Predicting missing values in spatio-temporal satellite data - - PowerPoint PPT Presentation

Reinhard Furrer, I-Math/ICS, UZH ISNPS2018, Salerno, 2018/06/14

NZZ.ch

Predicting missing values in spatio-temporal satellite data

2

Joint work ◮ Florian Gerber ◮ Emilio Porcu

and with contributions of several others

Arctic NDVI

3

NDVI = NIR − R NIR + R

Why do we care?

4

Scientifically: ◮ Complex interplay between climate and vegetation/ecosystems ◮ Reflectance measurements as proxy for “greenness”

Why do we care?

5

Scientifically: ◮ Complex interplay between climate and vegetation/ecosystems ◮ Reflectance measurements as proxy for “greenness” Statistically: ◮ Large, spatio-temporal datasets with complex structures at low resolution ◮ . . . many missing values

• Imperfect “products”

Basic, classical kriging

6

Cov(pred, data) · Var(data)−1 · data = Σpred,data Σ−1

data y

◮ “Simple” spatial interpolation . . . . . . on paper or in class! ◮ Flexible models for covariances are required ◮ Computational limits are quickly attained

Flexible models

7

Space-time covariance functions on the sphere: ◮ Spectral representations/stochastic expansions ◮ Scale mixture representations ◮ Lagrangian framework See: Jeong, Jun, Genton, StatSci 2017 Porcu, Alegria, F, ISR 2018

Computational limits

8

Reduce “problem size” See Heaton et al, arXiv:1710.05013 ◮ enforce sparsity (‘misspecification’, tapering, . . . ) ◮ Use R’s long vector support spam64 (64-bit with tailored packages for type conversions between front-end R and pre-compiled code) See Gerber, M¨

• singer, F, CaGeo 2017; . . .

Arctic NDVI data

9

MODIS NDIV data (satellite product MOD13A1)

Kriging is smoothing

10

Kriging is smoothing

10

Interpolation using gapfill

11

Interpolation using gapfill

12

145 161 177 193 2004 2005 2006 2007

Day of the year

0.2 0.4 0.6 0.8

NDVI

gapfill: ranking of the images

13

r = 1 2 3 4 5 6 7 8 9 10 11 12

• 161

177 193 2004 2005 2006 2007

Day of the year Year

0.2 0.4 0.6 0.8

NDVI

low high

gapfill: quantile regression

14

Date: 193 doy 2004 177 doy 2006 177 doy 2005 193 doy 2006 193 doy 2005 Score: 0.65 0.71 0.77 0.88 0.91 Rank: 8 9 10 11 12 ˆ q: NA 0.64 NA 0.12 0.77

gapfill: prediction uncertainties

15

145 161 177 193 2004 2005 2006 2007

Day of the year Year

0.2 0.4 0.6 0.8

NDVI

145 161 177 193 2004 2005 2006 2007

Day of the year Year

0.2 0.4 0.6 0.8

interval length

data and predictions uncertainties

gapfill: location

16

gapfill: comparison

17 RMSE ×103

gapfill: uncertainties

18 (l) Uncertainty contribution from the indicated four steps of the gapfill procedure. (m) Average width of the 90% prediction intervals (40% missing values). (r) Average interval widths and coverage rate per day of the year.

Summary

19

Implementation: spam64

gapfill

Intuition: statistical conceptual Model: frequentist based distribution free Uncertainties: formal resampling type Practicality: play ground competitive

20

Collaboration with: – Emilio Porcu – Alfredo Alegria – Florian Gerber – Kaspar M¨

• singer

– former & present ‘Applied Statistics’ team . . . and many more URPP Global Change and Biodiversity 143282, 144973, 175529

References (some, alphabetical)

21 Furrer Sain (2010) spam: A sparse matrix R package with emphasis on MCMC methods for Gaussian Markov random fields JSS 36 1–25 Furrer et al (2017) spam: Sparse Matrix algebra. R package version 2.2-0 Furrer et al (2017) spam64: 64-Bit Extension of the SPArse Matrix R Package ’spam’. R package version 2.2-0 Gerber Moesinger Furrer (2017) Extending R Packages to Support 64-bit Compiled Code: An Illustration with spam64 and GIMMS NDVI3g Data Comput Geosci 104 109-119 Gerber et al (2018) Predicting Missing Values in Spatio-Temporal Remote Sensing

• Data. IEEE TGRS 56(5) 2841-2853

Gerber Moesinger Furrer (2017) dotCall64: An Efficient Interface to Compiled C/C++ and Fortran Code Supporting Long Vectors arXiv:1702.08188 Heaton et al (2017) A Case Study Competition among Methods for Analyzing Large Spatial Data arXiv:1710.05013 Porcu Alegria Furrer (2018) Modeling Temporally Evolving and Spatially Globally Dependent Data International Statistical Review first published.

Appendix

22

Goals and concepts

23

How to efficiently extend an R package for 64-bit use? ◮ EASY on maintainer: We do not want to re write source code! ◮ EASY on user: no loss for classical use (speed, complexity, . . . ) minimal effort for ‘expert’ use Illustrated here with use of .Fortran or .C calls (aka Foreign Function Interface).

Implementation dotCall64

24

◮ choose 32-bit or 64-bit compiled code accordingly ◮ exploit DUP=FALSE use dotCall64

R function dotCall64 Compiled code 32-bit compiled code 64-bit compiled code Input Preprocess Postprocess Output Use 64-bit?

Implementation spam64

25

◮ choose 32-bit or 64-bit compiled code accordingly ◮ exploit DUP=FALSE use ◮ spam64 is ‘sed‘ed out of spam ◮ .Fortran − → dotCall64::.C64

Illustration

26

◮ residual field from AVHRR NDVI3g product: y = y2000−2009 − y1990−1999, n = 769, 940 observations ◮ Nonstationary Gaussian random field (zero mean)

Nonstationary covariance matrix

27

Σ(κ, β, τ) = κ D(β)

• (1 − τ)I + τR
• D(β)

◮ κ > 0: scaling parameter ◮ D(β) = diag(exp(Xβ)): controls strength via covariates ◮ τ ∈ [0, 1]: “no spatial correlation” vs “spatial correlation” ◮ I: identity matrix ◮ R: stationary correlation matrix: – compactly supported covariance – range 50km, sparsity 0.2%

Optimization

28

◮ Fast is relative . . . optim suboptimal Task Function Time Sparsity Distances h <- nearest.dist(...) 23min 1.4 Gb 0.2o /

• Covariances

T <- cov.Wend(h, ...) 2min 1.4 Gb 0.2o /

• Cholesky

chol(T, ...) 29min 8.5 Gb 1.9o /

• o (64-bit)

◮ optimization strategy: – (iterative) grid search over τ exploit multicore architecture – for given τ use quasi-Newton optimizer to optimize κ, β

Nonstationary covariance matrix

29

◮ with covariates “distance to nearest coast” and “elevation” ◮ diag(

Σ):

◮ BIC improvement (1%) compared to nonstationary model

. . . but not sufficiently flexible ◭
