Overview of Quanto ukasz Zubkowicz 17 listopada 2010 ukasz - - PowerPoint PPT Presentation

Introduction to Quanto Some details

Overview of Quanto

Łukasz Zubkowicz 17 listopada 2010

Łukasz Zubkowicz Overview of Quanto

Introduction to Quanto Some details Basic information About project

About authors

University of California (Berkeley): Rodrigo Fonseca, Prabal Dutta Stanford University: Philip Lewis, Ion Stoica

Łukasz Zubkowicz Overview of Quanto

Introduction to Quanto Some details Basic information About project

Support

Two National Science Foundation grants Microsoft Intel HP Sharp

Łukasz Zubkowicz Overview of Quanto

Introduction to Quanto Some details Basic information About project

Purpose

Project’s objective is to measure power draft in a novel approach. It works on HydroWatch embedded systems (MSP430) under TinyOS, but the idea is supposed to work on other configurations as well. Quanto enables energy profiling in real environment what is useful in comparing different project decisions and verifying claims about low energy usage from a number of other projects.

Łukasz Zubkowicz Overview of Quanto

Introduction to Quanto Some details Basic information About project

Terminology

Energy sinks (e.g. radio transceiver, temperature sensor, CPU). Power states (tuples of energy sinks’ power states). (RADIO RX, TEMPSENSOR CONV, CPU SLEEP) Activities (16-bit pairs of node id and activity). (NODE ID, ACTIVITY)

Łukasz Zubkowicz Overview of Quanto

Introduction to Quanto Some details Basic information About project

Input

Project requires real-time data from power switching regulator. The rest of conditions is defined statically (set of tracked activities, possible power states). All energy sinks must be considered completly - otherwise output would be inaccurate.

Łukasz Zubkowicz Overview of Quanto

Introduction to Quanto Some details Basic information About project

Output

Hardware performs energy logging and dumping results to an external destination. Off-line processing allows to recognize energy breakdown among activities during a period of time. Activities are being tracked over the whole network, not

• nly one device.

Łukasz Zubkowicz Overview of Quanto

Introduction to Quanto Some details Basic information About project

Example of results

This picture describes only a form the results might have after

• analysis. It does not show any real data.

Łukasz Zubkowicz Overview of Quanto

Introduction to Quanto Some details Basic information About project

Performance

Why is it so important? The faster, the more accurate it is. Logging takes 102 cycles (Blink example: 71.05% of active time, 0.12% of total time, 0.08% of total energy). Transferring logs to external destinations takes between 4 and 15% of active time, but it doesn’t affect accuracy. The chages introduced to the TinyOS: 1275 new LOC, 350 modified LOC.

Łukasz Zubkowicz Overview of Quanto

Introduction to Quanto Some details Basic information About project

Limitations

Constant per-state power draws. Linear independence. Modifications to system. Energy usage visibility. Hardware energy metering.

Łukasz Zubkowicz Overview of Quanto

Introduction to Quanto Some details Basic information About project

Enabled research

Energy leaks Tracking butterfly effects Real time tracking (on-line processing) Energy-aware operating systems (scheduling) Continuous profiling

Łukasz Zubkowicz Overview of Quanto

Introduction to Quanto Some details Basic information About project

Borrowed solutions/ideas

Energy as a first class resource (ECOSystem). Current metering (iCount). Power breakdown (PowerTOSSIM). Activities as a basic abstraction (RIALTO operating system) and their tracking (EON). Others (like network-wide impact).

Łukasz Zubkowicz Overview of Quanto

Introduction to Quanto Some details Energy tracking Activity tracking

Exposing power states

Device drivers must be enriched to use the following interface:

i n t e r f a c e PowerState { // Sets the powerstate to v a l u e . async command void s e t ( p o w e r s t a t e t v a l u e ) ; // Sets the b i t s r e p r e s e n t e d by mask to v a l u e . async command void s e t B i t s ( p o w e r s t a t e t mask , u i n t 8 t

• f f s e t ,

p o w e r s t a t e t v a l u e ) ; } Łukasz Zubkowicz Overview of Quanto

Introduction to Quanto Some details Energy tracking Activity tracking

Exposing power states - an example

For many peripherals it is very simple to obtain. Below is the example with LEDs:

async command void Leds . led0On () { c a l l Led0PowerState . s e t ( 1 ) ; // S e t t i n g pin to low t u r n s Led on c a l l Led0 . c l r ( ) ; } async command void Leds . l e d 0 O f f () { c a l l Led0PowerState . s e t ( 0 ) ; // S e t t i n g pin to high t u r n s Led

