Outlook in the building construction industry in conjunction with adhesive solutions tapes and windows Bernhard ELIAS RAL Gtegemeinschaft Kuststoff- Fensterprofilsysteme e.V., Germany Promoting the Interests of the Self Adhesive Tape

slide-1
SLIDE 1

Promoting the Interests of the Self Adhesive Tape Industry

Outlook in the building construction industry in conjunction with adhesive solutions … tapes and windows

Bernhard ELIAS RAL Gütegemeinschaft Kuststoff- Fensterprofilsysteme e.V., Germany

slide-2
SLIDE 2

Promoting the Interests of the Self Adhesive Tape Industry

Bernhard Elias ▪ GKFP e.V. ▪ Germany 2 - 5 October 2013 Afera Annual Conference, Taormina 2

Windows ?

  • 120 mill windows / year in Europe and

RUS (PVC, wood, aluminum)

  • New construction and renovation
  • Existing market

for bonded glazing in

– A – CH – D

slide-3
SLIDE 3

Promoting the Interests of the Self Adhesive Tape Industry

Bernhard Elias ▪ GKFP e.V. ▪ Germany 2 - 5 October 2013 Afera Annual Conference, Taormina 3

How to use tapes in windows

by Lohmann Tapes, Germany

slide-4
SLIDE 4

Promoting the Interests of the Self Adhesive Tape Industry

Bernhard Elias ▪ GKFP e.V. ▪ Germany 2 - 5 October 2013 Afera Annual Conference, Taormina 4

Load situation in windows

  • Static load
  • Dynamic load
  • Thermic load
slide-5
SLIDE 5

Promoting the Interests of the Self Adhesive Tape Industry

Bernhard Elias ▪ GKFP e.V. ▪ Germany 2 - 5 October 2013 Afera Annual Conference, Taormina 5

Why using tapes in windows

  • Technical reasons

– Size – Stiffness – no need for adjustments – Service life – Energy efficiency – Noise reduction – RC2

1,80 meter 2,30 meter

by Gealan

slide-6
SLIDE 6

Promoting the Interests of the Self Adhesive Tape Industry

Bernhard Elias ▪ GKFP e.V. ▪ Germany 2 - 5 October 2013 Afera Annual Conference, Taormina 6

Why using tapes in windows

  • Economical reason

– no steel – more automatisation – cut manufactoring costs – offering a “special product”

by Lohmann Tapes

slide-7
SLIDE 7

Promoting the Interests of the Self Adhesive Tape Industry

Bernhard Elias ▪ GKFP e.V. ▪ Germany 2 - 5 October 2013 Afera Annual Conference, Taormina 7

Why using tapes in windows

  • Design

– Innovation, slimmer frames, larger glasses, complete new window designs

by Lohmann Tapes, Germany by Gealan, Germany

slide-8
SLIDE 8

Promoting the Interests of the Self Adhesive Tape Industry

Bernhard Elias ▪ GKFP e.V. ▪ Germany 2 - 5 October 2013 Afera Annual Conference, Taormina 8

Standardisation: RAL-GZ 716

  • Defining state of the art: RAL-GZ 716,

part 2

  • High quality of system granted

with the RAL q-mark

  • Acknowledged in D, A, CH
  • 716, Clause 3: fitness for purpose of the

adhesive system

  • 716, Clause 4: Compatibility of

components

slide-9
SLIDE 9

Promoting the Interests of the Self Adhesive Tape Industry

Bernhard Elias ▪ GKFP e.V. ▪ Germany 2 - 5 October 2013 Afera Annual Conference, Taormina 9

Fitness for purpose

  • RAL-GZ 716, part 2, clause 3:

fitness for purpose of the adhesive system

slide-10
SLIDE 10

Promoting the Interests of the Self Adhesive Tape Industry

Bernhard Elias ▪ GKFP e.V. ▪ Germany 2 - 5 October 2013 Afera Annual Conference, Taormina 10

Compatibility of components

  • National regulations exist
  • The basis: ETAG 002

(europ.tech.approv.guidline) glass facades, silikon adhesives: defines test specimen

  • RAL-GZ 716, clause 4

– Consider direct

  • r indirect contact

– Peelingtest

slide-11
SLIDE 11

Promoting the Interests of the Self Adhesive Tape Industry

Bernhard Elias ▪ GKFP e.V. ▪ Germany 2 - 5 October 2013 Afera Annual Conference, Taormina 11

Certified profile systems with bonded glazing by GKFP

www.gkfp.de
