perform only intended function calls Traverse control flow graph along programmed edges Execute basic blocks from start to end Preserve instructions and their order

check auth

  • pen_door()

alert_police() log_event()

Werner, Wenger, Mangard, 5th November 2015, Bochum 5

slide-13
SLIDE 13

www.iaik.tugraz.at

Control-Flow Integrity

Execute code as programmed

Perform only intended function calls Traverse control flow graph along programmed edges Execute basic blocks from start to end Preserve instructions and their order

check_auth: // auth in R0 (1 if true) LDR R1, #1 CMP R0, R0 BNE not_authenticated

Werner, Wenger, Mangard, 5th November 2015, Bochum 5

slide-14
SLIDE 14

www.iaik.tugraz.at

Concept

Instruction stream integrity through derived signatures [MM88] Generalized path signature analysis (GPSA) [WS90] Optimize against fault attacks Implemented as hybrid scheme Dedicated assertions Continuous checks

Werner, Wenger, Mangard, 5th November 2015, Bochum 6

slide-15
SLIDE 15

www.iaik.tugraz.at

Derived Signatures [MM88]

R e s e t _ H a n d l e r x x b 5 b b 5 b : p u s h { r 4 , r 5 , r 7 , l r } x 1 6 4 b 2 a f 2 : a d d r 7 , s p , # 8 x 1 a c b f 4 8 d : l d r r , [ p c , # 5 2 ] x 1 f 5 c d 4 9 e : l d r r 1 , [ p c , # 5 6 ] x 2 3 8 5 5 4 2 8 8 : c m p r , r 1 x 3 a 6 2 d 2 d : b h s # 2 6 R e s e t _ H a n d l e r : 1 x 3 a 6 2 x 3 5 4 6 f 4 a d : l d r r 2 , [ p c , # 5 2 ] . . . R e s e t _ H a n d l e r : 2 x 3 a 6 2 x 3 5 6 6 8 4 c 6 : l d r r 4 , [ p c , # 2 4 ] . . . ???

Werner, Wenger, Mangard, 5th November 2015, Bochum 7

slide-16
SLIDE 16

www.iaik.tugraz.at

Generalized Path Signature Analysis [WS90]

% 1 ( i f ) / / . . . % 2 / / . . . / / . . . % 3 / / . . . % 4 / / . . . / / . . .

Werner, Wenger, Mangard, 5th November 2015, Bochum 8

slide-17
SLIDE 17

www.iaik.tugraz.at

Generalized Path Signature Analysis [WS90]

% 1 ( i f ) / / . . . % 2 / / . . . / / . . . % 3 / / . . . update(sig1) % 4 / / . . . / / . . .

Werner, Wenger, Mangard, 5th November 2015, Bochum 8

slide-18
SLIDE 18

www.iaik.tugraz.at

Generalized Path Signature Analysis [WS90]

% 1 ( i f ) / / . . . % 2 / / . . . / / . . . % 3 / / . . . update(sig1) % 4 / / . . . / / . . . check(sig2)

Werner, Wenger, Mangard, 5th November 2015, Bochum 8

slide-19
SLIDE 19

www.iaik.tugraz.at

Generalized Path Signature Analysis [WS90]

% 1 ( i f ) / / . . . % 2 / / . . . / / . . . % 3 / / . . . update(sig1) % 4 / / . . . / / . . . check(sig2)

Werner, Wenger, Mangard, 5th November 2015, Bochum 8

slide-20
SLIDE 20

www.iaik.tugraz.at

Generalized Path Signature Analysis [WS90]

% 2 ( w h i l e ) / / . . . % 1 / / . . . % 3 ( i f ) / / . . . % 6 / / . . . r e t u r n % 4 / / . . . % 5 / / . . . r e t u r n

Werner, Wenger, Mangard, 5th November 2015, Bochum 8

slide-21
SLIDE 21

www.iaik.tugraz.at

Generalized Path Signature Analysis [WS90]

% 2 ( w h i l e ) / / . . . % 1 / / . . . % 3 ( i f ) / / . . . % 6 / / . . . r e t u r n % 4 / / . . . update(sig1) % 5 / / . . . r e t u r n

Werner, Wenger, Mangard, 5th November 2015, Bochum 8

slide-22
SLIDE 22

www.iaik.tugraz.at

Generalized Path Signature Analysis [WS90]

% 2 ( w h i l e ) / / . . . % 1 / / . . . % 3 ( i f ) / / . . . % 6 update(sig2) / / . . . r e t u r n % 4 / / . . . update(sig1) % 5 / / . . . r e t u r n

