Polymeric Insulator Materials for HVDC: Important Properties, Test Methods & Challenges for Standardization

JENS SEIFERT

The fascination of solutions

lappinsulators.com

Mini Conference 9

Polymeric Insulator Materials for HVDC: Important Properties, Test Methods & Challenges for Standardization

Jens M. Seifert Lapp Insulators, BU LIKE GERMANY

The fascination of solutions

lappinsulators.com

Results of D1.27 Brochure No. 611 “DC Tracking & Erosion Test”

DC vs. AC Test Voltage Idea: Development Approach based on IEC 60587 “Inclined Plane Test”

The fascination of solutions

lappinsulators.com

Development Approach based on IEC 60587 “Inclined Plane Test””

mass loss, erosion depth, erosion length

The fascination of solutions

lappinsulators.com

Investigation of Electrode Shape and Quality:

Development Approach based on IEC 60587 “Inclined Plane Test””

The fascination of solutions

lappinsulators.com

Development Approach based on IEC 60587 “Inclined Plane Test”

Investigation of Electrolyte Flow Rate:

The fascination of solutions

lappinsulators.com

Development Approach based on IEC 60587 “Inclined Plane Test”

Investigation of Corrosion Effects (Electrodes): 0.05 g dissolved Fe2+ by 180 C charge (Coulomb‘s law) simulated by adding to the eletrcolyte:

The fascination of solutions

lappinsulators.com

Development Approach based on IEC 60587 “Inclined Plane Test”

Round Robin Test (Specification):

The fascination of solutions

lappinsulators.com

Development Approach based on IEC 60587 “Inclined Plane Test”

Round Robin Test Results „PASS/FAIL“:

The fascination of solutions

lappinsulators.com

Development Approach based on IEC 60587 “Inclined Plane Test”

RRT Results: „EROSION DEPTH“

The fascination of solutions

lappinsulators.com

Comparison of „TEST SEVERITY“:

The fascination of solutions

lappinsulators.com

DC-IPT as investigated can not be recommended for the base of an IEC standard CONCLUSIONS:

The fascination of solutions

lappinsulators.com

Retention of Hydrophobicity – Why is this property important?

HC=1

HC=1 HC=6

The fascination of solutions

lappinsulators.com

Retention of Hydrophobicity - “Dynamic Drop Test (DDT)” (Electra 272/03)"

The fascination of solutions

lappinsulators.com

Retention of Hydrophobicity - “Dynamic Drop Test (DDT)” (Electra 272/03)

Investifation of surface topology: Specification for RRT: RZ = 5µm by means of special moulds and sandblasting Target: Explore and define a surface topology and roughness in order to achieve reasonable time to loss of HY with good reproducibility

The fascination of solutions

lappinsulators.com

Retention of Hydrophobicity - “Dynamic Drop Test (DDT)” (Electra 272/03)

 High Scatter! Results of „explorative“ RRT for AC and DC stress: Weibull 63% Quantilles and 95% CI

The fascination of solutions

lappinsulators.com

• DDT is a promising test method for evaluating the retention of HY
• Different materials and their performances can be distinguished
• Reasonable test parameters for „short time test“ have been defined
• Surface roughness RZ shall be 5 µm by means of sandblasting of moulds
• High scatter in time to failure is still a weak point
• Additional (larger) RRTs shall be conducted with different kinds of materials and 5-10 labs
• The work is continued in D1.58 in order to improve the test specification and test setup

Conclusion and further recommendations:

The fascination of solutions

lappinsulators.com

Applicability and Reference to HVDC Composite Insulators:

Composite Insulators

• Comparison of Laboratory Tests and Field Ageing
• Design and Service Performance Reviews (Case Studies)
• Design & Standardisation Approaches for HVDC (IEC 60815-4)

The fascination of solutions

lappinsulators.com

Applicability and Reference to HVDC Composite Insulators:

