PRESSURE VESSELS (INDIA)

ISO & ASME Accredited Company

Pressure Vessels Heat Exchangers Tube Bundles Storage Vessels Spherical Vessels

slide-2
SLIDE 2

We are…

Leading manufacturer & exporter of Pressure Vessels, Shell and Tube Heat Exchangers and Distillation Columns required for water treatment, chemical and petrochemical industries.

An ISO 9001:2008 certified company established in the year1986.

Accredited by ASME for manufacture of Pressure Vessels under ASME ‘U’, ‘R’, ‘NB’.

Government of India Recognized STAR Export House.

Approved by CCOE / PESO Nagpur for manufacture of Unfired Pressure Vessels.

Major Supplier of equipment's under Council Directive 97/23/EC & CE certification.

Manufacturer of equipments under ASME, PD 5500, IS 2825, PED 97/23/ECS, AD 2000 Merkblatt, JIS, SMPV Rules & API 650.

Exporting more than 80% of the equipments manufactured to the different parts of the world.

slide-3
SLIDE 3

Quality Policy

PRESSURE VESSELS (INDIA)

IS COMMITTED TO TOTAL CUSTOMERS SATISFACTION. WE WILL SUPPLY EXCELLENT QUALITY EQUIPMENTS, ON TIME AS PER CUSTOMERS SPECIFICATIONS & INTERNATIONAL STANDARDS AT OPTIMUM COST THROUGH TRAINING & MOTIVATING THE EMPLOYEES AND CONTINUAL IMPROVEMENT IN QUALITY MANAGEMENT SYSTEM.

slide-4
SLIDE 4

Health Safety & Environment Policy

PRESSURE VESSELS (INDIA) IS COMMITTED TO BEING AN ENVIRONMENT FRIENDLY COMPANY IN ALL ITS ACTIVITIES, PRODUCTS, AND SERVICES AND TO PROVIDE SAFE AND HEALTHY WORKING ENVIRONMENT TO ALL EMPLOYEES AS AN INTEGRAL PART OF BUSINESS PERFORMANCE THROUGH:

COMPLIANCE WITH APPLICABLE LEGISLATION AND REGULATIONS.

CONTINUAL IMPROVEMENT IN THE OCCUPATIONAL HEALTH, SAFETY AND ENVIRONMENTAL MANAGEMENT SYSTEMS PERFORMANCE.

PROMOTION OF ACTIVITIES FOR CONSERVATION OF RESOURCES BY ENVIRONMENTAL MANAGEMENT.

ENHANCEMENT OF ENVIRONMENTAL, SAFETY AND OCCUPATIONAL HEALTH AWARENESS AMONGST EMPLOYEES, CUSTOMERS AND SUPPLIERS BY PROACTIVE COMMUNICATION AND TRAINING.

PERIODICAL REVIEW OF OCCUPATIONAL HEALTH, SAFETY & ENVIRONMENTAL MANAGEMENT SYSTEMS TO ENSURE ITS CONTINUING SUITABILITY, ADEQUACY AND EFFECTIVENESS.

COMMUNICATION OF THIS HSE POLICY TO ALL EMPLOYEES AND INTERESTED PARTIES.

COORDINATION WITH CONCERNED GOVERNMENT AGENCIES/ REGULATORY BODIES ENGAGED IN OCCUPATIONAL HEALTH, SAFETY & ENVIRONMENTAL ACTIVITIES.

slide-5
SLIDE 5

Industries we serve..

