– 3 :: 2 – 0024 Spring 2010

Outline

Please check the web page about your recitation groups meeting place. First group meeting: this Thursday (13:15) Terminology Exceptions Control flow -- the order of execution

• “throw” and “catch”

– 3 :: 3 – 0024 Spring 2010

Terminology

Program -> sequence of operations

Translation is done by the compiler We may later see exactly what operations are executed

We are for now interested in atomic operations

– 3 :: 4 – 0024 Spring 2010

Java model

– 3 :: 5 – 0024 Spring 2010

Java rules

Simple “print"

– 3 :: 6 – 0024 Spring 2010

Java rules

– 3 :: 7 – 0024 Spring 2010

Java model

– 3 :: 8 – 0024 Spring 2010

Simple Thread class

class TwoThreads { public static void main(String args[]) { SimpleThread st1 = new SimpleThread(); SimpleThread st2 = new SimpleThread(); st1.start(); st2.start(); } /* main */ }

– 3 :: 9 – 0024 Spring 2010

Simple Thread class, part 2

class SimpleThread extends Thread { public void run() { System.out.println(“Started.”); } /* run */ }

– 3 :: 10 – 0024 Spring 2010

Variant

class TwoThreads_2 { public static void main(String args[]) { Thread t1 = new Thread(new MyRunnable()); Thread t2 = new Thread(new MyRunnable()); t1.start(); t2.start(); } /* main */ }

– 3 :: 11 – 0024 Spring 2010

Variant, part 2

class MyRunnable implements Runnable { public void run() { System.out.println(“Started.”); } /* run */ }

– 3 :: 12 – 0024 Spring 2010

Atomic operations

An activity is called atomic if it completes without the possibility of interruption int j, k; j = k + 1; Is this (Java) statement executed atomically? int j, k; j = j + 1; Is this (Java) statement executed atomically?

– 3 :: 13 – 0024 Spring 2010

Atomic operations

int j, k; j = j++; Is this (Java) statement executed atomically? Who decides what operations are done atomically?

• Ideally, the language designers have specified

exactly what operations must be executed atomically.

– 3 :: 14 – 0024 Spring 2010

Atomic operations

For now, we accept that reading or writing an int value is done atomically. And nothing else.

Not completely true. All 32-bit quantities must be written

atomically.

Some details are missing.

– 3 :: 15 – 0024 Spring 2010

Primitive data types in Java

Java provides a rich set of primitive types Weve seen int. Variables, stored in 32 bits. int j, k; There are “long int” and “double” -- both require 64 bits

• f storage.

– 3 :: 16 – 0024 Spring 2010

Machine instruction not atomic

(Normal) machine instruction are not atomic

Several operations E.g., addl 4(%ebp), %eax // add register and memory

Compute effective address (4+ebp) Get value from memory Get value from %eax Add Update %eax

Interruption possible after each step Possibility of interruption implies that the machine

instruction does not execute atomically.

– 3 :: 17 – 0024 Spring 2010

Why looking at details?

Well stay at as high a level as possible but sometimes we must look “under the hood”

Most of the time source statements (or even methods) are a

good abstraction level

When we want to understand parallel execution then we

must understand which operations are executed atomically.

Well later see how we can ensure the atomic execution of

sequences of operations (even methods)

– 3 :: 18 – 0024 Spring 2010

Terminology, continued

Thread

Model of execution of a sequence of operations “Program counter” (PC) + state

Program counter - tells us what operation to do next

State = local variables (sometimes in registers)

Address (data) space

Sequence of memory locations

Abstract memory cells No information about access time

All memory locations have the same protection properties

Access rights, kind of address space (read-only, execute, ….)

Threads work with one (or more) address spaces

Each thread has a private address space for its private data Some of the address spaces may be shared among threads

– 3 :: 19 – 0024 Spring 2010

Terminology, continued

Process consists of one (or more) threads and one (or more address spaces) Job: collection of processes (Essential) Operating System (OS) services

Thread management

Creation, execution, interruption, termination, …

Address space management

Creation, mapping to real storage, setting/revoking access

rights, space reclamation, …

Process management Inter-process communication (IPC)

Threads communicate via shared address space(s)

– 3 :: 20 – 0024 Spring 2010

Threads and processes

A simple model (but good for many scenarios)

1 thread (“init thread” -- started by OS) 1 address space for private data (i.e. stack) (for init thread) 1 address space for thread (private) instructions 1 address space for shared libraries 1 address space for object instances

A slightly more sophisticated setup

1 thread (“init thread”) -- started by OS 1 .. N-1 threads started by init thread N address spaces for thread-private data N address spaces for thread (private) instructions 1 address space for shared libraries 1 address space for object instances

OS may not use (full) address space but just use different segments

– 3 :: 21 – 0024 Spring 2010

Thread

Thread

Model of execution of a sequence of operations “Program counter” (PC) + state

Program counter - tells us what operation to do next

State = local variables

class T1 { public static void main(String args[]) { int k; k = 0; k = k + 1; } } (at least) 4 Operations: update k, read k, add one, update k

– 3 :: 22 – 0024 Spring 2010

Detour: static methods

class S1 { public int static foo () { return 1; } } class S2 { public void static main(String args[ ]) { System.out.println(S1.foo()); } } Static methods can be invoked with class name.

You dont need an object instance

– 3 :: 23 – 0024 Spring 2010

Why bother?

Java knows constructors -- special method to produce an instance of a given class.

Great if you need one instance. What if you need two instances. Or two instances from

different classes.

Constructor(s) wont do the job.

Static methods help in such a situation.

Can impose rules on the usage/construction of object

instances.

Also useful at the start of a program -- when there are no

• bjects yet.

