Php

Web-based applications: main elements

HTTP PROTOCOL CLIENT SIDE SERVER SIDE

HTTP request

• An HTTP request consists of: a request method (verb), resource URL,

header fields (metadata), body (data)

• HTTP 1.1 defines 9 request methods, among which:
• GET: Retrieves the resource identified by the request URL
• HEAD: Returns the headers identified by the request URL

POST: Sends data of unlimited length to the Web server

• POST: Sends data of unlimited length to the Web server
• PUT: Stores a resource under the request URL
• DELETE: Removes the resource identified by the request URL
• HTTP 1.0 includes only the GET, HEAD, and POST methods.

HTTP response

• An HTTP response contains a result code, header fields, and a body.
• Some commonly used status codes include:
• 100: Continue
• 200: OK
• 401: the request requires HTTP authentication
• 404: the requested resource is not available
• 404: the requested resource is not available
• 500: an error occurred inside the HTTP server that prevented it from
• fulfilling the request
• 503: the HTTP server is temporarily overloaded and unable to handle the

request

• For detailed information on this protocol, see the Internet RFCs: HTTP/1.0

(RFC 1945), HTTP/1.1 (RFC 2616). (http://www.rfc-editor.org/rfc.html)

Example

Example

HTTP is ‘stateless’

• Although HTTP uses the TCP protocol, it has no notion of end-

user

• For example, filling in data through multi-page forms requires

the server to keep track of which client is requesting the page.

First Name: Second Name: …. Location:

• --:

….

First step Second step

Static web pages

HTTP PROTOCOL

• Content is pre-determined
• Web pages are static

HTTP PROTOCOL Content

Sequence diagram

BROWSER HTTPD Get URL

FILE

Get html file

FILE SYSTEM

Send html file Render html

Dynamic web pages

• Content of a page is not static
• Page content is changes based on:

– User input, form completion,etc. Database interaction – Database interaction – External data sources (db, service provider)

• Server side techniques
• Client side techniques

Technique overview

• Server side

– CGI (Common Gateway Interface)

• An http request triggers the execution of an independent program
• Data passed via standard input or environment variables

– Script

code executed inside the server process

• code executed inside the server process
• Interleaved with html code (php)
• Confined into a different page (code behind, e.g., ASP.NET)
• Client Side

– Script

• Source code passed from the server and executed by the browser

– Compiled code

• Applet (no longer used…)

• BROWSER

HTTPD Get URL Send html file CGI-process Execute program Build html on-the-fly

FILE SYSTEM

Read/Write data Client sends the request along with data (e.g., from a form) The server lunches a process and transmits data input to the program The program writes a html page The web server sends the page back to the client Send html file Render html Build html on-the-fly

SYSTEM

• BROWSER

HTTPD Get URL Send html file CGI-process Execute program Build html on-the-fly Query DB Send html file Render html Build html on-the-fly

• HTTPD

CGI PROCESS CGI

FILE SYSTEM

• round-trip time

HTTPD CGI PROCESS CGI

FILE SYSTEM

One process per request

• round-trip time

HTTPD + functions..

FILE SYSTEM

Integrate the functionality as an additional module of the server process… (script)

• Make the browser ‘smart’

(execute code or script) HTTPD + functions..

FILE SYSTEM

Integrate the functionality as an additional module of the server process… (script)

• WEB SERVER

SCRIPT

html document

SCRIPT

Script engine WEB Client HTTP

• Pages are generated by a program
• A html document at the server side includes the code to be

executed (script)

• The code is delimited via special escape characters
• The web server extracts the script part from the document
• A script engine runs the code
• Web server replaces the script with the output of the

execution

• Client sees pure html (no way to access the code)

Script engine

Principle of Active Server Page

• Code behind
• 2 files

– Standard html file + custom web control Code behind file (handler code for events) – Code behind file (handler code for events)

• We see later on

• Web Client

Script engine

• html document at the client side contains the code to be

executed

• The code is delimited via special escape characters
• The client extracts the script part from the document
• Executes the code
• It can perform computation, remote communication, change

the rendering of a document

• It can access local events (mouse events,..)

