"Our choice of solutions is based first and foremost on quality. That means one hundred percent reliability combined with the highest possible audio quality. The Digigram IQOYA range of IP transport products offers extremely low latency, excellent audio transport stability, and numerous redundancy options. Digigram meets our most stringent criteria for developing high quality, reliable audio-over-IP solutions that we can present to our clients with complete confidence." Jean-Louis Degoul, Head End Lead Buyer, TDF Group, France

LX-IP

The sound card for the IP studios

Digigram confidential

Presentation summary

• 1. Workflow and use cases overview
• 2. Product range
• 3. Benefits and assets
• 4. References

Workflow overview and use cases

Digigram confidential

6

The audio workflow

Digigram confidential

• Broadcast in-house

○ Signal management in central facilities and Production studios ○ Distribution between studios and production areas ○ SSL and contribution networks between regional studios ○ High density feed distribution to DSNG actors

• Mobile studios

○ OB vans ○ Connection with venue / event installations

• Installed sound

○ Inter-facility links across corporate networks

• Industrial applications

○ Ultra-precise audio distribution and management

7

LX-IP applications

Digigram confidential

Production & automation AoIP System The perfect gateway from mission critical applications to RAVENNA / AES 67 AoIP networks

8

LX-IP use cases

Digigram confidential

OB-Van

MADI

AES 67 remote studio MAM, DAW, Automation…

Embedded 128/64/64 routing matrix

9

MADI migration & hook-up

Digigram confidential

Editor & Media Asset Management

10

RAVENNA, AES67 or Dante/AES67 - enabled mixer

Large production

Automation and Production range

Digigram confidential

12

Automation and Production range

• LX-IP
• VX-IP
• PCX-IP
• LX-MADI
• VX range
• PCX range
• LoLa range
• CANCÙN and UAX
• LX6464ESe

Digigram confidential

Matching every usage

13

• PCX
• VX
• LX
• LoLa
• UAX
• CANCÙN

Digigram confidential

The Mission Critical challenge

14

Digigram confidential

Low latency on high channel count Instant fader start (<5 mS) Performance & stability independant of Automation application Premium Hardware reliability

15

Why a hardware soundcard ?

Benefits and assets of the product

Digigram confidential

Benefits

17

Benefits Proofed by A seamless migration to IP High density, ultra-low latency and phase accurate AoIP / PC / MADI bridge Secure your content delivery HW-based permanence of service Same latency as Digital audio Round trip latency better than 1 ms Ensure interoperability Triple standards AES67, RAVENNA and MADI

Digigram confidential

Low latency

→ down to 1 ms round trip

High channel count

→ 2 banks of 64/64 AES67/RAVENNA I/O

Performance & stability independant of PC applications Premium Hardware reliability

→ FPGA + Linux-based technology

18

MADI 64/64 I/O channels (factory option)

→ Allows seamless migration from Legacy audio

Why a hardware soundcard ?

Digigram confidential

Professional environment

• EMC
• High reliability FPGA and

Linux-based technology

Networking Audio specs

• 2x64/64 RAVENNA/AES67 I/O channels
• Embedded switching matrix
• Local clock eligible as PTP Grand Master
• Dual RAVENNA/AES67 Gigabit ports
• Full compliance with AES67 and Dante/AES67
• Discovered and managed by Dante controller

MADI interface (option)

• 64/64 I/O MADI channels
• Directly connected to switching matrix
• Optical MADI I/O

19

Features

• Wordclock input or output
• PCI Express
• Windows 7/8/10 32/64 drivers
• ALSA Linux drivers
• Web and EMBER+ control

Assets

Digigram confidential

PC or DAW* Record / Play MADI In / Out RAVENNA/AES67 ETH 0 RAVENNA/AES67 ETH 1

#

64/64 64/64 64/64 64/64

Control: Web GUI and EMBER+ protocol

20

Switching matrix overview

(*) Digital Audio Workstation

All channels are Mono

Success stories

Digigram confidential

Some clients testimonials

22

"In a nutshell: The IQOYA offers a good price/performance ratio. Furthermore we appreciate the quick response and fantastic support of Digigram.” Sandra Müller, Product Manager, Media Broadcast, Germany “The Digigram sound cards integrate very smoothly with our preferred broadcast systems. We are confident that Digigram will provide the quality and stability essential for the creation of a top-tier broadcast solution.” Yun Seong Lee, Manager, Radio Technology Department, Korean Broadcasting Systems, Korea

Digigram clients

Digigram confidential

Thank you for your attention!

Pascal Malgouyard malgouyard@digigram.com