– 3 :: 24 – 0024 Spring 2010

Example revisited

class S1 { public int foo () { /* not static */ return 1; } } class S2 { public void static main(String args[ ]) { int j; S1 sref = new S1(); j = sref.foo() System.out.println(j); } }

– 3 :: 25 – 0024 Spring 2010

Comments

Default constructor -- S1(); Reference variable to instance of S1 -- sref “new” operator with constructor X() yields a reference to an instance of class X. “j” and “sref” are local variables (local to method main)

– 3 :: 26 – 0024 Spring 2010

Operations in example

1 (or more) to get reference to instance of S1

Plus whatever it takes to produce an instance of S1

1 (or more) to access sref 1 (or more) to invoke foo() 1 (or more) to get the result from foo() 1 to update j 1 (or more) to access System 1 (or more) to access field out 1 (or more) to invoke println() 1 (or more) to return

– 3 :: 27 – 0024 Spring 2010

More comments

Our goal is not to count operations. Want to understand that many operations are not atomic and that a thread can be interrupted often.

– 3 :: 28 – 0024 Spring 2010

Terminology, continued

Address (data) space

Sequence of memory locations

Abstract memory cells Can store values

» Dont worry for now about details

No information about access time

All memory locations have the same protection properties

Access rights, kind of address space (read-only, execute, ….) Not important for us right now -- just for the record

public void static main(String args[ ]) { int j; S1 sref … } Space for j and sref

– 3 :: 29 – 0024 Spring 2010

Data space

S1 sref = new S1(); System will find space to store instance of S1. sref can be stored, passed as an argument (to a method), or copied. No other manipulation is allowed.

– 3 :: 30 – 0024 Spring 2010

Terminology, continued

Threads work with one (or more) address spaces

Each thread has a private address space for its private data Some of the address spaces may be shared among threads

Private data: stored in the stack

Well look in the 3rd semester at stacks.

Threads that can read a reference can also access the

• bject the reference refers to.

– 3 :: 31 – 0024 Spring 2010

Terminology, continued

Process consists of one (or more) threads and one (or more address spaces) Job: collection of processes (Essential) Operating System (OS) services

Thread management

Creation, execution, interruption, termination, …

Address space management

Creation, mapping to real storage, setting/revoking access

rights, space reclamation, …

Process management Inter-process communication (IPC)

Threads communicate via shared address space(s)

– 3 :: 32 – 0024 Spring 2010

Threads and processes

A simple model (but good for many scenarios)

1 thread (“init thread” -- started by OS) 1 address space for private data (i.e. stack) (for init thread) 1 address space for thread (private) instructions 1 address space for shared libraries 1 address space for object instances

A slightly more sophisticated setup

1 thread (“init thread”) -- started by OS 1 .. N-1 threads started by init thread N address spaces for thread-private data N address spaces for thread (private) instructions 1 address space for shared libraries 1 address space for object instances

OS may not use (full) address space but just use different segments

– 3 :: 33 – 0024 Spring 2010

Model of execution

Thread instructions: a sequence of statements

Or operations that the statements have been translated into

After finishing one statement the next statement is the sequential successor statement. Statement 0; … Statement j; Statement j+1; …. Transition Statement_j --> Statement_j+1: control transfer

– 3 :: 34 – 0024 Spring 2010

Control flow changes

Control flow: sequence of control transfers Simple control transfers: S_j and S_(j+1) adjacent Conditional control transfers: if (N == M) { System.out.println(“Equal”); } else { System.out.println(“Not Equal”); }

– 3 :: 35 – 0024 Spring 2010

Other control flow changes

Method invocation Method return Switch statement Break/jump statement Loops

Hide the control transfer

All these transfers have in common that they are happen in a “predicatable” fashion.

If you inspect the program you can see what is going on.

– 3 :: 36 – 0024 Spring 2010

Exceptional control flow changes

What if your program must react to an “unpredictable” situations? Read a file. Encounter end of file. Run a program. Exceed your time slot. Add two numbers. Encounter an overflow.

– 3 :: 37 – 0024 Spring 2010

Exceptions

Exception is shorthand for the phrase "exceptional event” A method encounters an exception. It creates an “exception object” and hands it off to the runtime system for handling.

Exception objects are objects -- instances of some

appropriate class

Handing off the exception object requires special statement.

– 3 :: 38 – 0024 Spring 2010

Throwing an exception

Handing off the exception object is called throwing an exception Java contains the throw clause Exception e = new Exception(); throw (e);

– 3 :: 39 – 0024 Spring 2010

Consider this setup

A call chain: Main has invoked a method. This method invoked another method. The method invoked last encounters an error and throws an exception.

– 3 :: 40 – 0024 Spring 2010

Looking for someone to handle an exception

– 3 :: 41 – 0024 Spring 2010

Catching an exception

To handle an exception it must be “caught”. Java has a catch clause that will catch exceptions of a certain type

Type = class

catch (<ExceptionType> <name>) .. For example catch (Exception e_caught) …

If you catch type X you also catch all subtypes of X.

– 3 :: 42 – 0024 Spring 2010

Java rules

Code that can throw exceptions must be enclosed in a try statement: try { <statements> } catch (ExceptionType1 name) { <handler for exceptions of type1> } catch (ExceptionType2 name) { <handler type2> }

– 3 :: 43 – 0024 Spring 2010

Kinds of exceptions

Java knows 3 types of exceptions

Checked exceptions -- exceptions a programs wants to

recover from

Open a non-existing file (user input error)

Errors -- exception beyond the programs control

Hard disk error (block cannot be read)

Runtime exceptions -- violation of logic of program

Null pointer access Could be handled but better to eliminate the bug

These terms are defined by Java - we are mostly concerned about the first kind.
