Part2: Analysis

Prepared by: Paul Funkenbusch, Department of Mechanical Engineering, University of Rochester

 Review  ANOM  ANOVA

• Error estimate  Replication vs. Pooling
• ANOVA table
• Judging statistical significance

DOE mini-course, part 2, Paul Funkenbusch, 2015 2

Terms

Example

(measure the volume of a balloon as a function of temperature and pressure)

 Factors  variables whose

influence you want to study.

 Levels specific values given

to a factor during experiments (initially limit ourselves to 2- levels)

 Treatment condition  one

running of the experiment

 Response  result measured

for a treatment condition

 Temperature,

Pressure

 50C, 100C

1Pa, 2Pa

 Set T = 50C, P = 1Pa

and measure volume

 measured volume

DOE mini-course, part 2, Paul Funkenbusch, 2015 3

Leve vel Factor

• 1

+1

• X1. Temperature (C)

50 100

• X2. Pressure (Pa)

1 2 TC TC X1 X1 X2 X2 y 1

• 1
• 1

y1 2 +1

• 1

y2 3

• 1

+1 y3 4 +1 +1 y4 etc.

DOE mini-course, part 2, Paul Funkenbusch, 2015

Use X1, X2, etc. to designate factors. Use -1, +1 to designate levels X1 at level -1 means T = 50 C Use a table to show factor levels and response (a) for each treatment condition. For example, during TC2, set T = 100C and P = 1Pa, measure the balloon volume = y2

y  response y = volume of balloon

4

 Test all combinations  Responses  4 DOF

• 4 measured (y) values

 Effects  4 DOF

• 4 values calculated
• m* = (y1+y2+y3+y4)/4
• DX1 = (y3+y4)/2 - (y1+y2)/2
• DX2 = (y2+y4)/2 - (y1+y3)/2
• D12 = (y1+y4)/2 - (y2+y3)/2

 Model  4 DOF

• 4 constants in model
• ypred = ao+a1X1+a2X2+a12X1X2

DOE mini-course, part 2, Paul Funkenbusch, 2015

Leve vel Factor

• 1

+1

• X1. Temp (C)

50 100

• X2. Pressure (Pa)

1 2 TC TC X1 X1 X2 X2 X1*X2 *X2 y 1

• 1
• 1

+1 y1 2

• 1

+1

• 1

y2 3 +1

• 1
• 1

y3 4 +1 +1 +1 y4

5

 Most basic level of analysis  Which effects are largest (which

factors/interactions most important)?

 Which levels produce the best (highest or

lowest) responses?

 Just based on the D values

• you’ve already done this

DOE mini-course, part 2, Paul Funkenbusch, 2015

   

1 1

m

• m

1 level at response average

• 1

level at response average

 

    D

6

Sign and Magnitude of D Graphically

 Positive D

• +1 level should increase

the response

• -1 level should decrease

the response

 Negative D  reversed  Magnitude of D

• Indicates relative

importance

DOE mini-course, part 2, Paul Funkenbusch, 2015

m* A-1 A+1 B-1 B+1

 Choose A-1 and B+1 to

increase response

 A is more important

7

 Can treat interactions terms the same way  Larger D  more important interaction  If interactions are large  “best settings” to

increase (or decrease) the response will depend

• n the combination of factor levels

 Use model to test different combinations

• ypred = ao+a1X1+a2X2+a12X1X2

DOE mini-course, part 2, Paul Funkenbusch, 2015 8

DOE mini-course, part 2, Paul Funkenbusch, 2015

Leve vel Factor

• 1

+1

• X1. applied load (kg)

2 3

• X2. previous cuts

(new) 20

 From part I.  Removal rate of

• steotomy drills vs.

applied load and number of cuts.

 Which effects are

most important?

 How can you

increase the removal rate?

TC TC X1 X1 X2 X2 X1*X2 *X2 Remov

• val

al rate (mm3/s) /s) 1

• 1
• 1

+1 3 2

• 1

+1

• 1

2 3 +1

• 1
• 1

5 4 +1 +1 +1 2

9

DOE mini-course, part 2, Paul Funkenbusch, 2015

 Effects

• DX1 = +1
• Dx2 = -2
• D12 = -1

 Number of previous cuts is most important  new drill (level -1) will increase removal rate the most  Applied load and the interaction are comparable  higher load (level +1) will increase removal rate  but need to test combinations (since interaction is

important too).

Factor Leve vel

• 1

+1

• X1. applied load (kg)

2 3

• X2. previous cuts

(new) 20

10

DOE mini-course, part 2, Paul Funkenbusch, 2015

 ypred = 3.0 + (0.5)X1 - (1.0)X2 - (0.5)X1X2  Set X2 = -1 (Much larger than X1 and interaction)  What is best level for X1?

