Probing super light neutral Higgs boson at the LHC in CP violating MSSM Higgs sector Dilip Kumar Ghosh Department of Theoretical Physics Indian Association for the Cultivation of Science 2A & 2B Raja S.C. Mullick Road, Kolkata, India

slide-1
SLIDE 1

Probing super light neutral Higgs boson at the LHC in CP violating MSSM Higgs sector

Dilip Kumar Ghosh Department of Theoretical Physics Indian Association for the Cultivation of Science 2A & 2B Raja S.C. Mullick Road, Kolkata, India Tohoku University,Sendai, Japan 1-2 September, 2010

slide-2
SLIDE 2

Plan

  • CP violating (

CP) MSSM Higgs sector

  • General feature of the phenomenology of the CP violating (

CP) MSSM Higgs sector

  • Study of ultra light Higgs boson (mH ≤ 60 GeV) at LHC in Four possible

scenarios

  • Summary

Tohoku University, Sendai, Japan, 1-2 September, 2010 Dilip Kumar Ghosh

slide-3
SLIDE 3

CP violation in Higgs sector

  • CP violation arises naturally in the three generation SM (Phase in the CKM

matrix)

  • The CP violation has been first measured in neutral K-meson decays.

[J. H. Christenson, J. W. Cronin, V. L. Fitch, and R. Turlay , Phys. Rev. Lett.13, 138 (1964)]

  • CP non-conservation provides a key ingredient for cosmological baryogenesis
  • It is possible to have CP violation in Multi-Higgs models
  • MSSM contains an extended Higgs sector : may realize CP violation

Tohoku University, Sendai, Japan, 1-2 September, 2010 Dilip Kumar Ghosh

slide-4
SLIDE 4

General frame work

  • Higgs potential of the MSSM is invariant under CP at the tree level
  • Two CP-even neutral Higgs bosons :h0, H0 (MH0 > Mh0)
  • One CP-odd neutral Higgs boson :A0
  • One charged Higgs boson :H±
  • MA, tan β, µ and At,b control the MSSM Higgs spectrum
  • The tree level CP invariance of the MSSM Higgs potential may be violated

sizeably by loop effects involving soft CP-violating trilinear couplings At,b [ A.

Pilaftsis, PRD58,096010 (1998) and PLB435,88 (1998)]

Tohoku University, Sendai, Japan, 1-2 September, 2010 Dilip Kumar Ghosh

slide-5
SLIDE 5

CP violation in MSSM

  • After radiative corrections to the tree level Higgs potential:

CP violation induced through loop effects via 3 generation sfermion and gaugino mass parameters

  • From the one loop effective potential Higgs boson mass matrix is calculated

[J.Ellis et al’90, Y.Okada et al ’90, E.Haber et al’90,..M.Carena et al’95...A.Demir’99, A.Pilaftsis et al’99... S.Y.Choi et al’99] M 2

N =

M 2

S

M 2

SP

M 2

P S

M 2

P

!

  • M 2

S, M 2 P and M 2 SP denote the 2 × 2 matrices of the scalar, pseudoscalar and

scalar-pseudoscalar squared mass terms of the neutral Higgs bosons. M 2

P S ≃ O

m4

t

v2 |µ||At| 32π2M 2

S

  • sin φCP
  • 1, |At|2

M 2

S

, |µ|2 tan βM 2

S

, |µ||At| M 2

S

  • MS is stop mass average, φCP = Arg(At,µ)

Tohoku University, Sendai, Japan, 1-2 September, 2010 Dilip Kumar Ghosh

slide-6
SLIDE 6

CP violation in MSSM Higgs sector

  • In CP conserving MSSM: MSP = 0: 2 CP-even h, H and one CP-odd A.
  • Diag(M 2

H1, M 2 H2, M 2 H3) = OTM 2 NO , with MH1 < MH2 < MH3

  • After diagonalization the Physical mass eigenstates are mixed states of CP,

H1,2,3 have undefined CP properties.

