Project Status Time- 35.45% (464/1309) Earned- 48.28% ($27,975,596/$58,086,596) Estimated Completion: January 2016 Phase 1-MOT 82 Avenue Transal Park NW 25 Street Truck Lot N BP Station Traffic shifted to the south side of NW 25 Street and

slide-1
SLIDE 1
slide-2
SLIDE 2

Project Status

Time- 35.45% (464/1309) Earned- 48.28% ($27,975,596/$58,086,596) Estimated Completion: January 2016

slide-3
SLIDE 3

Phase 1-MOT

82 Avenue NW 25 Street

BP Station Transal Park Truck Lot N

Traffic shifted to the south side of NW 25 Street and work zone set up to the north.

slide-4
SLIDE 4

Phase 1- Major Operations

  • Culvert Construction
  • Drilled Shafts
  • Pile Driving
  • Foundation Construction
  • Miami-Dade Water and Sewer JPA
  • Intersection Improvements (NW 79,82 and

87 Avenues)

  • Roadway Widening
slide-5
SLIDE 5

Phase 1- Culvert Installation

2393 LF of 2870 LF (83.3%)

slide-6
SLIDE 6

Phase 1- Drilled Shafts

  • All five 96 inch drilled

shafts completed

  • Required full SR 826 ramp

closures over weekend (24 hrs/day)

  • Drilled shafts ranged in

depth from 120 feet to 65 feet.

slide-7
SLIDE 7

Phase 1- Drilled Shaft

slide-8
SLIDE 8

Phase 1- Panel Wall Pile Driving

Piles Driven- 259 of 269 (96.2%)

slide-9
SLIDE 9

Phase 1- Foundation Pile Driving

Piles Driven- 85 out of 204 (41.6%)

slide-10
SLIDE 10

Phase 1 Upcoming Work

  • Culvert crossing NW 79 Avenue‐ one northbound and
  • ne southbound lane in each direction (mid‐October

2013 through May 2014)

  • Bridge girders over 25 Street just east and west of

Palmetto will require full weekend closures of NW 25 Street

  • Reconstruction of north side of NW 87 Avenue‐ two

lanes in each direction and one turn lane. (December 2013‐ May 2014)

  • Phase 2‐ May 2014 through March 2015
slide-11
SLIDE 11

Phase 2

Traffic shifted to the north and work zone set to the south. Major operations include reconstruction of south side roadway, new drainage and installation

  • f water and sewer mains.

82 Avenue NW 25 Street

BP Station Transal Park Truck lot N

slide-12
SLIDE 12
slide-13
SLIDE 13
slide-14
SLIDE 14
slide-15
SLIDE 15

Contacts

Oscar Gonzalez Nelson Perez Public Information Specialist Project Engineer 8290 NW 27 Street 8290 NW 27 Street Doral, Florida 33122 Doral, Florida 33122 Phone: (305) 463-7701 Phone: (305) 463-7701 Fax: (305) 463-7749 Fax: (305) 463-7749 Mobile: (786) 280-0983 Mobile: (305) 216-5112 Email: ogonzalez@mrgmiami.com Email: nperez@apcte.com

www.fdotmiamidade.com

slide-16
SLIDE 16

www.fdotmiamidade.com

QUESTIONS?
