"Our choice of solutions is based first and foremost on quality. That means one hundred percent reliability combined with the highest possible audio quality. The Digigram IQOYA range of IP transport products offers extremely low latency, excellent audio transport stability, and numerous redundancy options. Digigram meets our most stringent criteria for developing high quality, reliable audio-over-IP solutions that we can present to our clients with complete confidence." Jean-Louis Degoul, Head End Lead Buyer, TDF Group, France

AoIP Contribution solutions

IQOYA *CALL and *CALL/LE

Digigram confidential

IQOYA *CALL and *CALL/LE Presentation summary

• IP contribution range
• Benefits of the products
• Presentation and assets
• References
• Some client testimonials

4

Digigram confidential

5

IP Contribution product range

Digigram confidential

Context : your IP migration

• ISDN fading out & declining quality
• Lower OPEX
• Easier to provide better audio quality
• More mobility, flexibility & productivity
• More contribution from external talents

7

Digigram confidential

8

Contribution product range

• IQOYA *CLOUD
• SIP infrastructure
• IQOYA *CALL
• IQOYA *CALL/LE
• IQOYA *MOBILE
• IQOYA V*MOTE
• CANCÙN
• Q-Mic

Digigram confidential

The contribution workflow

Mobile Studio Live interview Commentary voice talent Infrastructure Fleet Manager

Benefits of the products

Digigram confidential

Benefits of IQOYA *CALL and *CALL/LE

11

Benefits Proofed by Dial like a telephone Smart profiles replace technical formats Get rid of technical constraints Smart signalling, with or without SIP Talk naturally Ultra-low latency Select 100 % interoperability Full ACIP + Livewire/AES67 interfaces Easy fleet operation Ubiquity of SIP+Cloud management

Presentation and assets of IQOYA *CALL and *CALL/LE

Digigram confidential

IQOYA *CALL

• Full ACIP interoperability

○ SIP signalling for interoperability AND Symmetrical RTP for simplicity ○ Includes AAC and OPUS full duplex

• Ultra-fast phone-like connection

○ Audio and Network Profiles management ○ Active phonebook when managed by IQOYA *CLOUD application

• All-inclusive dual audio I/O on studio side

○ AES and Analog audio ○ Livewire, AES67, RAVENNA Audio-over-IP

• LCD, keypad and headphone on front panel
• Enhanced-aptX as an option

13

Digigram confidential

• A perfect match with IQOYA *MOBILE

○ Symmetrical RTP : “SIP without SIP” IQOYA *CALL/LE automatically adapts audio Rx and Tx formats

• Ultra-fast phone-like connection

○ Audio and Network Profiles management ○

Active phonebook with IQOYA *CLOUD application and SIP option

• Simplified front plate: No LCD, no keypad
• Includes AAC and OPUS full duplex
• All-inclusive dual audio I/O on studio side

○ AES and Analog audio ○ Livewire, AES67/RAVENNA Audio-over-IP

• SIP as an option

IQOYA *CALL/LE

14

Digigram confidential

1/ Audio Quality 3 / Ease of use 2 / Ultra-low latency 4 / Interoperability

Assets

5/ … leveraged by IQOYA *CLOUD ubiquity

Digigram confidential

1- Audio quality

16

FluidIP provides reliable audio on unreliable networks

• Fraunhofer’s AAC error concealment
• Time Diversity included in FEC
• Same audio integrity as ISDN with smart clock recovery
• The widest selection of algorithms

Audio quality Latency Bandwidth

Digigram confidential

2- Ease of use

17

No technician for operation

• Click-to dial from structured phone book
• Automatic + favorite profiles
• Smart signalling with and without SIP
• Smart monitoring
• Active phonebook with IQOYA *CLOUD
• Color LCD (*CALL)

• PCM : 8 mS
• E-aptX : 12 mS
• OPUS < 30 ms (Speech and Music)
• AAC-ELD : 32 mS
• MPEG Layer 2 : 53 mS

End-to-end latency:

• Two codecs involved / one way
• Analog audio in to analog out
• IP network includes 2 ms jitter buffer

3- Ultra-low latency

Digigram confidential

4- Interoperability: ACIP

19

Between IQOYA and 3rd party codecs

• Full ACIP interoperability in SIP (EBU Tech 3326)
• Includes ACIP-2 profiles management (EBU Tech-3368)
• Large interoperability in Symmetrical RTP (G722,

MPEG-L2, AAC)

Independant tests:

• EBU ACIP interoperability plugfests
• ARD (Germany) infrastructure tests

Digigram confidential

4- Interoperability: Synchronous AoIP

20

Between IQOYA and audio consoles

• Native Livewire+ interface with Axia

consoles

• AES67 interoperability plugfest 2015

○ 13 companies ○ IQOYA *CALL presented in 2nd plugfest

Digigram confidential

5- Ubiquity of IQOYA *CLOUD

IQOYA *CLOUD

• Install / Configure / Operate a fleet of codecs
• SIP & NAT traversal infrastructure

All the benefits of SaaS

• Phonebook and profile management in the Cloud
• SIP reference infrastructure and stream relays
• Activates Active phone book on codec GUIs
• Centralized stream monitoring

21

References

Digigram confidential

References

3000+ IQOYA *LINK equipment operated by more than 15 Broadcasters or Telecom Operators since 2010

. 23

Some clients testimonials

Digigram confidential

« Everything got up and running perfectly from

• Chicago. The audio quality was excellent, and we had

the impression that the reporter was located in our studio in Brussels. We were amazed! » Laurent Flemal, head of RTBF digitization division

US presidential elections, November 2012

25

Thank you for your attention!

Pascal Malgouyard malgouyard@digigram.com

Addendum : Benefits by customer profiles

Digigram confidential

Ex: VRT – Sveriges Radio – NPR - SSR – CBC – RNE - RAI

Large and national radios

Main customer focus Proofed by Interoperability within large & heterogeneous fleets IQOYA *CALL ACIP compliance checked in EBU plug-tests Permanence of Service, whatever «Last Mile» connection to Internet Same smart signalling with and without SIP FluidIP « The audio quality was excellent, and we had the impression that the (Chicago) reporter was located in our studio in Brussels “ (RTBF) Audio and transport quality Stable and low latency, end-to-end eaptX < 12 ms, AAC-ELD < 36 ms, OPUS < 30 ms Security of operation and studio management Operated by largest and most demanding organisations (TDF, ARQIVA, MB, DIGITA..) 28

Digigram confidential

Regional networks

Ex: Espace - NRJ – Alouette - RCF – SRG-SSR

Main customer focus Proofed by Low cost of operation IQOYA *CALL

• r

IQOYA *CALL/LE High quality on low bit rate Simplified set-up Smart profiles Robustness on Internet & 3G/4G FluidIP on Internet & 3G/4G Simplified fleet management IQOYA *CLOUD SaaS Scalability to larger infrastructure and fleets Same Smart signalling with and without SIP Studio-to-Studio connection Very low end-to-end latency

29

Digigram confidential

Small radios

Ex: WPKZ...

Main customer focus

Proofed by

Value for money IQOYA *CALL/LE No hidden options Simplified set-up Smart profiles without SIP Robustness on the Internet & 3G/4G FluidIP on the Internet & 3G/4G Light management infrastructure IQOYA *CLOUD SaaS
