Barrel slice assembly -Present status and ongoing preparations- Markus Moritz, 2nd Physics Institute PANDA CM, Nov. 2016 Outline Module Assembly Slice Coordinate System Slice Assembly Workspace & Tools Light Pulser Fiber

slide-1
SLIDE 1

Barrel slice assembly

  • Present status and ongoing preparations-

PANDA CM, Nov. 2016

Markus Moritz, 2nd Physics Institute

slide-2
SLIDE 2

Justus-Liebig-Universität Gießen 06.12.2016 PANDA collaboration meeting – Darmstadt

  • Markus Moritz-

Outline

  • Module Assembly
  • Slice Coordinate System
  • Slice Assembly Workspace & Tools
  • Light Pulser Fiber Coupling
  • APD Irradiation Setup
  • APD Status 1st Slice
slide-3
SLIDE 3

Justus-Liebig-Universität Gießen 06.12.2016 PANDA collaboration meeting – Darmstadt

  • Markus Moritz-

Reminder

3

  • Envisaged milestone:

Assembly of 1st full Barrel EMC Slice

  • 710 crystals in 11 different

geometries.

  • 1420 matched APDs after 1st

screening, irradiation, 2nd screening.

  • 710 APFEL ASCIs
  • 360 left and 360 right handed

APFEL-ASIC flex PCBs

  • 4500 m of signal cables.
  • Cooling
  • Capsules, Foils, …
slide-4
SLIDE 4

Justus-Liebig-Universität Gießen 06.12.2016 PANDA collaboration meeting – Darmstadt

  • Markus Moritz-

Module Assembly

4

3 sessions for module assembly 1 session for supermodule & slice assembly first second third

slide-5
SLIDE 5

Justus-Liebig-Universität Gießen 06.12.2016 PANDA collaboration meeting – Darmstadt

  • Markus Moritz-

Module Assembly

5

GOOD NEWS: WE HAVE STARTED TO ASSEMBLY THE 1ST SLICE!!!

second session should be finished today 2/3 of all modules are assembled

slide-6
SLIDE 6

Justus-Liebig-Universität Gießen 06.12.2016 PANDA collaboration meeting – Darmstadt

  • Markus Moritz-

Schedules - module assembly sessions -

6

  • proposal last cm-

Shifted due to APD throughput now

Awaiting feedback from PSL

now

slide-7
SLIDE 7

Justus-Liebig-Universität Gießen 06.12.2016 PANDA collaboration meeting – Darmstadt

  • Markus Moritz-

Module Assembly –Slice Coordinate System-

7

slide-8
SLIDE 8

Justus-Liebig-Universität Gießen 06.12.2016 PANDA collaboration meeting – Darmstadt

  • Markus Moritz-

Module Assembly –Slice Coordinate System-

8

slide-9
SLIDE 9

Justus-Liebig-Universität Gießen 06.12.2016 PANDA collaboration meeting – Darmstadt

  • Markus Moritz-

Module Assembly –Temp. Sensor Distribution-

9

Sensor distribution over alveole types marked red

slide-10
SLIDE 10

Justus-Liebig-Universität Gießen 06.12.2016 PANDA collaboration meeting – Darmstadt

  • Markus Moritz-

Module Assembly –Temp. Sensor Distribution-

10

slide-11
SLIDE 11

Justus-Liebig-Universität Gießen 06.12.2016 PANDA collaboration meeting – Darmstadt

  • Markus Moritz-

Module Assembly –Temp. Sensor Distribution-

11

slide-12
SLIDE 12

Justus-Liebig-Universität Gießen 06.12.2016 PANDA collaboration meeting – Darmstadt

  • Markus Moritz-

Slice Assembly Workspace & Tools

  • final layout assembly room-

12

Supermodule assembly Slice assembly Slice test turning device transportation & lifting unit

Here: 2t bridge crane

slide-13
SLIDE 13

Justus-Liebig-Universität Gießen 06.12.2016 PANDA collaboration meeting – Darmstadt

  • Markus Moritz-

13

  • Design of all assembly devices are ready and

all parts were ordered except:

  • Lugs fitting for transportation device
  • Intermediate plates for turning device
  • They were discussed last week,

drawings will be created soon.