Script engine

Client-side vs server-side

• Client-side

– Minimal processing on the server. Server sends web page with embedded script. Client browser executes the script executes the script – Client browser may not fully support, or script execution turned off – Security issue (user can see the script)

Client-side vs server-side

• Server-side

– Easier to create large-scale site. Create a small set

• f dynamic pages

– Poor coding programmer may open resources to – Poor coding programmer may open resources to attack through security flaws

Introduction to PHP

• Scripting language
• Server side execution

Code is scattered inside a html document – Code is scattered inside a html document – The web server executes the code and produces a simple html page.

PHP code embedding

• !"#$!%

& & !"#$!' &

• !

" # ! short_open_tags INI option;

PHP code embedding

• !"#$!%

&

• !"#$!%

"#$

• &

!"#$!' &

• $%!

%&" # ! short_open_tags INI option;

• 1.1.php

Variables

• A variable always starts with the dollar sign $

– $a – $A – $1 (not allowed)

• Identifiers are case sensitive (not when referring to function)

Variable and function can have the same name!

• Variable and function can have the same name!

Types

• Basic types like in other programming languages

– Boolean, Integer, Floating Point, Object,

• Main difference concerns:

– string (regular expression,…)

• single quoted (variables are not replaced with their values)

double quoted (variables are replaced with their values)

• double quoted (variables are replaced with their values)
• here-doc

– array (associative arrays)

• Other types:

– null

• No type associated yet

– resource

• Generic type, e.g. the result of a query

Types

• PHP uses a Weakly Typed System
• variables’ type is not declared
• PHP automatically converts the variable to the correct data

type, depending on how they are set

• $integer=10

$integer=10

• $float = 10.0
• $string = “10”

Some example

• !"#"

$$ %& '

echo statement

• Placing a variable outside quotes outputs the variable’s value

(line 2)

• Single quote ' sends literal string output (line 3), no variable

value substitution

• Double quote “ sends variable value (line 4)
• Double quote “ sends variable value (line 4)

<?php $a=6; echo $a; echo 'The var name is $a'; echo "The var contains $a"; ?> Note: no declaration (line 1) 1 2 3 4 1.2.php

echo statement

• To achieve newlines in browser, use appropriate

tagging

• Use \ to escape (negate) the effect of the following

character character

<?php $a=6; echo $a; echo 'The var name is $a'. '<br>'; echo "The var contains $a"; ?> <?php echo "She said, \"How are you?\""; echo "<a href=\"page.htm\">link</a>"; ?> 1.3.php 1.4.php

print_r()

• print_r() can be used to "dump" variable
• utput, typically for debugging of complex

structures.

<?php echo "<pre>"; print_r($_SERVER); echo "</pre>"; ?>

Comments

• Multi-line comments

/* This is a multi-line comment */

• Single line comments

// This single line is commented // This single line is commented # So is this single line

– PHP comments are distinct from HTML comments in that PHP comments are not sent to the client browser.

Constant

• Unchangeable values. In all caps by convention. No $.

<?php define('MYCONST',100); define('NAME',"My Name");

• To output, must list constant name outside of ' and ".
• echo "Hello, ".NAME;
• Predefined system constants also exist.
• To see a complete list:

print_r(get_defined_constants())

define('NAME',"My Name"); ?>

Variable’s scope

• Names inside a function has local scope
• Script level names can be accessed through the special built-

in array $GLOBALS

$m

main script

$a is only visible in the function Af’s scope $m can be seen via GLOBALS[‘m’] $a $m

function Af function Bf main script

$b $b is only visible in the function Bf’s scope $a is not visible $m can be seen via GLOBALS[‘m’]

Predefined System "Superglobals"

• Provide access to key runtime data elements.
• Set by and managed through web server run-

time environment and available to the script. Superglobals are key to form processing,

• Superglobals are key to form processing,

cookies, and other techniques.

Some Superglobals

• $_GET[ ]. An array that includes all the GET variables that PHP

received from the client browser.

• $_POST[ ]. An array that includes all the POST variables that

PHP received from the client browser.

• $_COOKIE[ ]. An array that includes all the cookies that PHP

received from the client browser.

• $_SERVER[ ]. An array with the values of the web-server

variables.

Example

• What’s this code doing?

<?php echo '<pre>'; print_r($GLOBALS); print_r($GLOBALS); echo '</pre>'; ?>

Managing variables

• isset ()

– determines whether a certain variable has already been declared by PHP.

