Printed Circuit Board Design Updates Andrew Laundrie and Xu Zhai UW Physical Sciences Laboratory March 27, 2019 Design Updates Overview Foot Boards and Side Boards - Dimensions stretched to fit larger frame tubes - Multi-layer boards are

slide-1
SLIDE 1

Printed Circuit Board Design Updates

Andrew Laundrie and Xu Zhai UW Physical Sciences Laboratory March 27, 2019

slide-2
SLIDE 2

Design Updates ̶ Overview

3/27/19 DUNE PCB Design Updates 2

  • Foot Boards and Side Boards
  • Dimensions stretched to fit larger frame tubes
  • Multi-layer boards are required in some locations
  • Head Boards
  • Increased spacing between wire traces
  • Improved interface for electrical testing
  • Hardware Improvements
  • Custom Mill-Max sockets and pins
  • Stronger threaded inserts in boards
slide-3
SLIDE 3

X-Layer Foot Boards

3/27/19 DUNE PCB Design Updates 3

Old New

slide-4
SLIDE 4

V-Layer Side Boards

3/27/19 DUNE PCB Design Updates 4

slide-5
SLIDE 5

U-Layer Side Boards

3/27/19 DUNE PCB Design Updates 5

slide-6
SLIDE 6

Head Board Structure

3/27/19 DUNE PCB Design Updates 6

slide-7
SLIDE 7

Slots Between CR Boards

3/27/19 DUNE PCB Design Updates 7

slide-8
SLIDE 8

Solder Pads (48) X Plane Sockets and Test Pads (48) VSS pass‐throughs V U

X-layer Head Board: ProtoDUNE

3/27/19 DUNE PCB Design Updates 8

V and U signals pass through connected socket pairs

slide-9
SLIDE 9

X-layer Head Board: ProtoDUNE

3/27/19 DUNE PCB Design Updates 9

  • Spacing of 0.5 mm

between channels limits the safe voltage that can be applied between adjacent wires (~100 V)

  • Increased spacing is

desired to support voltage differences as high as 400 V

slide-10
SLIDE 10

X-layer Head Board: DUNE

3/27/19 DUNE PCB Design Updates 10

slide-11
SLIDE 11

X-layer Head Board: DUNE

3/27/19 DUNE PCB Design Updates 11

  • Spacing between U and V

wire channels has increased to 2.5 mm

  • Board edge was moved

4.0 mm to accommodate increased channel spacing

  • Fiducials were added to all

boards to support inspection by automatic vision systems

Fiducial reference point V U

slide-12
SLIDE 12

X-layer Head Board: DUNE

3/27/19 DUNE PCB Design Updates 12

  • Landing pads were

added to the bottom side of X head boards (blue traces)

  • Pads allow the

attachment of test headers in place of CR boards

  • Headers use spring-

loaded contact pins

slide-13
SLIDE 13

Test Header Concept

3/27/19 DUNE PCB Design Updates 13

  • Four connectors

provide access to all channels on the X, U, and V head boards

slide-14
SLIDE 14

CR Board (ProtoDUNE)

3/27/19 DUNE PCB Design Updates 14

slide-15
SLIDE 15

New CR Board

3/27/19 DUNE PCB Design Updates 15

Minor changes only

slide-16
SLIDE 16

V-layer Head Boards (new / old)

3/27/19 DUNE PCB Design Updates 16

slide-17
SLIDE 17

U Layer Head Boards (new / old)

3/27/19 DUNE PCB Design Updates 17

slide-18
SLIDE 18

G Layer Head Board: ProtoDUNE

3/27/19 DUNE PCB Design Updates 18

Solder Pads (48) Landing pads for G bias (12 + 6)

slide-19
SLIDE 19

G Bias Board: ProtoDUNE

3/27/19 DUNE PCB Design Updates 19

slide-20
SLIDE 20

G Layer Head Board: DUNE

3/27/19 DUNE PCB Design Updates 20

Solder Pads (48) Landing pads for G bias (48 + 6)

slide-21
SLIDE 21

G Bias Board: DUNE

3/27/19 DUNE PCB Design Updates 21

slide-22
SLIDE 22

ProtoDUNE Sockets and Pins

3/27/19 DUNE PCB Design Updates 22

Standard catalog items had some performance issues

slide-23
SLIDE 23

DUNE Sockets

3/27/19 DUNE PCB Design Updates 23

slide-24
SLIDE 24

DUNE Pins

3/27/19 DUNE PCB Design Updates 24

slide-25
SLIDE 25

CE Assembly Installation

3/27/19 DUNE PCB Design Updates 25

  • Captive screws in ProtoDUNE were

meant to pull connectors together in a controlled fashion, but they posed a risk of being dropped into the cryostat during CE installation or removal

slide-26
SLIDE 26

CE Assembly Installation

3/27/19 DUNE PCB Design Updates 26

  • Captive screws were eliminated

by changing the angle brackets

  • n CR boards
  • Threaded tools are inserted and

rotated to pull connectors together, then removed

slide-27
SLIDE 27

CE Assembly Installation

3/27/19 DUNE PCB Design Updates 27

slide-28
SLIDE 28

Hardware Improvements

3/27/19 DUNE PCB Design Updates 28

  • Expanding threaded

inserts have been replaced by broaching fasteners to prevent breaking and reduce metal debris

slide-29
SLIDE 29

Process Improvements

3/27/19 DUNE PCB Design Updates 29

  • Improved tools and methods are being evaluated for PCBs
  • Instrumented tips on soldering irons for process control
  • Vapor-phase reflow soldering for CR and G Bias boards
  • Improved board-washing equipment
  • Automated test systems for CR boards and G-Bias boards
slide-30
SLIDE 30

Quality Assurance and Control

3/27/19 DUNE PCB Design Updates 30

  • All ProtoDUNE boards were inspected when received
  • Complex mechanical features were frequently out of spec
  • Continued inspection of most boards is probably needed
  • Manual board inspection was time-consuming
  • Vision systems are being evaluated for board inspection
slide-31
SLIDE 31

Backup Slides

3/27/19 DUNE PCB Design Updates 31

slide-32
SLIDE 32

Mill-Max Pins and Sockets

Pins are fragile and not repairable once bent. Their exposure is minimized during APA assembly. .

CR X V U

32

slide-33
SLIDE 33

In ProtoDUNE the separation between exposed metal through-hole pads is about 0.5 mm.

33