Typical Design of Generation III Composite Insulator

In DC applications 250-600 kV for more than 36 years

The fascination of solutions

lappinsulators.com

1000h Salt Fog Testing (CN Std.) D/L T 864 -2004

The fascination of solutions

lappinsulators.com

1000h Salt Fog Testing (CN Std.) D/L T 864 -2004

Well selected materials and designs pass the CN 1000 h std. test

The fascination of solutions

lappinsulators.com

5000h DC Multi-Stress Test

The fascination of solutions

lappinsulators.com

Design Approach AC and DC

CIGRE Technical Brochure No. 518

The fascination of solutions

lappinsulators.com

Design Rules DC

CIGRE Technical Brochure No. 518

Why? Different electro-dynamical Characteristics of partial arcs AC: small p, small s, small s/p DC: large p, large s limited s/p  1.0 Normal distance p1 and p2 Large distance p1 and p2

The fascination of solutions

lappinsulators.com

Design Rules DC

CIGRE Technical Brochure No. 518

AC DC AC: small p, small s, low s/p DC large p, large s limited s/p Normal distance between p1 and p2 larger distance between p1 and p2 NEW IEC 60815-4: Prague 2015 TC 36 WG11

The fascination of solutions

lappinsulators.com

Case #1: 500 kV Pacific Intertie (USA)

36 years very positive experience with HTV Silicone Rubber Composites

Dual pole

The fascination of solutions

lappinsulators.com

Case #1: 500 kV Pacific Intertie (USA) - Design Review

Design Pacific Intertie CD`=25.7 mm/kV

The fascination of solutions

lappinsulators.com

Case #2: 533 kV Cabora Bassa - Apollo (SA) - Design Review

38 years very positive experience with HTV Silicone Composites

2 Mono Poles

The fascination of solutions

lappinsulators.com

Case #2: 533 kV Cabora Bassa - Apollo (SA) - Statistical Design Approach

Re-Insulation 2013: 6800 glass disk strings were exchanged by composites, with CD`=35 mm/kV @ 4700 mm connection length

The fascination of solutions

lappinsulators.com

Pollution Performance Curves

AC DC DC Silicone Composites

?

The fascination of solutions

lappinsulators.com

IEC 60815 Statistical Method based on Pollution Performance Curves

AC DC DC Silicone Composites

?

400 kV HVDC Design for New Lines in Germany High design efficiency, optimum CD` and length selection!

The fascination of solutions

lappinsulators.com

IEC 60815-4 (New) – Emprical Method „HTM“ Non-„HTM“

Based on best practice and correction factors (longer insulators)

The fascination of solutions

lappinsulators.com

Conclusions on DC Material Tests

• Tracking & Erosion Resistance (T&E) and Retention of Hydrophobicity under DC voltage

stress were recognized by CIGRE as important properties for further standardisation

• With the results of a RRT („Feasibility Study“) performed by CIGRE WG D1.27 it is not

recommended to develop a DC T&E test based on the „Inclined Plane Test Method“

• The Dynamic Drop Test (DDT) has been evaluated positively in order to assess the

Retention of Hydrophobicity of polymeric materials

• The DDT method will be further investigated and developed by CIGRE WG D1.58
• Hydrophobicity is a very important property for the performance of DC Insulators

The fascination of solutions

lappinsulators.com

Conclusions on DC Composite Insulators

• No Tracking & Erosion failures have been reported under DC voltage stress in service. Justification of

a T&E DC test is not given from relevance point of view. The results of this material test are not reflecting the positive experiences made in service

• Artifificial Ageing tests (1000 h, 5000 h, wheel test) under DC voltage stress are passed by composite

insulators with good design and well selected materials

• The hydrophobicity has a very positive impact on the life-time and performance of DC composite

insulators

• Very positive long-term service experiences exist with HTV silicone material (>30 years)
• Standardisation of housing profile and CD selection process is almost completed (IEC 60815-4):

Empirical and Statistical Method

The fascination of solutions

lappinsulators.com

The fascination of solutions

lappinsulators.com

for listening