Werner, Wenger, Mangard, 5th November 2015, Bochum 8

slide-23
SLIDE 23

www.iaik.tugraz.at

Signature Functions against Fault Attacks

Compression function Avoid collisions within one cycle Qualitative Requirements for GPSA: Reliability: Sj+1 ⊕ ∆Sj+1 = f(Sj, Ij ⊕ ∆Ij) Error preservation: Sj+1 ⊕ ∆Sj+1 = f(Sj ⊕ ∆Sj, Ij) Non associativity: f(f(Sj, Ij), Ik) = f(f(Sj, Ik), Ij) Invertibility: Sj = f −1(Sj+1, Ij) → single faulty instructions detectable

Werner, Wenger, Mangard, 5th November 2015, Bochum 9

slide-24
SLIDE 24

www.iaik.tugraz.at

Quantitative Evaluation

MISRs and CRCs with various polynomials How hard is it to bypass the protection? Quality function: q(j, t) = HW(∆Ij) + HW(∆Ij+t) Worst case behavior min(q) matters → CRCs are better than MISRs against faults → min(q) = 8 for CRC-32C and CRC-32Q

Werner, Wenger, Mangard, 5th November 2015, Bochum 10

slide-25
SLIDE 25

www.iaik.tugraz.at

Implementation

Hardware: Monitor for derived signatures Extended fetch unit Software: Compiler for ... GPSA signature updates ... assertions Post-processing tool for ... update and check constants ... continuous signature monitoring (CSM)

Werner, Wenger, Mangard, 5th November 2015, Bochum 11

slide-26
SLIDE 26

www.iaik.tugraz.at

Hardware Modifications

Cortex-M3 Execute Decode Fetch ALU MUL/ DIV Code Addr. CodeIn Address DataIn Register File DataOut Fetch Controller Address Generation Unit System Address Space Signature Monitor RAM Peripherals Fetched Instructions Reference Signatures for CSM Controller f u signature Werner, Wenger, Mangard, 5th November 2015, Bochum

12

slide-27
SLIDE 27

www.iaik.tugraz.at

Evaluation

Hardware: CPU Core: 37 kGE Monitor: 1.5 kGE (4 %) Monitor + Core with CSM: 39 kGE (6.4 %) Benchmarks: Modified vs stock LLVM Coremark AES-256 Elliptic Curve Cryptography in C and with ASM

Werner, Wenger, Mangard, 5th November 2015, Bochum 13

slide-28
SLIDE 28

www.iaik.tugraz.at

RAM NVM Runtime 20 40 60 80

2.3 69 56.7 9.6 29 36.7 9 78.9 33.3 8 53.5 1.9

GPSA Overhead [%] Coremark AES-256 ECC C ECC ASM

Werner, Wenger, Mangard, 5th November 2015, Bochum 14

slide-29
SLIDE 29

www.iaik.tugraz.at

1 2 4 8 16 5 10 15 20 h-bit Continuous Signature Checks CSM Runtime Overhead [%] Coremark AES-256 ECC C ECC ASM

Werner, Wenger, Mangard, 5th November 2015, Bochum 15

slide-30
SLIDE 30

www.iaik.tugraz.at

Conclusion

Analysis and evaluation of signature functions Detect a faulty instruction with 99.9 % within 3 cycles (arbitrary fault) Resistant against at least 7 precise bit flips injected across two instructions HDL implementation for a Cortex-M3 clone LLVM based toolchain 6.4 % hardware overhead 2 % to 71 % runtime overhead

Werner, Wenger, Mangard, 5th November 2015, Bochum 16

slide-31
SLIDE 31

W I S S E N T E C H N I K L E I D E N S C H A F T www.iaik.tugraz.at

Protecting the Control Flow

  • f Embedded Processors

against Fault Attacks

Mario Werner1, Erich Wenger2, and Stefan Mangard1,

1 Graz University of Technology 2 Infineon Technologies AG, Munich

5th November 2015, Bochum

slide-32
SLIDE 32

www.iaik.tugraz.at

References I

[MM88] A Mahmood and E.J. McCluskey, Concurrent error detection using watchdog processors-a survey, IEEE Transactions on Computers 37 (1988), no. 2, 160–174. [WS90] Kent D. Wilken and John Paul Shen, Continuous signature monitoring: low-cost concurrent detection of processor control errors, IEEE Transactions on Computer-Aided Design of Integrated Circuits and Systems 9 (1990), no. 6, 629–641.

Werner, Wenger, Mangard, 5th November 2015, Bochum 18