  • To get sizeable CP violation, large | µ |, | At,b | and large sin φCP

are needed

  • mA no longer a physical parameter, but the mH± can be used as a physical

parameter

  • Elements of matrix O are similar to cos α and sin α in the CP-conserving case.

But 3rd row and column are zero in the non-diagonal elements in such a case

  • Large mH± implies H1 → Hsm

Tohoku University, Sendai, Japan, 1-2 September, 2010 Dilip Kumar Ghosh

slide-7
SLIDE 7

The interaction between Higgs and gauge bosons

LHiV V = gmW

3

  • i=1

gHiV V [HiW +

µ W −,µ +

1 2c2

W

HiZµZµ] LHiHjZ = g 2cW

3

  • j>i=1

gHiHjZ (Hi

↔

∂µ Hj)Zµ LHH∓W ± = g 2cW

3

  • i=1

gHiH−W + (Hi

↔

∂µ H−)W +,µ gHiV V = O1i cos β + O2i sin β, gHiHjZ = O3i(cos βO2j − sin βO1j) − (i ↔ j) gHiH+W − = O2i cos β − O1i sin β + iO3i gHkV V = ǫijkgHiHjZ

  • We have the following Sum rules: 3

X

i=1

g2

HiV V = 1,

Tohoku University, Sendai, Japan, 1-2 September, 2010 Dilip Kumar Ghosh

slide-8
SLIDE 8

Implications of CP violating phases on Higgs searches

The CPX Scenario (Carena, Ellis, Pilaftsis & Wagner, PLB495(2000) 155)

  • Designed to showcase the effects of CP violation in the MSSM Higgs sector

M˜

t = M˜ b = M˜ τ = MSUSY

µ = 4MSUSY, | At,b,τ |= 2MSUSY, | M˜

g |= 1TeV

  • Allows the following parameters to vary:

tan β, MH±, MSUSY ΦAt, ΦAb, ΦAτ, Φ˜

g, Φµ

  • The spectrum is generated by CPSUPERH code

[J. S. Lee etal, Comput.Phys.Commun. 156,283(2004), hep-ph/0307377] Tohoku University, Sendai, Japan, 1-2 September, 2010 Dilip Kumar Ghosh

slide-9
SLIDE 9

Implications of CP violating phases on Higgs searches

10

  • 2

10

  • 1

1 20 40 60 80 100 120 arg (At) = arg (Ab) [ deg ] MH1, MH2 [ GeV ]

CPX scenario

(a) MSUSY = 0.5 TeV arg (At) = arg (Ab) [ deg ] g2

H1ZZ

, g2

H2ZZ

, g2

H3ZZ

g2

H3ZZ

g2

H3ZZ

g2

H2ZZ

g2

H1ZZ

(b) 40 50 60 70 80 90 100 110 120 130 140 20 40 60 80 100 120

  • (a) MH1, MH2 and (b) g2

HiZZ as functions of

Arg(At), in the CPX scenario for MSUSY = 1 TeV and for the following choices

  • f

(MH±, tan β): (160 GeV, 4)(solid lines), (150 GeV, 5) (dashed lines) and (140 GeV, 6) (dotted lines)

Tohoku University, Sendai, Japan, 1-2 September, 2010 Dilip Kumar Ghosh

slide-10
SLIDE 10

Implications of CP violating phases on Higgs searches

  • In CPC MSSM, we have access only two neutral Higgses h, H in Higgsstrahlung

/WW fusion process

  • In CPV MSSM, the three neutral Higgs mass eigenstates Hi (i=1,2,3) do not

have well defined CP quantum numbers.

  • Each of them can be produced in the Higgs-Strahlung process: (e+e− → ZHi)

and/or in the WW fusion (e+e− → Hiνe ¯ νe)

  • Also in pair (e+e− → HiHj(i = j))
  • The relative rates depend of the choice of the parameters describing the

CP-odd/even mising. [A.Akeroyd & A. Arhrib, PRD64,095018 (2001)]

Tohoku University, Sendai, Japan, 1-2 September, 2010 Dilip Kumar Ghosh

slide-11
SLIDE 11

Higgs production in CP violating MSSM

  • We studied WHi and ZHi, (i = 1, 2, 3) pair production at Tevatron (p¯

p) Run II and LHC (pp) Collider.