• For X1 = -1, X2 = -1  ypred = 3.0
• For X1 = +1, X2 = -1  ypred = 5.0

 Best settings X1 = +1 (3kg load), X2 = -1 (new drill)  Note; This is a synergistic interaction,

• Best level for interaction (-1) corresponds to best factor levels

[X1X2 = (+1)(-1) = -1]

• Interaction enhances effects of “best” factor level choices

 For an anti-synergistic interaction,

• Conflict between best factor settings and best interaction level
• Best overall settings then depend on relative strength of the

interaction vs. factor

11

 Second level of analysis  Which of the observed effects are statistically

significant?

• Based on comparing observed effects against an estimate
• f error.
• Compares D2 for factors and interactions with D2 for

error.

• Actually compare “mean square” or “MS”  proportional

to D2

 How much does each factor/interaction contribute

to the total variance in system?

DOE mini-course, part 2, Paul Funkenbusch, 2015 12

Replication Pooling of higher-order interactions



Repeat (replicate) each of the treatment conditions



Independent experimental runs (not multiple measurements from the same TC)



Differences in the responses measured for identical TCs run at different times provide error



“Pure error”  not dependent on modeling assumptions



Best way to estimate error, but greatly increases effort

DOE mini-course, part 2, Paul Funkenbusch, 2015



Assume that higher-order interactions are unimportant/zero



Must choose these interactions upfront (before examining results)  these form a “pool” for error



Effects measured for pooled interactions are used to estimate error



“Error”  includes modeling error (i.e. assumptions about interactions)



Requires less experimental effort, but error estimate is not as good

13

TC TC X1 X1 X2 X2 y 1

• 1
• 1

y1 2

• 1

+1 y2 3 +1

• 1

y3 4 +1 +1 y4

DOE mini-course, part 2, Paul Funkenbusch, 2015

1b

• 1
• 1

y1b 2b

• 1

+1 y2b 3b +1

• 1

y3b 4b +1 +1 y4b TC TC X1 X1 X2 X2 y 1a

• 1
• 1

y1a 2a

• 1

+1 y2a 3a +1

• 1

y3a 4a +1 +1 y4a

 Original design two factors at 2-

levels

 4 DOF  m*, DX1, Dx2, D12  Replicated design (2x)  8 DOF total  4 DOF  m*, DX1, Dx2, D12  + 4 DOF for error  Contrast responses measured

under nominally identical TC

2X

14

DOE mini-course, part 2, Paul Funkenbusch, 2015

 Test more factors. Increase size and DOF.  Example: three 2-level factors instead of two.  8 DOF total

1 DOF for m* 3 DOF for factors DX1, DX2, DX3 3 DOF for 2-factor interactions D12, D13, D23 1 DOF for 3-factor interaction D123

 Pool all interactions  decide before examining results  assess m*, DX1, DX2, DX3 (4 DOF)  use D12, D13, D23 ,D123 for error (4 DOF)

TC TC X1 X1 X2 X2 X3 X3 y 1

• 1 -1 -1 y1

2

• 1 -1 +1 y2

3

• 1 +1 -1 y3

4

• 1 +1 +1 y4

5 +1 -1 -1 y5 6 +1 -1 +1 y6 7 +1 +1 -1 y7 8 +1 +1 +1 y8

Note: alternative choice (pool only the highest order , 3- factor,interaction) is possible, but only leaves 1 DOF for the error estimate  not desirable. For larger experiments this is not as much of a constraint (more higher-order interactions that can be pooled).

15

 24 = 16TC = 16 DOF

• m*

 1 DOF

• factors

 4 DOF

• 2-factor inter.

 6 DOF

• 3-factor inter.

 4 DOF

• 4-factor inter.

 1 DOF

 Pool 3 and 4 factor int.

• Assess factors and 2-factor

interactions

• 5 DOF for error estimate

 25 = 32TC = 32 DOF

• m*

 1 DOF

• factors

 5 DOF

• 2-factor inter.

 10 DOF

• 3-factor inter.

 10 DOF

• 4-factor inter.

 5 DOF

• 5-factor inter.

 1 DOF

 Pool 4 and 5 factor int.

