PRODUCT BASICS

DIAMOND DESKING

Diamond Desking

Desktop shapes Leg types

Four Legged Single Upright Twin Upright Panel Cable Managed Goal Post

Key furniture componentry

Key furniture componentry

Desking specification overview

Desktops

• Desktop board material MFC (melamine faced chipboard).
• Board thicknesses available – 18mm, 25mm, 36mm (dependent on range).

Cable Ports

• All cable ports have been changed to round, grey 80mm diameter across all desktop and leg

designs.

• Radial desking will come with 3 x pre-fitted cable ports.
• All cable ports come pre-fitted in the desktop BOX A.
• Cable port hole on the modesty panel has been changed to a cut-out.

Modesty Panel

• Modesty panel position has moved to the rear of the leg on the double, twin and

panel leg designs (gone from 520mm from front of desk to front side of modesty to 690).

• Modesty panel is packaged in BOX B.

Packaging

• All desktop, modesty and leg packaging is 100% recyclable…NO POLYSTYRENE.

Legs

• Steel thickness – minimum 1.2mm (dependent on range).
• Steel finish – powder coating (All RAL numbers will be shown at the back of our 2020

catalogue). New Considerations

• All our legs have moved to our supplier, so 2019 leg designs and

finish will be different for 2020.

• New cable and goal post leg design introduced for 2020.
• New assembly instruction format
• All 1000mm wave legs have been replaced with 800mm leg.
• Corner post used on the radial desking for Woodstock has changed from 50mmx50mm to

25mmx25mm.

RECTANGULAR - SINGLE UPRIGHT LEG (SU)

All cable ports have changed from 62mm to round, grey 80mm diameter across ALL desktops. Modesty panel position no change. Modesty panel cable port changed to cut-

• ut with grey plastic

edging Leg cap and adjustable Foot colour will match the colour of the leg (white or silver)

WAVE - SINGLE UPRIGHT LEG (SU)

All cable ports have changed from 62mm to round, grey 80mm diameter across ALL desktops. Modesty panel position no change. Modesty panel cable port changed to cut-

• ut with grey plastic

edging Leg cap and adjustable Foot colour will match the colour of the leg (white or silver) 1000mm leg has been replaced with 800mm leg

RADIAL - SINGLE UPRIGHT LEG (SU)

All cable ports have changed from 62mm to round, grey 80mm diameter across ALL desktops. Radial desktop will have 3 x cable ports in the positions shown here. Modesty panel position no change. Modesty panel cable port changed to cut-

• ut with grey plastic

edging Leg cap and adjustable Foot colour will match the colour of the leg (white or silver)

RECTANGULAR – TWIN UPRIGHT LEG (TWU)

All cable ports have changed from 62mm to round, grey 80mm diameter across ALL desktops. Modesty panel position moved to rear upright. Modesty panel cable port changed to cut-

• ut with grey plastic

edging Leg cap and adjustable Foot colour will match the colour of the leg (white or silver)

WAVE - TWIN UPRIGHT LEG (TWU)

All cable ports have changed from 62mm to round, grey 80mm diameter across ALL desktops. Modesty panel position moved to rear upright. Modesty panel cable port changed to cut-

• ut with grey plastic

edging Leg cap and adjustable Foot colour will match the colour of the leg (white or silver)

RADIAL - TWIN UPRIGHT LEG (TWU)

All cable ports have changed from 62mm to round, grey 80mm diameter across ALL desktops. Modesty panel position moved to rear upright. Modesty panel cable port changed to cut-

• ut with grey plastic

edging Leg cap and adjustable Foot colour will match the colour of the leg (white or silver)

RECTANGULAR

• DOUBLE UPRIGHT LEG

All cable ports have changed from 62mm to round, grey 80mm diameter across ALL desktops. Modesty panel position moved to rear upright. Modesty panel cable port changed to cut-

• ut with grey plastic

edging Leg cap and adjustable Foot colour will match the colour of the leg (white or silver) Wood and metal inserts available as a accessory

WAVE - DOUBLE UPRIGHT LEG

All cable ports have changed from 62mm to round, grey 80mm diameter across ALL desktops. Modesty panel position moved to rear upright. Modesty panel cable port changed to cut-

