[PPT] - Overview of Multivariate Optimization Topics Multivariate PowerPoint Presentation

SLIDE 1

Example 1: Optimization Problem

a1 a2 −5 −4 −3 −2 −1 1 2 3 4 5 −5 5

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

3

Overview of Multivariate Optimization Topics

Problem definition
Algorithms

– Cyclic coordinate method – Steepest descent – Conjugate gradient algorithms – PARTAN – Newton’s method – Levenberg-Marquardt

Concise, subjective summary
J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

1

Example 1: Optimization Problem

a1 a2 −5 −4 −3 −2 −1 1 2 3 4 5 −5 5

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

4

Multivariate Optimization Overview

The “unconstrained optimization” problem is a generalization of

the line search problem

Find a vector a such that

a∗ = argmin

a

f(a)

Note that the are no constraints on a
Example: Find the vector of coefficients (w ∈ Rp×1) that

minimize the average absolute error of a linear model

Akin to a blind person trying to find their way to the bottom of a

valley in a multidimensional landscape

We want to reach the bottom with the minimum number of “cane

taps”

Also vaguely similar to taking core samples for oil prospecting
J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

2

SLIDE 2

Example 1: Optimization Problem

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

7

Example 1: Optimization Problem

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

5

Example 1: MATLAB Code

function [] = OptimizationProblem (); % ============================================================================== % User - Specified Parameters % ============================================================================== x =

5:0 .05 :5;

y =

5:0 .05 :5;

% ============================================================================== % Evaluate the Function % ============================================================================== [X,Y] = meshgrid(x,y); [Z,G] = OptFn(X,Y); functionName = ’OptimizationProblem ’; fileIdentifier = fopen ([ functionName ’.tex ’],’w’); % ============================================================================== % Contour Map % ============================================================================== figure; FigureSet (2,’Slides ’); contour(x,y,Z ,50); xlabel(’a_1 ’); ylabel(’a_2 ’); zoom on; AxisSet (8); fileName = sprintf(’%s-%s’,functionName ,’Contour ’);

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

8

Example 1: Optimization Problem

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

6

SLIDE 3

case 1, view (45 ,10); case 2, view ( -55 ,22); case 3, view ( -131 ,10);

therwise , error(’Not
implemented. ’);

end fileName = sprintf(’%s-%s%d’,functionName ,’Surface ’,c1); print(fileName ,’-depsc ’); fprintf(fileIdentifier ,’%%============================================================================= fprintf(fileIdentifier ,’\\ newslide\n’); fprintf(fileIdentifier ,’\\ slideheading{ Example \\ arabic{exc }: Optimization Problem }\n’); fprintf(fileIdentifier ,’%%============================================================================= fprintf(fileIdentifier ,’\\ includegraphics [ scale =1]{ Matlab /%s}\n’,fileName ); fprintf(fileIdentifier ,’\n’); end % ============================================================================== % List the MATLAB Code % ============================================================================== fprintf(fileIdentifier ,’%%==============================================================================\ n’ fprintf(fileIdentifier ,’\\ newslide \n’); fprintf(fileIdentifier ,’\\ slideheading{ Example \\ arabic{exc }: MATLAB Code }\n’); fprintf(fileIdentifier ,’%%==============================================================================\ n’ fprintf(fileIdentifier ,’\t \\ matlabcode{Matlab /% s.m }\n’,functionName ); fclose( fileIdentifier );

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

11

print(fileName ,’-depsc ’); fprintf(fileIdentifier ,’%%==============================================================================\ n’ fprintf(fileIdentifier ,’\\ newslide\n’); fprintf(fileIdentifier ,’\\ stepcounter{exc }\n’); fprintf(fileIdentifier ,’\\ slideheading{Example \\ arabic{exc }: Optimization Problem }\n’); fprintf(fileIdentifier ,’%%==============================================================================\ n’ fprintf(fileIdentifier ,’\\ includegraphics [ scale =1]{ Matlab /%s}\n’,fileName ); fprintf(fileIdentifier ,’\n’); % ============================================================================== % Quiver Map % ============================================================================== figure; FigureSet (1,’Slides ’); axis ([-5 5 -5 5]); contour(x,y,Z ,50); h = get(gca ,’Children ’); set(h,’LineWidth ’,0.2); hold on; xCoarse =

5:0.5 :5;

yCoarse =

5:0.5 :5;

[X,Y] = meshgrid(xCoarse ,yCoarse ); [ZCoarse ,GCoarse] = OptFn(X,Y); nr = size(xCoarse ,1); dzx = GCoarse( 1:nr ,1:nr); dzy = GCoarse(nr + (1: nr),1:nr); quiver(xCoarse ,yCoarse ,dzx ,dzy ); hold

ff;

xlabel(’a_1 ’); ylabel(’a_2 ’); zoom on;

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

9

Global Optimization?

In general, all optimization algorithms find a local minimum in as

few steps as possible

There are also “global” optimization algorithms based on ideas

such as – Evolutionary computing – Genetic algorithms – Simulated annealing

None of these guarantee convergence in a finite number of

iterations

All require a lot of computation
J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

12

AxisSet (8); fileName = sprintf(’%s-%s’,functionName ,’Quiver ’); print(fileName ,’-depsc ’); fprintf(fileIdentifier ,’%%==============================================================================\ n’ fprintf(fileIdentifier ,’\\ newslide\n’); fprintf(fileIdentifier ,’\\ slideheading{ Example \\ arabic{exc }: Optimization Problem }\n’); fprintf(fileIdentifier ,’%%==============================================================================\ n’ fprintf(fileIdentifier ,’\\ includegraphics [ scale =1]{ Matlab /%s}\n’,fileName ); fprintf(fileIdentifier ,’\n’); % ============================================================================== % 3D Maps % ============================================================================== figure; set(gcf ,’Renderer ’,’zbuffer ’); FigureSet (1,’Slides ’); h = surf(x,y,Z); set(h,’LineStyle ’,’None ’); xlabel(’a_1 ’); ylabel(’a_2 ’); shading interp; grid on; AxisSet (8); hl = light(’Position ’ ,[0 ,0 ,30]); set(hl ,’Style ’,’Local ’); set(h,’BackFaceLighting ’,’unlit ’) material dull for c1 =1:3 switch c1

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

10

SLIDE 4

Cyclic Coordinate Method

1. For i = 1 to p,

ai := argmin

α

f([a1, a2, . . . , ai−1, α, ai+1, . . . , ap])