• Assess factors and 2-factor

and 3-factor interactions

• 6 DOF for error estimate

DOE mini-course, part 2, Paul Funkenbusch, 2015

Four 2-level factors Five 2-level factors

16

 Best for:

• small numbers of factors
• systems with large

uncertainties

DOE mini-course, part 2, Paul Funkenbusch, 2015

“Pure error” (no modeling assumptions needed) Assess more factors for same effort (or same number of factors for less effort)

 Best for:

• large numbers of factors
• systems with strong

time/cost constraints on experimental size

17

Source ce SS SS DOF MS MS F p % SS A 100 1 100 20 0.011

56

B 50 1 50 10 0.034

28

AxB 10 1 10 2 0.230

6

error 20 4 5

• 11

Total 180 7

• 100

 Typical way of presenting ANOVA results.  Explain each column so you can interpret these

results.

 Most software packages will output their analysis in

some variant of this format.

 Will also show how you can do the calculations.

DOE mini-course, part 2, Paul Funkenbusch, 2015 18

Source ce SS SS DOF MS MS F p % SS X1 100 1 100 20

0.011 56

X2 50 1 50 10

0.034 28

X1X2 10 1 10 2

0.230 6

error 20 4 5

• 11

Total 180 7

• 100

 ANOVA works by determining how much of the variance in the

experiment can be attributed to each source.

 Sources are factors, interactions, and the error.

• Interactions “pooled” to get error are included in the error row and do

not appear as a separate source (don’t double count them).

 The “Total” includes everything except terms which are

attributed to the overall average (i.e. m*).

DOE mini-course, part 2, Paul Funkenbusch, 2015 19

Source ce SS SS DOF MS MS F p % SS X1 100 1 100 20 0.011

56

X2 50 1 50 10 0.034

28

X1X2 10 1 10 2 0.230

6

error 20 4 5

• 11

Total 180 7

• 100

 Total  variance of the responses about the overall average.

(summation over all treatment conditions)

 For 2-level (factor or interaction) in a factorial design:

SS = D2 х (# of TC)/4

 Can obtain the error term by subtraction.

DOE mini-course, part 2, Paul Funkenbusch, 2015

   





n 1 = i 2 i

* m = SS Total y

Measures the variance attributable to each effect (factor

• r interaction)

20

Source ce SS SS DOF MS MS F p % SS X1 100 1 100 20

0.011 56

X2 50 1 50 10

0.034 28

X1X2 10 1 10 2

0.230 6

error 20 4 5

• 11

Total 180 7

• 100

 Total  One less than the total number of treatment

conditions (i.e. one less than the # of responses).

• Because 1 DOF is used in calculating m*

 For 2-level (factors or interactions)  1 DOF  Can obtain the error term by subtraction.

DOE mini-course, part 2, Paul Funkenbusch, 2015 21

Source ce SS SS DOF MS MS F p % SS X1 100 1 100 20 0.011

56

X2 50 1 50 10 0.034

28

X1X2 10 1 10 2 0.230

6

error 20 4 5

• 11

Total 180 7

• 100

 SS “normalized” against the DOF  For 2-level (factors or interactions)  1 DOF  MS = SS  For error, averages the different measurements of the

error variance.

DOE mini-course, part 2, Paul Funkenbusch, 2015 22

Source ce SS SS DOF MS MS F p % SS X1 100 1 100 20 0.011

56

X2 50 1 50 10 0.034

28

X1X2 10 1 10 2 0.230

6

error 20 4 5

• 11

Total 180 7

• 100

 Compares size of effect with error  The larger the F, the more likely an effect is “real”  But judging statistical significance also depends on the DOF for

the effect, the DOF for the error, and chosen significance level.

 Having at least 2 (and preferably 3 or 4) DOF for error greatly

improves chances of identifying statistically significant effects.

DOE mini-course, part 2, Paul Funkenbusch, 2015 23

 Standard tables are available in most statistics textbooks to

determine the critical value of F based on the DOF for error, DOF for effect, and the chosen significance level a).

 a estimates the chance that an F value larger than the critical

value could occur randomly (i.e. even if the effect was not real)

 If F > Fcritical , the factor or interaction is judged statistically

significant.

DOE mini-course, part 2, Paul Funkenbusch, 2015

DOF (error) DOF (effect) 1 2 3 1 161.45 199.50 215.71 2 18.51 19.00 19.16 3 10.13 9.55 9.28 4 7.71 6.94 6.59 Critical F for a = 0.05 Portion of an a = 0.05 table

(Note the very high values when there is only 1 DOF for error.)

