Pointless fusion for pointwise application

Malcolm Wallace

University of York (soon @ Standard-Chartered Bank)

1 Monday, 15 February

1.000E+003 7.216E+001 7.599E-001 6.937E-005 2.400E-001 3.135E-054 4.936E-079 2.600E-012 1.455E-010 7.263E-015 1.000E+003 7.216E+001 7.599E-001 6.937E-005 2.400E-001 2.410E-054 4.936E-079 2.601E-012 1.456E-010 7.264E-015 1.000E+003 7.216E+001 7.599E-001 6.937E-005 2.400E-001 1.853E-054 4.936E-079 2.601E-012 1.457E-010 7.265E-015 1.000E+003 7.216E+001 7.599E-001 6.937E-005 2.400E-001 1.425E-054 4.936E-079 2.602E-012 1.458E-010 7.266E-015 1.000E+003 7.216E+001 7.599E-001 6.937E-005 2.400E-001 1.095E-054 4.936E-079 2.602E-012 1.459E-010 7.267E-015 1.000E+003 7.216E+001 7.599E-001 6.937E-005 2.400E-001 8.421E-055 4.936E-079 2.602E-012 1.460E-010 7.268E-015 1.000E+003 7.216E+001 7.599E-001 6.937E-005 2.400E-001 6.474E-055 4.936E-079 2.603E-012 1.461E-010 7.269E-015 1.000E+003 7.216E+001 7.599E-001 6.937E-005 2.400E-001 4.977E-055 4.936E-079 2.603E-012 1.462E-010 7.270E-015 1.000E+003 7.216E+001 7.599E-001 6.937E-005 2.400E-001 3.827E-055 4.936E-079 2.604E-012 1.463E-010 7.271E-015 1.000E+003 7.216E+001 7.599E-001 6.937E-005 2.400E-001 2.942E-055 4.936E-079 2.604E-012 1.464E-010 7.272E-015 8.563E+002 2.051E+004 4.180E-004 7.596E-001 5.260E-005 6.898E-002 1.710E-001 8.053E-011 2.686E-013 8.650E-012 8.571E+002 2.050E+004 4.205E-004 7.596E-001 5.546E-005 7.249E-002 1.675E-001 8.104E-011 2.729E-013 8.706E-012 8.581E+002 2.049E+004 4.231E-004 7.596E-001 5.855E-005 7.627E-002 1.637E-001 8.158E-011 2.775E-013 8.764E-012 8.592E+002 2.047E+004 4.258E-004 7.596E-001 6.190E-005 8.037E-002 1.596E-001 8.214E-011 2.823E-013 8.824E-012 8.604E+002 2.046E+004 4.286E-004 7.596E-001 6.555E-005 8.479E-002 1.551E-001 8.274E-011 2.874E-013 8.887E-012 8.619E+002 2.044E+004 4.315E-004 7.596E-001 6.952E-005 8.958E-002 1.504E-001 8.338E-011 2.929E-013 8.952E-012 8.635E+002 2.041E+004 4.346E-004 7.596E-001 7.383E-005 9.474E-002 1.452E-001 8.405E-011 2.988E-013 9.020E-012 8.653E+002 2.039E+004 4.379E-004 7.596E-001 7.851E-005 1.003E-001 1.396E-001 8.477E-011 3.052E-013 9.090E-012 8.674E+002 2.036E+004 4.413E-004 7.596E-001 8.358E-005 1.063E-001 1.336E-001 8.555E-011 3.120E-013 9.164E-012 8.697E+002 2.032E+004 4.450E-004 7.596E-001 8.905E-005 1.127E-001 1.272E-001 8.639E-011 3.194E-013 