• unset()

– “undeclares” a previously set variable, and frees any memory that was used by it if no other variable references its value.

• empty ()

– empty() may be used to check if a variable has not been declared or its value is false.

Example

<?php $user = (isset($_GET[‘user’]))? $_GET[‘user’]: ‘’; … ?>

Operators

• +, -, *, /, %, ++, -- same as other languages
• Combining above with = for assignment can be

done:

• +=, -=, *=, /=, %=, .=

+=, -=, *=, /=, %=, .=

• Two Comparison operators
• == (performs type conversion)
• === (no type conversion)
• ‘1’==1 true
• ‘1’===1 false

Variable variables

<?php $name = "John"; $$name = "Registered user"; print $John; //display “Registered user” ?> ?> John $name Registered user $$name (=$John)

Conditional control structures

( ( (

• )

( ) (

• )
• (

) (

• <?php if ($num < 0): ?>

<h1>$num is negative</h1> <?php elseif($num == 0): ?> <h1>$num is zero</h1> <?php else: ?> <h1>$num is positive</h1> <?php endif; ?> if ($num<0) print '<h1>$num is negative</h1>'; elseif ($num==0) print '<h1>$num is zero</h1>'; else print '<h1>$num is positive</h1>';

Traditional loop control structures

#% ( #% ) ( #%

• #%

& & " " * !* !+* !* !+* !* !+ ( ( for ($i = 0; $i <= count($array); $i++) { } $count = count($array); for ($i = 0; $i <= $count; $i++) { }

'

• '
• (

–

• )
• *#
• #)
• #

– +,

, " --(-*-."-(-/0,/ , " --(-*-."-(-/1(,/,/ 1() , " -*-(-(-/,/ 2() , " -*-(-(-/,/,/

• , " -"(-(-3"(-."--/,/

4%.&) , " -%&*-(-.%-."-5&-/,/ 4%.) , " -%&*-(-.%-."-6-/,/

'#

,((- "-- % -$--/

# . (%( % )% %(7(89(59*(9.%5&93"( %

#

, --/

• #

,/#!,/ ,/#!:,/ ,/ ,/ ,/ ,/ ,/ ,/#:!,/ ,/#:!:,/

Exercise

• Write a simple php program that displays the

Pitagora’s table. The size of the table is a parameter passed through a form..

Processing data form

html FORM Collects information PHP Script Send data PHP Script (form processing) DB access Send .html back html output

• f results

Creating a form

• Key elements:

– Input fields must be contained inside a form tag. – All input fields must have a name. – Names cannot have spaces in them. Fields should be – Names cannot have spaces in them. Fields should be named well for clear identification.

• Form action should be URL to PHP processing

script.

• Appropriate form transmission method selected:

– GET or POST.

GET vs POST

• Name/value pairs appended in clear text to the URL of

the receiving page/script.

• Each name/value pair separated by '&'. Value data

automatically URL encoded.

• Names are taken from the form field names.

Names are taken from the form field names.

• GET URLs can be saved, bookmarked, etc. and used to

recall the script with the same data.

• GET strings provide 'transparency' that may/may not

be desired.

• Long GET strings may be problematic.
• Data available into the $_GET superglobal

GET vs POST

• Data is encoded in the page request body sent by the

browser, but not shown in the URL. Unseen to user.

• Since data not part of URL, bookmarking and reusing

URL to recall the script with the same data is not URL to recall the script with the same data is not possible.

• Large POST packets not a problem.
• On most browsers, hitting 'refresh' causes post data

to be retransmitted.

