"Our choice of solutions is based first and foremost on quality. That means one hundred percent reliability combined with the highest possible audio quality. The Digigram IQOYA range of IP transport products offers extremely low latency, excellent audio transport stability, and numerous redundancy options. Digigram meets our most stringent criteria for developing high quality, reliable audio-over-IP solutions that we can present to our clients with complete confidence." Jean-Louis Degoul, Head End Lead Buyer, TDF Group, France

AoIP distribution solution:

IQOYA *LINK and IQOYA *LINK/LE

Digigram confidential

IQOYA *LINK and *LINK/LE Presentation summary

• IP distribution range
• Context of the migration to IP networks
• Benefits of using the products
• Presentation and assets
• References
• Use cases

4

Digigram confidential

Digigram audio Workflow

5

Digigram confidential

IQOYA range for IP audio distribution

Product Description Application IQOYA *LINK

1U Full duplex stereo IP audio codec with LCD display and keypad STL – SSL Single program delivery to DVB/cable operator

IQOYA *LINK/LE

1U Full duplex stereo IP audio codec STL – SSL Single program delivery to DVB/cable operator

IQOYA *SERV/LINK

Multi-stereo and multichannel full duplex IP audio codec STL-SSL WEB radio delivery to CDNs Multiple programs delivery to DVB/cable operators Multiple Intercom & Commentary IP streams transcoding

6

Digigram confidential

Context : migration to IP networks

• ISDN fading out on most of the countries
• Satellite is quite expensive
• IP access providers propose offers for reliable transport over IP networks
• Lower OPEX
• More flexibility

7

IP Distribution product range

Benefits of using IQOYA the products

Digigram confidential

IQOYA *LINK and *LINK/LE

10

Benefits Proof Value for money Most of the features are included in standard: FECs, dual redundant streaming, VLANs, QoS, SNMP, Fraunhofer AAC codecs Lower your OPEX Very high MTBF, Low consumption, very stable Fluid IP streaming Guarantee the audio service on your transmitter sites 3 configurable backup levels with switching criteria Backup on IP stream, audio inputs, local SDcard Hardware by-pass of audio I/Os in case of power supply failure Take the most of your managed or unmanaged networks 2 Eth ports, QoS, VLANs, IGMPv3, FECs, dual redundant streaming, real time metrics on received IP streams Use any popular professional software applications for supervision Full SNMP support (SET, GET, Traps) Dataminer driver Connect IQOYA to legacy audio or IP audio in-house infrastructure Supported audio I/Os: analog, AES/EBU, Livewire, AES67, RAVENNA

Presentation and assets of IQOYA *LINK and *LINK/LE

IQOYA *LINK & IQOYA *LINK/LE

• verview and assets

Digigram confidential

IQOYA *LINK (1/2)

• Full-duplex stereo IP audio codec

○ 1U rack 19’’ ○ Selectable audio I/Os: Analog, AES/EBU, Livewire, AES67, RAVENNA ○ 1 encoding and 1 decoding ○ Unicast, multicast, multi-unicast, multi-multicast ○ Supports standard RTP (ACIP), Icecast/Shoutcast, MPEG-TS/IP

• Robust IP streaming

○ Two network ports: control / IP audio, backup network, redundant dual streaming ○ Digigram Fluid IP streaming engine offers all mechansims to get a reliable transport over unmanaged and managed networks ○ Real time metrics on the received RTP stream ○ VLANs with QoS ○ IGMPv3

13

Digigram confidential

IQOYA *LINK (2/2)

• In-band auxiliary data tunneling (8 GPIOs, serial data through RS232 port or IP)
• Multiple fail-over solutions

○ 3 backup levels ○ SD card for local backup sound files, save/load configuration ○ Switchable hardware by-pass of audio I/Os in case of power suply failure

• SDHC card reader, LCD, keypad and headphones jack on front panel

14

Digigram confidential

IQOYA *LINK/LE

Same as IQOYA *LINK except: ○ No LCD and keypad on front panel ○ 4 GPIOs instead of 8

15

Digigram confidential

1/ Reliability 3 / Audio quality 2 / Audio service continuity 4 / Interoperability

Assets

Digigram confidential

1-a Reliability (hardware)

Rock-solid, dedicated hardware platform

• Low consumption (<10W) fanless design
• Robust ARM-based processor (AEC-Q100 qualified - Automotive)
• Embedded Linux distribution sized by Digigram
• Very high field measured MTBF > 150 years (more than 3000 installed units)
• Strong radiated & conducted EMI resilience : 10 V/m & 10V
• Lightning protection on network ports

<=> Designed for tansmitter sites

17

Digigram confidential

18

1-b Reliability (Fluid IP streaming engine)

• Management of network errors

○ Reordering of received packets ○ Management of duplicated packets ○ Jitter buffer

• Choice of FEC schemes to
• vercome packet losses on a

network path.

• Dual redundant Streaming with

time diversity to get rid of packet losses by using two separate network paths

• AAC Fraünhofer codec error

concealment

• Constant latency between

encoder and decoder through smart synchronization on the incoming IP stream

Digigram confidential

2 - Audio service continuity

• Up to four configurable decoding priorities
• Priority sources: RTP stream, HTTP stream, sound file / playlist on local SD

card, audio inputs

• Configurable switching criteria: IP stream loss and recovery durations
• Playlists and sound files on SD card managed through FTP
• Silence detection on the audio inputs: alarm, stop/start streaming
• Silence detection on the decoded IP audio stream: alarm, switching to backup
• Fail-over in case of power supply failure

Hardware by-pass of analog and AES/EBU inputs to outputs Manually switchable from rear panel for the AES I/O, and for analog I/Os

19

Digigram confidential

3- Audio quality

20

Digigram expertise in designing broadcast grade hardware audio I/Os Wide choice of included audio formats:

• PCM 16/20/24 bits
• ISO MPEG 1/2 layer II, and layer III
• MPEG-4 AAC LC, HE-AACv1, HE-AACv2, AAC-LD, AAC-ELD (Fraunhofer)

with error concealment

• Opus

Optional audio format: CSR apt-X Enhanced

Digigram confidential

4- Interoperability

21

• Supports the following audio connectivity:

Analog, AES/EBU, Livewire, AES67, RAVENNA

• Compatible with third party codecs thanks to the standard ACIP

IP audio streaming

• Compatible with all SNMP supervisors

○

SNMP control, monitoring, alarming (SET, GET, TRAPs)

○

SNMPv2c MIB included

• Supported by Skyline Dataminer
• Can be used in symetrical RTP for temporary remote IP

contribution

References

Digigram confidential

References

3000+ IQOYA *LINK and LINK/LE codecs operated by more than 15 Broadcasters or Telecom Operators since 2010

. 23

Use cases

Digigram confidential

IQOYA *LINK

Radio headquarter

IQOYA *Link/LE IQOYA *Link/LE IQOYA *Link

Supervision

Backup playlist on SD card + Backup 2 playlist on SD card Backup 1 RTP/HTTP stream Backup 1 RTP/HTTP stream Backup 1 RTP/ HTTP stream

25

Studio to multiple transmitters

Multi-unicast, multicast

Backup playlist on SD card

Digigram confidential

26

Audio synchro for multiple STL

Digigram confidential

27

STL with monitoring feed

Digigram confidential

28

SLT with 3 backups

Digigram confidential

29

IP Link with Dual redundant streaming

Digigram confidential

30

IP backup to satellite

Digigram confidential

31

Streaming to DVB/cable operator

Thank four for your attention!

Stephane Bert bert@digigram.com