  • Water Treatment
  • Petrochemical
  • Chemical/

Fertilizer

  • Defense
  • Oil & Gas
  • Ship Building
  • Steel Plant
  • Refrigeration
slide-6
SLIDE 6

Certifications

▪ ISO ▪ 9001:2008▪ ASME ‘U’ ▪ ASME ‘R’ ▪ National Board ▪ HP-0 ▪ PESO ▪ Export House ▪ Marine Classification Societies ▪

slide-7
SLIDE 7

Manufacturing Capabilities

1 Maximum Diameter 6 meter. 2 Maximum Length 30 meter 3 Rolling Capacity Up to 75 mm 4 Dished End Pressing Up to 5.2 meter x 56 mm (Single Piece Construction) Above 5.2 Meter – Petal Type Construction 5 Maximum Weight Up to 150 Metric Tons

slide-8
SLIDE 8

Design Capabilities

 Code we follow

 ASME Section VIII Division 1 & Division 2  PD 5500  AD 2000 Merk Blatter  EN 13445  IS 2825

 Software available for Design

 PV-Elite  ANSYS

slide-9
SLIDE 9

Quality

 Testing Facilities – In

house

 Dye Penetrant Test  Radiography (viewing &

interpretation)

 Magnetic Particle Test  Hydrostatic Test  Pneumatic Test

 Testing Facilities –

Outsourced

 Radiography (Processing)  Helium Leak Test  Mechanical & Physical

Testing

 Ultrasonic testing  PMI  Hardness Testing

slide-10
SLIDE 10

Organisation Structure

C.E.O.

Management Representative

Administration Finance

Head Engineering & Operation Marketing Manager Marketing Engineer Design Manager Design Engineer Draftsman Purchase Manager Purchase Assistant Store Incharge Production Manager Production Engineer QAC & Welding Manager NDE Level II Calibration Engineer QAC & Welding Engineer NDE Level III

slide-11
SLIDE 11

Sales over the years …

USD 0.00 USD 5,00,000.00 USD 10,00,000.00 USD 15,00,000.00 USD 20,00,000.00 USD 25,00,000.00 USD 30,00,000.00 USD 35,00,000.00 USD 40,00,000.00

2010-11 2011-12 2012-13 2013-14

Total Sales in USD Export Sales in USD Domestic Sales in USD

slide-12
SLIDE 12

MANUFACTURING FACILITIES

slide-13
SLIDE 13

PVI - Chakan Plant

Covered Area 20000 Sq. Ft. 150 KM from JNPT 30 KM from Pune Air Port 25 KM from Pune Railway Station

slide-14
SLIDE 14

Rolling Machine

Make : Sertom (Italy) Rolling Capacity : up to 75 mm Thick Rolling Span : up to 3 Meters

slide-15
SLIDE 15

600 MT – Forming Press Machine

Make : PVI Thickness : up to 50 mm Thick Span : 5500 mm

slide-16
SLIDE 16

700 MT – Forming Press Machine

Make : PVI Thickness : up to 56 mm Thick Span: up to 4500 mm

slide-17
SLIDE 17

700 MT – Forming Press Machine

Make : PVI Thickness : up to 56 mm Thick Span: up to 4500 mm

slide-18
SLIDE 18

Spinning Machine

Make : PVI Diameter: 5 Meter Thickness : 25 mm

slide-19
SLIDE 19

EOT Cranes

Make : Electromech Capacity : 25 MT Quantity : 2 Nos.

slide-20
SLIDE 20

PRESSURE VESSELS FOR WATER TREATMENT INDUSTRY

slide-21
SLIDE 21

Condensing Polishing Units - Siemens

Design Code: ASME Section VIII Div. 1 & 2 Capacity : 32 M3 Design Pressure : 40 bar g. Weight : 15 MT Dimensions: 2800 mm Dia Thickness: 32 mm Thk.

slide-22
SLIDE 22

Flocculators – Black & Veatch (UK)

Design Code: PD 5500 With CE Marking Design Pressure : 16 bar g. Weight : 13 MT Dimensions: 2200 mm Dia x 3000 mm Long

Coated Internally with 162 PWX Epoxy Paint

slide-23
SLIDE 23

Pressure Filters – Black & Veatch (UK)

Design Code: PD 5500 With CE Marking Design Pressure : 16 bar g. Weight : 21 MT Dimensions: 4000 mm Dia x 7500 mm Long