• Data available into the $_POST superglobal

)

,%(/ ,%/,/;,/,%/ ,/ ,%/;,%/ $(!!(! )! ,/ ,/ ,/<=(),/,/*+(,-,(,,,/,/ ,/ ,/<=(),/,/*+(,-,(,,,/,/ ,/ ,/1(),/,/, " >*>(>$(>/,/ ,/ ,/ ,/2(),/,/, " >*>(>$(>/,/,/ ,/ ,/?#),/,/*+(, $,(, $, ,/,/ ,/ , >:>/*+(, *.,(, ,/*(,0 ,,/,/ ,/

• ,/

,%(/

)

,%(/ ,%/,/;,/,%/ ,/ ,%/;,%/ $(!!(! )! ,/ ,/ ,/<=(),/,/*+(,-,(,,,/,/

• ,/

,/<=(),/,/*+(,-,(,,,/,/ ,/ ,/1(),/,/, " >*>(>$(>/,/ ,/ ,/ ,/2(),/,/, " >*>(>$(>/,/,/ ,/ ,/?#),/,/*+(, $,(, $, ,/,/ ,/ , >:>/*+(, *.,(, ,/*(,0 ,,/,/ ,/

• ,/

,%(/

http://localhost/register.php?email=PSD&first_name=Piattaforme&last_name=SW&password=Pippo&register=Register

key value

Input validation

• Never assume a form:

– is filled out completely – Contains the type of information requested – Has been submitted by a benign user Has been submitted by a benign user – Only contains the fields and values or value ranges expected

• Check all form data to verify that it is

complete and valid …

• … and secure!

Input validation

• Required Fields are filled
• Type is correct
• Length is ‘reasonable’
• Structure adhere to a scheme
• Structure adhere to a scheme

– Regular expression – Check consistency

• No malicious data

– SQL injection – Cross-site scripting

Helpful form validation functions

• Functions exist for testing data types:
• is_numeric($x), etc.,.
• isset($var)

does $var exist? – does $var exist?

• empty($var)

– returns false unless $var contains an empty string, 0, "0", NULL, or FALSE.

Example

• How to check if first name is

correct?

$fn= $_GET[‘first_name’]; if (empty($fn]) || !isnumeric($fn) || strlen ($fn)<3 || strlen ($fn)>10) die(“Not valid data…”);

Other tricky checks

• Radio buttons and check box may not be set

$ if !(isset($_GET[‘gender'])) && ($_GET[‘gender’]==‘Male’ || $_GET[‘gender’]==‘Famale’)): die(“…”)

• Even if the number of options are known, check the actual

value is a best practice… why?

Other tricky checks

• Suppose you are designing a guest book, or a

survey where people tell their impression

'<script language='Javascript'>alert('ALLARM!');</script>'

User authentication: naïve approach

<h1>Login</h1> <form method=“get" action="login.php"> <table> <tr> <td>User name:</td> <td> <input type='text' name=‘user'/></td> </tr> <tr> <td>Password:</td> <td> <input type='password' name=‘pwd'/></td> </tr> ..

<?php $query=“SELECT login_id FROM users WHERE users=‘$user’ AND pwd=‘$pwd’ ”; $ans = mysql_query($query) .. ?>

.. </table> </form>

http://example.com/login?user=pippo&pwd=pippo

SQL injection

• Exploiting an application that takes data from user input and

uses it to form an SQL query without proper "sanitation".

• Let consider this…

# starts a comment

http://example.com/login?user=admin’;# $query=“SELECT login_id FROM users WHERE users=‘$user’ AND pwd=‘$pwd’ ”; $query=“SELECT login_id FROM users WHERE users=‘admin’; # AND pwd=‘’ ”;

# starts a comment

Preventing

• Every time you give user chance to enter data, you MUST

check to be sure not trying to manipulate your application. Create and use a clean() function like this

function clean($input, $maxlength) { $input = trim($input) $input = substr($input,0,$maxlength); $input = substr($input,0,$maxlength); $input = escapeShellCmd($input); $input = htmlspecialchars($input,ENT_QUOTES); return $input; }

• escapeshellcmd() escapes characters that might be used to trick a shell

command into executing arbitrary commands.

• htmlspecialchars() prevents user-supplied text from containing HTML markup.

Self referencing Sticky form

• Form display and form processing can be

consolidated into one script.

• Requiring a user to retype all form data in event
• f error/omission reduces usability.
• Allows "sticky form": display error message to
• Allows "sticky form": display error message to

user and also retain values the user has already entered.

• Design (at minimum):

– Form validity checking embedded on page with form. – Form submits to itself for processing. Typically done using PHP superglobal $_SERVER[PHP_SELF].