[Arhrib,Ghosh & Kong,PLB’2002]

  • Our parameters are fixed as:

Set A:

  • MQ =

Mt = Mb = 1TeV, |µ| = 4TeV, |At| = |Ab| = 2TeV, Arg(At) = Arg(Ab), tan β = 6 Set B:

  • MQ =

Mt = Mb = 0.5TeV, |µ| = 2TeV, |At| = |Ab| = 2TeV, Arg(At) = Arg(Ab), tan β = 15

  • Interested in MH± <

∼ 300 GeV MH± > 300 is the decoupling scenario and H1 is SM like V V H1 = 1, V V H2 = V V H3 = 0

Tohoku University, Sendai, Japan, 1-2 September, 2010 Dilip Kumar Ghosh

slide-12
SLIDE 12

Higgs production in CP violating MSSM

50 70 90 110 130 150

Higgs Mass (GeV) H1 H2 H3 (a)

100 120 140 160 180 200

H1 H2 H3 (d)

1e-06 0.0001 0.01 1

σ(pb) ZH1 ZH2 ZH3 (b) ZH1 ZH2 ZH3 (e)

1e-06 0.0001 0.01 1 20 40 60 80 100 120 140 160 180

σ (pb)

Φ

CP (degree)

WH1 WH2 WH3 (c)

20 40 60 80 100 120 140 160 180

Φ

CP (degree)

WH1 WH2 WH3 (f)

  • Tevatron Run II energy.

MH± = 150(left pannel) and 200 GeV (right pannel). Other MSSM parameters correspond to set A.

Tohoku University, Sendai, Japan, 1-2 September, 2010 Dilip Kumar Ghosh

slide-13
SLIDE 13

Higgs production in CP violating MSSM

50 70 90 110 130 150

Higgs Mass (GeV) H1 H2 H3 (a)

100 120 140 160 180 200

H1 H2 H3 (d)

1e-06 0.0001 0.01 1 10

σ (pb) ZH1 ZH2 ZH3 (b) ZH1 ZH2 ZH3 (e)

1e-06 0.0001 0.01 1 10 20 40 60 80 100 120 140 160 180

σ (pb)

Φ

CP (degree)

WH1 WH2 WH3 (c)

20 40 60 80 100 120 140 160 180

Φ

CP (degree)

WH1 WH2 WH3 (f)

  • LHC energy. MH± = 150(left pannel) and

200 GeV (right pannel). Other MSSM parameters correspond to set A.

Tohoku University, Sendai, Japan, 1-2 September, 2010 Dilip Kumar Ghosh

slide-14
SLIDE 14

Higgs search in CP violating MSSM Higgs sector

MH1 (GeV) tanβ LEP(95)/TeV(3σ)/LHC(5σ) for CPX0.5

2 5 10 20 30 40

900

2 5 10 20 30 40

600

2 5 10 20 30 40

300

2 5 10 20 30 40

00

20 40 60 80 100 120 20 40 60 80 100 120 20 40 60 80 100 120 20 40 60 80 100 120

  • M. Carena etal.

[NPB659,145 (2003)] looked for several channels for Higgs boson Hi searches at hadron colliders

  • 45◦ line: Tevatron: W/ZHi(→ b¯

b).

  • 135◦

line: LHC: gg → Hi → γγ( 100 fb−1), t¯ tHi(→ b¯ b)( 100 fb−1), W W/ZZHi(→ τ +τ −)( 100 fb−1).

