SLIDE 1
O u r B a c k g r o u n d
O u r B a c k g r o u n d Part of Gpi Group Tanks & Process - - PowerPoint PPT Presentation
O u r B a c k g r o u n d Part of Gpi Group Tanks & Process - - PowerPoint PPT Presentation
O u r B a c k g r o u n d Part of Gpi Group Tanks & Process Scraped Surface Heat Pickling & Pacifating Equipment Exchangers O U R C O M P A N Y I N N U M B E R S > 150 600 > 25 5 People working Production locations
SLIDE 2
SLIDE 3
Part of Gpi Group
Tanks & Process Equipment Pickling & Pacifating Scraped Surface Heat Exchangers
SLIDE 4
O U R C O M P A N Y I N N U M B E R S
> 150
People working
5
Production locations
600
Tanks & equipment annualy
> 25
Years in business
SLIDE 5
O u r E q u i p m e n t
SLIDE 6
Heat Exchanger Types
Plate Heat Exchanger
SLIDE 7
Heat Exchanger Types
Plate Heat Exchanger Tubular Heat Exchanger
SLIDE 8
Heat Exchanger Types
Plate Heat Exchanger Tubular Heat Exchanger Scraped Surface Heat Exchanger
SLIDE 9
Continuous Scraping
Efficient Heat Transfer No Burn-on No Fouling of Surface
SLIDE 10
2 Heat Transfer Surfaces
Efficient Heat Transfer Compact Solution Low Pressure Drop
SLIDE 11
2 Heat Transfer Surfaces
Efficient Heat Transfer Compact Solution Low Pressure Drop Productspace
SLIDE 12
2 Heat Transfer Surfaces
Efficient Heat Transfer Compact Solution Low Pressure Drop Heat Transfer Surfaces
SLIDE 13
Vertical Design
Easy Inspection No oil contamination One Seal Small Footprint
SLIDE 14
Hygienic Lipseal
Cardridge Easy Replaceable Low TCO Cleanable Controllable
SLIDE 15
Hygienic Lipseal
Cardridge Easy Replaceable Low TCO Cleanable Controllable Cleanable
SLIDE 16
Hygienic Lipseal
Cardridge Easy Replaceable Low TCO Cleanable Controllable Controllable
SLIDE 17
Low Shear
35 – 130 RPM No Product Damage Particle Size Up To 25mm
SLIDE 18
Detectable Scrapers
PEEK (polyetheretherketone) Non-Toxic Temperature Resistant X-Ray & Metal Detectable
SLIDE 19
P r o d u c t s
SLIDE 20
Viscous Products
SLIDE 21
Viscous Products
SLIDE 22
Crystallizing products
SLIDE 23
Particle Laden Products
SLIDE 24
A p p l i c a t i o n s
SLIDE 25
Crystallizing
Jellifying Tempering Cooling
Cooling Applications
SLIDE 26
Sterilisation Pasteurisation Boiling Heating
Heating Applications
SLIDE 27
C a l c u l a t i o n
SLIDE 28
Parameters
Type of medium Medium temperature Medium pressure Flow Product temperature in Product temperature out Flow rate (m³/h) Density (kg/m³) Specific Heat (J/kgK) Conductivity (W/mK) Viscosity (cP)
SLIDE 29
Model Heat Transfer Surface Footprint Height Kelstream F50 0.5m² 0.8m 1.3m Kelstream F100 1.0m² 0.8m 1.6m Kelstream F150 1.5m² 0.8m 1.9m Kelstream F200 2.0m² 0.8m 2.3m Kelstream F450 4.5m² 1.3m 2.4m Kelstream F700 7.0m² 1.3m 3.4m
Models
SLIDE 30
Worldwide Network
HQ Orange = Dealer
SLIDE 31
R e f e r e n c e s
SLIDE 32