Sticky form pseudo-code

• If form submitted:

– Check validity – If not valid display the form back again with field set set

• Send the form

Gluing script

Script1 Script2 Check ok Script2 Check nok

Array

• The key is optional, and when it’s not specified, the key is

automatically assigned one more than the largest previous integer key (starting with 0).

array([key =>] value, [key =>] value, ...)

• There are three different kind of arrays:

– Numeric array - An array with a numeric ID key – Associative array - An array where each ID key is associated with a value – Multidimensional array - An array containing one or more arrays

Examples

1. array(1, 2, 3) 2. array(0 => 1, 1 => 2, 2 => 3) 3. array ("name" => "John", "age" => 28) 4. array(1 => "ONE", "TWO", "THREE") 5. array(1 => "ONE", 2 =>"TWO", 3 => "THREE") 6. array (array ("name" => "John", "age" => 28), array ("name" => "Barbara", "age" => 67)) "Barbara", "age" => 67)) 1 and 2 are same, 3 and 5 are same, 6 is a nested array

Examples

!:! :@A :@A: :@:A 8

• @A/

@A/: @:A/

• print_r($arr1)
• (-/-B%-!--/

:C :@-(-A-B%- :@--A:C :D >:%(> E :%(

Traversing

• $key contains the currently iterated value’s key
• & if present allows to modify the array
• $value contains the value

foreach($array as [$key =>] [&] $value)

• B%-!-5-!-5-!-F-
• G% ),/-

% &/."D

• H&.",/-

E

The players are: #0 = John #1 = Barbara #2 = Bill #3 = Nancy

Exercise

• Format the output of the players as a html

table

Exercise

,7 %

• B%-!-5-!-5-!-F-

>G% ,/,--/> % &/." D ,$,)!12+!),$$,)!1/*!),$, ,$,)!12+!),$$,)!1/*!),$, E >,/> 7/

concat double quoted to replace $key with its value

list, each

• B%-!-5-!-5-!-F-

#%&!.% D

• H&.-

E

each() returns the current key/value pair as an array with four elements: the elements 0, "key", 1 and "value" list() assigning multiple array elements to multiple variables in one statement

LAB

• LAB1.

– Scrivere uno script che costruisca la tabella di Pitagora n x n

• LAB2. Sticky form

– Scrivere uno script che genera un form per l’inserimento di nome e cognome. Se i due campi non sono completi rigenera una form con i valori nei campi rimempiti una form con i valori nei campi rimempiti

• LAB 3.

– Scrivere una generica funzione di “sanity check”, che a partire da un vettore ‘signature’ contentente tipo, caratteristica dei campi della form (required o meno) e nome funzione:

• controlli se tutti i campi di una form sono stati riempiti
• Converta I tipi come specificato
• Applichi una funzione a tutti gli argomenti

Functions

• Any valid PHP code may appear inside a user-

defined function, even other function…

• Functions need not be defined before they are

referenced referenced

• Call-by-reference, call-by-value, default value,

variable-length argument, lambda-style function

Parameter passing

function function_name (arg1, arg2, arg3, …) { statement list } function square($n) { $n = $n*$n; } function square(&$n) { $n = $n*$n; } parameter by-value … by-reference

Default value

function makeAcoffee ($type=“espresso”) { return “Making a cup of $type”; } echo makeAcoffee(); echo MakeAcoffee(“French”)

• The default value must be a constant
• Default arguments should be on the right side of any non-default

argument

echo MakeAcoffee(“French”)

Variable-length argument list

function foo() { $numargs = func_num_args(); echo "Number of arguments: $numargs\n"; } foo(1, 2, 3); foo(1, 2, 3);

Variable function

• If a variable name has parentheses appended to

it, PHP looks for a function with that name and executes it

function foo() {echo “in foo()<br>”;} function foo() {echo “in foo()<br>”;} Function bar($arg = ‘’) { echo “in bar(); argument was $arg”<br>”; } $func = ‘foo’; $func(); #call foo() $fun = ‘bar’; $func(‘test’);

Static variables

function do_something() { static $first_time = true; if ($first_time) { // Execute this code only the first time the function is called ... ... $first_time=false; } // Execute the function's main logic every time the function is called ... }

Array_map

• Applies a callback function to the elements of

the given arrays

<?php function Double($a){return 2*$a;}; function Double($a){return 2*$a;}; $in = range(1,5); $out = array_map("Double",$in); print_r($out); ?>

