Bring Back the Lakes

Revival of Bengaluru Lakes

Date: 13th June’2016

Karnataka Lake Conservation & Development Authority (KLCDA)

Brief History

• The City built by Sri.Kempegowda, 468 years ago, has well-

developed natural drainage system. Bangalore had more than 400 lakes, interlinked by a system of canals (Rajakalave) that followed the natural gradient of the land in which excess water from one lake would flow through waste-weirs into the next lake/ tank, thereby preventing flooding. This system could be maintained for a long time, through the colonial period, till more recent times. This has contributed enormously for creating micro climate in the City as well high level of recharging of ground water in the city.

PART -I – AN OVERVIEW

• Bangalore - “The City of Lakes”
• Kempegowda (16th Century)
• Founder of Bangalore
• Established several tanks for
• Drinking
• Irrigation
• Domestic purposes
• Maintain the water-table
• Flood mitigation
• To enhance the beauty of ‘Garden

City’

Water bodies Area in Acres Kere/ Lake > 3 Gokatte 1-3 Kunte < 1

Lakes of Bengaluru

Details of BBMP areas & Water supply/ Waste water generation in Bengaluru (BWSSB)

• Bruhat Bengaluru Mahanagara Plaike (BBMP) comprises of 800 Sq Kms

consists of core area (245 Sq Kms), erstwhile CMC/ TMC (330 Sq Kms) and 110 Villages (225 Sq Kms)

• BWSSB is supplying 1400 MLD of water from River Cauvery. It is estimated

that about 250 MLD water is utilized from bore well supply (public + private). Total water supply is 1650 MLD.

• Out of the quantity of water supplied, 80% will convert in to wastewater. It

is estimated that 40% of the quantity of wastewater generated will flow towards Vrishabhavathi valley, 40% towards Koramangala and Challaghatta Valley and 20% towards Hebbal valley. Vrishabhavathi valley joins Arkavathy river which in turn joins River Cauvery at Sangam, Kanakapura

• taluk. Koramangala, Challaghatta and Hebbal valleys joins South Pinakini

river which in turn joins Penniyar river.

• As on today, core area & erstwhile CMC/ TMC area covering

550 Sq Kms is supplied with Cauvery water and rest depends

• n bore well water (public & private).
• Core area is provided with UGD network of 3300 Kms lateral

and 300 Kms of sub-mains, mains and trunk sewers. Laterals are repaired/ replaced/ rehabilitated as and when required with Board funds and in case of sub-mains, mains and trunk sewers involves huge costs depends on outside/ external funding

• In respect of erstwhile CMC/ TMC area, providing of UGD

network is in progress under KMRP/ JnNURUM/ State/ Board

• funds. Laterals of 2400 Kms and submains/mains/ trunk

sewers of 340 Kms is being provided as UGD. Work is in progress and expected to be completed by end of 2016. Contd….

• With respect to 110 Villages, a Detailed

Project Report costing Rs.2800 Cr for water supply component and Rs.2300 Cr for UGD facilities including Road restoration totalling to Rs.5100 Cr is approved by GoK, cleared by CPHEEO and now it is with DEA for external funding from JICA. The project includes water supply and 2590 Kms of UGD network. Requires 4 to 5 years for completion when

• nce it is approved.

Contd….

Wastewater Treatment –

• Existing – 14 Nos. – 721 MLD capacity – treating up to

80% capacity due to connectivity problem – works are under progress – full capacity utilization by end of 2016

• Under Constructions – 10 Nos. – 336 MLD capacity –

expected to be completed – K & C Valley by March 2017 – V Valley by end of 2018

• Some of the projects of BWSSB are recently approved

and some of them are in pipeline. After the commissioning of these treatment plants the total treatment capacity will increase to 1761 MLD by 2020.