2. Loop to 1 until convergence

+ Simple to implement + Each line search can be performed semi-globally to avoid shallow local minima + Can be used with nominal variables + f(a) can be discontinuous + No gradient required − Very slow compared to gradient-based optimization algorithms − Usually only practical when the number of parameters, p, is small

There are modified versions with faster convergence
J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

15

Optimization Comments

Ideally, when we construct models we should favor those which

can be optimized with few shallow local minima and reasonable computation

Graphically you can think of the function to be minimized as the

elevation in a complicated high-dimensional landscape

The problem is to find the lowest point
The most common approach is to go downhill
The gradient points in the most “uphill” direction
The steepest downhill direction is the opposite of the gradient
Most optimization algorithms use a line search algorithm
The methods mostly differ only in the way that the “direction of

descent” is generated

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

13

Example 2: Cyclic Coordinate Method

−5 5 −5 −4 −3 −2 −1 1 2 3 4 5 X Y

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

16

Optimization Algorithm Outline

The basic steps of these algorithms is as follows
1. Pick a starting vector a
2. Find the direction of descent, d
3. Move in that direction until a minimum is found:

α∗ := argmin

α

f(a + αd) a := a + α∗d

4. Loop to 2 until convergence
Most of the theory of these algorithms is based on quadratic

surfaces

Near local minima, this is a good approximation
Note that the functions should (must) have continuous gradients

(almost) everywhere

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

14

SLIDE 5

Example 2: Cyclic Coordinate Method

5 10 15 20 25 1 2 3 4 5 6 Iteration Euclidean Position Error

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

19

Example 2: Cyclic Coordinate Method

−3 −2 −1 −3.5 −3 −2.5 −2 −1.5 −1 −0.5 0.5 X Y

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

17

Example 2: Relevant MATLAB Code

function [] = CyclicCoordinate (); %clear all; close all; ns = 26; x =

3;

y = 1; b0 =

1;

ls = 30; a = zeros(ns ,2); f = zeros(ns ,1); [z,dzx ,dzy] = OptFn(x,y); a(1 ,:) = [x y]; f(1) = z; for cnt = 2:ns , if rem(cnt ,2)==1 , d = [1 0]’; % Along x direction else d = [0 1]’; % Along y direction end; [b,fmin] = LineSearch ([x y]’,d,b0 ,ls); x = x + b*d(1); y = y + b*d(2);

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

20

Example 2: Cyclic Coordinate Method

5 10 15 20 25 1 2 3 4 5 6 7 Iteration Function Value

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

18

SLIDE 6

print -depsc CyclicCoordinateContourB ; figure; FigureSet (2,4.5 ,2 .75 ); k = 1:ns; xerr = (sum (((a-ones(ns ,1)*[ xopt2 yopt2 ])’).^2) ’).^(1/2); h = plot(k-1,xerr ,’b’); set(h(1),’Marker ’,’.’); set(h,’MarkerSize ’ ,6); xlabel(’Iteration ’); ylabel(’Euclidean Position Error ’); xlim ([0 ns -1]); ylim ([0 xerr (1)]); grid on; set(gca ,’Box ’,’Off ’); AxisSet (8); print -depsc CyclicCoordinatePositionError; figure; FigureSet (2,4.5 ,2 .75 ); k = 1:ns; h = plot(k-1,f,’b’ ,[0 ns],zopt *[1 1],’r’ ,[0 ns],zopt2 *[1 1],’g’); set(h(1),’Marker ’,’.’); set(h,’MarkerSize ’ ,6); xlabel(’Iteration ’); ylabel(’Function Value ’); ylim ([0 f(1)]); xlim ([0 ns -1]); grid on; set(gca ,’Box ’,’Off ’); AxisSet (8);

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

23

a(cnt ,:) = [x y]; f(cnt) = fmin; end; [x,y] = meshgrid (0+( -0 .01 :0 .001 :0.01 ) ,3+(-0 .01 :0 .001 :0.01 )); [z,dzx ,dzy] = OptFn(x,y); [zopt ,id1] = min(z); [zopt ,id2] = min(zopt ); id1 = id1(id2 ); xopt = x(id1 ,id2 ); yopt = y(id1 ,id2 ); [x,y] = meshgrid (1 .883 +(-0 .02 :0 .001 :0 .02),-2.963 +(-0 .02 :0 .001 :0 .02 )); [z,dzx ,dzy] = OptFn(x,y); [zopt2 ,id1] = min(z); [zopt2 ,id2] = min(zopt2 ); id1 = id1(id2 ); xopt2 = x(id1 ,id2 ); yopt2 = y(id1 ,id2 ); figure; FigureSet (1,4.5 ,2 .75 ); [x,y] = meshgrid ( -5:0.1:5,-5:0.1 :5); z = OptFn(x,y); contour(x,y,z ,50); h = get(gca ,’Children ’); set(h,’LineWidth ’,0.2); axis(’square ’); hold on; h = plot(a(:,1),a(:,2), ’k’,a(:,1),a(:,2),’r’);

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

21

print -depsc CyclicCoordinateErrorLinear;

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

24

set(h(1),’LineWidth ’,1.2); set(h(2),’LineWidth ’,0.6); h = plot(xopt ,yopt ,’kx’,xopt ,yopt ,’rx’); set(h(1),’LineWidth ’,1.5); set(h(2),’LineWidth ’,0.5); set(h(1),’MarkerSize ’ ,5); set(h(2),’MarkerSize ’ ,4); hold

ff;

xlabel(’X’); ylabel(’Y’); zoom on; AxisSet (8); print -depsc CyclicCoordinateContourA ; figure; FigureSet (1,4.5 ,2 .75 ); [x,y] = meshgrid (-1.5 + ( -2:0 .05 :2),-1.5 + ( -2:0 .05 :2)); [z,dzx ,dzy] = OptFn(x,y); contour(x,y,z ,75); h = get(gca ,’Children ’); set(h,’LineWidth ’,0.2); axis(’square ’); hold on; h = plot(a(:,1),a(:,2), ’k’,a(:,1),a(:,2),’r’); set(h(1),’LineWidth ’,1.2); set(h(2),’LineWidth ’,0.6); hold

ff;

xlabel(’X’); ylabel(’Y’); zoom on; AxisSet (8);

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

22

SLIDE 7

Example 3: Steepest Descent

−5 5 −5 −4 −3 −2 −1 1 2 3 4 5 X Y

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

27

Steepest Descent The gradient of the function f(a) is defined as the vector of partial derivatives: ∇af(a) ≡

∂f(a)

∂a1 ∂f(a) ∂a2

. . .