9.241E-012 8.723E+002 2.028E+004 4.489E-004 7.596E-001 9.495E-005 1.195E-001 1.204E-001 8.729E-011 3.275E-013 9.323E-012 8.752E+002 2.024E+004 4.531E-004 7.595E-001 1.013E-004 1.267E-001 1.132E-001 8.827E-011 3.364E-013 9.408E-012 8.784E+002 2.019E+004 4.576E-004 7.595E-001 1.080E-004 1.343E-001 1.056E-001 8.934E-011 3.461E-013 9.498E-012 8.819E+002 2.013E+004 4.624E-004 7.595E-001 1.151E-004 1.421E-001 9.775E-002 9.049E-011 3.567E-013 9.593E-012 8.857E+002 2.007E+004 4.675E-004 7.595E-001 1.225E-004 1.502E-001 8.966E-002 9.174E-011 3.684E-013 9.692E-012 8.899E+002 2.000E+004 4.730E-004 7.595E-001 1.303E-004 1.584E-001 8.145E-002 9.312E-011 3.813E-013 9.797E-012 8.945E+002 1.992E+004 4.791E-004 7.595E-001 1.382E-004 1.666E-001 7.324E-002 9.465E-011 3.959E-013 9.908E-012 8.994E+002 1.984E+004 4.856E-004 7.595E-001 1.462E-004 1.747E-001 6.518E-002 9.627E-011 4.116E-013 1.002E-011 9.043E+002 1.976E+004 4.923E-004 7.595E-001 1.542E-004 1.824E-001 5.744E-002 9.796E-011 4.283E-013 1.014E-011 9.092E+002 1.967E+004 4.992E-004 7.595E-001 1.619E-004 1.897E-001 5.012E-002 9.972E-011 4.459E-013 1.026E-011 9.140E+002 1.959E+004 5.063E-004 7.595E-001 1.693E-004 1.965E-001 4.335E-002 1.015E-010 4.644E-013 1.038E-011 9.191E+002 1.950E+004 5.138E-004 7.595E-001 1.765E-004 2.027E-001 3.716E-002 1.035E-010 4.846E-013 1.051E-011 9.240E+002 1.942E+004 5.215E-004 7.595E-001 1.831E-004 2.082E-001 3.164E-002 1.054E-010 5.054E-013 1.064E-011 9.286E+002 1.934E+004 5.290E-004 7.595E-001 1.893E-004 2.130E-001 2.678E-002 1.073E-010 5.264E-013 1.076E-011 9.329E+002 1.927E+004 5.365E-004 7.595E-001 1.948E-004 2.172E-001 2.257E-002 1.092E-010 5.477E-013 1.089E-011 9.368E+002 1.920E+004 5.439E-004 7.595E-001 1.998E-004 2.208E-001 1.895E-002 1.111E-010 5.691E-013 1.101E-011 9.406E+002 1.914E+004 5.514E-004 7.594E-001 2.044E-004 2.239E-001 1.588E-002 1.129E-010 5.911E-013 1.113E-011 9.442E+002 1.908E+004 5.590E-004 7.594E-001 2.086E-004 2.265E-001 1.328E-002 1.148E-010 6.137E-013 1.126E-011 9.475E+002 1.903E+004 5.665E-004 7.594E-001 2.124E-004 2.287E-001 1.110E-002 1.166E-010 6.363E-013 1.138E-011 9.506E+002 1.898E+004 5.738E-004 7.594E-001 2.158E-004 2.305E-001 9.281E-003 1.184E-010 6.590E-013 1.151E-011 9.534E+002 1.893E+004 5.811E-004 7.594E-001 2.189E-004 2.320E-001 7.767E-003 1.202E-010 6.818E-013 1.163E-011

