Programmable Logic Control Technology When is plc TECH required ? - PowerPoint PPT Presentation

Dec 16, 2022 •35 likes •155 views

Programmable Logic Control Technology When is plc TECH required ? When there is more than 200 addresses this is the most cost effective way to control lighting What other technologies are compatible with plc TECH ? A PLC can be integrated with

Programmable Logic Control Technology When is plc TECH required ? When there is more than 200 addresses this is the most cost effective way to control lighting What other technologies are compatible with plc TECH ? A PLC can be integrated with Dali as well as Push Dim
Programmable Logic Control Technology | AMG KZN The PLC is then programmed to give each board a signal at a specific time, instruct the direction of the motion and the speed of the pattern. The PLC is most cost effective control method, operating at 24Vdc and the signals sent from the PLC is also 24Vdc. We used 24Vdc LED boards in order to use the PLC signals to provide light. Signal Cable Each linear is broken up into boards that are 100mm sections. • Each board receives its own signal cable back to the control panel. 100mm LED Board • This is done to individually control each 100mm section. Signal Cable The PLC is fully adjustable. The client can decide on: 1. The pattern 2. The speed 3. The direction How each 100mm board is wired 4. The timeframe 5. Programming/re-programming a new sequence.
Programmable Logic Control Technology | AMG KZN