∂f(a) ∂ap

T

It can be shown that the gradient, ∇af(a), “points” in the

direction of maximum ascent

The negative of the gradient, −∇af(a), “points” in the direction
f maximum descent
A vector d is a direction of descent if there exists a ǫ such that

f(a + λd) < f(a) for all 0 < λ < ǫ

It can also be shown that d is a direction of descent iff

(∇af(a))

T

d < 0

The algorithm of steepest descent uses d = −∇af(a)
The most fundamental of all algorithms for minimizing a

continuously differentiable function

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

25

Example 3: Steepest Descent

−2 −1.8 −1.6 −1.4 −1.2 −2.2 −2.1 −2 −1.9 −1.8 −1.7 −1.6 −1.5 −1.4 −1.3 −1.2 X Y

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

28

Steepest Descent + Very stable algorithm − Can converge very slowly once near the local minima where the surface is approximately quadratic

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

26

SLIDE 8

Example 3: Relevant MATLAB Code

function [] = SteepestDescent (); %clear all; close all; ns = 26; x =

3;

y = 1; b0 = 0.01; ls = 30; a = zeros(ns ,2); f = zeros(ns ,1); [z,g] = OptFn(x, y); a(1 ,:) = [x y]; f(1) = z; d = -g/norm(g); for cnt = 2:ns , [b,fmin] = LineSearch ([x y]’,d,b0 ,ls); x = x + b*d(1); y = y + b*d(2); [z,g] = OptFn(x, y); d = -g; d = d/norm(d);

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

31

Example 3: Steepest Descent

5 10 15 20 25 1 2 3 4 5 6 7 Iteration Function Value

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

29

a(cnt ,:) = [x y]; f(cnt) = z; end; [x,y] = meshgrid (0+( -0 .01 :0 .001 :0.01 ) ,3+(-0 .01 :0 .001 :0.01 )); [z,dzx ,dzy] = OptFn(x,y); [zopt ,id1] = min(z); [zopt ,id2] = min(zopt ); id1 = id1(id2 ); xopt = x(id1 ,id2 ); yopt = y(id1 ,id2 ); [x,y] = meshgrid (1 .883 +(-0 .02 :0 .001 :0 .02),-2.963 +(-0 .02 :0 .001 :0 .02 )); [z,dzx ,dzy] = OptFn(x,y); [zopt2 ,id1] = min(z); [zopt2 ,id2] = min(zopt2 ); id1 = id1(id2 ); xopt2 = x(id1 ,id2 ); yopt2 = y(id1 ,id2 ); [zopt zopt2] figure; FigureSet (1,4.5 ,2 .75 ); [x,y] = meshgrid ( -5:0.1:5,-5:0.1 :5); z = OptFn(x,y); contour(x,y,z ,50); h = get(gca ,’Children ’); set(h,’LineWidth ’,0.2); axis(’square ’); hold on;

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

32

Example 3: Steepest Descent Method

5 10 15 20 25 1 2 3 4 5 6 Iteration Euclidean Position Error

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

30

SLIDE 9

AxisSet (8); print -depsc SteepestDescentErrorLinear ;

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

35

h = plot(a(:,1),a(:,2), ’k’,a(:,1),a(:,2),’r’); set(h(1),’LineWidth ’,1.2); set(h(2),’LineWidth ’,0.6); h = plot(xopt ,yopt ,’kx’,xopt ,yopt ,’rx’); set(h(1),’LineWidth ’,1.5); set(h(2),’LineWidth ’,0.5); set(h(1),’MarkerSize ’ ,5); set(h(2),’MarkerSize ’ ,4); hold

ff;

xlabel(’X’); ylabel(’Y’); zoom on; AxisSet (8); print -depsc SteepestDescentContourA; figure; FigureSet (1,4.5 ,2 .75 ); [x,y] = meshgrid (-1.6 + (-0.5:0 .01 :0.5),-1.7 + (-0.5:0.01 :0.5 )); z = OptFn(x,y); contour(x,y,z ,75); h = get(gca ,’Children ’); set(h,’LineWidth ’,0.2); axis(’square ’); hold on; h = plot(a(:,1),a(:,2), ’k’,a(:,1),a(:,2),’r’); set(h(1),’LineWidth ’,1.2); set(h(2),’LineWidth ’,0.6); hold

ff;

xlabel(’X’); ylabel(’Y’); zoom on;

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

33

Conjugate Gradient Algorithms

1. Take a steepest descent step
2. For i = 2 to p
α := argmin

α

f(a + αd)

a := a + αd
gi := ∇f(a)
β :=

g

T i gi

gT

i−1gi−1

d := −gi + βdi
3. Loop to 1 until convergence
Based on quadratic approximations of f
Called the Fletcher-Reeves method
J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

36

AxisSet (8); print -depsc SteepestDescentContourB; figure; FigureSet (2,4.5 ,2 .75 ); k = 1:ns; xerr = (sum (((a-ones(ns ,1)*[ xopt2 yopt2 ])’).^2) ’).^(1/2); h = plot(k-1,xerr ,’b’); set(h(1),’Marker ’,’.’); set(h,’MarkerSize ’ ,6); xlabel(’Iteration ’); ylabel(’Euclidean Position Error ’); xlim ([0 ns -1]); ylim ([0 xerr (1)]); grid on; set(gca ,’Box ’,’Off ’); AxisSet (8); print -depsc SteepestDescentPositionError; figure; FigureSet (2,4.5 ,2 .75 ); k = 1:ns; h = plot(k-1,f,’b’ ,[0 ns],zopt *[1 1],’r’ ,[0 ns],zopt2 *[1 1],’g’); set(h(1),’Marker ’,’.’); set(h,’MarkerSize ’ ,6); xlabel(’Iteration ’); ylabel(’Function Value ’); ylim ([0 f(1)]); xlim ([0 ns -1]); grid on; set(gca ,’Box ’,’Off ’);