An array of numbers

95,946,240,000 x

A LARGE array of numbers

2 Monday, 15 February

Multi-dimensional data

200 x 248 x 248 x 600 x 13

timesteps Z Y X fields fields: pressure temperature density gas motion (vector) H+ ion concentration H2 concentration ...

95,946,240,000 =

3 Monday, 15 February

Flat or structured?

Flat representation: “Virtual” dimensions: x=[0..27] y=[0..21] z=[0..4] i=[0..3079]

4 Monday, 15 February

2D contours

5 Monday, 15 February

2D continuous

6 Monday, 15 February

3D surfaces

7 Monday, 15 February

3D volume

8 Monday, 15 February

3D vectors

9 Monday, 15 February

2D sketchline vectors

10 Monday, 15 February

2D sketchline vectors

11 Monday, 15 February

Animation

12 Monday, 15 February

Overlays

13 Monday, 15 February

Scatterplot

14 Monday, 15 February

Requirements

200 x 248 x 248 x 600 x 13

timesteps Z Y X fields

95,946,240,000 =

• Flat
• Dimensionally-structured numeric data
• Packed
• Close-packing, no boxing
• Large
• Avoid copying, moving, or intermediates
• Affordable
• Good performance is a goal
• minimal traversals
• streaming if possible

15 Monday, 15 February

Observation

Array operations fall into three categories:

• structural manipulation
• slice, sub-range, downsample
• tuple, join, split
• transpose, rotate dimensions
• pointwise computation
• arithmetic
• comparison
• folds
• sums, products

16 Monday, 15 February

Structural fusion

17 Monday, 15 February

Isosurfacing

picture th dataset = isosurface th (mkCell8 (size dataset) (values dataset)) (mkCell8 (size dataset) (locations dataset)) isosurface th samples geom = zipWith (surf_cell th) (stream samples) (stream geom) surf_cell th sample geom = map (surf_geom th sample geom) $ mc_case $ fmap (>th) sample surf_geom th sample geom (v0,v1) = interp (inv_interp th samp_0 samp_1) geom_0 geom_1 where samp_0 = select v0 sample samp_1 = select v1 sample geom_0 = select v0 geom geom_1 = select v1 geom mkCell8 sz v = zipWith8 Cell8 v (drop 1 v) (drop line v) (drop (1+line) v) (drop plane v) (drop (1+plane) v) (drop (plane+line) v) (drop (1+plane+line) v) where line = thd3 size plane = snd3 size

18 Monday, 15 February

Isosurfacing

picture th dataset = isosurface th (mkCell8 (size dataset) (values dataset)) (mkCell8 (size dataset) (locations dataset)) isosurface th samples geom = zipWith (surf_cell th) (stream samples) (stream geom) surf_cell th sample geom = map (surf_geom th sample geom) $ mc_case $ fmap (>th) sample surf_geom th sample geom (v0,v1) = interp (inv_interp th samp_0 samp_1) geom_0 geom_1 where samp_0 = select v0 sample samp_1 = select v1 sample geom_0 = select v0 geom geom_1 = select v1 geom mkCell8 sz v = zipWith8 Cell8 v (drop 1 v) (drop line v) (drop (1+line) v) (drop plane v) (drop (1+plane) v) (drop (plane+line) v) (drop (1+plane+line) v) where line = thd3 size plane = snd3 size

19 Monday, 15 February

Re-structured data

200 x 248 x 248 x 600 x 13

timesteps Z Y X fields [160,162..180] [124] [0,4..247] [0,4..599] [2,7] slice sub-range downsample slices

20 Monday, 15 February

Fusion 1: Structural

slice i (transpose (subrange j k arr))

• riginal array

intermediate arrays result array

21 Monday, 15 February

Represent traversal explicitly

200 x 248 x 248 x 600 x 13

timesteps Z Y X fields

for (t=160; t<=180; t+=2) { z = 124; for (y=0; y<=247; y+=4) { for (x=0; x<=599; x+=4) { for (field `elem` [2,7]) { arr [ t*248*248*600*13 + z*248*600*13 + y*600*13 + x*13 + field ]; } } } }

[160,162..180] [124] [0,4..247] [0,4..599] [2,7] slice sub-range downsample slices varies faster

