PBE PAS Collision Avoidance/Proximity Detection System Adrian - - PowerPoint PPT Presentation

PBE is the leading single source provider of safety and productivity solutions, technology and engineering expertise that gives your company the competitive edge. PBE PAS Collision Avoidance/Proximity Detection System Adrian Barratt PBE


slide-1
SLIDE 1

PBE is the leading single source provider of safety and productivity solutions, technology and engineering expertise that gives your company the competitive edge.

PBE PAS Collision Avoidance/Proximity Detection System

Adrian Barratt PBE European Headquarters Milton Keynes United Kingdom

1

slide-2
SLIDE 2

Innovating Safety. Powering Productivity.

The PBE Group Overview

A global manufacturer of safety and productivity solutions

  • 1. PBE have been a leading manufacturer of safety, monitoring and communications equipment for 45 years
  • 2. 170 employees, 9 regional service centers and over 30 distributors
  • 3. With an estimated 850 tunnels and mines, served by Over 70 proprietary products – all designed and

manufactured in house to form a total integrated solution

Environmental Monitoring Conveyor Belt Monitoring Leaky Feeder Solutions Tagging & Tracking Complete Mine-wide Software Solutions Proximity Detection & Collision Avoidance In House Design, Local Support

2

slide-3
SLIDE 3

Innovating Safety. Powering Productivity.

A Selection of PBE Customers

Including a global portfolio of major UK customers and contractors

3

slide-4
SLIDE 4

Innovating Safety. Powering Productivity.

Services & Support

Reducing support costs and limiting any impact to productivity

4

  • 1. Installation and Commissioning

1.

Install times of 1-2 hours by 1 technician

2.

No specialized tools

3.

Remote and local configuration

  • 2. Vehicle Repair Philosophy

1.

Built in diagnostics

2.

Unit replacement for rapid return to operation of vehicle

3.

Estimated times <5mins

  • 3. Service Level Agreements and Support Philosophy

1.

Encouraged that due to design and ease of install/replacement, customer provides 1st line support with PBE supporting on site if required

2.

Level of expertise required is technician with a basic level of training

slide-5
SLIDE 5

Innovating Safety. Powering Productivity.

PAS Z & ZR Overview

Benefits of the PAS System

5

  • 1. The PAS Z is a cost effective tag based solution for above & below ground

– the ZR is a ruggedized version

  • 2. Suitable for mines, worksites, depots, temporary possessions and

hazardous areas

  • 3. Accurate range and direction for all vehicles, personnel, obstacles and

assets

  • 4. Audio and visual warnings with the option of an external strobe/siren
  • 5. All events logged internally with an extensive reporting capability
  • 6. Simplistic local configuration or user friendly software for future

download

  • 7. Wi-Fi and 3G capabilities to allow remote monitoring and configuration
  • 8. Self-contained for simplistic and quick installation
slide-6
SLIDE 6

Innovating Safety. Powering Productivity.

PAS Z & ZR Features

Overview of the features

6

  • 1. Multiple technologies for redundancy and accuracy
  • 2. User definable ranges (Urgent, Mid and Far)
  • 3. Customizable audio and visual warnings
  • 4. Advanced monitoring and reporting systems
  • 5. Geo-fencing capability
  • 6. 4 outputs and 4 inputs alarms allowing optional control

and interaction with vehicle and machines

  • 7. Recognizes 4 user definable groups, such as personnel,

assets, vehicle types, visitors, obstacles etc.

  • 8. Critical reports for daily review and full data capture for offsite analysis
  • 9. Compatible with PBE’s tracking system and entry/exit system functionality for an integrated solution
  • 10. Powered via the ignition circuit of the vehicle/machine or via an auxiliary power source
slide-7
SLIDE 7

Innovating Safety. Powering Productivity.

Technologies Used

4 technologies to provide redundancy and accuracy over long distances

7

  • 1. Multiple detection technologies - EM (Electromagnetics), RFID, GPS & bi-directional Radar
  • 2. GPS receiver for surface tracking and defining site geo-fencing
  • 3. Magnetic solid state compass
  • 4. Wi-Fi and 3G data capture and backhaul capabilities
  • 5. USB port for configuration and data extraction without wireless connectivity

FREQUENCIES ITU Region 1 ( EMEA) ITU Region 2 (Americas) ITU Region 3 (Asia/Oceania) RFID 868.3MHz 915MHz 920MHz Radar 4.5GHz 4.5GHz 6.5GHz Electromagne<c (EM) 122.1kHz 122.1kHz 122.1kHz

slide-8
SLIDE 8

Innovating Safety. Powering Productivity.