  • dark grey → LEP exclusion.
  • Gaps at MH1 ≤ 50 GeV for 90◦ and 60◦

Tohoku University, Sendai, Japan, 1-2 September, 2010 Dilip Kumar Ghosh

slide-15
SLIDE 15

LEP-2 exclusion

1 10 20 40 60 80 100 120 140 1 10

mH1 (GeV/c

2)

tanβ

Excluded by LEP Theoretically Inaccessible

CPX (b)

  • Exclusions, at 95%CL(light-green) and the

99.7%CL(dark-green)

  • Two main channels LEP studied :

(a) e+e− → H1Z(H2Z) and (b) e+e− → H1H2

  • For low MH1, LEP looked at e+e−H1H2 →

H1(H1H1) → 6b jets,and 6τ leptons

[Eur.Phys.J.C47, 547 (2006)]

Tohoku University, Sendai, Japan, 1-2 September, 2010 Dilip Kumar Ghosh

slide-16
SLIDE 16

Light Higgs window : Scenario I

  • LEP can not exclude the light Higgs mass in these two regions of parameter

space:

  • ΦCP = 90◦, tan β ∼ 4 − 5,

MH± ∼ 125 − 140 GeV, MH1

< ∼ 60 GeV

  • ΦCP = 60◦, tan β ∼ 2 − 3,

MH± ∼ 105 − 130GeV, MH1

< ∼ 40 GeV

  • Suppressed H1ZZ coupling and also the H1t¯

t.

  • Tevatron also can not probe this because of suppressed W/ZH1 coupling.
  • No hope at the LHC through t¯

tH1 and W/ZH1.

[with D. P. Roy and R. M. Godbole, PLB628,131(2005)] Tohoku University, Sendai, Japan, 1-2 September, 2010 Dilip Kumar Ghosh

slide-17
SLIDE 17

Light Higgs window : Scenario I

  • H1ZZ coupling is suppressed, H+W −H1 coupling remains large
  • Large H±WH1 coupling ⇒ large Br (H± → H1W ±)
  • Small tan β, light H±, (MH+ < Mt) ⇒ H± can be produced in the top decay.

tan β 3.6 5 Br(H+ → H1W +)(%) > 90(87.45) > 90(46.57) Br(t → bH+)(%) ∼ 0.7 1.0 – 1.3 MH+ (GeV) < 148.5 (149.9) < 126.2(134) MH1 (GeV) < 60.62 (63.56) < 29.78(53.49)

The BR (H± → H1W) > 0.47 over the entire kinematic region in the light H1 window still allowed by LEP. BR (H± → τντ) is suppressed by over an order of magnitude.

Tohoku University, Sendai, Japan, 1-2 September, 2010 Dilip Kumar Ghosh

slide-18
SLIDE 18

Light Higgs window : Scenario I

pp →

✲

t b

✲

H+

✲

W ℓν(q¯ q)

✲

H1 b¯ b +

✲

¯ t ¯ b

✲

W q¯ q(ℓν) + X

  • Process allows a probe of a light H± and light neutral Higgs.
  • Use t¯

t production with: t → bH+ → bH1W → bb¯ bW and ¯ t → ¯ bW, with one W decaying leptonically the

  • ther hadronically.
  • Look for WWbbbb events, demand 3 or more tagged b’s.
  • The mass of the b¯

b pair with the smallest value will cluster around MH1 and b¯ bW around MH+

Tohoku University, Sendai, Japan, 1-2 September, 2010 Dilip Kumar Ghosh

slide-19
SLIDE 19

Light Higgs window : Scenario I

As a basic selection criteria we require

  • | ηj,ℓ |< 2.5 :
  • pi

Tjets(i = 1, 2, 3) > 30 GeV

  • pT of all the other jets, lepton > 20 GeV,
  • ∆Rjj,ℓj > 0.4
  • Three or more tagged b-jets in the final state, ǫb = 0.5.
  • Signal cross-section varies between 20-150 fb for the range of light Higgs mass

20-50 GeV

  • The main SM background σ(pp → t¯

tb¯ b) ∼ 0.5 fb after all cuts

  • With 30 fb−1 data one expects upto ∼ 4500 events after all cuts

Tohoku University, Sendai, Japan, 1-2 September, 2010 Dilip Kumar Ghosh

slide-20
SLIDE 20

Light Higgs window : Scenario I

1 2 3 4 5 6 7 8 9 10 50 100 150 200 d σ/dminv (fb/GeV) minv (GeV) ΦCP = 90o tan β = 5 MH1 = 51 (GeV) MH+ = 133 (GeV) Mt = 175 (GeV)

mbb

  • mbbW
  • mbbWb
  • (a)