Coated Internally with 162 PWX Epoxy Paint

slide-24
SLIDE 24

Mixed Bed Exchangers - Metito

Design Code: ASME Section VIII Div. 1 Design Pressure : 6 bar g. Weight : 16 MT Dimensions: 3000 mm Dia x 7500 mm Long

Internally Rubber lined. Specially Coated Hardware EPC : Abu Dhabi Polymer Company Ltd. UAE

slide-25
SLIDE 25

Activated Carbon Filters – Metito

Design Code: ASME Section VIII Div. 1 Design Pressure : 10 bar g. Weight : 12 MT Dimensions: 3200 mm Dia x 7500 mm Long

Internally Rubber lined. EPC : Abu Dhabi Polymer Co. Ltd. UAE

slide-26
SLIDE 26

Activated Carbon Filters – Metito

Design Code: ASME Section VIII Div. 1 Design Pressure : 10 bar g. Weight : 12 MT Dimensions: 3200 mm Dia x 7500 mm Long

Internally Rubber lined. EPC : Tasnee Petrochemicals

slide-27
SLIDE 27

PRESSURE SAND FILTERS - AQUABORE INTERNATIONAL

Year : 2014

EPC Contractor : AQUABORE PMC : WTE (I) PVT. LTD. Scope of Supply : 5 Pressure Sand Filters

slide-28
SLIDE 28

Water Treatment Equipment - Internals

slide-29
SLIDE 29

PRESSURE VESSELS FOR STEEL INDUSTRY

slide-30
SLIDE 30

Pressurizing Gas Vessel – Tata Steel (Jamshedpur)

Design Code: PD 5500 + FEA Capacity : 120 M3 Design Pressure : 44.1bar g. Weight : 75 MT Dimensions: 2750 mm Dia x 22500 mm Long Thickness: 40 mm Thk. Shell / 50 mm Thk. Head

slide-31
SLIDE 31

EI Gas Vessel – Tata Steel (Jamshedpur)

Design Code: PD 5500 + FEA Capacity : 80 M3 Design Pressure : 44.1bar g. Weight : 50 MT Dimensions: 2300 mm Dia x 18000 mm Long Thickness: 36 mm Thk. Shell / 40 mm Thk. Head

slide-32
SLIDE 32

EI Gas Vessel – Tata Steel (Jamshedpur)

Design Code: PD 5500 + FEA Capacity : 50 M3 Design Pressure : 44.1bar g. Weight : 35 MT Dimensions: 2400 mm Dia x 13000 mm Long Thickness: 36 mm Thk. Shell / 40 mm Thk. Head

slide-33
SLIDE 33

Pressurizing Gas Vessel – SAIL (Bhilai)

Design Code: ASME Section VIII Div. 1 + FEA Capacity : 90 M3 Design Pressure : 19 bar g. Weight : 30 MT Dimensions: 2600 mm Dia x 18000 mm Long Thickness: 20 mm Thk. Shell / 28 mm Thk. Head

slide-34
SLIDE 34

Nitrogen Storage Vessel – JSW ( Bellary)

Design Code: ASME Section VIII Div. 1 Capacity : 150 M3 Design Pressure : 18.2 bar g. Weight : 50 MT Dimensions: 3800 mm Dia x 15000 mm Long Thickness: 28 mm Thk. Shell / 32 mm Thk. Head

slide-35
SLIDE 35

Conveying Hoppers – SAIL (Bhilai)

Design Code: ASME Section VIII Div. 1 & 2 Capacity : 32 M3 Design Pressure : 19 bar g. Weight : 30 MT Dimensions: 3000 mm Dia x 7800 mm Long Thickness: 45 mm Thk. Shell / 50 mm Thk. Head

slide-36
SLIDE 36

Propane Storage Tank – Can For Manufacturing Cans (Egypt)

