South East Pipe Industries

South East Asia Pipe lndustries

South East Pipe Industries South East Pipe Industries INTRODUCTION South East Asia Pipe lndustries SEAPI was established since 1996 and start it’s commercial product by july 1999. SEAPI is licensed under API (American Petroleum Institute) No : 5L-0374 On February 2001, SEAPI signed on agreement with TENARIS, one of the largest world pipe producers. The agreement involved management assistance, technical assistance and marketing assistance. This agreement was ended by 2003. As indicated by its name, SEAPI is designed to service major customers in South East Asia Region. The company has supplied pipes for major subsea pipelines namely the 250km 28” North Sumatera - Singapore pipeline and the 160km 32” South Sumatera - WestJava (SSWJ) ll pipeline.

South East Pipe Industries Certification As companies with Petroleum Institute has international standards, SEAPI entrusted SEAPI for its API has obtained several spec 5L monogram on each of cer tification, since 2008 the its products, and followed by American other cer tificates such as API spec Q1, API QMS Cer tificate (ISO 9001 : 2008 ) and ISO/TS 29001

South East Pipe Industries Supply T rack Reco rd SEAPI Already supply the product to several company such as: PROJECT COSTUMERS West natuna Trunk line System PT Mc Dermott Indonesia Petrokimia Gresik PT Satriati jaya Sukses Sumpal Gas Project Hyunday Engineering Co Suban Gas Project Hyunday Engineering Co PetroKimia Gresik PT Satriati Jaya Sukses Iran Kallanaft Project Confab Trading NV Brazil Kuala Tungkal Panaran Branch Line Perusahaan Gas Negara (PGN) Offshore IKPT / PERTAMINA Sumbagsel Gas Project Hyunday Engineering Co / Conoco Philips Suban Phase2 Perusahaan Gas Negara (PGN) SSWJ II (Labuan Maringgai Muara Bekasi) (Offshore) Total E&P Total tunu 11 EPSC 7 PT Transportasi Gas Indonesia Kuala Tungkal Panaran Pipe Line PT BPI - TOTAL E&P Indonesia Repair PT Bakrie Construction South Mahakam PO 105 Project Exometal PTE. LTD Trang Siraun Batur I project YHE Project

South East Pipe Industries Supply T rack Reco rd SIZE AND GRADE DNV OS F101- 485 FUD 28”x14.6mm x 12.1 m L API 5L X 52/28” x 14.6 x 12 m L API 5L X60 PSL 2/Nace MR-01-75 (Sour Gas Service) API 5L X60 PSL 2/Nace MR-01-75 (Sour Gas Service) API 5L X52 PSL 1 28”x12 mm x 12 m L API 5L X60 PSL1 30”x7.93/8.74 m x 12M DNV OS F-101 FUDS 28”x12.7mm x 12M API 5L X52 PSL 2 28”x11.9/15.9MM x 12M API 5L X52 PSL 2 26”x11.1/15.9MM x 12M DNV OS F 101- 450 FUD 32”x15.9/19.1mm x 12M Total GS STR 301 S355 KTO 30”x15.9mm, 36”x19.05 DNV OS F 101-450 FD 28”x15.9 mm x 12 m Total GS EP PLR 202 X65 30”x15.9mm, 36”19.05 API 5L X52 PSL2 28” / 32” x 25mm x 9M API 5L X52 PSL2 24” x 15.9mm x 12M

South East Pipe Industries Application Oil and Gas Line Pipe Water Line Pipe Piles Platform, Living Quarter Structure Product Specification API 5L Grade A, B, X42 up to X80 : Oil and Gas Line Pipe DNV OS-F101 : Submarine Line Pipe ASTM252 : Steel Pipe for Piles ASTM A53 : Steel Pipe General Purposes SNI - 0068-87 : Steel Pipe fo General Construction

South East Pipe Industries Product Range STEEL Grade API 5LX 42 52 60 65 70 80 14,5 13 12,2 11,7 11,3 10,5 24” (609,6 mm) R M a x . WA L L T H I C K N E S S 26” (660,4 mm) 18,0 16,2 15,0 14,5 14,0 13,0 E 28” (711,2 mm) T 20,6 18,5 17,3 16,6 16,0 15,0 30” (762 mm) E 23,3 21,0 19,6 19,0 18,2 17,0 M 32” (812,8 mm) 26,2 23,5 22,2 21,5 20,5 19,2 36” (914,4 mm) 32,0 30,0 28,0 27,0 26,0 24,0 A 24,0 42” (1066,8 mm) 27,0 26,0 32,0 30,0 28,0 I D 48” (1219 mm) 27,0 26,0 32,0 30,0 28,0 24,0 : Current Capability MAXIMUM PIPE LENGTH UP TO 12.2 M (40 FEET) DIAMETER(in) Wall Thickness (mm) Note : Other Sizes, Grades & Thickness are available for any specific needs, please consult PT. SEAPI Representative for the avability

South East Pipe Industries Quality Assurance SEAPI Plant equipped with a strict quality system and modern production facilities in order to be able to produce world class standard for large diameter pipes. In order to secure high quality product, several quality control tests are under taken from the beginning to the end of production process such as : visual Inspection; Chemical Analysis; Hardnes Test; Tensile Test; Bend Test; Impact Test; Hydrostatic Test; X-ray Test; which will ensure customer confidence. In addition to the convantional testing we can carry out selective test to assure the desired product quality. To anticipate and meet fast growing global demand of large diameter steel pipes meant for critical application in the petroleum, oil and natural gas sectors, refinering and fertilizer, SEAPI quality system has been conforming to international accepted standards laid down by American Petroleum Institute (API) for Q1 Specification and international Standard Organitation (ISO).

South East Asia Pipe lndustries pipe production plant to ketapang pipe storage field pipe coating plant (planed) pipe storage field pipe storage field to bakauheni dedicated harbor (planed) sunda strait SEAPI Head Office SEAP I Factory Office Bakrie Tower, 7th. Floor Bakauheni, Kec. Penengahan, Jl H.R Rasuna Said Kabupaten Lampung Selatan, Jakarta Selatan, Jakarta 12940 Indonesia Provinsi Lampung 35592, Indonesia Tel. (62-727) 331234, Fax. (62-727) 331348 Contact Email : commercial@e-bakrie.com Phone : +62-21 29941270 Fax : +62-21 29941267-69
