Planning application 02/12/0637 Increase in the height of 5 biofilter exhaust stacks from 12.65m to 25m at Thornton Waste Technology Park, Enterprise Road, Thornton Technology Park, Enterprise Road, Thornton

Planning application 02/12/0637 Site location

Boundary of Thornton Waste Technology Park Existing Stacks Residential properties – estate under construction Residential properties on Dallam Dell

Planning application 02/12/0637 Aerial View – Waste Technology Park (July 2010)

Planning application 02/12/0637 Site Layout Plan

OGM building Percolation / Biogas Building Location of the 5 existing stacks proposed to be increased in height from 12.65m – 25m Green waste compost building Waste Transfer Separation / HHRW Building

Planning application 02/12/0637 – Site elevations

North South East West

Planning application 02/12/0637 – stack elevations

Proposed stack height – 25m Adjacent building Existing stack height – 12.5m

Planning application 02/12/0637 Conceptual images

View from Public Rights of Way (PROW) footpath looking southwest

Planning application 02/12/0637 Conceptual images

View from B5628 Fleetwood Road looking east

Planning application 02/12/0637 Conceptual images

View from Public Open Space along Bourne Way looking north east

Planning application 02/12/0637 Conceptual images

View from Bourne Road looking north

Planning application 02/12/0637 Temporary stack at Leyland WTP (for illustrative purposes)

Temporary stack – approx 20m high