22 Monday, 15 February

Manipulate traversal order

slice i (transpose (subrange j k arr)) 200 x 248 x [0,4..248] x [0,4..600] x [2,7]

timesteps Z Y X fields

for (t=0; t<=199; t+=1) { for (z=0; z<=247; z+=1) { for (y=0; y<=247; y+=4) { for (x=0; x<=599; x+=4) { for (field `elem` [2,7]) { arr [ t*248*248*600*13 + z*248*600*13 + y*600*13 + x*13 + field ]; } } } } }

23 Monday, 15 February

for (t=j; t<=k; t+=1) { for (z=0; z<=247; z+=1) { for (y=0; y<=247; y+=4) { for (x=0; x<=599; x+=4) { for (field `elem` [2,7]) { arr [ t*248*248*600*13 + z*248*600*13 + y*600*13 + x*13 + field ]; } } } } }

Manipulate traversal order

slice i (transpose (subrange j k arr)) [j..k] x 248 x [0,4..248] x [0,4..600] x [2,7]

timesteps Z Y X fields

24 Monday, 15 February

for (z=0; z<=247; z+=1) { for (t=j; t<=k; t+=1) { for (y=0; y<=247; y+=4) { for (x=0; x<=599; x+=4) { for (field `elem` [2,7]) { arr [ t*248*248*600*13 + z*248*600*13 + y*600*13 + x*13 + field ]; } } } } }

Manipulate traversal order

slice i (transpose (subrange j k arr)) 248 x [j..k] x [0,4..248] x [0,4..600] x [2,7]

Z timesteps Y X fields

25 Monday, 15 February

{ z=i; for (t=j; t<=k; t+=1) { for (y=0; y<=247; y+=4) { for (x=0; x<=599; x+=4) { for (field `elem` [2,7]) { arr [ t*248*248*600*13 + z*248*600*13 + y*600*13 + x*13 + field ]; } } } } }

Manipulate traversal order

slice i (transpose (subrange j k arr)) [i] x [j..k] x [0,4..248] x [0,4..600] x [2,7]

Z timesteps Y X fields

26 Monday, 15 February

Haskell array representation

type Iterator = [ForLoop] data ForLoop = FL { fl_jump :: !Int , fl_count :: Maybe Int } data Block a = Block { block_data :: !(UArr a) , block_start :: !Int , block_steps :: Iterator }

27 Monday, 15 February

Deforestation / fusion

Array operations fall into three categories:

• structural manipulation
• slice, sub-range, downsample
• tuple, join, split
• transpose, rotate dimensions
• pointwise computation
• arithmetic
• comparison
• folds
• sums, products

✓

28 Monday, 15 February

Point-wise fusion

29 Monday, 15 February

Pointwise ops

linear :: Double -> Double -> Double

• > Double -> Double -> Double

linear thresh val0 val1 pos0 pos1 = let interpolant = thresh - val0 / val1 - val0 in pos0 + interpolant * (pos1-pos0)

position: 3.1 5.2 value: 10.5 -4.7 threshold: 6.0 interpolated position?

30 Monday, 15 February

Pointwise ops

linear :: Double -> Double -> Double

• > Vec2 Double -> Vec2 Double -> Vec2 Double

linear thresh val0 val1 pos0 pos1 = let interpolant = thresh - val0 / val1 - val0 in pos0 + interpolant * (pos1-pos0)

position: (3.1,0.2) (5.2,2.8) value: 10.5 -4.7 threshold: 6.0 interpolated position?