R.R. Nagar K.R. Puram Yelahanka Byatrayanpura Bommanahalli Mahadevapura Kengeri Dasarahalli Core area 245 Sq. Km 8 ULB 330 Sq. Km 110 Villages 225 Sq. Km Total 800 Sq. Km

Core Area

BWSSB Service Area 800.00 Sq.km

110 Villages

8

B B M P

• K

E Y

• M

A P

Reports

• Expert Committee Report on preservation of lakes

(Sri N. Lakshman Rau, 1986)

• Karnataka Legislature Joint House Committee Report

(Sri A.T.Ramaswamy, 2006)

• On encroachment of Government land (lake bed &

Gomala land)

• Recovery of Public Land - Task Force Report

(Sri V.Balasubramanian, 2011)

• Committee constituted by Hon’ble High Court of Karnataka

(Hon’ble Sri Justice N.K. Patil, 2011)

• Resurvey of lake area & interconnecting lake canals

About KLCDA Act 2014

• Earlier LDA (Lake Development Authority)
• Formulated as KLCDA under the Karnataka Lake

Conservation and Development Authority Act, 2014

• Lakes/ water bodies in the 11 corporations of the

State has been taken under the control

• Major roles are

– Monitor the status of lake in 11 corporations – Maintain the ledgers about the lakes – Approve the DPR for rejuvenation of lakes – Take stringent action on the polluters

PART -II – LEGISLATIVE FRAME WORK

Salient Features of KLCDA

• Government of Karnataka has passed the Karnataka Lake

Conservation & Development Authority Act 2014 vide its Notification No. No.SAMVYASHAE 07 SHASANA 2012, Bangalore dated 07.03.2015.

• The Government has published Rules of Karnataka Lake

Conservation & Development Authority vide notification dated: 05.03.2016.

• The Government has sanctioned 96 posts of different cadres to be

filled by deputation basis vide Government order dated: 11.11.2015.

• The Chief Secretary to Government of Karnataka is the Chairman of

Governing Council of the Authority.

• The Additional Chief Secretary to Government, Forest, Ecology and

Environment Department is the Chairman of Executive Committee

• f the Authority.

• To exercise regulatory control over all the lakes within its

jurisdictions including prevention and removal

• f

encroachment of lake.

• To protect, conserve, reclaim, regenerate and restore lakes to

facilitate recharge of depleting ground water by promoting integrated approach with the assistance of concerned Government departments, local and other authorities.

• The take up environmental planning and mapping of lakes

and their surrounding area with the help of geographical information system and prepare database and atlas of lakes and their catchments.

Important functions of the Authority

• To prepare a plan for integrated development of

lakes.

• To encourage participation of communities and

voluntary and agencies and to launch public awareness programmes for lake conservation, preservation and protection of lakes.

• To do such other acts as the authority may consider

necessary, conducive or incidental, directly or indirectly, to achieve the object of this act.

Important Powers of the Authority

• To cause entry upon or authorize any officer to enter upon any land, to survey,

demarcate and make a map of lakes

• To receive grants, donations, contributions, deposits and rents, and to levy fees
• r charges for development and maintenance of lakes at such rates approved

by the Government.

• The Authority has powers to remove any illegal construction of buildings or

encroachment of lake area etc, seize, evict and confiscate the property and impose penalty.

• To grant technical approval to any project proposal made by any Government

department or organization or association or person interest in developing, maintaining, conserving or protecting a lake and also to take up such activities

• n its own which shall be approved by the Government.
• Act provides to impose penalty of not less than five years imprisonment and

with a fine of rupees one lakh.

