Platte to Park Hill: Stormwater Systems March 2016 Topics Project Need Open Channel Detention Options (Cole, City Park Golf Course) Park Hill Detention Globeville Landing Outfall Funding, Timing & Next Steps

slide-1
SLIDE 1

Platte to Park Hill: Stormwater Systems

March 2016

slide-2
SLIDE 2
  • Project Need
  • Open Channel
  • Detention Options (Cole, City Park Golf Course)
  • Park Hill Detention
  • Globeville Landing Outfall
  • Funding, Timing & Next Steps

Topics

slide-3
SLIDE 3

PROJECT NEED

slide-4
SLIDE 4

36th & High, 2011

Project Need

slide-5
SLIDE 5

Natural Drainage Patterns

slide-6
SLIDE 6

Existing Pipes

7

slide-7
SLIDE 7

Priority Areas

8

slide-8
SLIDE 8

Priority Areas

9

slide-9
SLIDE 9

Open Drainage Channel

10

slide-10
SLIDE 10

Example: Harvard Gulch

slide-11
SLIDE 11

Basin Low Areas

12

slide-12
SLIDE 12

Detention Option 1: Cole

slide-13
SLIDE 13

Example: Crestmoor Park

slide-14
SLIDE 14

Detention Option 2: City Park Golf Course

slide-15
SLIDE 15

Example: Lakewood Golf Course

slide-16
SLIDE 16

Hole 1 2 3 4 5 6 7 8 9 Total 10 11 12 13 14 15 16 17 18 Total Par 4 4 5 3 4 4 3 4 4 35 5 5 3 4 4 4 3 5 4 37

PAR 72

City Park Golf Course: Feasibility Study Option 1

DRAFT

slide-17
SLIDE 17

City Park Golf Course: Feasibility Study Option 1

slide-18
SLIDE 18

5-year storm (DRAFT)

City Park Golf Course: Feasibility Study Option 1

slide-19
SLIDE 19

City Park Golf Course: Feasibility Study Option 1

10-year storm (DRAFT)

slide-20
SLIDE 20

City Park Golf Course: Feasibility Study Option 1

100-year storm (DRAFT)

slide-21
SLIDE 21

Hole 1 2 3 4 5 6 7 8 9 Total 10 11 12 13 14 15 16 17 18 Total Par 4 4 3 4 4 3 5 3 5 35 4 3 4 4 4 5 4 3 4 35

PAR 70

City Park Golf Course: Feasibility Study Option 2

DRAFT

slide-22
SLIDE 22

City Park Golf Course: Feasibility Study Option 2

slide-23
SLIDE 23

City Park Golf Course: Feasibility Study Option 2

5-year storm (DRAFT)

slide-24
SLIDE 24

City Park Golf Course: Feasibility Study Option 2

10-year storm (DRAFT)

slide-25
SLIDE 25

City Park Golf Course: Feasibility Study Option 2

100-year storm (DRAFT)

slide-26
SLIDE 26

Hole 1 2 3 4 5 6 7 8 9 Total 10 11 12 13 14 15 16 17 18 Total Par 4 4 4 4 3 5 3 4 4 35 4 4 3 4 5 4 4 3 4 35

PAR 70

City Park Golf Course: Feasibility Study Option 3

DRAFT

slide-27
SLIDE 27

City Park Golf Course: Feasibility Study Option 3

slide-28
SLIDE 28

City Park Golf Course: Feasibility Study Option 3

5-year storm (DRAFT)

slide-29
SLIDE 29

City Park Golf Course: Feasibility Study Option 3

10-year storm (DRAFT)

slide-30
SLIDE 30

City Park Golf Course: Feasibility Study Option 3

100-year storm (DRAFT)

slide-31
SLIDE 31

153 trees impacted out of 872 Of the trees impacted, 47% of them are under 12” diameter and 5% of them are 36”+ diameter

Tree Impacts: Option 1

DRAFT

slide-32
SLIDE 32

Tree Impacts: Option 2

280 trees impacted out of 872 Of the trees impacted, 49% of them are under 12” diameter and 4% of them are 36”+ diameter DRAFT

slide-33
SLIDE 33

Tree Impacts: Option 3

246 trees impacted out of 872 Of the trees impacted, 49% of them are under 12” diameter and 5% of them are 36”+ diameter DRAFT

slide-34
SLIDE 34

Cole Detention City Park Golf Course Detention

Two Detention Location Options

slide-35
SLIDE 35

Areas of Reduced Flooding

slide-36
SLIDE 36

PARK HILL BASIN

slide-37
SLIDE 37

Park Hill Detention

38

slide-38
SLIDE 38

Park Hill Detention

39

slide-39
SLIDE 39

Alternative Pipe Alignments

40

slide-40
SLIDE 40

GLOBEVILLE LANDING OUTFALL

slide-41
SLIDE 41

Globeville Landing Outfall

42

slide-42
SLIDE 42

Globeville Landing Outfall

  • New outfall

(with existing)

  • Natural open

channel

  • Incorporating

water quality

  • Opportunity to

re-envision park and uses Existing Outfall New Outfall

slide-43
SLIDE 43

FUNDING, TIMING & NEXT STEPS

slide-44
SLIDE 44

Funding for Citywide Stormwater Projects

  • Denver pays for stormwater and drainage projects

through wastewater fees and through partnerships when feasible

  • Four types of stormwater projects:

– Citywide storm improvements – Major basin projects – Urban waterways (gulches) – Water quality

  • Over the last 20 years, Denver has only had 2

stormwater rate increases

  • City Council is scheduled to hear full proposal for rate

increase in spring 2016

slide-45
SLIDE 45

Funding for Platte to Park Hill

  • Platte to Park Hill: Stormwater Systems will be
  • ne of many projects paid for through

wastewater fees

  • Other funding partners may include:

– Urban Drainage and Flood Control District – CDOT – RTD

slide-46
SLIDE 46

Overall Timeline

Fall/ Winter 2015 Spring 2016 Summer/Fall 2016 Late 2016 2017 2018 2019

Montclair/Park Hill Basin Conceptual Planning Montclair/Park Hill Preliminary Design

Montclair/Park Hill Basin

  • perational

Globeville Landing Outfall Construction Montclair/Park Hill Basin Construction

Globeville Landing Outfall

  • perational

Globeville Landing Outfall Conceptual Planning and Preliminary Design

slide-47
SLIDE 47

Preliminary Construction Timeline

  • Globeville Landing Outfall construction

– Begin 2016, complete by 2017

  • Open Channel

– Begin 2017, complete by 2018

  • Cole or City Park Golf Course Detention

construction

– Begin 2017, complete by 2018

  • Park Hill Detention & Pipe construction

– Begin 2018, complete 2019

slide-48
SLIDE 48

Next Steps

  • Extending the public comment window
  • Ramping up community outreach between now and

the selection of the preferred option

  • Project updates, website, small community

meetings

  • Further refinement of the draft options based on

additional input

  • Announcement of preferred option in early April
slide-49
SLIDE 49

ADDITIONAL INFORMATION

slide-50
SLIDE 50

2014 Storm Drainage Master Plan

  • Citywide planning tool that identifies basic

stormwater needs

  • Master Plan identifies and prioritizes projects, which

consist of pipes that meet 5-year storm criteria

  • Platte to Park Hill was not included in the master

plan because it solves the 100-year event

  • Modeling for Platte to Park Hill area indicated a

need to consider higher level of criteria (100-year) due to high flood risk

slide-51
SLIDE 51

Thank You

Visit the project website at: http://denvergov.org/PlattetoParkHill