31 Monday, 15 February

Pointwise ops

linear :: Double -> Array Double -> Array Double

• > Array (Vec2 Double)
• > Array (Vec2 Double)
• > Array (Vec2 Double)

linear thresh val0 val1 pos0 pos1 = let interpolant = pure thresh - val0 / val1 - val0 in pos0 + interpolant * (pos1-pos0)

position: (3.1,0.2) (5.2,2.8) (7.0,2.5) value: 10.5 -4.7 7.2 interpolated positions

32 Monday, 15 February

Pointwise ops

(+) :: (Num a) => a -> a -> a (+) :: (Num a, Applicative f) => f a -> f a -> f a (+) :: (Num a) => Array a -> Array a -> Array a

33 Monday, 15 February

The Applicative Functor

class Applicative f where pure :: a -> f a (<*>) :: f (a->b) -> f a -> f b (<$>) :: (a->b) -> f a -> f b instance Applicative Array where pure x = newArray x f <$> a = arrayMap f a

The functor f can be: a container, sequence, stream, a parser, pretty-printer ...

34 Monday, 15 February

Applicative Arithmetic

instance (Num a, Applicative f) => Num (f a) where a + b = pure (+) <*> a <*> b a - b = pure (-) <*> a <*> b a * b = pure (*) <*> a <*> b instance (Fractional a, Applicative f) => Fractional (f a) where a / b = pure (/) <*> a <*> b

35 Monday, 15 February

Applicative Arithmetic

instance (Num a, Applicative f) => Num (f a) where a + b = (+) <$> a <*> b a - b = (-) <$> a <*> b a * b = (*) <$> a <*> b instance (Fractional a, Applicative f) => Fractional (f a) where a / b = (/) <$> a <*> b

36 Monday, 15 February

linear thresh val0 val1 pos0 pos1 = let interpolant = pure thresh - val0 / val1 - val0 in pos0 + interpolant * (pos1-pos0)

thr v0 Ap Ap

The need for fusion

(/) Ap Ap (-) v1 v0 Ap Ap (-) Intermediate arrays everywhere!

37 Monday, 15 February

linear thresh val0 val1 pos0 pos1 = let interpolant = pure thresh - val0 / val1 - val0 in pos0 + interpolant * (pos1-pos0)

The outcome of fusion

\thr v0 v1 -> thr-v0/v1-v0 thr v0 v1 Ap Ap Ap We can calculate this. :: Double -> Double -> Double -> Double

38 Monday, 15 February

An explicit expression tree

data Expr c a = Val (c a) | Fun a | forall b . Ap (Expr c (b->a)) (Expr c b) instance (Applicative c) => Applicative (Expr c) where pure a = Val (pure a) f <*> a = Ap f a f <$> a = Ap (Fun f) a

Val Fun Ap

39 Monday, 15 February

Graph transformation: rule 1

Ap Ap

f g a

Ap Ap

f g a

Ap (.) f (g a) => (.) f g a Ap f (Ap g a) => Ap (Ap (Ap (Fun (.)) f) g) a Rule 1: flatten the tree to a single spine

40 Monday, 15 February

Graph transformation: rule 2

Ap

f a

Ap Ap

f a

Ap flip f a g => flip f g a Ap (Ap f a) (Fun g) => Ap (Ap (Ap (Fun flip) f) (Fun g)) a Rule 2: move all functions towards the left Ap g g Warning: not possible for all applicative functors

41 Monday, 15 February

Graph transformation: rule 3

Ap Ap (Fun f) (Fun g) => Fun (f g) Rule 3: reduce applications

• f functions to functions

f g f g

42 Monday, 15 February

a g f

thr v0 Ap Ap

Example: rule 1

(/) Ap Ap (-) v1 v0 Ap Ap (-)

43 Monday, 15 February

a g f

thr v0 Ap Ap

Example: rule 1

(/) Ap (-) v1 v0 Ap (-) Ap (.) Ap Ap

44 Monday, 15 February

a g f

thr v0 Ap Ap

Example: rule 1

(/) Ap (-) v1 v0 Ap (-) Ap (.) Ap Ap

45 Monday, 15 February

f a g

thr v0 Ap Ap

Example: rule 1

(/) Ap (-) v1 v0 (-) Ap (.) Ap Ap Ap Ap (.)

46 Monday, 15 February

f a g

thr v0 Ap Ap

Example: rule 1

(/) Ap (-) v1 v0 (-) Ap (.) Ap Ap Ap Ap (.)

