Open House Meetings Tier 2 Evaluation April 24 & 25, 2007 April 24 & 25, 2007 1 Agenda Introductory Comments 1. Background 2. Tier 1 Evaluation 3. Tier 2 Alternatives Evaluation 4. Traffic Evaluation 5. Next Steps 6. 2

slide-1
SLIDE 1

1

Open House Meetings Tier 2 Evaluation

April 24 & 25, 2007 April 24 & 25, 2007

slide-2
SLIDE 2

2

Agenda

1.

Introductory Comments

2.

Background

3.

Tier 1 Evaluation

4.

Tier 2 Alternatives Evaluation

5.

Traffic Evaluation

6.

Next Steps

slide-3
SLIDE 3

3

Kendall Corridor Transportation Alternatives Analysis

slide-4
SLIDE 4

4

What is the problem to be addressed

slide-5
SLIDE 5

5

slide-6
SLIDE 6

6

slide-7
SLIDE 7

7

Kendall Area Travel Patterns

slide-8
SLIDE 8

8

3 Primary Study Corridors

  • Kendall Drive

East – West U.S. 1 – Krome

  • HEFT / 107th

North – South Metro Zoo – MIC

  • 874/826/CSX

North – South Metro Zoo – MIC Kendall Airport - MIC

slide-9
SLIDE 9

9

Tier 1 Alternatives Tier 1 Alternatives

slide-10
SLIDE 10

10

Tier 1 Alternatives

Kendall Corridor Kendall Corridor

1.

Bus Rapid Transit

2.

Light Rail Transit

3.

MetroRail

HEFT / 107 HEFT / 107th

th Corridor

Corridor

1.

Bus Rapid Transit

2.

MetroRail

826 / 874 Corridor 826 / 874 Corridor

1.

Bus Rapid Transit

CSX Corridor CSX Corridor

1.

Diesel Multiple Unit (DMU)

slide-11
SLIDE 11

11

Tier 2 Alternatives Tier 2 Alternatives

slide-12
SLIDE 12

12

Tier 2 Alternatives

  • Kendall Drive
  • Exclusive BRT
  • Metrorail
  • HEFT Corridor
  • Metrorail (Extension of East-West Corridor)
  • CSX Corridor
  • DMU
  • 137th Ave BRT (New Option)
slide-13
SLIDE 13

13

Transit Technologies Transit Technologies

slide-14
SLIDE 14

14

Bus Rapid Transit (BRT) Bus Rapid Transit (BRT)

Please view the Bus Rapid Transit (BRT) Please view the Bus Rapid Transit (BRT) example video on the main project page example video on the main project page

slide-15
SLIDE 15

15

Diesel Multiple Unit (DMU) Diesel Multiple Unit (DMU)

Please view the Diesel Multiple Unit (DMU) Please view the Diesel Multiple Unit (DMU) example video on the main project page example video on the main project page

slide-16
SLIDE 16

16

Kendall Corridor Alternatives Kendall Corridor Alternatives

slide-17
SLIDE 17

17

Alternatives A1-A3 – Kendall BRT

slide-18
SLIDE 18

18

Alternative A1 – A3 - Kendall BRT

Mode Mode BRT BRT Daily Transit Trips A1 - Daily Transit Trips A1 - 10,000 10,000 A2 - A2 - 7,041 7,041 A3 - A3 - 5,834 5,834 Headways Headways 6 / 10 Minutes 6 / 10 Minutes Capital Cost Capital Cost A1 - A1 - $326.6m $326.6m A2 - A2 - $253.7m $253.7m A3 - A3 - $249.7m $249.7m O&M Cost O&M Cost $4.6m-5.2m $4.6m-5.2m

slide-19
SLIDE 19

19

Alternative A4 – Kendall MetroRail

slide-20
SLIDE 20

20

Alternative A4 – Kendall MetroRail

Mode Mode MetroRail MetroRail Daily Transit Trips 15,600 Daily Transit Trips 15,600 Headways Headways 6/12 Minutes 6/12 Minutes Capital Cost Capital Cost $1.68b $1.68b O&M Cost O&M Cost $18.8m $18.8m

slide-21
SLIDE 21

21

HEFT Corridor Alternatives HEFT Corridor Alternatives

slide-22
SLIDE 22

22

Alternative B1- HEFT MetroRail

slide-23
SLIDE 23

23

Alternative B1- HEFT MetroRail

Mode Mode MetroRail MetroRail Daily Transit Trips 12,250 Daily Transit Trips 12,250 Headways Headways 6/12 minutes 6/12 minutes Capital Cost Capital Cost $ 1.69b $ 1.69b O&M Cost O&M Cost $19.7m $19.7m