(b)

m

b b

  • mbbW
  • Tohoku University, Sendai, Japan, 1-2 September, 2010

Dilip Kumar Ghosh

slide-21
SLIDE 21

Light Higgs window : Scenario II

  • Use the same fact that W ±H∓H1 coupling is enhanced
  • We look at pp → H± + H1 → (H1W ±) + (b¯

b) → (b¯ b)(ℓν) + (b¯ b)

  • Signal will be 4b + ℓ± with missing energy
  • Important feature : Two pairs of b-jets reconstruct at light Higgs mass
  • The signal cross-section is not large (production process is a weak interaction)
  • After all cuts σsignal can reach up to 1.6 fb for MH1 ∼ 45 GeV

[with S. Moretti, EPJC42,341 (2005)] Tohoku University, Sendai, Japan, 1-2 September, 2010 Dilip Kumar Ghosh

slide-22
SLIDE 22

Light Higgs window : Scenario II

  • Following SM backgrounds were generated using MADGRAPH :
  • We used same set of basic cuts as in Scenario I
  • (a)

σ(gg → b¯ bjjℓν) < ∼ 2.2 × 10−3 fb

  • (b)

σ(q¯ q′ → ZZW ± → b¯ bjjℓν) < ∼ 4.0 × 10−3 fb;

  • (c)

σ(gg → t¯ t → b¯ bjjℓν) < ∼ 2.9 × 10−2 fb

  • We have assumed the b-tagging efficiency ǫb = 0.5 (for each b-jet) and the

appropriate light-quark rejection factors (Ru,d,s = 1/50 and Rc = 1/25).

Tohoku University, Sendai, Japan, 1-2 September, 2010 Dilip Kumar Ghosh

slide-23
SLIDE 23

Light Higgs window : Scenario II

0.01 0.02 0.03 0.04 0.05 0.06 0.07 0.08 0.09 50 100 150 200 dσ dmbb (GeV)-1 1 σ mbb (GeV)

  • EW background

(a) QCD background MH1= 54.34 (GeV) MH1= 32.41 (GeV) tt background

  • Tohoku University, Sendai, Japan, 1-2 September, 2010

Dilip Kumar Ghosh

slide-24
SLIDE 24

Light Higgs window : Scenario III

  • Use ˜

t1˜ t∗

1h1 coupling

  • σ(˜

t1˜ t∗

1h1) is large in CPV scenario, due to large value of At.

Large At = ⇒ lighter stop. In addition, both h2 and h3 also couple favorably to the t¯ t pair can add modestly to the signal

  • Typical masses (GeV) :mhi = (48.9, 103.3, 135.7); m˜

ti = (322, 664); m˜ χ0

1,2 =

(99.6, 198.4); m˜

χ±

1 = 198.4; m˜

g = 1000

  • Cross-sections(fb):

σ˜

t1˜ t∗

1h1 = 440; σ˜

t1˜ t∗

1h2 = 6; σ˜

t1˜ t∗

1h3 = 4; σt¯

th1 = 8; σt¯ th2 =

198; σt¯

th3 = 135; σ˜ g˜ g = 134

  • Typical Branching fractions: Br(˜

t1 → b˜ χ+

1 ) = 0.81; Br(˜

t1 → t˜ χ0

1) = 0.19; Br(h1 →

b¯ b) = 0.91; Br(h2 → h1h1) = 0.71; Br(h3 → h1h1) = 0.82; Br(˜ g → t˜ t∗

1) = 0.16 [P. Bandyopadhyay, PRD78, 015017 (2008)] Tohoku University, Sendai, Japan, 1-2 September, 2010 Dilip Kumar Ghosh

slide-25
SLIDE 25

Light Higgs window : Scenario III

  • They looked at pp → ˜

t1˜ t∗

1h1 and pp → t¯

th2,3

  • h1 and both top (stop) dominantly decay to b quarks
  • For the signal, the associate Ws (or ˜

