MARINA FACTORY L.L.C PRODUCT PRESENTATION PI PIPE PE MOUNTE TED SI SIDE E WIND JAC ACK CAPACITY : 2000 Lbs. 7000 Lbs. Pipe Mounted Jack Technical Data MODEL HEIGHT MIN MAX. OUTSIDE INSIDE NO. (mm) LIFTING LIFTING DIA.

slide-1
SLIDE 1

MARINA FACTORY L.L.C

PRODUCT PRESENTATION

slide-2
SLIDE 2

PI PIPE PE MOUNTE TED SI SIDE E WIND JAC ACK

CAPACITY : 2000 Lbs. – 7000 Lbs.

slide-3
SLIDE 3

Pipe Mounted Jack Technical Data

MODEL NO. HEIGHT (mm) MIN LIFTING HEIGHT (mm) MAX. LIFTING HEIGHT (mm) OUTSIDE DIA. (mm) INSIDE DIA. (mm) 2001 433 277 547 38.5 50.5 2002 542 386 770 38.5 50.5 5001 425 261 518 38.5 50.5 5002 562 398 765 38.5 50.5 7000 640 1026 7001 456 290 548 52 63.5

slide-4
SLIDE 4

WHEEL JACK

slide-5
SLIDE 5

SINGLE WHEEL JACK 1500 Lbs

HEIGHT MAXIMUM LIFTING HEIGHT 680 mm 935mm

slide-6
SLIDE 6

SINGLE WHEEL JACK 1200 Lbs

HEIGHT MAXIMUM LIFTING HEIGHT 580 mm 935 mm

slide-7
SLIDE 7

DOUBLE WHEEL JACK 1500 Lbs

HEIGHT MAXIMUM LIFTING HEIGHT 640 mm 885mm

slide-8
SLIDE 8

5 BOLTS HUB W/ FLANGE

slide-9
SLIDE 9

4 BOLTS HUB W/ FLANGE

slide-10
SLIDE 10

5 BOLTS HUB WITHOUT FLANGE

slide-11
SLIDE 11

4 BOLTS HUB WITHOUT FLANGE

slide-12
SLIDE 12

TIGER AUTOMATIC BREAK HAND WINCH

CAPACITY : 800 Lbs / 1200 Lbs / 1800 Lbs / 2600 Lbs

slide-13
SLIDE 13

Tiger Automatic Break Hand Winch Specifications

MODEL NUMBER BHW-800 BHW-1200 BHW-1800 BHW-2600 Capacity (Lbs.) 800 1200 1800 2600 Hand Force Required (kg) 14.5 15 22 19 Gear Ratio 4.1 : 1 4.1 : 1 5 : 1 10 : 1 Hub Diameter (mm) Ø40 Ø50 Ø70 Ø80 Handle Length (mm) 160 210 320 320 Unit Weight (mm) 3 3.3 8 10.3 Rope Diameter (mm)(Ref.) Ø4 Ø5 Ø7 Ø8 Rope Storage Cap. (M) 36 23 24 18

slide-14
SLIDE 14

TOWING BAR

slide-15
SLIDE 15

TOWING BRACKET WITH 50mm HITCH BALL

slide-16
SLIDE 16

LEAF SPRING

MODEL NO. MARINA - 8312

  • NO. OF LEAF

2 LOAD CAPACITY 486 Kgs.

slide-17
SLIDE 17

LEAF SPRING

MODEL NO. MARINA - UNA-216

  • NO. OF LEAF

3 LOAD CAPACITY 787.5 Kgs.

slide-18
SLIDE 18

LEAF SPRING

MODEL NO. MARINA ML- 025-00

  • NO. OF LEAF

4 LOAD CAPACITY 1,170 Kgs.

slide-19
SLIDE 19

LEAF SPRING

MODEL NO. MARINA UNA-111

  • NO. OF LEAF

5 LOAD CAPACITY 1,350 Kgs.

slide-20
SLIDE 20

LEAF SPRING

MODEL NO. MARINA ML- 027-00

  • NO. OF LEAF

6 LOAD CAPACITY 1,570 Kgs.

slide-21
SLIDE 21

LEAF SPRING

MODEL NO. MARINA ML- 079-00

  • NO. OF LEAF

7 LOAD CAPACITY 1,800 Kgs.

slide-22
SLIDE 22

KEEL ROLLERS & WHEELS

slide-23
SLIDE 23

U-BOLTS

Hot Dip Galvanized and G.I

Available in different sizes

slide-24
SLIDE 24

COUPLING WITH HANDLE

SIZES 2” / 50mm / 17/8

slide-25
SLIDE 25

RED COUPLING WITH SHOCK ABSORBER

SIZES 2” , 50mm & 17/8

slide-26
SLIDE 26

RED COUPLING

SIZES 2” , 50mm & 17/8

slide-27
SLIDE 27

G.I COUPLING

DESCRIPTION SIZE Tongue Size 2” & 3” Hitch Ball Size 2” Tongue Size 2” & 3” Hitch Ball Size 50mm Tongue Size 2” & 3” Hitch Ball Size 17/8

slide-28
SLIDE 28

50mm 2”

Hitch Balls

17/8

slide-29
SLIDE 29

MARINA FACTORY L.L.C.

P.O. Box 5529 Industrial 2 Sharjah United Arab Emirates

  • Tel. No.:

+971 6 533 7076

  • Fax. No.:

+971 6 5326852 Email Address: marina1@emirates.net.ae Website: www.marinaintl.com