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

34

SLIDE 10

Example 4: Fletcher-Reeves Conjugate Gradient

5 10 15 20 25 1 2 3 4 5 6 7 Iteration Function Value

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

39

Example 4: Fletcher-Reeves Conjugate Gradient

−5 5 −5 −4 −3 −2 −1 1 2 3 4 5 X Y

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

37

Example 4: Fletcher-Reeves Conjugate Gradient

5 10 15 20 25 1 2 3 4 5 6 Iteration Euclidean Position Error

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

40

Example 4: Fletcher-Reeves Conjugate Gradient

1.5 2 2.5 −3.5 −3.4 −3.3 −3.2 −3.1 −3 −2.9 −2.8 −2.7 −2.6 −2.5 X Y

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

38

SLIDE 11

h = plot(a(:,1),a(:,2), ’k’,a(:,1),a(:,2),’r’); set(h(1),’LineWidth ’,1.2); set(h(2),’LineWidth ’,0.6); h = plot(xopt ,yopt ,’kx’,xopt ,yopt ,’rx’); set(h(1),’LineWidth ’,1.5); set(h(2),’LineWidth ’,0.5); set(h(1),’MarkerSize ’ ,5); set(h(2),’MarkerSize ’ ,4); hold

ff;

xlabel(’X’); ylabel(’Y’); zoom on; AxisSet (8); print -depsc FletcherReevesContourA; figure; FigureSet (1,4.5 ,2 .75 ); [x,y] = meshgrid (1.5:0.01 :2.5 ,-3.5:0 .01:-2.5); z = OptFn(x,y); contour(x,y,z ,75); h = get(gca ,’Children ’); set(h,’LineWidth ’,0.2); axis(’square ’); hold on; h = plot(a(:,1),a(:,2), ’k’,a(:,1),a(:,2),’r’); set(h(1),’LineWidth ’,1.2); set(h(2),’LineWidth ’,0.6); hold

ff;

xlabel(’X’); ylabel(’Y’); zoom on;

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

43

Example 4: Relevant MATLAB Code

function [] = FletcherReeves (); %clear all; close all; ns = 26; x =

3;

y = 1; b0 = 0.01; ls = 30; a = zeros(ns ,2); f = zeros(ns ,1); [z,g] = OptFn(x, y); a(1 ,:) = [x y]; f(1) = z; d = -g/norm(g); % First direction for cnt = 2:ns , [b,fmin] = LineSearch ([x y]’,d,b0 ,ls); x = x + b*d(1); y = y + b*d(2); go = g; % Old gradient [z,g] = OptFn(x, y); beta = (g’*g)/(go ’*go);

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

41

AxisSet (8); print -depsc FletcherReevesContourB; figure; FigureSet (2,4.5 ,2 .75 ); k = 1:ns; xerr = (sum (((a-ones(ns ,1)*[ xopt2 yopt2 ])’).^2) ’).^(1/2); h = plot(k-1,xerr ,’b’); set(h(1),’Marker ’,’.’); set(h,’MarkerSize ’ ,6); xlabel(’Iteration ’); ylabel(’Euclidean Position Error ’); xlim ([0 ns -1]); ylim ([0 xerr (1)]); grid on; set(gca ,’Box ’,’Off ’); AxisSet (8); print -depsc FletcherReevesPositionError; figure; FigureSet (2,4.5 ,2 .75 ); k = 1:ns; h = plot(k-1,f,’b’ ,[0 ns],zopt *[1 1],’r’ ,[0 ns],zopt2 *[1 1],’g’); set(h(1),’Marker ’,’.’); set(h,’MarkerSize ’ ,6); xlabel(’Iteration ’); ylabel(’Function Value ’); ylim ([0 f(1)]); xlim ([0 ns -1]); grid on; set(gca ,’Box ’,’Off ’);

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

44

d = -g + beta*d; a(cnt ,:) = [x y]; f(cnt) = z; end; [x,y] = meshgrid (0+( -0 .01 :0 .001 :0.01 ) ,3+(-0 .01 :0 .001 :0.01 )); [z,dzx ,dzy] = OptFn(x,y); [zopt ,id1] = min(z); [zopt ,id2] = min(zopt ); id1 = id1(id2 ); xopt = x(id1 ,id2 ); yopt = y(id1 ,id2 ); [x,y] = meshgrid (1 .883 +(-0 .02 :0 .001 :0 .02),-2.963 +(-0 .02 :0 .001 :0 .02 )); [z,dzx ,dzy] = OptFn(x,y); [zopt2 ,id1] = min(z); [zopt2 ,id2] = min(zopt2 ); id1 = id1(id2 ); xopt2 = x(id1 ,id2 ); yopt2 = y(id1 ,id2 ); figure; FigureSet (1,4.5 ,2 .75 ); [x,y] = meshgrid ( -5:0.1:5,-5:0.1 :5); z = OptFn(x,y); contour(x,y,z ,50); h = get(gca ,’Children ’); set(h,’LineWidth ’,0.2); axis(’square ’); hold on;

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

42

SLIDE 12

Example 5: Polak-Ribiere Conjugate Gradient

−5 5 −5 −4 −3 −2 −1 1 2 3 4 5 X Y

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

47

AxisSet (8); print -depsc FletcherReevesErrorLinear ;

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

45

Example 5: Polak-Ribiere Conjugate Gradient

1.5 2 2.5 −3.5 −3.4 −3.3 −3.2 −3.1 −3 −2.9 −2.8 −2.7 −2.6 −2.5 X Y

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

48

Conjugate Gradient Algorithms Continued

There is also a variant called Polak-Ribiere where

β := (gi − gi−1)

Tgi

g

T

i−1gi−1

+ Only requires the gradient + Converges in a finite No. steps when f(a) is quadratic and perfect line searches are used − Less stable numerically than steepest descent − Sensitive to inexact line searches

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

46

SLIDE 13

Example 5: MATLAB Code

function [] = PolakRibiere (); %clear all; close all; ns = 26; x =

3;

y = 1; b0 = 0.01; ls = 30; a = zeros(ns ,2); f = zeros(ns ,1); [z,g] = OptFn(x, y); a(1 ,:) = [x y]; f(1) = z; d = -g/norm(g); % First direction for cnt = 2:ns , [b,fmin] = LineSearch ([x y]’,d,b0 ,ls); x = x + b*d(1); y = y + b*d(2); go = g; % Old gradient [z,g] = OptFn(x, y); beta = ((g-go)’*g)/(go ’*go);

