OPEN MEETING MARINE LICENCE APPLICATION

2

WELCOME

BY NIGEL KAY INDEPENDENT FACILITATOR

3

PROGRAMME

• Presentation from Port of Dover
• Presentation from world-class experts:
• Coastal Processes /

Questions

• Ecology

/ Questions

• Archaeology

/ Questions

• Closing Remarks

4

MARINE LICENCE APPLICATION

FROM JACK GOODHEW PORT OF DOVER

5

WHAT IS THIS FOR?

• Dover Western Docks Revival (DWDR)
• One-off opportunity for regeneration of Dover
• New investment into the area
• UK Government planning approval

6

WHAT IS THIS FOR?

• DWDR will deliver:
• A transformed waterfront / new Marina & Pier
• New cargo terminal & distribution centre
• Greater space inside the Port for ferry traffic
• Quality employment opportunities

7

ENVIRONMENTAL CREDENTIALS

• 26% carbon footprint reduction since 2007
• On track to achieve 100% landfill avoidance
• Over 90% of general waste streams recycled
• Sponsors annual Shakespeare Beach survey and

beach clean

• Dover beach is regularly listed in the Good Beach

Guide

8

CEEQUAL SUSTANABILITY AWARD

9

MARINE LICENCE APPLICATION

• Options
• Investigation
• Engagement
• Conclusions

10

MARINE LICENCE APPLICATION

• Full compliance with all legislation
• Engaged world-class consultancy firm:
• Environmental Impact Assessment study
• Environmental Statement – over 1,500

pages

11

OPTIONS

• Dredged material -
• Goodwin Sands
• Elsewhere
• Land based aggregate
• Material from navigational dredging
• Recycled aggregate

12

OPTION SELECTION

• Goodwin Sands - least overall

environmental impact

• Habitat recovers naturally - no lasting

effect on the eco-system

• Avoids long-haul shipping or 300,000

lorry movements

• PLUS local material recycled & used –

reducing volume required

13

14

• Marine Management Organisation

(MMO)

• Natural England
• Historic England
• Environment Agency

REGULATORY ADVISORS GROUP ENGAGEMENT

15

• Kent Wildlife Trust
• London Zoological Society
• National Trust
• Commercial & recreational fishing

industry

• Local councils & interest groups

STAKEHOLDER ENGAGEMENT

16

• Dover District Council
• Dover Town Council
• Deal Town Council
• Ramsgate Town Council
• Ringwould & Kingsdown Parish

Council

• Save Our Sands (SOS)
• Kent Association of Local Councils

STAKEHOLDER ENGAGEMENT

17

DETAILED SITE SELECTION

18

PROPOSED EXTRACTION ZONE

PORT OF DOVER WESTERN DOCKS REVIVAL l Workshop – June 2014 19

4 km

20

MORE THAN 99.7% UNTOUCHED

Modelling based on +60%

21

TECHNICAL WORKING GROUPS 2015/2016

• Coastal Processes
• Ecology
• Archaeology

22

COASTAL PROCESSES

• Wave heights: no change within 4.5km
• f the coast
• Tidal current velocities: no change

within 5km of the coast

• No indirect impacts on coastal erosion

and flood defence along coast

23

ECOLOGY

• Benthic and Fish
• Marine mammals
• With mitigation measures - all residual

impacts negligible or minor

• Proposed scheme should not have any

significant adverse environmental impacts

24

ARCHAEOLOGY

• No direct impacts on known wreck

sites

• Minor impacts on unknown wreck sites
• but offset by mitigations, monitoring

and reporting protocols

• No impact on heritage assets along the

coast

25

MARINE LICENCE APPLICATION

June 9 - July 20 MMO consultation July – August Information request & response period September 2016 MMO Licence decision

26

CONCLUSION

• Thorough environmental studies
• Small proportion to be taken
• No coastal impacts
• Option with least overall

environmental impact

27

COASTAL PROCESSES

FROM JOHN BAUGH HR WALLINGFORD DR DAVID BREW ROYAL HASKONINGDHV

28

PHYSICAL PROCESS MODELLING

Wave modelling Tidal flow modelling

Sediment dispersion modelling Coastal Impact Study Environment Statement

Sand transport modelling

29

SEDIMENT DISPERSION

Sediment dispersion modelling results

30

WAVE HEIGHT

Wave modelling results: 200 year return period waves Footprint of 2 cm change in significant wave height for all simulations – Full dredge area scenario

31

WAVE DIRECTION

31

Deal

Wave modelling results: 200 year return period waves Footprint of 0.2 degree change in wave direction for all simulations – Full dredge area scenario

*Blue shades = background bathymetry

32

TIDAL FLOW

Footprint of maximum current increase due to full area dredging Contour of maximum current change as %