Design Code: ASME Section VIII Div. 1 Capacity : 45 MT Design Pressure : 21.5 bar g. Weight : 25 MT Dimensions: 3800 mm Dia x 15000 mm Long Thickness: 28 mm Thk. Shell / 32 mm Thk. Head

slide-37
SLIDE 37

PRESSURE VESSELS FOR SHIP-BUILDING INDUSTRY

slide-38
SLIDE 38

ZAMIL SHIPYARD – SAUDI ARABIA

Year : 2008 – 09

CUSTOMER : ROLLS ROYCE MARINE (NORWAY) CLASSIFICATION SOCIETY : ABS Scope of Supply : 30 BHS TANKS FOR 6 SHIPSETS

slide-39
SLIDE 39

NAM CHEONG SHIPYARD – CHINA

Year : 2008 – 09

CUSTOMER : ROLLS ROYCE MARINE (NORWAY) CLASSIFICATION SOCIETY : ABS Scope of Supply : 20 BHS TANKS FOR 5 SHIPSETS

slide-40
SLIDE 40

LANGSTEN - ROMANIA

Year : 2011 - 12

CUSTOMER : ROLLS ROYCE MARINE (NORWAY) CLASSIFICATION SOCIETY : DNV Scope of Supply : 10 BHS TANKS FOR 2 SHIPSET

slide-41
SLIDE 41

PAXOCEAN - ROMANIA

Year : 2011 - 12

CUSTOMER : ROLLS ROYCE MARINE (NORWAY) CLASSIFICATION SOCIETY : DNV Scope of Supply : 10 BHS TANKS FOR 2 SHIPSETS

slide-42
SLIDE 42

LABROY - ITALY

Year : 2010 - 11

CUSTOMER : ROLLS ROYCE MARINE (NORWAY) CLASSIFICATION SOCIETY : RINA Scope of Supply : 10 BHS TANKS FOR 2 SHIPSETS

slide-43
SLIDE 43

ROSETTI MARINO - ITALY

Year : 2010 - 11

CUSTOMER : ROLLS ROYCE MARINE (NORWAY) CLASSIFICATION SOCIETY : RINA Scope of Supply : 20 BHS TANKS FOR 4 SHIPSETS

slide-44
SLIDE 44

BREVIK - NORWAY

Year : 2010 - 11

CUSTOMER : ROLLS ROYCE MARINE (NORWAY) CLASSIFICATION SOCIETY : RINA Scope of Supply : 10 BHS TANKS FOR 2 SHIPSETS

slide-45
SLIDE 45

COSCO SHIPYARD - CHINA

Year : 2010 - 11

CUSTOMER : ROLLS ROYCE MARINE (NORWAY) CLASSIFICATION SOCIETY : ABS Scope of Supply : 20 BHS TANKS FOR 4 SHIPSETS

slide-46
SLIDE 46

NEW ORLEANS SHIPYARD - USA

Year : 2015 - 16

CUSTOMER : CARGOFLEXX B.V. (THE NETHERLANDS) CLASSIFICATION SOCIETY : ABS Scope of Supply : 4 BHS TANKS FOR 1 SHIPSET

slide-47
SLIDE 47

BHS TANKS – Rolls Royce Marine (Norway)

Design Code: ASME Section VIII Div. 1 Classification Society :ABS MOC : SA 516 Gr 70 Weight : 18 MT

slide-48
SLIDE 48

BHS TANKS – Rolls Royce Marine (Norway)

Design Code: ASME Section VIII Div. 1 Classification Society :DNV MOC : SA 516 Gr 70 Weight : 18 MT

slide-49
SLIDE 49

HEAT EXCHANGERS & TUBE BUNDLES

slide-50
SLIDE 50

Falling Film Evaporator - Tecnicas Reunidas

Design Code: AD 2000 Merkblatt / TEMA (CE Marked) MOC : EN 1.4306 Weight : 25 MT

slide-51
SLIDE 51

Falling Film Evaporator - Tecnicas Reunidas

Design Code: ASME Section VIII Div. 1 / TEMA ASME “U” Stamped MOC : SA 240 316L / SA 213 TP 316L Weight : 17 MT

slide-52
SLIDE 52

CO2 Cooler – Johnson Controls

Design Code: ASME Section VIII Div. 1 / TEMA MOC : SA 240 304 / SA 213 TP 304 Weight : 25 MT

slide-53
SLIDE 53

Superheater – Hindustan Zinc Ltd.

