PERMiT – Pipeline Erosion Risk Mitigation Toolkit

Reduce erosion risk while optimizing production

• PERMiT is a unique tool designed to predict and mitigate erosion
• risk. It helps with design and operation of oil and gas pipelines

within acceptable erosion limits.

• Designers can size pipelines and recommend operating envelopes

to stay within the erosion limits.

• Field operators can optimize production rates to stay within erosion

limits when production scenarios change. It ensures safe and reliable operation of pipelines.

An integrated tool kit that enables Pipeline Integrity teams to analyze and manage erosion using data science, erosion science and CFD models.

Key Features:

• Comprehensive suite of erosion models (API, DNV, Salama, Salama-

Venkatesh, Jordan, and ECRC).

• Comparison of model data with lab and / or field data
• Automatic parametric analysis to rapidly determine operating

envelope (for e.g. velocity boundary plots, sensitivity plots and

• perating envelope curves)
• CFD module to enable CFD analysis of piping components
• Data science module to facilitate development of data driven models

Erosion Model Calculations

• Prediction and comparison of erosion rates using

various erosion models for piping components such as elbows, tees, welded joints, straight pipes, and reducers

• Erosion models available in PERMiT: API RP 14 E, DNV

RP 0501, Salama, Salama & Venkatesh, Jordan – ECRC, ECRC –Bubble flow

• Construct

erosion velocity boundary plots using different models

• Allows user to superimpose operating envelope curves

generated using different models for comparison

• Create sensitivity plots to see how erosion is affected

by changes to a parameter such as gas velocity or pipe diameter

• Store

wall thickness, coupon data,

• r

erosion rates along with all relevant piping configuration, process flow conditions, etc.

• Customizable database

with ability to integrate and streamline entire process from end to end

• Built-in database of published experimental

data available

• Ability to filter databases for experimental

data relevant to present case

• Ability to compare experimental data to

erosion model results

Experimental Data Module

• Fully automated module that allows design and operations

engineers to create CFD models and analyze their pipelines

• Automated geometry creation
• Fully automated mesh generation
• Pre-optimized

meshing algorithm which create unstructured mesh for the complete domain

• Combination of hexahedral and polyhydric cells
• Appropriate refinement of mesh near impeller to capture

higher velocity gradients

• Choice between two turbulence models and two erosion

models

• Ability to model sand particles as constant diameter or Rosin-

Rammler size distribution

• Automated post-processing
• Contour plots of erosion and velocity
• Vector plots
• Path lines plots

CFD Module

Erosion rate contour

• n elbow wall

Pathlines

• Exp. Maximum
• Exp. Maximum

PERMiT Validation with Experiments

DATAe – Data Driven Models

• Ability to import field data, clean the data,

visualize the data in various ways, and create data-driven models

• Automated

process

• f

choosing which variables in dataset are most significant

• Ability to create several data-driven models

and choose the ones that fit the data best

• Ability to use model for predicting erosion

rate, similar to published models used in PERMiT

DATAe Model Prediction DATAe Data Visualization

for your Enterprise

800+ Projects

Using Computational model-based technology Global Experience

12+ Years 15 Patents Successfully delivered R&D

Projects leading to patents owned by our clients Working with Multinational & Multisectoral

fortune 100 Clients 100+ R&D & Testing professional (with top talent >

70 % masters / Post Doc.) Worlds largest Oil & Gas Flow Lab

Testing Facility Deep domain knowledge

with Technology penetration across functions

10+ M $ customer savings using

computational model-based technology tools

15+ Applications

Developed for complex engineering calculations

IEC & Testing Facility NA Operations

Tridiagonal Solutions

TM

Our Core Competence

Domain Apps Validation (Testing) Lab Computational (model-based) Technologies CFD | DEM | FEA

• Multiphase flow

Simulation studies

• CFD Modeling &

Simulations

• DEM Simulations
• DEM - CFD Coupled

Simulations

• Combustion
• Finite Element

Modeling

• Flow assurance

studies

• Pilot Experiment set-

ups

• Mixer Testing Facility
• Customer Testing

Programs Design Modification & Performance Enhancement

• Vertical Apps for

Process Equipment’s

• MixIT
• Smart CFD
• Smart DEM
• PermIT
• Separator

Process Frameworks

• Design Configurator
• Sales Configurator
• Costing Configurator
• ERP Integration
• Centralized Database

management Design Price Quote (DPQ) Experimental (Validation) Services

Servicing Customers in Several Segments

Process / Product Design and Optimization | Experimental (Testing) Services | Product Development | Engineering IT & Data Management

Multiphase Stirred Reactor Static Mixer Solidification Furnace Cyclone Separator Sedimentation Mixing Separators Reverse Flow Cyclones Combustion Modeling SCR & AIG Modeling Gas Flotation Cell Solid Waste Incinerator Air and Flue Gas Duct Pneumatic Conveying Boiler Flue Gas Flow Analysis Windbox Modelling

Connected Engineering Applications Workflow Automation (Configurators) Vertical Applications Combine Science and Knowledge Management tools in an unified environment (deployable enterprise-wide)

• Evaluate new ideas/concepts with a combination of Digital & Physical

Lab

• World class experimental facilities with sophisticated measurement

techniques (Support up to prototype development)

• Established Flow Lab for multi-phase flow assurance studies
• Single window approach for analysis, verification and validation

studies for a quick product development

• Solve complex issues effectively using combination of technologies

(model-based CFD-DEM / Physical testing)

• Design & Build Customized Experimental Set up (for end customers)

Global Testing Programs – Managed by Tridiagonal Solutions Pvt. Ltd. Pune, India Experimental Set-up/ Testing Programs

Instruments: High speed photography, Ultrasonic velocity profiler, Conductivity- based volume fraction sensor, High precision ultrasound thickness measurement system, Hot wire anemometer, Gas Anemometer

Sand Screen Erosion, Wet Gas Erosion testing facility (4 inch), Multiphase Erosion Test facility (4 inch), Sand Transport and Multiphase Flow Facility (16 inch), Liquid entrainment and Slurry transport flow loop (4 inch and 10 inch), Multiphase Wax Flow loop (2 inch and 4 inch), Erosion-Corrosion test facility (4 inch)