• f peak

current

33

SAND TRANSPORT

Sand transport modelling results: Change in pattern of bed change

due to full area dredging

Change to erosion Change to deposition

Ramsgate Ramsgate Deal Deal

34

ASSESSMENT CONCLUSIONS

• Wave heights and directions: negligible change
• ffshore and no change within 4.5km of the coast
• Tidal current velocities: negligible change offshore

and no change within 5km of the coast

• Increase in suspended sediment: negligible

change offshore and no change at the coast

• Sediment transport: negligible offshore and no

change at the coast

• No impacts on coastal erosion and flood defence

along coast

35

COASTAL PROCESSES Q&A

36

ECOLOGY

FROM DR ELIZABETH JOLLEY & DR JENNIFER LEARMONTH ROYAL HASKONINGDHV

37

DESIGNATED SITES & MARINE ECOLOGY

38

DESIGNATED SITES

39

DESIGNATED SITES

• Approach to Designated Sites:
• Zone of Influence (ZOI)
• Dredger transit route
• MMO Scoping Instruction:
• No Habitats Regulations Assessment
• No formal MCZ assessment for Goodwin

Sands rMCZ

• Potential impacts considered:
• rMCZ features
• Habitats and Species of Principal Importance

40

MARINE ECOLOGY BASELINE SURVEY

41

PROTECTED HABITATS / SPECIES

42

BENTHIC ECOLOGY CONCLUSIONS

• Species / habitat sensitivity = low /

negligible sensitivity

• Direct loss of species = minor impact
• Increase in suspended sediment = minor

impact

• Suspended sediment/ smothering =

negligible impact

• Impact of hydrodynamic changes =

negligible significance

43

SUITABLE SANDEEL HABITAT

44

HERRING SPAWNING GROUNDS

45

FISH ECOLOGY CONCLUSIONS

• Direct loss / damage to fish / eggs/larvae

within dredge area = minor impact

• Direct loss / disturbance to spawning,

nursery / feeding / overwintering grounds = minor impact

• Smothering of fish / fish eggs from

suspended sediments = negligible impact

46

MARINE MAMMALS

47

SEAL HAUL-OUT SITES

48

SEAL HAUL-OUT SITES

In proximity to the proposed dredge area only a very small area is exposed for a short period of time

49

ASSESSMENT CONCLUSIONS

• Underwater noise during dredging = minor

impact

• Collision risk with dredgers= negligible impact
• Disturbance to seals at haul-out sites = minor

impact

• Change or loss of seal haul-out sites =

negligible impact

• Increased suspended sediment during

dredging = negligible impact

• Reduced prey availability = minor impact

50

ASSESSING ANY DISTURBANCE TO SEALS AT HAUL-OUT SITES

• Significant disturbance of seals at haul-out sites is

unlikely due to the dredging

• Precautionary mitigation measures are proposed:
• 500m minimum distance between the dredger and

seals haul-outs

• 1km minimum distance for:
• Harbour seal breeding season (June to July)
• Harbour seal moult period (August)
• Trained marine mammal observer on board

51

ECOLOGY SUMMARY

• With mitigation measures - all residual

impacts negligible or minor

• Proposed scheme should not have any

significant adverse environmental impacts

52

ECOLOGY Q&A

53

ARCHAEOLOGY

FROM VICTORIA COOPER ROYAL HASKONINGDHV

54

DESK BASED ASSESSMENT

• Geophysical survey data assessed by Wessex

Archaeology

• Existing records of wrecks and obstructions,

archaeological sites/finds and reported losses

• Background information and secondary sources
• Consultation
• Historic England/MMO, Local Authorities
• Protected Wreck Licensees
• Local Archaeological Groups
• Commonwealth War Graves Commission

55

WRECKS AND GEOPHYSICAL ANOMALIES

 2 Wrecks

• Outside dredge area

 22 Geophysical Anomalies

• 16 outside dredge area

 4 Historic Records

• 3 outside dredge area

 Britannia

: Identified Wrecks : Geophysical Anomalies : Historic Record

56

AVOIDANCE OF KNOWN SITES

 Geophysical Anomalies

• Avoid six locations

 Archaeological Exclusion Zones

• 7006
• Britannia

57

PROTECTED WRECKS & LOSSES

 55 Documented Losses  Battle of the Downs 1639  No Aircraft Losses

Recorded Aircraft ‘Kent HER U-12’ artitrary position

58

UNEXPECTED DISCOVERIES

 Potential greatest where sand is deepest

Sand Thickness (m)

59

MITIGATION

• Archaeological Exclusion Zones and Avoidance
• Pre-dredge and post-dredge geophysical survey to

include the Admiral Gardner

• On board archaeological monitoring during dredging
• Archaeological monitoring during discharge of dredged

material

• Protocol for reporting discoveries of archaeological

interest

• Written Scheme of Investigation
• To be agreed with Historic England and the MMO

60

ARCHAEOLOGY SUMMARY

• No direct impacts on known wreck

sites

• Potential impacts on unknown wreck

sites, reduced by mitigation including monitoring & reporting protocol

• No impact on heritage assets along the

coast

61

ARCHAEOLOGY Q&A

62

CLOSING REMARKS

BY NIGEL KAY INDEPENDENT FACILITATOR