PAS Technology Overview

Combining 4 technologies to provide all range protection and redundancy

  • 1. All technologies have restrictions but a combination can provide accuracy, range and direction
  • 2. PAS uses the most accurate of the combined technologies, dependent on vehicle type, application or

requirement

  • 3. Precedence for each technology can be defined

8

RANGE & ACCURACY ESTIMATIONS Range Accuracy Notes RFID ≈ 60m, 200A Zonal awareness Accuracy limited, communicaJons channel only for EM and GPS. External antenna opJonal Radar ≈ 100m, 300A ≈ 0.3m, 1A Requires parJal line of sight, external antenna available as an opJon Electromagne<c ≈ 10m, 30A ≈ 0.3m, 1A None line of sight GPS Autonomous 2.5 m ( ≈ 8.2 A) CEP; SBAS = 2.0 m ( ≈ 6.56 A.) CEP

slide-9
SLIDE 9

Innovating Safety. Powering Productivity.

General Specifications

High level specifications for the PAS Z & ZR

9

GENERAL SPECIFICATION PAS Z Enclosure Dimensions 6.014(L) x 4.008(W) x 1.502(D) inches 152.8(L) x 101.8(W) x 38.2(D) millimeters PAS ZR Enclosure Dimensions 6.14 (L) x 4.95 (W) x 4.45 (D) inches 155.96 (L) x 125.73 (W) x 113.03 (D) millimeters Input & IgniJon Voltage 11-15 VDC (OpJonal 24-12VDC convertor available) Temperature 0˚to 70˚C | 32˚F to 158˚F Outputs (4) Dry relay contacts for outputs 1, 2 and 4. Relay 3 reserved for strobe/siren funcJonality with its own 12VDC supply (internally fused) Inputs (4) Input 1 & 2 External Sense (Up to 30VDC) 0-1.2V = 0, >3.3V = 1 Input 3 & 4 Internal Sense (Dry Relay Contracts compaJble) NO = 0, NC =1 Internal Storage Capacity 25GB Warranty 12 Month

slide-10
SLIDE 10

Innovating Safety. Powering Productivity.

PAS Z Unit

Compact solution designed for in vehicle/cab use

10

  • 1. Designed for in-cab mounting
  • 2. Powered via a 12VDC source

(either via the ignition circuit

  • r auxiliary power source)
  • 3. Built in RFID, Radar & GPS as

standard, up to 4 EM Sensors

  • ptional
slide-11
SLIDE 11

Innovating Safety. Powering Productivity.

11

PAS Z Connections

Compact unit for quick deployment

(i.e. Optional sounder/ Strobe

  • r Creep & Brake functionality)
slide-12
SLIDE 12

Innovating Safety. Powering Productivity.

12

PAS ZR Ruggedized Unit

IP65 unit for external mounting

  • 1. Same functionality as the PAS Z but

contained within a ruggedized box and external connectors

  • 2. Can be mounted within the cab if

extra protection required or external to the cab

slide-13
SLIDE 13

Innovating Safety. Powering Productivity.

13

PAS Z Connections

Compact unit for quick deployment

slide-14
SLIDE 14

Innovating Safety. Powering Productivity.

Display Operation

How range and direction is shown

  • 1. Distance to the closest object is displayed
  • 2. The total number of each object type is indicated in the 4

counters, showing how many of that object in each of the 3 zones

  • 3. Radial lines of LEDs emanating from the center indicate the

angle of detected tagged objects

  • 4. Bearing is achievable by EM, Radar and GPS – if no bearing is

available the circle will provide zone indication

  • 5. A sensor will provide automatic dimming in bright conditions
  • 6. The arrows allow for complete local configuration of the

system and fault finding

14

PAS Display

slide-15
SLIDE 15

Innovating Safety. Powering Productivity.

PAS PT-Tag and Notifications

Personnel tag functionality

  • 1. Personnel tag contains all 4

technologies

  • 2. Same tag used in PBE’s tracking

solution

  • 3. LED performance indicators
  • 4. Power indicator
  • 5. Sounder and LED indication when

within a set distance of vehicle

  • 6. 25, 10 and single charging stations

available – acts as a tally board

  • 7. Tag test stations available

15

RFID EM GPS RADAR RED Aiached to PAS-110 Lightbar Invalid EM recepJon On but no fixed GPS posiJon Radar out of range GREEN Aiachment to Lightbar pending user acknowledgement Valid EM recepJon GPS posiJon fixed 2 way comms tag & PAS – System OK BLUE RFID packet transmimng EM packet transmimng GPS packet transmimng The tag recognizes a PAS system but the PAS system is not picking up the tag

PT-Tag LED Indications Tag Charging Station LED Indications

slide-16
SLIDE 16

Innovating Safety. Powering Productivity.