Design Code: ASME Section VIII Div. 1 / TEMA MOC : SA 516 Gr 70 / P11 Weight : 65 MT

slide-54
SLIDE 54

LPG Column Condenser – ONGC Hazira

Design Code: ASME Section VIII Div. 1 / TEMA MOC : SA 516 Gr 70 / SA 1179 Weight : 25 MT

slide-55
SLIDE 55

Forced Circulated Heat Exchanger - AIC

Design Code: ASME Section VIII Div. 1 / TEMA MOC :

SA 240 TP 304 / SS Duplex / Titanium Gr 2

Weight : 18 MT

slide-56
SLIDE 56

Brine Chiller – Johnson Controls

Design Code: ASME Section VIII Div. 1 / TEMA MOC : SA 516 Gr 70 / SA 334 Gr 6 Weight : 18 MT

slide-57
SLIDE 57

AES Tube Bundle – Essar Oil Ltd. Vadinar

Design Code: ASME Section VIII Dev. 1/ TEMA MOC :

Tubes: Cupro Nickel 70:30 Tubesheet Carbon Steel with 10 mm thick Cupro Nickel 70:30 Cladding

Weight : 15 MT

Qty : 1 no.

slide-58
SLIDE 58

AES Tube Bundle – Essar Oil Ltd. Vadinar

Design Code: ASME Section VIII Dev. 1/ TEMA MOC :

Tubes: Cupro Nickel 90:10 Tubesheet Carbon Steel with 10 mm thick Cupro Nickel 90:10 Cladding

Weight : 18 MT Qty: 3 Nos.

slide-59
SLIDE 59

BKU Tube Bundle – HZL. Debari

Design Code: ASME Section VIII Dev. 1/ TEMA MOC :

Tubes: SA 179 Tubesheet Carbon Steel

Weight : 10 MT

Qty: 1 No.

slide-60
SLIDE 60

BKU Tube Bundle – ORPIC. Sohar Refinery

Design Code: ASME Section VIII Dev. 1/ TEMA MOC :

Tubes: SA 213 TP 316L Tubesheet SA 182 F 316 L

Weight : 18 MT

slide-61
SLIDE 61

BKU Tube Bundle – Essar Oil Ltd. Vadinar

Design Code: ASME Section VIII Dev. 1/ TEMA MOC :

Tubes: SA 179 Tubesheet Carbon Steel

Weight : 15 MT

slide-62
SLIDE 62

AES Tube Bundles Re-Tubing – ONGC. Uran

Design Code: ASME Section VIII Dev. 1/ TEMA MOC :

Tubes: SA 213 TP 410 Tubesheet SA 266 Gr 2

Weight : 6 MT

QTY : 5 Nos.

slide-63
SLIDE 63

OUR CLIENTELE - INTERNATIONAL

slide-64
SLIDE 64

OUR CLIENTELE - INTERNATIONAL

slide-65
SLIDE 65

OUR CLIENTELE - DOMESTIC

slide-66
SLIDE 66

OUR CLIENTELE - DOMESTIC

slide-67
SLIDE 67

OUR CLIENTELE - DOMESTIC

slide-68
SLIDE 68

THIRD PARTY / CONSULTANTS

slide-69
SLIDE 69

THIRD PARTY / CONSULTANTS

slide-70
SLIDE 70

Visit us @
