PE Refresher Course Digital Systems and Computers Joanne Degroat degroat.1@osu.edu ece.osu.edu/~degroat 3/1/20007 PE Refresher Computer Area - 1 Joanne DeGroat The Basics Basic Switching Algebra Truth Tables of Basic Functions AND

SLIDE 1

3/1/20007 PE Refresher Computer Area - Joanne DeGroat 1

PE Refresher Course

Digital Systems and Computers

Joanne Degroat degroat.1@osu.edu ece.osu.edu/~degroat

SLIDE 2

3/1/20007 PE Refresher Computer Area - Joanne DeGroat 2

The Basics

Basic Switching Algebra

Truth Tables of Basic Functions AND and OR

A B C=A+B 1 1 1 1 1 1 1 OR A B C=A*B 1 1 1 1 1 AND

SLIDE 3

3/1/20007 PE Refresher Computer Area - Joanne DeGroat 3

The Basics (cont)

Inversion – The not or

inverter gate

Exclusive OR - XOR

A B Χ=Α ⊕ Β 1 1 1 1 1 1 XOR - exclusive OR

A A 1 1 NOT - inversion

SLIDE 4

3/1/20007 PE Refresher Computer Area - Joanne DeGroat 4

And two other common gates

The NAND – NOT AND The NOR – NOT OR

A B C=A*B 1 1 1 1 1 NAND

SLIDE 5

3/1/20007 PE Refresher Computer Area - Joanne DeGroat 5

Some Basic Theorems

A+0 = A A+1 = 1 A+B = B+A A+BC = (A+B)(A+C) A+A’ = 1 A+AB = A A1 = A A0 = 0 AB = BA A(B+C) = AB+AC A*A’ = 0 A(A+B) = A

Equality Identity Commutative Distributive Involution Absorption

SLIDE 6

3/1/20007 PE Refresher Computer Area - Joanne DeGroat 6

More Theorems

A+AB = A + B

A(Α + B) = AB

(A + B) = AB

(AB) = A + B

A*A = A

A + A = A

(A) = A AB + AC + BC = AB + AC Dual:

(A+B)(A+C)(B+C) = (A+B)(A+C)

DeMorgan’s Law

SLIDE 7

3/1/20007 PE Refresher Computer Area - Joanne DeGroat 7

Truth Tables

A B A+B 1 1 1 1 1 1 Proof of DeMorgan's Law 1 1 1 (A+B) 1 A B 1 1 1 A*B = Truth tables can be used to prove equalities

SLIDE 8

3/1/20007 PE Refresher Computer Area - Joanne DeGroat 8

Venn Diagram and Karnaugh Maps

A=1 B=1 C=1 000 001 010

011

100

101 110 111

00 01 11 10 1 A B C

SLIDE 9

3/1/20007 PE Refresher Computer Area - Joanne DeGroat 9

Function Simplification

f(a,b,c) = ab + bc + abc Simplify using Karnaugh map

Start with each term

SLIDE 10

3/1/20007 PE Refresher Computer Area - Joanne DeGroat 10

Function Simplification

f(a,b,c) = ab + bc + abc

A term with a Single element results In 4 ones A term with 2 elements Gives two A term with 3 elements Gives a single 1

SLIDE 11

3/1/20007 PE Refresher Computer Area - Joanne DeGroat 11

Simplify K maps

Conbining the previous three maps Can represent what a K map shows by a sum

f products

Take the largest group possible

On one line, a square, two
Group needs to be a
power of 2

00 01 11 10 1 A 1 1 1 1 1 BC

f(a,b,c) = a + bc

SLIDE 12

3/1/20007 PE Refresher Computer Area - Joanne DeGroat 12

4 variable functions

Also expressed in minterm notation f(a,b,c,d) = Σm(7,13,14,15)

So function is a 1 when abcd = 0111 (7)

1101 (13) 1110 (14) 1111 (15) 00 01 11 10 AB 1 1

1 1 CD 00 01 11 10

2 3 5 6 7 4 13 14 15 12 9 10 11 8

SLIDE 13

3/1/20007 PE Refresher Computer Area - Joanne DeGroat 13

Form into largest groups

For 4 variables form

into groups of

16 – function would be a

0 or a 1

8 – 1 variable
4 – 2 variables
2 – 3 variables

Simplifies to

F = ABD + BCD + ABC

SLIDE 14

3/1/20007 PE Refresher Computer Area - Joanne DeGroat 14

Another Example of function simplification

From a Truth Table Step 1 – map to

K- maps

x y z F1 F2 0 0 0 1 0 0 0 1 0 0 0 1 0 1 0 0 1 1 1 1 1 0 0 1 0 1 0 1 0 1 1 1 0 0 1 1 1 1 1 1