  • Delivery of the crane delayed to cw 50 due to

delivery difficulties. Slice Assembly Workspace & Tools

slide-14
SLIDE 14

Justus-Liebig-Universität Gießen 06.12.2016 PANDA collaboration meeting – Darmstadt

  • Markus Moritz-

Light Pulser Fiber Coupling

14

  • Different length for different positions
  • Prototypes will be ordered next week
  • Inside coating with high reflective material
  • Different coatings will be tested:
  • Titanium dioxide
  • Barium sulfate
  • Aluminium
  • ….
slide-15
SLIDE 15

Justus-Liebig-Universität Gießen 06.12.2016 PANDA collaboration meeting – Darmstadt

  • Markus Moritz-

Light Pulser Fiber Coupling

15

backward forward

slide-16
SLIDE 16

Justus-Liebig-Universität Gießen 06.12.2016 PANDA collaboration meeting – Darmstadt

  • Markus Moritz-

PSL APD radiation Setup @ Giessen -status last cm-

16

  • Bochum HV control Software EPICS was installed last week by Tobias

Triffterer.

  • Previous Software causes several problems, for example:
  • USB-CAN converter produced a lot of error messages.
  • Channels stopped randomly voltage ramp up
  • Several Software crashes
  • With the new Software and Andrea it was figured out:
  • Some channels had (have) a short circuit
  • Some channels had (have) a loose contact
  • Some channels were (are) wrong wired.
  • The Problems will be fixed together with Andrea in the next few

days.

slide-17
SLIDE 17

Justus-Liebig-Universität Gießen 06.12.2016 PANDA collaboration meeting – Darmstadt

  • Markus Moritz-

PSL APD radiation Setup @ Giessen –present procedure-

17

  • Exact 20°C
  • Before irradiation:
  • electric contact checked

individual

  • Dark current measurement
  • Irradiate with 30 Gy and

individual bias for gain 100.

  • After irradiation:
  • Dark current measurement
  • Shipping to PSL
slide-18
SLIDE 18

Justus-Liebig-Universität Gießen 06.12.2016 PANDA collaboration meeting – Darmstadt

  • Markus Moritz-

APD Status 1st Slice

18

23 Girds irradiated, waiting for 2nd screening 1114 APDs ready

slide-19
SLIDE 19

Justus-Liebig-Universität Gießen 06.12.2016 PANDA collaboration meeting – Darmstadt

  • Markus Moritz-

APD Status 1st Slice

19

  • …..

01/07/2016 01/08/2016 01/09/2016 01/10/2016 01/11/2016 01/12/2016 100 200 300 400 500 600 700 800 900 1000 1100 1200

time # apds

today: 1114 APDs available for matching 51 APDs / week since beginning of project

remark: recycled APDs from PROTO120 not included

matching yield: 90 %

  • approx. 500 APDs for 3th session

missing

slide-20
SLIDE 20

Justus-Liebig-Universität Gießen 06.12.2016 PANDA collaboration meeting – Darmstadt

  • Markus Moritz-

Schedules

20

slide-21
SLIDE 21

Justus-Liebig-Universität Gießen 06.12.2016 PANDA collaboration meeting – Darmstadt

  • Markus Moritz-

Conclusion / Summary

  • Module assembly:
  • 2/3 of all modules already assembled
  • APD throughput delayed the module assembly

schedule.

  • Still 500 APDs needed.
  • Slice assembly:
  • Workspace and Tools will be ready for slice

assembly before Christmas

  • Fiber coupling will be tested soon
  • Delivery date of needed ASICs and flex PCBs

so far unknown

  • Cooling concept has to be developed

21

slide-22
SLIDE 22

Justus-Liebig-Universität Gießen 06.12.2016 PANDA collaboration meeting – Darmstadt

  • Markus Moritz-

Backup - Schedules last cm-

22

slide-23
SLIDE 23

Justus-Liebig-Universität Gießen 06.12.2016 PANDA collaboration meeting – Darmstadt

  • Markus Moritz-

Backup

23