IPT Tag

In line tag for any wired cap lamp

  • 1. Unique ID for each tag
  • 2. Installed in-line with the cap lamp’s cable
  • 3. Compatible with virtually any wired cap lamp
  • 4. PAS (Proximity Alert System) compatible technologies including RFID,

GPS, EM, and Radar (model dependent)

  • 5. Built in sounder for audible alerts
  • 6. LED visual indicators on three (3) sides of tag for proximity alerts –
  • ffers multiple viewing angles
  • 7. Push button for alert acknowledgment and tag attachment
  • 8. Real Time Tracking and equipment control (Responsible Ventilation)
  • ffered through PBE Vantage
  • 9. Emergency evacuation (UHF or VHF) and flashing cap lamp options
  • 10. Convenient field installation

16 Zone Audible Alert Visual Alert Far Flash Yellow Single Beep Mid Flash Orange Double Beep Close Flash Red Triple Beep Urgent Double Flash Red Constant Beeping

slide-17
SLIDE 17

Innovating Safety. Powering Productivity.

PAS Lightbar

Providing attachment functionality and an additional driver warning aid

Colour/Indica<on Descrip<on Off No tag detected White Closest tag in far zone Yellow Closest tag in mid zone Red Solid Closest tag in close zone Red Flashing Closest tag in urgent zone Red Fast Flashing CauJon Alarm

17

  • 1. The attachment functionality for the PAS system is provided

by a lightbar assembly

  • 2. The PAS-Z requires a separate lightbar, the PAS-ZR has the

lightbar built into the assembly

  • 3. The lightbar also provides additional warning to the driver:
slide-18
SLIDE 18

Innovating Safety. Powering Productivity.

  • 1. Cap Lamp Tag:

1.

Tag designed to be inserted into existing cap lamp (or provided as new)

2.

Power taken from the cap lamp battery

3.

The Cap Lamp Tag has an Inline Proximity Tag (IPT), that will provide an audible and visual indication for the user

  • 2. Obstacle Tag:

1.

Same as Tag functionality, but in a robust enclosure

2.

Used for locating assets/obstacles/machines or providing to visiting vehicles

3.

Provides the users of the PAS system warning to the assets/obstacles/ machines

4.

Clear indications on the front panel

5.

Charged via a USB port

18

Cap Lamp Tag and PAS-O

Convenient tag inserted into the cap lamp assembly and additional Obstacle tag

Obstacle Tag Cap lamp Assembly with IPT

slide-19
SLIDE 19

Innovating Safety. Powering Productivity.

Configuration, Control & Monitoring

  • 1. The PAS Z & ZR have software to allow configuration, control

and monitoring­

  • 2. The information can be transferred to the PAS unit via a USB

stick or via Wi-Fi/3G connectivity

  • 3. Each unit has a configuration file that can be stored or

changed off-line for later download

  • 4. Reports are also accessed via the software

19

Software Menus Accessible data

slide-20
SLIDE 20

Innovating Safety. Powering Productivity.

Configuration – Set Up

General vehicle and warning set up

20

Adjustable volume control Set the vehicle dimensions Drag and drop sensor posiJoning, EM and GPS Each of the 3 zones can be independently set for each tag group Different alerts for the 4 different tag groups Different alerts for the 4 different tag groups

slide-21
SLIDE 21

Innovating Safety. Powering Productivity.

21

Linked tags allows certain tags to be non-alarming, however sJll monitored Controls the display types and user preferences Geo Fencing for hazardous areas, will alarm is vehicle or machines enters

  • r leaves zone

Set the compass (required for GPS posiJoning) System menu provides addiJonal configurable screen, including reports and

  • config. export

Control of the input and

  • utput digital

relays

Configuration – Set Up

Further configuration options

slide-22
SLIDE 22

Innovating Safety. Powering Productivity.

Additional Functional

Linking & attachments

22

Linking Attachment Suppresses Audible Warnings Yes Yes Suppresses Visual Warnings Yes Yes Global or Local Feature Local Global Suppression Intended For External Objects Occupants Remembered Across Power Cycles No No

  • 1. Attachments

1.

RF Bubble is set up around the PAS equipment (approx. 1m max)

2.

The driver “attaches” his tag to the vehicle by pressing the tag button twice

3.

No alarm will be generated by that machine for that tag (activity still recorded)

4.

The driver will then not set off other vehicle alarms because he is attached to that vehicle

  • 2. Linking

1.

The PAS system can be linked to single or multiple vehicles (pre defined via the software)

2.