slide-24
SLIDE 24

24

CSX Corridor Alternatives CSX Corridor Alternatives

slide-25
SLIDE 25

25

CSX Corridor - DMU

Option C2

4 passenger stations 30 min. peak hour headways

Option C3

7 passenger stations 20 min. peak hour headways

Options C4 & C5

Full Double track 9 passenger stations 15 min. peak hour headways

slide-26
SLIDE 26

26

Alternatives C2-C4 - DMU

slide-27
SLIDE 27

27

Alternatives C2-C4 - DMU

Mode Mode DMU DMU Da Daily Transit Trips C2 - Transit Trips C2 - 600 00 C3 - C3 - 1,144 ,144 C4 - C4 - 3,100 ,100 Headways Headways C2 - C2 - 30/60 minutes 30/60 minutes C3 - C3 - 20/40 20/40 C4 - C4 - 15/30 5/30 Capital Cost Capital Cost C2 - C2 - $190 190m C3 - C3 - $224.1m $224.1m C4 - C4 - $368m $368m O&M Cost O&M Cost $5.2m – $5.2m – 12 12m

slide-28
SLIDE 28

28

Alternative C5 - DMU

slide-29
SLIDE 29

29

Alternative C5 - DMU

Mode Mode DMU DMU Daily Transit Trips 3,000 Daily Transit Trips 3,000 Headways Headways 15/30 15/30 Capital Cost Capital Cost $386m $386m O&M Cost O&M Cost $12.2m $12.2m

slide-30
SLIDE 30

30

137 137th

th Ave. Corridor Alternatives

  • Ave. Corridor Alternatives
slide-31
SLIDE 31

31

Alternatives D1 – 137th BRT

slide-32
SLIDE 32

32

Alternative D1 – 137th BRT

Mode Mode BRT BRT Daily Transit Trips 7,800 Daily Transit Trips 7,800 Headways Headways 6 / 10 Minutes 6 / 10 Minutes Capital Cost Capital Cost $407M $407M O&M Cost O&M Cost $6.5m $6.5m

slide-33
SLIDE 33

33

Traffic Evaluation Traffic Evaluation

slide-34
SLIDE 34

34

Basis for BRT Analysis

  • BRT in Median

BRT in Median

  • Transit Signal Priority at Intersections

Transit Signal Priority at Intersections

  • 10-second green extension

10-second green extension

  • Six-Minute Headways

Six-Minute Headways

  • 2030 Traffic Conditions

2030 Traffic Conditions

  • PM Peak Hour

PM Peak Hour

  • Major Intersections Only (also looked at select intersections

Major Intersections Only (also looked at select intersections with geometric modifications) with geometric modifications)

slide-35
SLIDE 35

35

Evaluation of Impacts

  • Impacts of Transit Signal Priority

Impacts of Transit Signal Priority

  • Impacts of Geometric Modifications

Impacts of Geometric Modifications

  • In Comparison to No-Build Alternative

In Comparison to No-Build Alternative

  • Measured in Cumulative Vehicle Hours or Impact per

Measured in Cumulative Vehicle Hours or Impact per Vehicle in Seconds Vehicle in Seconds

slide-36
SLIDE 36

36

Impacts of BRT Alternative

  • 60
  • 40
  • 20

20 40 SW 147 Avenue SW 137 Avenue SW 127 Avenue SW 125 Avenue SW 122 Avenue Mills Drive SW 117 Avenue SW 107 Avenue SW 99 Court SR 874 SB Ramps SW 97 Avenue SR 878 EB Ramp SW 87 Avenue SW 79 Avenue SW 77 Avenue Dadeland Blvd

Intersection seconds per vehicle

Note: Positive values indicate time savings

slide-37
SLIDE 37

37

Summary – BRT Alternative

  • Transit Signal Priority

Transit Signal Priority Marginal Benefits to Marginal Benefits to Kendall Drive East-West Kendall Drive East-West Movement Movement