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

51

Example 5: Polak-Ribiere Conjugate Gradient

5 10 15 20 25 1 2 3 4 5 6 7 Iteration Function Value

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

49

d = -g + beta*d; a(cnt ,:) = [x y]; f(cnt) = z; end; [x,y] = meshgrid (0+( -0 .01 :0 .001 :0.01 ) ,3+(-0 .01 :0 .001 :0.01 )); [z,dzx ,dzy] = OptFn(x,y); [zopt ,id1] = min(z); [zopt ,id2] = min(zopt ); id1 = id1(id2 ); xopt = x(id1 ,id2 ); yopt = y(id1 ,id2 ); [x,y] = meshgrid (1 .883 +(-0 .02 :0 .001 :0 .02),-2.963 +(-0 .02 :0 .001 :0 .02 )); [z,dzx ,dzy] = OptFn(x,y); [zopt2 ,id1] = min(z); [zopt2 ,id2] = min(zopt2 ); id1 = id1(id2 ); xopt2 = x(id1 ,id2 ); yopt2 = y(id1 ,id2 ); figure; FigureSet (1,4.5 ,2 .75 ); [x,y] = meshgrid ( -5:0.1:5,-5:0.1 :5); z = OptFn(x,y); contour(x,y,z ,50); h = get(gca ,’Children ’); set(h,’LineWidth ’,0.2); axis(’square ’); hold on;

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

52

Example 5: Polak-Ribiere Conjugate Gradient

5 10 15 20 25 1 2 3 4 5 6 Iteration Euclidean Position Error

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

50

SLIDE 14

AxisSet (8); print -depsc PolakRibiereErrorLinear;

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

55

h = plot(a(:,1),a(:,2), ’k’,a(:,1),a(:,2),’r’); set(h(1),’LineWidth ’,1.2); set(h(2),’LineWidth ’,0.6); h = plot(xopt ,yopt ,’kx’,xopt ,yopt ,’rx’); set(h(1),’LineWidth ’,1.5); set(h(2),’LineWidth ’,0.5); set(h(1),’MarkerSize ’ ,5); set(h(2),’MarkerSize ’ ,4); hold

ff;

xlabel(’X’); ylabel(’Y’); zoom on; AxisSet (8); print -depsc PolakRibiereContourA ; figure; FigureSet (1,4.5 ,2 .75 ); [x,y] = meshgrid (1.5:0.01 :2.5 ,-3.5:0 .01:-2.5); z = OptFn(x,y); contour(x,y,z ,75); h = get(gca ,’Children ’); set(h,’LineWidth ’,0.2); axis(’square ’); hold on; h = plot(a(:,1),a(:,2), ’k’,a(:,1),a(:,2),’r’); set(h(1),’LineWidth ’,1.2); set(h(2),’LineWidth ’,0.6); hold

ff;

xlabel(’X’); ylabel(’Y’); zoom on;

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

53

Parallel Tangents (PARTAN)

1. First gradient step
d := ∇f(a)
α := argminα f(a + αd)
sp := αd
a := a + sp
2. Gradient Step
dg := ∇f(a)
α := argminα f(a + αd)
sg := αd
a := a + sg
3. Conjugate Step
dp := sp + sg
α := argminα f(a + αd)
sp := αd
a := a + sp
4. Loop to 2 until convergence
J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

56

AxisSet (8); print -depsc PolakRibiereContourB ; figure; FigureSet (2,4.5 ,2 .75 ); k = 1:ns; xerr = (sum (((a-ones(ns ,1)*[ xopt2 yopt2 ])’).^2) ’).^(1/2); h = plot(k-1,xerr ,’b’); set(h(1),’Marker ’,’.’); set(h,’MarkerSize ’ ,6); xlabel(’Iteration ’); ylabel(’Euclidean Position Error ’); xlim ([0 ns -1]); ylim ([0 xerr (1)]); grid on; set(gca ,’Box ’,’Off ’); AxisSet (8); print -depsc PolakRibierePositionError ; figure; FigureSet (2,4.5 ,2 .75 ); k = 1:ns; h = plot(k-1,f,’b’ ,[0 ns],zopt *[1 1],’r’ ,[0 ns],zopt2 *[1 1],’g’); set(h(1),’Marker ’,’.’); set(h,’MarkerSize ’ ,6); xlabel(’Iteration ’); ylabel(’Function Value ’); ylim ([0 f(1)]); xlim ([0 ns -1]); grid on; set(gca ,’Box ’,’Off ’);

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

54

SLIDE 15

Example 6: PARTAN

1.5 2 2.5 −3.5 −3.4 −3.3 −3.2 −3.1 −3 −2.9 −2.8 −2.7 −2.6 −2.5 X Y

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

59

PARTAN Concept

a0 a1 a2 a3 a4 a5 a6 a7

First two steps are steepest descent
Thereafter, each iteration consists of two steps
1. Search along the direction

di = ai − ai−2 where ai is the current point and ai−2 is the point from two steps ago

2. Search in the direction of the negative gradient

di = −∇f(ai)

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

57

Example 6: PARTAN

5 10 15 20 25 1 2 3 4 5 6 7 Iteration Function Value

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

60

Example 6: PARTAN

−5 5 −5 −4 −3 −2 −1 1 2 3 4 5 X Y

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

58

SLIDE 16

cnt = 2; while cnt <ns , % Gradient step [z,g] = OptFn(x,y); d = -g/norm(g); % Direction [bg ,fmin] = LineSearch ([x y]’,d,b0 ,ls); xg = x + bg*d(1); yg = y + bg*d(2); cnt = cnt + 1; a(cnt ,:) = [xg yg]; f(cnt) = OptFn(xg ,yg); fprintf(’G : %d %5 .3f\n’,cnt ,f(cnt )); if cnt ==ns , break; end; % Conjugate d = [xg -xa yg -ya]’; if norm(d)=0, d = d/norm(d); [bp ,fmin] = LineSearch ([xg yg]’,d,b0 ,ls); else bp = 0; end; if bp >0, % Line search in conjugate direction was successful fprintf(’P :’); x = xg + bp*d(1); y = yg + bp*d(2);

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

63

Example 6: PARTAN

5 10 15 20 25 1 2 3 4 5 6 Iteration Euclidean Position Error

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

61

else % Could not move - do another gradient update cnt = cnt + 1; a(cnt ,:) = a(cnt -1 ,:); f(cnt) = f(cnt -1); if cnt ==ns , break; end; fprintf(’G2:’); [z,g] = OptFn(xg ,yg); d = -g/norm(g); % Direction [bp ,fmin] = LineSearch ([xg yg]’,d,b0 ,ls); x = xg + bp*d(1); y = yg + bp*d(2); end; % Update anchor point xa = xg; ya = yg; cnt = cnt + 1; a(cnt ,:) = [x y]; f(cnt) = OptFn(x,y); fprintf(’ %d %5.3f\n’,cnt ,f(cnt )); end; [x,y] = meshgrid (0+( -0 .01 :0 .001 :0.01 ) ,3+(-0 .01 :0 .001 :0.01 )); [z,dzx ,dzy] = OptFn(x,y); [zopt ,id1] = min(z); [zopt ,id2] = min(zopt ); id1 = id1(id2 ); xopt = x(id1 ,id2 );