χ±

1 ) produced in the decay of t (or ˜

t1) are required to decay leptonically

  • These decay lead to 4b + 2ℓ + missing pT final state
  • Low mh1 give rise to softer b-jet ( less than 40 GeV)
  • This forced them to look for 3 tagged b + 2ℓ + other untagged jets + missing pT
  • Backgrounds: Two sources : CPC MSSM, & SM
  • CPC MSSM : pp → ˜

g˜ g, pp → t¯ th

  • SM : pp → t¯

t, t¯ tZ, t¯ tb¯ b, t¯ th

Tohoku University, Sendai, Japan, 1-2 September, 2010 Dilip Kumar Ghosh

slide-26
SLIDE 26

Light Higgs window : Scenario III

  • Decisive cuts:
  • 1. Missing pT ≥ 110 GeV
  • 2. pjet

T

≤ 300 GeV

  • 3. Nj ≤ 5
  • Cut (1) remove mainly SM t¯

th

  • Cut (2) & (3) remove ther CPC (pp → ˜

g˜ g) and rest of the SM backgrounds

  • Assuming L = 30 fb−1, they expect S/

√ B ∼ 7

Tohoku University, Sendai, Japan, 1-2 September, 2010 Dilip Kumar Ghosh

slide-27
SLIDE 27

Light Higgs window : Scenario IV

  • Look for ˜

χ0

2 → ˜

χ0

1h1

  • Br(˜

χ0

2 → ˜

χ0

1h1) ∼ 0.79 and Br(˜

g → ˜ χ0

2q¯

q) ∼ 0.17 in the region where a light Higgs is unexcluded by the present data

  • Consider the SUSY cascade decay chain starting with a gluino:
  • ˜

g → ˜ χ0

2q¯

q → ˜ χ0

1h1q¯

q → ˜ χ0

1q¯

qb¯ b(τ +τ −)

  • σ˜

g˜ g ≈ 8.5 pb for M˜ g = 500 GeV

  • Around 13% gluinos produced in this scenario will decay into h1
  • More detailed analysis (even parton level) is required to establish their claims

[A.C. Fowler and G. Weiglein, arXiv:0909.5165] Tohoku University, Sendai, Japan, 1-2 September, 2010 Dilip Kumar Ghosh

slide-28
SLIDE 28

Summary

  • CP violation in the MSSM Higgs sector can be generated at loop level leading

to very interesting phenomenology in the MSSM Higgs sector

  • LEP-2 still allows very light Higgs in the CP violating MSSM Higgs sector, due

to strong suppression of the H1ZZ coupling

  • No hope from Tevatron and LHC either through conventioanl channel:

H1W ±W ∓ and H1t¯ t couplings are suppressed in the same parameter space

  • At LHC the light Higgs window scenario may be closed through:

– pp → t¯ t → (bW +)(¯ bH−) → (bℓν)(bH1W −) → (bℓν)(bb¯ b)(jj) – pp → H±H1 → (H1W ±) + (b¯ b) → (b¯ bℓν) + (b¯ b)

  • Other possible channels:

– pp → ˜ t1˜ t∗

1h1, followed by 3 tagged b + 2ℓ + other untagged jets + missing pT

– Look for ˜ χ0

2 → ˜

χ0

1 + h1 decay Tohoku University, Sendai, Japan, 1-2 September, 2010 Dilip Kumar Ghosh

slide-29
SLIDE 29

Summary

– σ˜

g˜ g is large. ˜

g → ˜ χ0

2q¯

q → ˜ χ0

1h1q¯

q → ˜ χ0

1q¯

qb¯ b(τ +τ −)

  • So far no dedicated analysis using B decays
  • Question : Can B → µ+µ−, Xsγ, τντ close this light Higgs window ?

Tohoku University, Sendai, Japan, 1-2 September, 2010 Dilip Kumar Ghosh