Typical use is when one vehicle loading another or

  • perating in close proximity

3.

Performed when TAG is in the urgent zone

4.

Driver links tags by tapping the a button the PAS Z & ZR

slide-23
SLIDE 23

Innovating Safety. Powering Productivity.

Issuing Station

Control & monitoring of tag allocation

23

  • 1. The issuing station controls the issuing and returning of

the PT-TAG’s allocated to staff and visitors.

  • 2. The station monitors the number of tags in and out of

the system, providing an automated electronic tally board.

  • 3. All user details including tag test results are saved in a

SQL database.

  • 4. The user biometrics is captured at the terminal along

with compulsory user details such as company ID, telephone and contact details etc.

Issuing screen with finger print scan and user details Issuing screen user enrollment

slide-24
SLIDE 24

Innovating Safety. Powering Productivity.

PAS On-Site Testing Stations

In field testing stations for tags and vehicle units

  • 1. Independent units to provide on site verification of system

performance

  • 2. This is in addition to the PAS system having an internal start up

procedure and fault diagnosis

  • 3. The TAG Testing Station verifies all tag technologies are fully

functional

1.

Tag presented within approx. 0.5m

2.

Simplistic Green Pass/Red Fail indication

  • 4. Vehicle Testing Station provides:

1.

After initial commissioning records Vehicle ID, Number of Sensors, Technologies

2.

Vehicle passes close to check station for verification vs. past configuration

3.

Simplistic Green Pass/Red Fail indication with unknown vehicles showing as yellow

24

TAG Testing Station Equipment Vehicle Testing Station

slide-25
SLIDE 25

Innovating Safety. Powering Productivity.

Wi-Fi & 3G Capability

Simplistic data retrieval and configuration uploads

  • 1. Wi-Fi or 3G provides a convenient way of

uploading new configurations or downloading data from the vehicle for analysis via the reporting software

  • 2. Local Wi-Fi access points or use of 3G network

allow for constant downloading of data to a computer located in the service hut – allowing real time viewing of incidents and reporting

25

PAS Equipped Vehicle

IP Network 3G Network

Wifi Access Point Wifi Access Point PBE Vantage

slide-26
SLIDE 26

Innovating Safety. Powering Productivity.

PAS Networking (Windows Tablet)

View the software on suitable tablets via Wi-Fi

26

MODEL PAS-ZR-E

(FRONT VIEW)

ETHERNET

WIFI ROUTER TABLET WITH WIFI

  • 1. The ability to view full display functionality on an LCD display instead of the LED of a PAS-Z/ZR
  • 2. Connects via Wi-Fi trough a 3rd party router
slide-27
SLIDE 27

Innovating Safety. Powering Productivity.

PAS Reports

The complete portfolio provides extensive reporting capability

  • 1. Downloaded via the USB port or via Wi-Fi/3G for analysis
  • 2. Every event is recorded, that can be replayed in real time or through reports
  • 3. Flexible analysis e.g. incidents per shift, danger zone analysis, vehicle monitoring, individual worker etc.
  • 4. Predictive - identifies safety issues thus allowing training to increase safety, before an accident happens
  • 5. Graphs available:

1.

Urgent Zone (Counts/Times)

2.

Zone (Counts/Times)

3.

Distance (Counts/Times)

4.

Speed (Counts/Times)

5.

Proximity (Counts/Times)

  • 6. Period:

1.

Flexible from years to seconds

Simplistic operation Multiple display type

27

slide-28
SLIDE 28

Innovating Safety. Powering Productivity.

  • 1. Accurate provision of range accuracy and direction to all PAS LV, PAS

LV-Z and personnel

  • 2. RFID, GPS and 2-6* EM sensors (*depending on vehicle size) and Radar
  • 3. In addition to the functionality of the PAS Z & ZR, the PAS C offers:

1.

Radar type representation of all vehicles, people and assets

2.

Programming on the computer display

3.

Interactive display

4.

Full local on site reporting (can be downloaded for external review)

5.

Optional cameras

PAS C

Solution for large vehicles/machines

28

slide-29
SLIDE 29

Innovating Safety. Powering Productivity.

Entry & Exit / Tracking

Monitoring personnel and vehicles/machines for safety

  • 1. Using the same PAS tags, personnel and equipment

tracking was developed specifically to enable real time above & underground tracking of all personnel and equipment

  • 2. Tracking can be set up to enable entry and exit,

electronic tag boards, zonal positioning or real-time positioning of all equipment and personnel

  • 3. Provides for extensive data collection, real-time

management and reports

Tracking Software High powered tag readers Temporary mesh networks for tracking 29