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

64

Example 6: MATLAB Code

function [] = Partan (); %clear all; close all; ns = 26; x =

3;

y = 1; b0 = 0.01; ls = 30; a = zeros(ns ,2); f = zeros(ns ,1); [z,g] = OptFn(x,y); a(1 ,:) = [x y]; f(1) = z; xa = x; ya = y; % First step - substitute for a Conjugate step d = -g/norm(g); % First direction [bp ,fmin] = LineSearch ([x y]’,d,b0 ,100); x = x + bp*d(1); % Standin for a conjugate step y = y + bp*d(2); a(2 ,:) = [x y]; f(2) = fmin;

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

62

SLIDE 17

xlim ([0 ns -1]); ylim ([0 xerr (1)]); grid on; set(gca ,’Box ’,’Off ’); AxisSet (8); print -depsc PartanPositionError; figure; FigureSet (2,4.5 ,2 .75 ); k = 1:ns; h = plot(k-1,f,’b’ ,[0 ns],zopt *[1 1],’r’ ,[0 ns],zopt2 *[1 1],’g’); set(h(1),’Marker ’,’.’); set(h,’MarkerSize ’ ,6); xlabel(’Iteration ’); ylabel(’Function Value ’); ylim ([0 f(1)]); xlim ([0 ns -1]); grid on; set(gca ,’Box ’,’Off ’); AxisSet (8); print -depsc PartanErrorLinear ;

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

67

yopt = y(id1 ,id2 ); [x,y] = meshgrid (1 .883 +(-0 .02 :0 .001 :0 .02),-2.963 +(-0 .02 :0 .001 :0 .02 )); [z,dzx ,dzy] = OptFn(x,y); [zopt2 ,id1] = min(z); [zopt2 ,id2] = min(zopt2 ); id1 = id1(id2 ); xopt2 = x(id1 ,id2 ); yopt2 = y(id1 ,id2 ); figure; FigureSet (1,4.5 ,2 .75 ); [x,y] = meshgrid ( -5:0.1:5,-5:0.1 :5); z = OptFn(x,y); contour(x,y,z ,50); h = get(gca ,’Children ’); set(h,’LineWidth ’,0.2); axis(’square ’); hold on; h = plot(a(:,1),a(:,2), ’k’,a(:,1),a(:,2),’r’); set(h(1),’LineWidth ’,1.2); set(h(2),’LineWidth ’,0.6); h = plot(xopt ,yopt ,’kx’,xopt ,yopt ,’rx’); set(h(1),’LineWidth ’,1.5); set(h(2),’LineWidth ’,0.5); set(h(1),’MarkerSize ’ ,5); set(h(2),’MarkerSize ’ ,4); hold

ff;

xlabel(’X’); ylabel(’Y’); zoom on;

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

65

PARTAN Pros and Cons

a0 a1 a2 a3 a4 a5 a6 a7

+ For quadratic functions, converges in a finite number of steps + Easier to implement than 2nd order methods + Can be used with large number of parameters + Each (composite) step is at least as good as steepest descent + Tolerant of inexact line searches − Each (composite) step requires two line searches

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

68

AxisSet (8); print -depsc PartanContourA; figure; FigureSet (1,4.5 ,2 .75 ); [x,y] = meshgrid (1.5:0.01 :2.5 ,-3.5:0 .01:-2.5); z = OptFn(x,y); contour(x,y,z ,75); h = get(gca ,’Children ’); set(h,’LineWidth ’,0.2); axis(’square ’); hold on; h = plot(a(:,1),a(:,2), ’k’,a(:,1),a(:,2),’r’); set(h(1),’LineWidth ’,1.2); set(h(2),’LineWidth ’,0.6); hold

ff;

xlabel(’X’); ylabel(’Y’); zoom on; AxisSet (8); print -depsc PartanContourB; figure; FigureSet (2,4.5 ,2 .75 ); k = 1:ns; xerr = (sum (((a-ones(ns ,1)*[ xopt2 yopt2 ])’).^2) ’).^(1/2); h = plot(k-1,xerr ,’b’); set(h(1),’Marker ’,’.’); set(h,’MarkerSize ’ ,6); xlabel(’Iteration ’); ylabel(’Euclidean Position Error ’);

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

66

SLIDE 18

Example 7: Newton’s with Steepest Descent Safeguard

0.5 1 1.5 2 −3 −2.5 −2 −1.5 X Y

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

71

Newton’s Method ak+1 = ak − H(ak)−1 ∇f(ak) where ∇f(ak) is the gradient and H(ak) is the hessian of f(a), H(ak) ≡ ⎡ ⎢ ⎢ ⎢ ⎢ ⎢ ⎣

∂2f(a) ∂a2

1

∂2f(a) ∂a1 ∂a2

. . .

∂2f(a) ∂a1 ∂ap ∂2f(a) ∂a2 ∂a1 ∂2f(a) ∂a2

2

. . .

∂2f(a) ∂a2 ∂ap

. . . . . . ... . . .

∂2f(a) ∂ap ∂a1 ∂2f(a) ∂ap ∂a2

. . .