  • Geometric Modifications and Traffic Diversion

Geometric Modifications and Traffic Diversion Adverse Impacts Adverse Impacts

  • Most Significantly Affected Intersections

Most Significantly Affected Intersections SW 137 SW 137 Ave, SW 122 Ave, SW 117 Ave, SW 107 Ave, and SW 87 Ave, SW 122 Ave, SW 117 Ave, SW 107 Ave, and SW 87 Ave Ave

slide-38
SLIDE 38

38

Basis for DMU Analysis

  • DMU in CSX Corridor

DMU in CSX Corridor

  • Two-Car Trains Sets

Two-Car Trains Sets

  • Double Track

Double Track

  • 15-Minute Headways

15-Minute Headways

  • 2030 Traffic Conditions

2030 Traffic Conditions

  • PM Peak Hour

PM Peak Hour

  • Major Grade Crossings Only (Mid-Blocks and Intersections)

Major Grade Crossings Only (Mid-Blocks and Intersections)

slide-39
SLIDE 39

39

Evaluation of Impacts

  • Impacts of Gate Closure

Impacts of Gate Closure

  • 45-Second Gate Closure Duration

45-Second Gate Closure Duration

  • In Comparison to No-Build Alternative

In Comparison to No-Build Alternative

  • Measured in Cumulative Vehicle Hours or Impact per

Measured in Cumulative Vehicle Hours or Impact per Vehicle in Seconds Vehicle in Seconds

slide-40
SLIDE 40

40

Impacts of DMU Alternative

Cross Street Net Cumulative Impact (veh-hr) Flagler Street

  • 5.6

Tamiami Trail

  • 5.2

Coral Reef Drive

  • 6.9

Coral Way

  • 5.2

Bird Road

  • 7.8

Miller Road

  • 5.0

Sunset Drive

  • 5.1

Kendall Drive

  • 7.1

SW 112 Street

  • 2.2

Average

  • 5.6

Negative Values Indicate Delays

slide-41
SLIDE 41

41

Summary – DMU Alternative

  • Gate Closure Marginally Impacts Vehicular Traffic

Gate Closure Marginally Impacts Vehicular Traffic

  • Per Vehicle Impact is Around 45 Seconds

Per Vehicle Impact is Around 45 Seconds

  • Highest Cumulative Delay

Highest Cumulative Delay Bird Road, Kendall Bird Road, Kendall Drive, and Coral Reef Drive Drive, and Coral Reef Drive

slide-42
SLIDE 42

42

Comparison of Alternatives

  • BRT Alternatives

BRT Alternatives

Transit Signal Priority Marginally Benefits Traffic Geometric Modifications Adversely Impact Traffic

  • DMU Alternative

DMU Alternative

Affects Fewer Vehicles Average Delay Per Impacted Vehicle is 45 Seconds

slide-43
SLIDE 43

43

Summary Summary

slide-44
SLIDE 44

44

Tier 2 Summary

Alternative

Ridership (Trips) Capital Cost (millions) O & M Cost (millions) Traffic Impact Major Intersections Affected

A1 – Kendall BRT

10,048 $ 326.6 $ 4.8 High 16

A2 – Kendall BRT

7,041 $ 253.7 $ 5.2 High 15

A3 – Kendall BRT

5,834 $ 249.7 $ 4.6 High 13

A4 – Kendall MetroRail

15,565 $ 1,682.0 $ 18.8 Low N/A

B1 – HEFT MetroRail

12,265 $ 1,686.3 $ 19.7 Low N/A

C2 – DMU / CSX – 30 min.

600 $ 190.6 $ 5.2 Low 9

C3 – DMU / CSX - 20 min.

1,912 $ 224.1 $ 7.7 Low 9

C4 – DMU / CSX – 15 min.

3,083 $ 368.0 $ 12.0 Low 9

C4 – DMU / CSX – SW 157th

3,017 $ 386.5 $ 12.2 Low 10

D1 – 137th Ave. BRT

7,785 $ 407.9 $ 6.5 High 14

slide-45
SLIDE 45

45

Next Steps Next Steps

slide-46
SLIDE 46

46

Next Steps Next Steps

1. 1. Further Technical Analysis Further Technical Analysis

  • Refine Ridership Demand
  • Develop FTA User Benefits

2.

  • 2. Public / Stakeholder Outreach

Public / Stakeholder Outreach 3.

  • 3. Identify Preferred Transit Strategy

Identify Preferred Transit Strategy

  • Near-Term
  • Mid-Term
  • Long Term Vision

4.

  • 4. MPO Action

MPO Action

slide-47
SLIDE 47

47

www.kendall-link.com