• Other interesting functions (see manual):
• array_walk
• array_reduce
• …

Closure

• Closure allows to define an anonymous

function

<?php $out = array_map(function ($a){return 2*$a;},$in); $out = array_map(function ($a){return 2*$a;},$in); ?> <?php $double =function ($a){return 2*$a;}; $out = array_map($double,$in); ?>

Exercise: generic sanity check function

• Design a function that parametrically checks

– if all required fields are set – Type convert values

Code inclusion control structures

*$ *$3 4* I") . " " 4* 4*3 I") .

include $_SERVER["DOCUMENT_ROOT"] . "/myscript.php"; include "http://www.example.org/example.php";

Eval

• Include/require actually “execute” the

included script

• Eval, allows to dynamically execute php string

code code

Persistency

• Cookie, Session

– Per browser data storage, no cross-browser data exchange

• File, DB

File, DB

– Site level persistence storage

• +#,
• ##
• +)-./0#,
• #
• +,
• +,

• +#,
• ##
• +)-./0#,
• #
• +,
• +,

562% 0(77687'

• (*"9:5+5;<9;<<%<<%<<='

('$()$ )*9) 62% 0(77687

http header sent from the server to the client Header sent from the client to the server

Inspecting http header

• Browsers can install plug-in to inspect http

headers

• For example, liveHTTPHeader for firefox

,7 % .3 >?' 7/

Output must be buffered

7/ ,%(/ ,%/,/6&*( ,/,%/ ,/ ,7 % 2>+62",,? 7/ ,/ ,%(/

set a cookie (see documentation)

Cookie in PHP

• Cookie can be accesed via superglobal

variable, $_COOKIE

<?php print_r($_COOKIE); ?>

Example

• Implement a simple counter using Cookie

Solution

<?php

• b_start();

?> <HTML> <HEAD> <TITLE>COUNTER</TITLE> </HEAD> <BODY> <form method=“post" action="counter.php"> <table> <tr><td colspan='2'> <input type='submit' value='Inc' name='inc'/> </td></tr> <tr><td colspan='2'> <input type='submit' value='Dec'name='dec'/></td></tr> </table> </form>

Solution

<?php if (!isset($_COOKIE[C])): print "Counter=0"; setcookie(C,0); else: $Counter = $_COOKIE[C]; if (isset($_POST[inc])): $Counter++; endif; if (isset($_POST[inc])): $Counter++; endif; if (isset($_POST[dec])): $Counter--; endif; print "Counter=$Counter"; setcookie(C,$Counter); endif; ?> </BODY> </HTML>

Tic Tac Toe

Player arrives Player enters Display Form P=P1, enters for the first time P=P1, returns, P2 not entered display “Wait” Set Cookie P1 display “Wait” Index SYNC arrives P=P2 P=P1, returns, P2 entered P = Player P1 = First Player that arrives P2 = Second Player redirect Set Cookie P2 redirect Display Form

Tic Tac Toe

PLAY move Display new view PLAY Update the view Check winner

Session

• A PHP session allows for storing information locally

at the server on a per session basis

– Session data path is specified in the session.save_path of php.ini Data session can be stored in a database – Data session can be stored in a database

• PHP generates a session ID and sends it out as a

cookie with name PHPSESSIONID

• The client sends the session ID each time it interacts

again with the same site

Example

<?php session_start(); ?> create the id and an empty _SESSION array, stored at the server side cookie cookie’s content

Access to a private area

• Session can be used to protect a page
• When trying to access a page, check if

authorization is set… If not, redirect to a login page and then back

• If not, redirect to a login page and then back

to the page…

• ..otherwise just continue..