∂2f(a) ∂a2

p

⎤ ⎥ ⎥ ⎥ ⎥ ⎥ ⎦

Based on a quadratic approximation of the function f(a)
If f(a) is quadratic, converges in one step
If H(a) is positive-definite, the problem is well defined near local

minima where f(a) is nearly quadratic

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

69

Example 7: Newton’s with Steepest Descent Safeguard

10 20 30 40 50 60 70 80 90 1 2 3 4 5 6 7 Iteration Function Value

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

72

Example 7: Newton’s with Steepest Descent Safeguard

−5 5 −5 −4 −3 −2 −1 1 2 3 4 5 X Y

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

70

SLIDE 19

y = y + b*d(2); [z,g,H] = OptFn(x,y); a(cnt ,:) = [x y]; f(cnt) = z; end; [x,y] = meshgrid (0+( -0 .01 :0 .001 :0.01 ) ,3+(-0 .01 :0 .001 :0.01 )); [z,dzx ,dzy] = OptFn(x,y); [zopt ,id1] = min(z); [zopt ,id2] = min(zopt ); id1 = id1(id2 ); xopt = x(id1 ,id2 ); yopt = y(id1 ,id2 ); [x,y] = meshgrid (1 .883 +(-0 .02 :0 .001 :0 .02),-2.963 +(-0 .02 :0 .001 :0 .02 )); [z,dzx ,dzy] = OptFn(x,y); [zopt2 ,id1] = min(z); [zopt2 ,id2] = min(zopt2 ); id1 = id1(id2 ); xopt2 = x(id1 ,id2 ); yopt2 = y(id1 ,id2 ); figure; FigureSet (1,4.5 ,2 .75 ); [x,y] = meshgrid ( -5:0.1:5,-5:0.1 :5); z = OptFn(x,y); contour(x,y,z ,50); h = get(gca ,’Children ’); set(h,’LineWidth ’,0.2);

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

75

Example 7: Newton’s with Steepest Descent Safeguard

10 20 30 40 50 60 70 80 90 1 2 3 4 5 6 Iteration Euclidean Position Error

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

73

axis(’square ’); hold on; h = plot(a(:,1),a(:,2), ’k’,a(:,1),a(:,2),’r’); set(h(1),’LineWidth ’,1.2); set(h(2),’LineWidth ’,0.6); h = plot(xopt ,yopt ,’kx’,xopt ,yopt ,’rx’); set(h(1),’LineWidth ’,1.5); set(h(2),’LineWidth ’,0.5); set(h(1),’MarkerSize ’ ,5); set(h(2),’MarkerSize ’ ,4); hold

ff;

xlabel(’X’); ylabel(’Y’); zoom on; AxisSet (8); print -depsc NewtonsContourA ; figure; FigureSet (1,4.5 ,2 .75 ); [x,y] = meshgrid (1.0 + ( -1:0 .02 :1),

2.4 + ( -1:0 .02 :1));

z = OptFn(x,y); contour(x,y,z ,75); h = get(gca ,’Children ’); set(h,’LineWidth ’,0.2); axis(’square ’); hold on; h = plot(a(:,1),a(:,2), ’k’,a(:,1),a(:,2),’r’); set(h(1),’LineWidth ’,1.2); set(h(2),’LineWidth ’,0.6); hold

ff;

xlabel(’X’);

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

76

Example 7: Relevant MATLAB Code

function [] = Newtons (); %clear all; close all; ns = 100; x =

3;

% Starting x y = 1; % Starting y b0 = 1; a = zeros(ns ,2); f = zeros(ns ,1); [z,g,H] = OptFn(x, y); a(1 ,:) = [x y]; f(1) = z; for cnt = 2:ns , d = -inv(H)*g; if d’*g>0, % Revert to steepest descent if is not direction

f

descent %fprintf ( ’(%2d of %2d) Min. Eig :%5 .3f Reverting...\n’,cnt ,ns ,min(eig(H ))); d = -g; end; d = d/norm(d); [b,fmin] = LineSearch ([x y]’,d,b0 ,100); %a(cnt ,:) = (a(cnt -1,:)’ - inv(H)*g)’; % Pure Newton ’s Method x = x + b*d(1);

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

74

SLIDE 20

Newton’s Method Pros and Cons ak+1 = ak − H(ak)−1 ∇f(ak) + Very fast convergence near local minima − Not guaranteed to converge (may actually diverge) − Requires p × p Hessian − Requires a p × p matrix inverse that uses O(p3) operations

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

79

ylabel(’Y’); zoom on; AxisSet (8); print -depsc NewtonsContourB ; figure; FigureSet (2,4.5 ,2 .75 ); k = 1:ns; xerr = (sum (((a-ones(ns ,1)*[ xopt2 yopt2 ])’).^2) ’).^(1/2); h = plot(k-1,xerr ,’b’); set(h(1),’Marker ’,’.’); set(h,’MarkerSize ’ ,6); xlabel(’Iteration ’); ylabel(’Euclidean Position Error ’); xlim ([0 ns -1]); ylim ([0 xerr (1)]); grid on; set(gca ,’Box ’,’Off ’); AxisSet (8); print -depsc NewtonsPositionError ; figure; FigureSet (2,4.5 ,2 .75 ); k = 1:ns; h = plot(k-1,f,’b’ ,[0 ns],zopt *[1 1],’r’ ,[0 ns],zopt2 *[1 1],’g’); set(h(1),’Marker ’,’.’); set(h,’MarkerSize ’ ,6); xlabel(’Iteration ’); ylabel(’Function Value ’); ylim ([0 f(1)]); xlim ([0 ns -1]);

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

77

Levenberg-Marquardt

1. Determine if ǫkI + H(ak) is positive definite. If not, ǫk := 4ǫk

and repeat.

2. Solve the following equation for ak+1

[ǫkI + H(ak)] (ak+1 − ak) = −∇f(ak) 3. rk ≡ f(ak) − f(ak+1) q(ak) − q(ak+1) where q(a) is the quadratic approximation of f(a) based on the f(a), ∇f(a), and H(ak)

4. If rk < 0.25, then ǫk+1 := 4ǫk

If rk > 0.75, then ǫk+1 := 1

2ǫk

If rk ≤ 0, then ak+1 := ak

5. If not converged, k := k + 1 and loop to 1.
J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

80

grid on; set(gca ,’Box ’,’Off ’); AxisSet (8); print -depsc NewtonsErrorLinear;

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

78

SLIDE 21

Example 8: Levenberg-Marquardt Conjugate Gradient

1.5 2 2.5 −3.5 −3.4 −3.3 −3.2 −3.1 −3 −2.9 −2.8 −2.7 −2.6 −2.5 X Y

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

83

Levenberg-Marquardt Comments

Similar to Newton’s method
Has safety provisions for regions where quadratic approximation is

inappropriate

Compare

Newton’s: ak+1 = ak − H(ak)−1 ∇f(ak) LM : [ǫkI + H(ak)] (ak+1 − ak) = −∇f(ak)

If ǫ = 0, these are equivalent
If ǫ → ∞, ak+1 → ak
ǫ is chosen to ensure that the smallest eigenvalue of H(ak) is

positive and sufficiently large (≥ δ)

