Phase Synchronization of Two Tremor-Related Neurons

Sunghan Kim

Biomedical Signal Processing Laboratory Electrical and Computer Engineering Department Portland State University

2

ELECTRICAL & COMPUTER ENGINEERING

B I O M E D I C A L S I G N A L P R O C E S S I N G L A B

b s p . p d x . e d u

Background

• Physiological Tremors of Neurons

Fluctuation of an instantaneous firing rate of neurons Recorded through a microelectrode recorder Not amplitude-modulated signals like limb’s tremor recordings Several studies on the interaction between neuron’s tremors and limb’s tremors Few studies on the interaction between neurons’ tremors Phase-locking analysis between tremor-related neurons is critical to the study of the tremor control mechanism in the central nerve system

3

ELECTRICAL & COMPUTER ENGINEERING

B I O M E D I C A L S I G N A L P R O C E S S I N G L A B

b s p . p d x . e d u

Problem Introduction

• Limitations of Temporal Correlation Methods

Coherence analysis in frequency domains Crosscorrelogram analysis in time domains Both methods based on the stationarity assumption of signals Most tremor signals such as MER, EMG, and EEG are not stationary Current methods detect both phase and amplitude correlations Instantaneous phase analysis method is required to study the phase-locking between nonstationary signals

4

ELECTRICAL & COMPUTER ENGINEERING

B I O M E D I C A L S I G N A L P R O C E S S I N G L A B

b s p . p d x . e d u

• Phase-locking Analysis of Two Tremor Spike Trains

Extracted from a Single Microelectrode Recording

Instantaneous analysis Only focuses on the phase coherence between two oscillatory signals, not amplitude correlation Hypothesis test of two tremor’s independency

Objectives

5

ELECTRICAL & COMPUTER ENGINEERING

B I O M E D I C A L S I G N A L P R O C E S S I N G L A B

b s p . p d x . e d u

Methodology

• Overview

Building spike trains out of two-unit tremor MER Constructing phase evolution series (core step) Building instantaneous frequency series Estimating the distribution of phase coherence between two independent tremor signals Appling the result to a phase-locking index series of two tremor signals extracted from a single MER

6

ELECTRICAL & COMPUTER ENGINEERING

B I O M E D I C A L S I G N A L P R O C E S S I N G L A B

b s p . p d x . e d u

Methodology - Step 1

• Building Two Spike Trains out of Two-Unit Tremor MER

7

ELECTRICAL & COMPUTER ENGINEERING

B I O M E D I C A L S I G N A L P R O C E S S I N G L A B

b s p . p d x . e d u

Methodology - Step 1

• Histogram of All Peaks in a MER Signal

8

ELECTRICAL & COMPUTER ENGINEERING

B I O M E D I C A L S I G N A L P R O C E S S I N G L A B

b s p . p d x . e d u

Methodology - Step 1

• Histogram of All Peaks in a MER Signal

9

ELECTRICAL & COMPUTER ENGINEERING

B I O M E D I C A L S I G N A L P R O C E S S I N G L A B

b s p . p d x . e d u

Methodology - Step 1

• Building Two Spike Trains out of Two-Unit Tremor MER

10

ELECTRICAL & COMPUTER ENGINEERING

B I O M E D I C A L S I G N A L P R O C E S S I N G L A B

b s p . p d x . e d u

Methodology - Step 2

• Constructing Phase Evolution Series

Bandpass filter the spike trains to extract oscillatory components of the spike trains

3~8 Hz is the typical essential tremor (ET) frequency range

11

ELECTRICAL & COMPUTER ENGINEERING

B I O M E D I C A L S I G N A L P R O C E S S I N G L A B

b s p . p d x . e d u

Methodology - Step 2

Normalized Gabor representation of the oscillatory component time series through Hilbert transformation

Hilbert transformation where is the oscillatory component time series This new representation is in a complex domain Normalized Gabor representation of the time series Its unwrapped phase is the phase evolution series of the

• scillatory component time series

This process is equivalent to projecting the time series onto a unit circle in a complex domain

12

ELECTRICAL & COMPUTER ENGINEERING

B I O M E D I C A L S I G N A L P R O C E S S I N G L A B

b s p . p d x . e d u

Methodology - Step 3

• Building Instantaneous Frequency Series

Instantaneous frequency is equal to the derivative of the unwrapped phase evolution

13

ELECTRICAL & COMPUTER ENGINEERING

B I O M E D I C A L S I G N A L P R O C E S S I N G L A B

b s p . p d x . e d u

Methodology - Step 4

• Hypothesis Test for a Phase-Locking Index

Phase coherence as a phase-locking index

• where is the phase difference between two phase

evolution series

When two correlated signals’ phases are locked, the phase- locking index becomes large However, the large phase-locking index does not necessarily mean the correlation of two tremor signals

The instantaneous frequency series of two independent tremor signals may look synchronized, i.e. phase-locked, over a certain period of time

14

ELECTRICAL & COMPUTER ENGINEERING

B I O M E D I C A L S I G N A L P R O C E S S I N G L A B

b s p . p d x . e d u

Methodology - Step 4

Estimate the distribution of the phase coherence between two independent tremor signals to test a null hypothesis

Ho: two signals are independent Model a tremor spike train as a quasi-Poisson process Event occurring probability changes over time in a quasi Poisson process Generate the ensembles of two independent tremor signals based on the model Estimate the distribution of the phase coherence between these two independent synthetic tremor signals

15

ELECTRICAL & COMPUTER ENGINEERING

B I O M E D I C A L S I G N A L P R O C E S S I N G L A B

b s p . p d x . e d u

Methodology - Step 4

If two tremor signals’ phases are truly locked its phase coherence should be greater than 95th or 99th percentile of the estimated distribution of the phase coherence between two independent tremor signals The 99th percentile of the estimated distribution vs. the length of time window for the phase coherence index

16

ELECTRICAL & COMPUTER ENGINEERING

B I O M E D I C A L S I G N A L P R O C E S S I N G L A B

b s p . p d x . e d u

Result

• Applied This Method to the Tremor Signals Extracted

from the Two-Unit Tremor MER

Two tremor signals’ instantaneous frequency series Phase coherence vs. time

17

ELECTRICAL & COMPUTER ENGINEERING

B I O M E D I C A L S I G N A L P R O C E S S I N G L A B

b s p . p d x . e d u

Discussion

• The hypothesis test can be applied once to determine

whether two tremor signals are phase-locked during a specific period of time

• It cannot be applied to the sequential segments of two

tremor signals because they are not independent

• The 99th percentile of the estimate distribution of the

phase coherence was much greater than the phase coherence between two real tremor signals

It may indicate that two real tremor signals are not phase- locked at all Or, the real tremor spike trains are quite different from the model tremor spike train