SLIDE 15

3/1/20007 PE Refresher Computer Area - Joanne DeGroat 15

Step 2 – Generate simplified equation

For F1 For f2

SLIDE 16

3/1/20007 PE Refresher Computer Area - Joanne DeGroat 16

Example Problem

Design a circuit having 1 output Z and 4

inputs A B C D which represents a BCD number, such that Z = 1 if the BCD number is greater than 5.

BCD stands for binary coded decimal

Takes 4 binary digits
Only 0 through 9 are used

SLIDE 17

3/1/20007 PE Refresher Computer Area - Joanne DeGroat 17

Map onto K map

Fill in a 1 whenever

utput should be a 1

Here that would be 6,

7, 8 or 9

And a 0 for blocks 0

through 5

SLIDE 18

3/1/20007 PE Refresher Computer Area - Joanne DeGroat 18

The K map cont

Filled in What should other

blocks be?

They would be don’t

cares as in BCD notation they will never occur

And final K map for

simplification is

SLIDE 19

3/1/20007 PE Refresher Computer Area - Joanne DeGroat 19

Simplified using don’t cares

Form the largest power

f 2 grouping from 1’s

and don’t cares

Cover all the 1’s but

don’t need to cover all the don’t cares

Get Z = A + BC Gate implementation

1 2 3 5 6 7 4 13 14 15 12 9 10 11 8

SLIDE 20

3/1/20007 PE Refresher Computer Area - Joanne DeGroat 20

PLAs

PLA – Programmable

Logic Array

PAL – Programmable

Array Logic – much like a PLA but restricted connections

Formed of an AND

plane and an OR plane

SLIDE 21

3/1/20007 PE Refresher Computer Area - Joanne DeGroat 21

PLAs

PLA – Programmable

Logic Array

PAL – Programmable

Array Logic – much like a PLA but restricted connections

Formed of an AND

plane and an OR plane

SLIDE 22

3/1/20007 PE Refresher Computer Area - Joanne DeGroat 22

PLA example

Problem: A sequence box to control

automatic starting of a jet engine is to be

designed. It has the following signals

Problem stated on next slide.

SLIDE 23

3/1/20007 PE Refresher Computer Area - Joanne DeGroat 23

Problem statement

xx

SLIDE 24

3/1/20007 PE Refresher Computer Area - Joanne DeGroat 24

Problem statement translated to a table

The table

SLIDE 25

3/1/20007 PE Refresher Computer Area - Joanne DeGroat 25

K maps for the sequencer

SLIDE 26

3/1/20007 PE Refresher Computer Area - Joanne DeGroat 26

The logic implementation in gates

SLIDE 27

3/1/20007 PE Refresher Computer Area - Joanne DeGroat 27

And a PLA implementation

You will most like be asked for this in a

table representation form like this

SLIDE 28

3/1/20007 PE Refresher Computer Area - Joanne DeGroat 28

The PLA

SLIDE 29

3/1/20007 PE Refresher Computer Area - Joanne DeGroat 29

Basic Sequential Logic

Flip Flops Set Reset FF

Q*=S+R’Q

Toggle FF

Q*=Q’
Q* is next value
Or next state

SLIDE 30

3/1/20007 PE Refresher Computer Area - Joanne DeGroat 30

Basic Sequential Logic

D F/F

Q* = D

JK F/F

Q*=JQ’+K’Q

SLIDE 31

3/1/20007 PE Refresher Computer Area - Joanne DeGroat 31

A Simple up/down counter

Start with a state

diagram

SLIDE 32

3/1/20007 PE Refresher Computer Area - Joanne DeGroat 32

A Simple up/down counter

Start with a state diagram And a state table for T F/Fs

SLIDE 33

3/1/20007 PE Refresher Computer Area - Joanne DeGroat 33

K Maps for the toggle F/Fs

T1 = x’y2 + x y2’ = x xor y2 T2 = 1

SLIDE 34

3/1/20007 PE Refresher Computer Area - Joanne DeGroat 34

Implementation

Q Q

SET CLR

Q Q

SET CLR