• ut with grey plastic

edging Leg cap and adjustable Foot colour will match the colour of the leg (white or silver) Wood and metal inserts available as a accessory

RADIAL - DOUBLE UPRIGHT LEG

All cable ports have changed from 62mm to round, grey 80mm diameter across ALL desktops. Modesty panel position moved to rear upright. Modesty panel cable port changed to cut-

• ut with grey plastic

edging Leg cap and adjustable Foot colour will match the colour of the leg (white or silver) Wood and metal inserts available as a accessory

RECTANGULAR – PANEL LEG (PAN)

All cable ports have changed from 62mm to round, grey 80mm diameter across ALL desktops. Modesty panel position moved to rear

• f panel leg

Modesty panel cable port changed to cut-

• ut with grey plastic

edging

WAVE – PANEL LEG (PAN)

All cable ports have changed from 62mm to round, grey 80mm diameter across ALL desktops. Modesty panel position moved to rear

• f panel leg

Modesty panel cable port changed to cut-

• ut with grey plastic

edging

RADIAL – PANEL LEG (PAN)

All cable ports have changed from 62mm to round, grey 80mm diameter across ALL desktops. Modesty panel position moved to rear

• f panel leg

Modesty panel cable port changed to cut-

• ut with grey plastic

edging

RECTANGULAR – CABLE MANAGED LEG (CAB)

All cable ports have changed from 62mm to round, grey 80mm diameter across ALL desktops. Modesty panel position always at the rear of desk. Modesty panel cable port changed to cut-

• ut with grey plastic

edging Leg cap will match the colour of the leg (white or silver). Adjustable foot colour is black as per the

• riginal Woodstock

sample. Cable riser to run cables through the leg.

WAVE – CABLE MANAGED LEG (CAB)

All cable ports have changed from 62mm to round, grey 80mm diameter across ALL desktops. Modesty panel position always at the rear of desk. Modesty panel cable port changed to cut-

• ut with grey plastic

edging Leg cap will match the colour of the leg (white or silver). Adjustable foot colour is black as per the

• riginal Woodstock

sample. Cable riser to run cables through the leg.

RADIAL – CABLE MANAGED LEG (CAB)

All cable ports have changed from 62mm to round, grey 80mm diameter across ALL desktops. Modesty panel position always at the rear of desk. Modesty panel cable port changed to cut-

• ut with grey plastic

edging Leg cap will match the colour of the leg (white or silver). Adjustable foot colour is black as per the

• riginal Woodstock

sample. Cable riser to run cables through the leg.

RECTANGULAR – GOAL POST LEG (GP)

All cable ports have changed from 62mm to round, grey 80mm diameter across ALL desktops. Modesty panel position always at the rear of desk. Modesty panel cable port changed to cut-

• ut with grey plastic

edging Adjustable foot colour is black as per the

• riginal Woodstock

sample.

RADIAL – GOAL POST LEG (GP)

All cable ports have changed from 62mm to round, grey 80mm diameter across ALL desktops. Modesty panel position always at the rear of desk. Modesty panel cable port changed to cut-

• ut with grey plastic

edging Adjustable foot colour is black as per the

• riginal Woodstock

sample.

DIAMOND FURNITURE ASSEMBLY

DIAMOND SEATING

Ranges

Mechanism Guide

Mechanism Guide

DIAMOND SEATING ASSEMBLY

DIAMOND BENCH DESKING

ECONOMY BENCH (CB)

Screen depth desktops (780mm) has been discontinued for 2020. Full depth desktops (800mm) will be sold across both bench systems. Desktop options: cable port or cut-

• ut

New screen brackets will sit on top of the desktop. CB bench framework specification and construction has not changed.

PREMIUM BENCH (PB)

Top hats to fix beam and desktops to the legs. Sliding desktops available as a special. Telescopic beams for cable management Screen depth desktops (780mm) has been discontinued for 2020. Full depth desktops (800mm) will be sold across both bench systems. Desktop options: cable port or cut-

• ut

BENCH SCREEN BRACKETS

Both screen clamps sit

• n top of the desktop

across double and single benching. To fit screens;

• Contempo
• Elco
• Lyle (New)

To fit screens;

• Toolrail
• Panel