24

 Use a  0.05  Fcritical = 7.71  F (X1) = 20 > Fcritical  X1 significant  F (X2) = 10 > Fcritical  X2 significant  F (X1X2) = 2 < Fcritical  X1X2 not significant

DOE mini-course, part 2, Paul Funkenbusch, 2015

Source ce SS SS DOF MS MS F X1 100 1 100 20 X2 50 1 50 10 X1X2 10 1 10 2 error 20 4 5

• Total

180 7

• 25

Source ce SS SS DOF MS MS F p % SS X1 100 1 100 20

0.011 56

X2 50 1 50 10

0.034 28

X1X2 10 1 10 2

0.230 6

error 20 4 5

• 11

Total 180 7

• 100

 Difficult/cumbersome to determine p values “manually”. But,

commonly provided by statistical software packages

 Estimates how likely an F value as big as that observed is to have

• ccurred randomly (i.e. if the effect was not real)

 p values below a chosen a value (typically = 0.05)  indicate

statistical significance

 p depends on the DOF (effect) and DOF (error) in addition to F

DOE mini-course, part 2, Paul Funkenbusch, 2015 26

 Choose a significance level, a  0.05  p (X1) = 0.011 < 0.05  X1 significant  p (X2) = 0.034 < 0.05  X2 significant  p (X1X2) = 0.23 > 0.05  X1X2 not significant

DOE mini-course, part 2, Paul Funkenbusch, 2015

Source ce SS SS DOF MS MS F p % SS X1 100 1 100 20 0.011

56

X2 50 1 50 10 0.034

28

X1X2 10 1 10 2 0.230

6

error 20 4 5

• 11

Total 180 7

• 100

27

Source ce SS SS DOF MS MS F p %SS X1 100 1 100 20 0.011 56 X2 50 1 50 10 0.034 28 X1X2 10 1 10 2 0.230 6 error 20 4 5

• 11

Total 180 7

• 100

 Sometimes used to measure the

“importance” of each factor/interaction

 How much of the total variance in the

experiment can be attributed to each of the factors/interactions?

DOE mini-course, part 2, Paul Funkenbusch, 2015

84% of the total variance can be attributed to the two factor effects.

28

1b

• 1
• 1

+1 3.2 2b

• 1

+1

• 1

1.9 3b +1

• 1
• 1

5.3 4b +1 +1 +1 1.8

DOE mini-course, part 2, Paul Funkenbusch, 2015

 Data on the removal

rate of osteotomy drills is collected as a function of the load applied and the number of previous cuts made.

 Assume the data

was collected as part of an experiment with one replication

TC TC X1 X1 X2 X2 X1*X2 *X2 Remov

• val

al rate (mm3/s) /s) 1a

• 1
• 1

+1 2.8 2a

• 1

+1

• 1

2.1 3a +1

• 1
• 1

4.7 4a +1 +1 +1 2.2

29

DOE mini-course, part 2, Paul Funkenbusch, 2015

Effects

m* = +3 DX1 = +1 Dx2 = -2 Dx1x2 = -1

 X1

• SS = D2*(# of TC)/4 = 12*(8)/4 = 2; DOF = 1

 X2

• SS = D2*(# of TC)/4 = (-22)*(8)/4 = 8; DOF = 1

 X1X2

• SS = D2*(# of TC)/4 = 12*(8)/4 = 2; DOF = 1

 Total

• DOF = (# of TC) – 1 = 8 – 1 = 7

 Error (by subtraction)

• SS = 12.36 – (2 + 8 + 2) = 0.36
• DOF = 7 – (1 + 1 + 1) = 4

       

36 . 12 3 8 . 1 ... 3 1 . 2 3 8 . 2 * m = SS

8 1 2 2 2 n 1 = i 2 i

       

 

 i

y

30

DOE mini-course, part 2, Paul Funkenbusch, 2015

 Judge X1 (load), X2 (previous # of cuts), and X1X2

(interaction between load and # of cuts) significant.

Source ce SS SS DOF MS MS F X1 2 1 2 22.2 X2 8 1 8 88.8 X1X2 2 1 2 22.2 error 0.36 4 0.09

• Total

12.36 7

• F critical = 7.71

for a  0.05 Critical F for a = 0.05

31

 ANalysis OF Means (ANOM)

• Which effects are largest (which factors/interactions most

important)?

• Which levels produce the best (highest or lowest) responses?

 ANalysis Of VAriance (ANOVA)

• Which of the observed effects are statistically significant?

 Error estimate

• Replication  pure error, multiplies required effort
• Pooling  requires upfront assumptions (sparsity of effects)

DOE mini-course, part 2, Paul Funkenbusch, 2015 32

 This material is based on work supported by

the National Science Foundation under grant CMMI-1100632.

 The assistance of Prof. Amy Lerner and Mr.

Alex Kotelsky in preparation of this material is gratefully acknowledged.

 This material was originally presented as a

module in the course BME 283/483, Biosolid Mechanics.

33 DOE mini-course, part 2, Paul Funkenbusch, 2015