Example

<?php

• b_start();

session_start(); ?> <?php if (!(isset($_SESSION['auth'])&&($_SESSION['auth']=='ok’))) { $url = $_SERVER['PHP_SELF']; header("location: login.php?url=$url"); } auth not set get this url.. redirect to login } ?> <?php //check login… $_SESSION['auth']='ok'; $url=$_GET['url']; header(“location: $url"); ?> Included in example.php login.php set auth get original url redirect back http://localhost/example.php http://localhost/login?url=example.php http://localhost/example.php

Example: shopping cart

• Simple example
• User can login…
• User can select/deselect items…

…then check out…

• …then check out…

" )"

cookie ‘uid’ not set success / set cookie ‘uid’

12

login failure

" "

click on logout unset cookie ‘uid’

passwd DB

want to register done

31 4315

• 1!6
• 78
• #9
• :1

Open/create a db

+;<!;<!=;>??, @31##)" ,7 % 43-340?2<J5-!!9 ,7 % #@. -340?2<J5-!9 43-340?2<J5-!!9

• J5K?<F<J--L-
• 7/

340?2<J5 #@. -340?2<J5-!9

• %J5K?<F<J-
• 7/

Create a table

$I" - 600A6> $+2+" $ " 4*+ Sql statment

A:)

Executes a result-less query against a given database bool queryExec ( string $query [, string &$error_msg ] )

• I"

4*+ ?

• =/4*+->134*+?'

db

PRODUCTS

A:) +,

Insert a row

I"-7B07B0A6>$"$ "4*+?CA>9",C,"9?- =/I"<*I"

• J

I"

• JMJ
• db

PRODUCTS

Update/delete

$db->queryexec('DELETE FROM PRODUCTS WHERE id=2'); $db->queryexec('UPDATE PRODUCTS SET id=19 WHERE id=4');

Fetch results

query fetch, fetch all, 3N2;" seek rewind, current… unbufferedquery 3N2O" forward only, much faster

Fetch results

$q = "SELECT * FROM PRODUCTS;"; $qr = $db->query($q); //Executes a query against a given database and returns a result handle $r = $qr->fetchAll();//Fetches all rows from a result set as an array of arrays foreach ($r as $entry) { echo $entry['id'].' '.$entry['description'].' '.$entry['quantity'].'<br>'; } 1 DVD 1

LAB /Project (shopping cart 2)

• PRODUCT table

– View content – Insert items – Delete items – Delete items

• Password DB

– User registration – User authentication

Login Form

• http://www.html-form-guide.com/php-

form/php-registration-form.html

OO Model

• An OO program is a collection of objects
• Every object is an instance of a class
• An object has properties

An object has a set of methods

• An object has a set of methods

Constructor

• Unified constructor name
• __construct()

class MyClass { function __construct() { function __construct() { echo "Inside constructor"; } }

Destructor

• __destruct()
• Called when an object is

destroyed (no more reference)

class MyClass { function __destruct() { print "An object of type MyClass is being destroyed\n"; } } $obj = new MyClass(); $obj = NULL; An object of type MyClass is being destroyed

Copying objects

class MyClass { public $var = 1; }

• bj1
• bject

$obj1 = new MyClass(); $obj2 = $obj1;

• bj2

$obj2 = $obj1; $obj2->var = 2; print $obj1->var; //print 2 $obj1 = new MyClass(); $obj2 = clone $obj1; $obj2->var = 2; print $obj1->var; //print 1

• bj1
• bject
• bj2
• bject

Access protection of member variables

class MyDbConnectionClass { public $queryResult; protected $dbHostname = "localhost"; private $connectionHandle; // ... } class MyFooDotComDbConnectionClass extends MyDbConnectionClass { protected $dbHostname = "foo.com"; }

Example

class Person { private $name; function setName($name) { $this->name = $name; } function getName() { return $this->name; } }; $judy = new Person(); $judy->setName("Judy"); $joe = new Person(); $joe->setName("Joe"); print $judy->getName() . "\n"; //print Judy print $joe->getName(). "\n"; //print Joe

Static properties

class MyUniqueIdClass { static $idCounter = 0; public $uniqueId; function __construct() { self::$idCounter++; $this->uniqueId = self::$idCounter; self: refer to the current class $this->uniqueId = self::$idCounter; } } $obj1 = new MyUniqueIdClass(); print $obj1->uniqueId ; //print 1 $obj2 = new MyUniqueIdClass(); print $obj2->uniqueId ; //print 2

POLYMORPHISM

• Single class inheritance

– like Java

• Multiple interface implementations

Final keyword – Final keyword

class Child extends Parent { ... } class A implements B, C, ... { ... } interface I1 extends I2, I3, ... { ... }

