Sources of Field Perturbations LLRF Lecture Part2 S. Simrock, M. Grecki ITER / DESY RF System Architecture S. Simrock & M. Grecki, 5 th LC School, Switzerland, 2010, LLRF & HPRF 2 Sources of Field Perturbations o Beam loading o

slide-1
SLIDE 1

Sources of Field Perturbations

LLRF Lecture Part2

  • S. Simrock, M. Grecki

ITER / DESY

slide-2
SLIDE 2
  • S. Simrock & M. Grecki, 5th LC School, Switzerland, 2010, LLRF & HPRF

2

RF System Architecture

slide-3
SLIDE 3
  • S. Simrock & M. Grecki, 5th LC School, Switzerland, 2010, LLRF & HPRF

3

Sources of Field Perturbations

  • Beam loading
  • Beam current fluctuations
  • Pulsed beam transients
  • Multipacting and field emission
  • Excitation of HOMs
  • Excitation of other passband modes
  • Wake fields
  • Cavity dynamics
  • cavity filling
  • settling time of field
  • Cavity resonance frequency change
  • thermal effects (power dependent)
  • Microphonics
  • Lorentz force detuning
  • Cavity drive signal
  • HV- Pulse flatness
  • HV PS ripple
  • Phase noise from master oscillator
  • Timing signal jitter
  • Mismatch in power distribution
  • Other
  • Response of feedback system
  • Interlock trips
  • Thermal drifts (electronics, power

amplifiers, cables, power transmission system)

slide-4
SLIDE 4
  • S. Simrock & M. Grecki, 5th LC School, Switzerland, 2010, LLRF & HPRF

4

Lorenz Force Detuning

slide-5
SLIDE 5
  • S. Simrock & M. Grecki, 5th LC School, Switzerland, 2010, LLRF & HPRF

5

Cavity Deformation by Electromagnetic Field Pressure

  • Radiation pressure
  • Resonance frequency shift

2 acc

E K f ⋅ − = ∆

4

2 2

      − = E H P   ε µ

slide-6
SLIDE 6
  • S. Simrock & M. Grecki, 5th LC School, Switzerland, 2010, LLRF & HPRF

6

Lorenz Force Detuning

  • Effects of Lorenz force detuning

– Change cavity voltage and phase during RF pulse – Generate more reflection power – Limit maximum repetition rate of RF pulses

  • Properties

– Gradient dependent – Predictable from pulse to pulse – Perturbations are correlated from cavity to cavity

slide-7
SLIDE 7
  • S. Simrock & M. Grecki, 5th LC School, Switzerland, 2010, LLRF & HPRF

7

Measurement of Lorentz Force Detuning

slide-8
SLIDE 8
  • S. Simrock & M. Grecki, 5th LC School, Switzerland, 2010, LLRF & HPRF

8

Microphonics

slide-9
SLIDE 9
  • S. Simrock & M. Grecki, 5th LC School, Switzerland, 2010, LLRF & HPRF

9

Sources of Microphonics

  • Mechanical vibrations caused by the accelerator environment are

always present and may be transferred to the cavity.

slide-10
SLIDE 10
  • S. Simrock & M. Grecki, 5th LC School, Switzerland, 2010, LLRF & HPRF

10

Microphonics

  • Effects of microphonics

– It mainly influences the resonance frequency of the cavity and therefore the RF phase with respect to the beam

  • Properties

– Slow perturbation – Not predictable – Uncorrelated along the Linac

slide-11
SLIDE 11
  • S. Simrock & M. Grecki, 5th LC School, Switzerland, 2010, LLRF & HPRF

11

Microphonics at JLAB

slide-12
SLIDE 12
  • S. Simrock & M. Grecki, 5th LC School, Switzerland, 2010, LLRF & HPRF

12

Microphonics at FLASH

slide-13
SLIDE 13
  • S. Simrock & M. Grecki, 5th LC School, Switzerland, 2010, LLRF & HPRF

13

Beam Current (Bunch Charge) Fluctuation

slide-14
SLIDE 14
  • S. Simrock & M. Grecki, 5th LC School, Switzerland, 2010, LLRF & HPRF

14

Beam Loading Effect

  • Single bunch transient is not controllable
  • Bunch charge fluctuation will introduce energy spread
slide-15
SLIDE 15
  • S. Simrock & M. Grecki, 5th LC School, Switzerland, 2010, LLRF & HPRF

15

Bunch Charge Pattern at FLASH

slide-16
SLIDE 16
  • S. Simrock & M. Grecki, 5th LC School, Switzerland, 2010, LLRF & HPRF

16

Phase Noise of Master Oscillator

slide-17
SLIDE 17
  • S. Simrock & M. Grecki, 5th LC School, Switzerland, 2010, LLRF & HPRF

17

Phase Noise of FLASH MO

slide-18
SLIDE 18
  • S. Simrock & M. Grecki, 5th LC School, Switzerland, 2010, LLRF & HPRF

18

Thermal Drift

slide-19
SLIDE 19
  • S. Simrock & M. Grecki, 5th LC School, Switzerland, 2010, LLRF & HPRF

19

Phase Drift of 80 m 7/8“ Reference Line at FLASH

0.25 deg. One way 12 hours

slide-20
SLIDE 20
  • S. Simrock & M. Grecki, 5th LC School, Switzerland, 2010, LLRF & HPRF

20

Error Map

slide-21
SLIDE 21
  • S. Simrock & M. Grecki, 5th LC School, Switzerland, 2010, LLRF & HPRF

21

Reference

[1] T. Schilcher. Vector Sum Control of Pulsed Accelerating Fields in Lorentz Force Detuned Superconducting Cavities. Ph.D. Thesis of DESY, 1998 [2] V. Ayvazyan, S. Simrock. Dynamic Lorenz Force Detuning Studies in TESLA Cavities. EPAC 2004, July 2004.