47 Monday, 15 February

Several steps omitted....

48 Monday, 15 February

thr v0

Example: rule 1

(/) (-) v1 v0 (-) (.) Ap Ap Ap (.) Ap Ap Ap Ap Ap Ap Ap Ap Ap (.) (.) (.) (.)

49 Monday, 15 February

thr v0

Example: rule 3

v1 v0 (-) Ap Ap Ap Ap Ap (.) ((.) ((.) ((.) (.) (.)) (/))) (-)

50 Monday, 15 February

f a g

thr v0

Example: rule 2

(/) (-) v1 v0 (-) (.) Ap Ap Ap (.) Ap Ap Ap Ap Ap Ap Ap Ap Ap (.) (.) (.) (.)

51 Monday, 15 February

f a g

thr v0

Example: rule 2

(/) (-) v1 v0 (-) (.) Ap (.) Ap Ap Ap Ap Ap Ap Ap Ap (.) (.) (.) (.) Ap flip Ap Ap Ap

52 Monday, 15 February

f a g

thr v0

back to rule 1

(/) (-) v1 v0 (-) (.) Ap (.) Ap Ap Ap Ap Ap Ap Ap Ap (.) (.) (.) (.) Ap flip Ap Ap Ap

53 Monday, 15 February

Several steps omitted....

54 Monday, 15 February

thr v0

Example: complete

v1 v0 Ap Ap Ap Ap ((((((flip ((.) (flip) ((.) ((.) (.)) ((.) ((.) (.)) ((.) ((.) (/)) (-)))))) (-))) \thr v0 v1v0 -> thr - v0 / v1 - v0

55 Monday, 15 February

Conversion to points-free form

Rule 1: flatten the tree to a single spine Rule 2: move all functions towards the left Rule 3: reduce applications

• f functions to functions

compose flip apply

56 Monday, 15 February

Code for graph reduction

• - | Normal form of an expression tree has a single, unnested, application
• - spine, with a single fused function in the leftmost leaf position.

normalise :: Expr c a -> Expr c a normalise (Val x s) = Val x s normalise (Fun f s) = Fun f s normalise t | allFunctional t = uncurry Fun (reduce t) normalise (Ap f a) = case normalise a of Val b s -> Ap (normalise f) (Val b s) Ap g b -> normalise $ Ap (Ap (Ap (Fun (.) "(.)") f) g) b Fun g s -> case normalise f of Ap f' v -> normalise (Ap (Ap (Ap (Fun flip "flip") f') (Fun g s)) v) f' -> error "normalised function not an Ap"

• - | Reduce takes an expression tree consisting of only Compose and Fun
• - nodes, and collapses it to a single combined function.

reduce :: Expr c a -> (a,String) reduce (Val _ _) = (error "reduce of ground value","bad val") reduce (Fun f s) = (f,s) reduce (Ap f a) = let (f',s) = reduce f (a',t) = reduce a in (f' a', "("++s++" "++t++")")

• - | Does the expression tree consist solely of Fun, Compose, and Flip nodes?

allFunctional :: Expr c a -> Bool allFunctional (Val _ _) = False allFunctional (Fun _ _) = True allFunctional (Ap f a) = allFunctional f && allFunctional a

57 Monday, 15 February

Deforestation / fusion

Array operations fall into three categories:

• structural manipulation
• slice, sub-range, downsample
• tuple, join, split
• transpose, rotate dimensions
• pointwise computation
• arithmetic
• comparison
• folds
• sums, products

✓ ✓

58 Monday, 15 February

Conclusions

• Arbitrary expression trees of structural and pointwise
• perations can be fused into a single zipWith-like

function.

• The fused expression is akin to the numerical

“kernel” one can write (by hand) in CUDA for a GPGPU.

• Hence also suitable for SIMD, multicore, etc.
• Applicative functors are cool.

59 Monday, 15 February