KLCDA Bengaluru Jurisdiction

3.57% of Lake Area BBMP Area - 809.49 km2

192 Lakes

Covering of 25.350 Km2

Lakes under KLCDA jurisdiction in Bengaluru (above 3 acres)

SL.NO. NAME OF THE TALUK TOTAL NO. OF LAKES 1 BANGALORE EAST TALUK 104 2 BANGALORE NORTH TALUK 160 3 BANGALORE SOUTH TALUK 147 4 ANEKAL TALUK 60 5 Hosakote Taluk, Bangalore Rural Dist 5 Total 476

Lake details and there custodians in the Bengaluru city

Sl. No. Name of the Department

• No. Of tanks in

Custody

• No. Of Tanks

restored

• No. Of Tanks

under progress No of tanks yet to taken up 1 BBMP 109 53 14 42 2 BDA 92 12 17 63 3 KFD 5

• 5
• 4

KLCDA 4 3 1

• Total

210 68 37 105

Lakes in the Jurisdiction-Mahanagara Palike in Karnataka

Sl No. Name of the Districts Total No of Lakes 1 Belagavi (Belgaum) 8 2 Bellary 4 3 Vijayapura (Bijapura) 2 4 Davangere 2 5 Kalaburgi (Gulbarga) 1 6 Hubli-Dharwad 27 7 Mangaluru (Mangalore) 8 Mysore 8 9 Shimoga 22 10 Tumkur 10 Total 84

Non-Existing Lakes

Kethamaranahalli lake Converted as Ground Agrahara lake Converted as BBMP Ground Makali lake Converted as Warehouse

Kasaba Yeshwantpur lake Converted as Hospital

Issues being faced by the water bodies/ Lakes (BBMP & BDA Area)

Soil Excavation in Gantiganahalli Lake Sand Mining in Kudurigere Lake Encroachment photos

• Dumping of Wastes
• Inflow of Sewage

Weeds

Garbage dump in Basappana Katte Sewage inflow in Andarahalli Lake Weeds in Chikkabanavara Lake Garbage Float in Nellagadarahalli Lake Garbage in Chokkasandra Lake Drain

Encroachment (EMPRI Database)

20 40 60 80 100 120 140

• Bng. North
• Bng. East
• Bng. South

Anekal Hoskote 127 79 126 59 5 65 42 73 34 5

• No. of Lakes

Taluk Name Existing Lakes

• No. of lakes have possible Encroachments

2005 2016

Laggeri-Basappana katte

• Roads
• Park
• Temple
• Residential Houses/ Layout
• Grave Yard
• Agriculture

Water Quality

• KSPCB is monitoring water quality of 48 lakes in Bengaluru City.
• In March 2014, 21 lake are dried, Four Lakes have D class water and

remaining 23 lakes have E class water

• In March’2015, six lakes are dried, Sankey tank water is C class, eight lakes

have D class water and other lakes have class E water

• Since the year 2015-2016, KSPCB is monitoring

75 lakes on monthly basis.

• Result shows that

– 25 lakes have D class water quality – 46 lakes have E class water quality – Four lakes water quality are Below E class

• Somasundra Palya lake, Thigalarapalya lake,

Gangondanahalli lake & Kammasandra lake

Causes

• Major Causes

– Encroachment – Pollution due to entry of sewage and disposal of solid wastes

• Other Causes

– Siltation & excavation of earth – Buffer zone – Broken interlinks of drains/ streams – Lack of awareness among the stakeholders

• 1. Public Private Participation (PPP)
• 2. Rejuvenate lakes through Authorities
• 3. Generate Database through EMPRI
• 4. Initiatives taken under the KLCDA Act
• 5. Rejuvenate lakes under CSR

Initiatives by KLCDA

• Nagavara, Vengaiahnakere & Hebbal lakes
• Court Intervention and stay

Initiative-1: PPP

Initiative-2: Revival through Authorities

Authorities

• No. of Lakes

under custodian Lakes Rejuvenated Lakes under Rejuvenation KLCDA 4 3 1 BBMP 109 53 14 BDA 92 12 17 Forest Department 5

• 5

Total Lakes 210 68 37

* Still 105 lakes have to be restored

• 1. Inventories all the water bodies (Kere, Kunte & Katte)
• 2. Document the present status of water bodies

– Morphometric characteristics – Assess & document the pollution, issues – Assess the water quality