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

81

Example 8: Levenberg-Marquardt Conjugate Gradient

5 10 15 20 25 1 2 3 4 5 6 7 Iteration Function Value

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

84

Example 8: Levenberg-Marquardt Conjugate Gradient

−5 5 −5 −4 −3 −2 −1 1 2 3 4 5 X Y

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

82

SLIDE 22

y = a(cnt ,2); zo = zn; % Old function value zn = OptFn(x,y); xd = (a(cnt ,:)’-ap); qo = zo; qn = zn + g’*xd + 0.5*xd ’*H*xd; if qo==qn , % Test for convergence x = a(cnt ,1); y = a(cnt ,2); a(cnt:ns ,:) = ones(ns -cnt +1 ,1)*[x y]; f(cnt:ns ,:) = OptFn(x,y); break; end; r = (zo -zn )/(qo -qn); if r<0.25 , eta = eta * 4; elseif r>0.50 , % 0.75 is recommended , but much slower eta = eta / 2; end; if zn >zo , % Back up a(cnt ,:) = a(cnt -1 ,:); else ap = a(cnt ,:) ’; end; x = a(cnt ,1);

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

87

Example 8: Levenberg-Marquardt Conjugate Gradient

5 10 15 20 25 1 2 3 4 5 6 Iteration Euclidean Position Error

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

85

y = a(cnt ,2); a(cnt ,:) = [x y]; f(cnt) = OptFn(x,y); %disp ([ cnt a(cnt ,:) f(cnt) r eta ]) end; [x,y] = meshgrid (0+( -0 .01 :0 .001 :0.01 ) ,3+(-0 .01 :0 .001 :0.01 )); [z,dzx ,dzy] = OptFn(x,y); [zopt ,id1] = min(z); [zopt ,id2] = min(zopt ); id1 = id1(id2 ); xopt = x(id1 ,id2 ); yopt = y(id1 ,id2 ); [x,y] = meshgrid (1 .883 +(-0 .02 :0 .001 :0 .02),-2.963 +(-0 .02 :0 .001 :0 .02 )); [z,dzx ,dzy] = OptFn(x,y); [zopt2 ,id1] = min(z); [zopt2 ,id2] = min(zopt2 ); id1 = id1(id2 ); xopt2 = x(id1 ,id2 ); yopt2 = y(id1 ,id2 ); figure; FigureSet (1,4.5 ,2 .75 ); [x,y] = meshgrid ( -5:0.1:5,-5:0.1 :5); z = OptFn(x,y); contour(x,y,z ,50); h = get(gca ,’Children ’); set(h,’LineWidth ’,0.2); axis(’square ’);

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

88

Example 8: Relevant MATLAB Code

function [] = LevenbergMarquardt (); %clear all; close all; ns = 26; x =

3;

% Starting x y = 1; % Starting y eta = 0.0001; a = zeros(ns ,2); f = zeros(ns ,1); [zn ,g,H] = OptFn(x, y); a(1 ,:) = [x y]; f(1) = zn; ap = [x y]’; % Previous point for cnt = 2:ns , [zn ,g,H] = OptFn(x,y); while min(eig(eta*eye (2)+H))<0, eta = eta * 4; end; a(cnt ,:) = (ap - inv(eta*eye (2)+H)*g )’; x = a(cnt ,1);

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

86

SLIDE 23

set(gca ,’Box ’,’Off ’); AxisSet (8); print -depsc LevenbergMarquardtErrorLinear;

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

91

hold on; h = plot(a(:,1),a(:,2), ’k’,a(:,1),a(:,2),’r’); set(h(1),’LineWidth ’,1.2); set(h(2),’LineWidth ’,0.6); h = plot(xopt ,yopt ,’kx’,xopt ,yopt ,’rx’); set(h(1),’LineWidth ’,1.5); set(h(2),’LineWidth ’,0.5); set(h(1),’MarkerSize ’ ,5); set(h(2),’MarkerSize ’ ,4); hold

ff;

xlabel(’X’); ylabel(’Y’); zoom on; AxisSet (8); print -depsc LevenbergMarquardtContourA ; figure; FigureSet (1,4.5 ,2 .75 ); [x,y] = meshgrid (1.5:0.01 :2.5 ,-3.5:0 .01:-2.5); z = OptFn(x,y); contour(x,y,z ,75); h = get(gca ,’Children ’); set(h,’LineWidth ’,0.2); axis(’square ’); hold on; h = plot(a(:,1),a(:,2), ’k’,a(:,1),a(:,2),’r’); set(h(1),’LineWidth ’,1.2); set(h(2),’LineWidth ’,0.6); hold

ff;

xlabel(’X’); ylabel(’Y’);

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

89

Levenberg-Marquardt Pros and Cons [ǫkI + H(ak)] (ak+1 − ak) = −∇f(ak)

Many equivalent formulations

+ No line search required + Can be used with approximations to the hessian + Extremely fast convergence (2nd order) − Requires gradient and hessian (or approximate hessian) − Requires O(p3) operations for each solution to the key equation

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

92

zoom on; AxisSet (8); print -depsc LevenbergMarquardtContourB ; figure; FigureSet (2,4.5 ,2 .75 ); k = 1:ns; xerr = (sum (((a-ones(ns ,1)*[ xopt2 yopt2 ])’).^2) ’).^(1/2); h = plot(k-1,xerr ,’b’); set(h(1),’Marker ’,’.’); set(h,’MarkerSize ’ ,6); xlabel(’Iteration ’); ylabel(’Euclidean Position Error ’); xlim ([0 ns -1]); ylim ([0 xerr (1)]); grid on; set(gca ,’Box ’,’Off ’); AxisSet (8); print -depsc LevenbergMarquardtPositionError ; figure; FigureSet (2,4.5 ,2 .75 ); k = 1:ns; h = plot(k-1,f,’b’ ,[0 ns],zopt *[1 1],’r’ ,[0 ns],zopt2 *[1 1],’g’); set(h(1),’Marker ’,’.’); set(h,’MarkerSize ’ ,6); xlabel(’Iteration ’); ylabel(’Function Value ’); ylim ([0 f(1)]); xlim ([0 ns -1]); grid on;

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14

90

SLIDE 24

Optimization Algorithm Summary Algorithm Convergence Stable ∇f(a) H(a) LS Cyclic Coordinate Slow Y N N Y Steepest Descent Slow Y Y N Y Conjugate Gradient Fast N Y N Y PARTAN Fast Y Y N Y Newton’s Method Very Fast N Y Y N Levenberg-Marquardt Very Fast Y Y Y N

J. McNames

Portland State University ECE 4/557 Multivariate Optimization

Ver. 1.14