<?php class Auth { function Auth() { mysql_connect('localhost', 'user', 'password'); mysql_select_db('my_own_bookshop'); } public function addUser($email, $password) { $q = ' INSERT INTO users(email, passwd) VALUES (“ '. $email. ‘ ", “ '. sha1($password).‘ ") '; mysql_query($q); }

public function authUser($email, $password) { $q = ' SELECT * FROM users WHERE email=“ '. $email. ' " AND passwd =“ '. sha1($password). ' " '; $r = mysql_query($q); $r = mysql_query($q); if (mysql_num_rows($r) == 1) { return TRUE; } else { return FALSE; } } } ?>

Autoload

• When writing object-oriented code, it is often

customary to put each class in its own source file.

• Using the _autoload() function (one per
• Using the _autoload() function (one per

application) a class can be included at run- time

• The system implicitily passes the name of the

missed class as a parameter of the function

Myclass.php <?php function __autoload($class_name) { require_once($_SERVER["DOCUMENT_ROOT"] . "/classes/$class_name.php"); } ?> general.inc autoload called if MyClass must be placed in /classes directory

file has same name of the class

<?php class MyClass { function printHelloWorld() { print "Hello, World\n"; } } ?> Myclass.php <?php require_once "general.inc"; $obj = new MyClass(); // calls __autoload $obj->printHelloWorld(); ?> main.php if MyClass is not defined

Reflection

• Allows to have class information at run-time
• Just an example

<?php class C { function F() { print "Hello, World\n"; } } ReflectionClass::export("C"); ?> …

• Constants [0] { }
• Static properties [0] { }
• Static methods [0] { }
• Properties [0] { }
• Methods [1] {

Method [ public method F ] …

Example: delegate pattern

PHP Communication

string file_get_contents ( string $filename [ …]) Reads entire file into a string

,7 % 4 .! * ( 142< %( $$-%%(*- ; ( ( ###*( ( " PGG? % $$-%###*( (*- ; ( ( ###*( ( " PGG?3 % $$- )###*( (*- ; ( ( *( ( " 1G? $$-%") Q *( (*- ; ( ( *( ( " 1G?3 $$- )") Q *( (*- 7/

Example

• Flickr is a web site that allows to share

personal photos

• Free account for 90 days

API with different formats

• API with different formats

– Request: REST,XML-RPC,SOAP – Reply: REST,XML-RPC,SOAP,JSON,PHP

Flickr’s application end-points

• http://api.flickr.com/services/rest/
• http://api.flickr.com/services/soap/
• http://api.flickr.com/services/xmlrpc/
• http://api.flickr.com/services/upload/
• http://api.flickr.com/services/upload/
• http://api.flickr.com/services/replace/

% ) &(. 7$)))9/*)))

• REST format is the simplest way; it uses the HTTP POST method

CLIENT SERVER ; !() ;<3G!R02=;?6!3K8?!B3KF!?P? >

Example of API call

flickr.photos.getInfo

api_key (Mandatory) Your API application key.

In Parameters:

Your API application key. photo_id (Mandatory) The id of the photo to get information for. secret (optional) The secret for the photo. If the correct secret is passed then permissions checking is skipped, unless photo is shared.

Out Parameters: info with different format…

Example of reply

An example:

invoking a REST end-point from PHP code

( > $&> / >SCC:'TU'T'TC>! >(%> / >& %4>! > %$> / >>! >(> / > % $>!

• $ (

Parameters "

• Reply in php serial format

% ( &/. $ ( @A"&>>". " -% ) &(.7-( >9>!$ (

% ) &(.7 $&SCC:'TU'T'TC9(%& %49 %$9( % $

"

• non-alphanumeric as %

sign two hex digits

• spaces as plus (+) signs.
• Join array elements with

a string,

• & used as glue string

( "

Serialization

string serialize ( mixed $value ) Generates a storable representation of a value mixed unserialize ( string $str ) Creates a PHP value from a stored representation

$ans = file_get_contents($url); $ans_obj = unserialize($ans); if ($ans_obj['stat']=='ok') { echo $ans_obj['photo']['id'].'<br>'; echo $ans_obj['photo']['title'] ['_content']; Invoke method Transform format into an associative array echo $ans_obj['photo']['description']['_content']; echo $ans_obj['photo']['dates']['taken']; }