• f f

c a l l Led0 . s e t ( ) ; } Łukasz Zubkowicz Overview of Quanto

Introduction to Quanto Some details Energy tracking Activity tracking

Power state tracking

The core of the Quanto system exposes such an interface to log powerstate changes:

i n t e r f a c e PowerStateTrack { // C a l l e d i f an energy s i n k power s t a t e changes async event void changed ( p o w e r s t a t e t v a l u e ) ; } Łukasz Zubkowicz Overview of Quanto

Introduction to Quanto Some details Energy tracking Activity tracking

Regression

Energy breakdown is calculated off-line. To calculate the results, the weighted multivariate least squares method is implemented. The method requires having collected sufficiently many linearly independent data. The problem is similar to solving a set of linearly independent

• equations. The difference is that data is slightly incorrect

(mostly due to measurement errors).

Łukasz Zubkowicz Overview of Quanto

Introduction to Quanto Some details Energy tracking Activity tracking

API for single activity devices

Components which can perform only one activity at a time must implement the following interface:

i n t e r f a c e S i n g l e A c t i v i t y D e v i c e { // Returns the c u r r e n t a c t i v i t y async command a c t t get ( ) ; // Sets the c u r r e n t a c t i v i t y async command void s e t ( a c t t n e w A c t i v i t y ) ; // Sets the c u r r e n t a c t i v i t y and i n d i c a t e s // that the p r e v i o u s a c t i v i t y s r e s o u r c e // usage should be charged to the new one async command void bind ( a c t t n e w A c t i v i t y ) ; } Łukasz Zubkowicz Overview of Quanto

Introduction to Quanto Some details Energy tracking Activity tracking

API for multiple activity devices

Components which can perform more than one activity at a time must implement the following interface:

i n t e r f a c e M u l t i A c t i v i t y D e v i c e { // Adds an a c t i v i t y to the s e t

• f

c u r r e n t // a c t i v i t i e s f o r t h i s d e v i c e async command e r r o r t add ( a c t t a c t i v i t y ) ; // Removes an a c t i v i t y from the s e t

• f

c u r r e n t // a c t i v i t i e s f o r t h i s d e v i c e async command e r r o r t remove ( a c t t a c t i v i t y ) ; }

Examples of such devices are timers or radio transceivers. Their work may be useful for multiple activities at once.

Łukasz Zubkowicz Overview of Quanto

Introduction to Quanto Some details Energy tracking Activity tracking

Example of an API usage

This is how the high level of API usage for a client programmer should look like:

task void sensorTask () { c a l l CPUActivity . s e t (ACT HUM) ; c a l l Humidity . read ( ) ; c a l l CPUActivity . s e t (ACT TEMP) ; c a l l Temperature . read ( ) ; } void sendIfDone () { i f ( sensingDone ) { c a l l CPUActivity . s e t (ACT PKT ) ; post sendTask ( ) ; sensingDone = 0; } } Łukasz Zubkowicz Overview of Quanto

Introduction to Quanto Some details Energy tracking Activity tracking

Activity propagation - an example

System programmers who develop device drivers are responsible for propagating activity labels should follow more or less the pattern

• n the listing:

void loadTXFIFO () { . . . // prepare packet . . . c a l l R a d i o A c t i v i t y . s e t ( c a l l CPUActivity . get ( ) ) ; c a l l TXFIFO . w r i t e (( u i n t 8 t ∗) header , header− >l e n g t h − 1 ) ; } Łukasz Zubkowicz Overview of Quanto

Introduction to Quanto Some details Energy tracking Activity tracking

Activity tracking

The Quanto’s module for collecting activity data for accounting implements the following interfaces:

i n t e r f a c e S i n g l e A c t i v i t y T r a c k { async event void changed ( a c t t n e w A c t i v i t y ) ; async event void bound ( a c t t n e w A c t i v i t y ) ; } i n t e r f a c e M u l t i A c t i v i t y T r a c k { async event void added ( a c t t a c t i v i t y ) ; async event void removed ( a c t t a c t i v i t y ) ; } Łukasz Zubkowicz Overview of Quanto

Introduction to Quanto Some details

Bibliografia

• R. Fonseca, P. Dutta, P. Levis, and I. Stoica: “Quanto:

Tracking Energy in Networked Embedded Systems“, in Proceedings USENIX OSDI 2008, San Diego, CA, USA, December 2008. All code examples come from the paper listed above.