• 3. Create Comprehensive Database using Microsoft Excel
• Morphometric Characteristics with 27 attributes
• Non-Existing water bodies details with 9 attributes
• Water Quality & Biodiversity details with 22 attributes
• Issues include encroachment & pollution such as solid waste dump,

sewage inflow has been included as 15 attributes

• 4. Generate Lake Atlas

Initiative-3: Database by EMPRI

Database

Database Content Attributes Morphometric Characteristics 28 Details of Non-Existing Lakes 2 Water Quality & Biodiversity 17 (12+5) Issues 11 Total 76

– Morphometric Characteristics

Lake Atlas

• Section 5(1) of KLCDA Act envisages that –

“ to exercise regulatory control over all the lakes within its jurisdictions including prevention and removal of encroachment of lakes.”

• Section (11) of KLCDA Act envisages that-

“Authorized officer is a Group A officer of the State Civil Services who shall exercise powers under this Act and such

• ther powers as may be specified by the Government from

time to time.”

• To achieve this objective Government of Karnataka/

Karnataka Lake Conservation & Development Authority has taken action to appoint Authorized officer vide G.O. No.FEE 8 ENV 2016 dated 19.05.2016.

Initiative-4: Appointment of Authorized, Designated & Empowered officer as per the KLCDA Act

• Section 12 of KLCDA Act 2014, KLCDA may designate
• r appoint any officers as Designated officer to be

incharge of one or more lakes to ensure their protection, conservation, development and for any

• ther purpose.
• Section 13 of KLCDA Act 2014, KLCDA may designate
• r appoint any officer as Empowered officer to

carry out any of the works assigned by the Designated officer.

• In this direction KLCDA has already taken action to

appoint Designated and Empowered Officer vide O.M. No.KLCDA/25/EST/2015-16/210 dated 03.06.2016.

• Section 5(10) of KLCDA Act envisages that –

“ to encourage participation of communities and voluntary agencies and to launch public awareness programmes for lake conservation, preservation and protection of lakes.”

• In this direction Government of Karnataka has taken action

to appoint “Lake Warden” vide G.O. No. FEE 99 ENV 2016 dated 19.05.2016 involving public which enables the custodian authority of the lake to have a interface with the public on the issues of lake protection, conservation and

• development. This will help the authorities in taking

action for abating the pollution, encroachment and dumping of debris problem in and around the lakes.

Initiative-4 (Present): Under CSR

• CSR (Corporate Social

Responsibility)

Government of Karnataka has also taken action to organize a Workshop titled “Bring Back the Lakes” to encourage the Industries and Corporate Sectors under the CSR (Corporate Social Responsibility) initiative to support for rejuvenation, restoration, conservation and development of lakes in Bengaluru.

Lake Revival

• Core Works

– Desiltation – Bund Strengthening – Foreshore Planting – Inlet & waste weir restoration – Divert sewage? and construction of STP – Artificial wetland

• Non-Core Works

– Walkways – Boat Jetties – Idol Immersion Tank – Park & Children Play area – Superstructures – Gazebo, Food Courts, Toilet

Nature of works taken up in Lake Development projects

Sl No Particulars

1 Construction of wet land. 2 Strengthening of Bund. 3 RCC drain for sewage / waste water diversion 4 Desilting, Deweeding, Construction of Pathways / Walk ways 5 Construction of Silt trap and screen barriers 6 Improvements to storm water inlets, outlets and catchment area 7 Improvements to outlets Such as Sluice and Waste weir 8 Construction of Kalyani / Tank for Idol immersion 9 Afforestation, Landscaping, development of Garden, plantation around the lake. 10 Developmental activities around the lake for recreational facilities Such as – children’s park, litter bins, fountains, boat jettys, Gazzebos, watch towers etc. 11 Boundary Protection works (Chain link Fencing). 12 Community participation and Environmental Education – if necessary. 13 STP Works if necessary. 14 Electrification such as High mast and park lighting.
