slide-1
SLIDE 1

NOPTA Offshore Petroleum Data – Building a new offshore data management capacity National Data Repositories 2014 BAKU, October 2014

Presented by Mark Ducksbury Assistant Manager, Compliance and Operations Support www.nopta.gov.au

slide-2
SLIDE 2

Major Australian Petroleum Basins

www.nopta.gov.au

  • 95% of Australian oil and 83% of gas production is offshore
  • Major offshore exploration WA , Major production WA/Victoria

subseaworldnews.com

slide-3
SLIDE 3

Australian Commonwealth Offshore Areas

www.nopta.gov.au

  • A single set of rules but multiple interpretations
  • 7 Designated Authorities into a single Joint Authority

http://www.ga.gov.au

slide-4
SLIDE 4

About NOPTA

  • NOPTA – National Offshore Petroleum Titles Administrator
  • NOPSEMA - National Offshore Petroleum Safety and Environment

Management Authority

  • Productivity Commission review of upstream petroleum industry in Australia
  • Montara, Varanus Island, Deepwater Horizon, lessons from petroleum emergencies
  • Split of regulatory responsibilities – economic versus safety and environment
  • NOPTA established from 1st January 2012 - head office in Perth, Branch Office in Melbourne
  • Cost recovery funding model – paid by industry
  • NOPTA’s key functions in regard to Commonwealth waters
  • Providing technical advice to the Joint Authority (the formal approver of offshore activities)
  • Administering titles in offshore areas– streamlining the approvals process
  • Providing consistent data and resource management functions

www.nopta.gov.au

enviroinfo.com.au nopesema.gov.au

slide-5
SLIDE 5

NOPTA – Setting the scene

www.nopta.gov.au

Microsoft's 2014 Roadmap: Kurt Mackie 2013

Last 30 months

  • Understanding NOPTA’s role and functions –legislation, Minister’s statement of expectations
  • Recruitment, training development – ‘a little knowledge is a dangerous thing’
  • Strategic planning, risk management, business continuity frameworks
  • Quality control and process development across all teams, linking the pieces
  • Online NEATS Releases Stage 1 and Stage 2 – titles online
  • Data Management Review – physical samples, digital data, submission guidelines
  • NOPDCR – implementing the National Data Repository management model
  • Engaging stakeholders and gaining credibility
  • Consolidation of the Commonwealth data collection
slide-6
SLIDE 6

NOPTA – Setting the scene

Data management role and responsibility

Administration of Offshore Petroleum and Greenhouse Gas (OPGGSA) Act 2006 and Resource Management Administration (RMA) Regulations

  • Titles Administrator’s role in Data Management:
  • Ensuring legislative compliance of submissions and ensuring data quality
  • Maintaining the data whilst under confidentiality and making it known – public release
  • Responsibility for ongoing management and access to the open file data
  • NOPTA not funded to provide this function – funded only in relation to collection and compliance
  • Build on the systems, experience and expertise of others – Geoscience Australia
  • Geoscience Australia's - open file offshore data custodian
  • GA’s appropriation now augmented for this function
  • National Offshore Petroleum Data & Core Repository
  • Tri-partite collaborative agreement b/w NOPTA, GA & WA’s DMP
  • Operating from 1 January 2013 – East and West repositories

www.nopta.gov.au

DonStock Photos - http://www.shutterstock.com/s/don/

slide-7
SLIDE 7

NOPTA – Setting the scene

Data Compliance Responsibilities

  • Daily Drilling Reports – 80 -100 new wells each year
  • Weekly Survey Reports – 20 to 40 new surveys each year
  • Monthly Production Reports – 90 offshore production leases
  • Discovery Reports – varies, 10 to 15 each year
  • Annual Title Assessment Reports – up to 450 titles each year
  • Title Condition Reports – work programs, surrenders/expiries
  • Export & Submission Variation approvals – up to 250 each year
  • Wells Reports & Data – new wells/major well work overs
  • Well Completion Reports & data – basic and interpretative
  • Outstanding or non compliant data & data due for submission
  • Survey Reports & Data – new/reprocessed surveys

Survey acquisition, processing, interpretative reports & data Reprocessing activities – work programs

  • Log QC – GA/NOPDCR as QC partner
  • Data release – 300 to 400 activities each year

www.nopta.gov.au

slide-8
SLIDE 8

NOPTA – Setting the scene

NEATS - National Electronic Approval Tracking System

www.nopta.gov.au NEATS includes a public portal and provides access to information held within the title register, application tracking and the electronic lodgement of applications.

slide-9
SLIDE 9

NOPTA – Setting the scene

NOPDCR – funding of data management operations

www.nopta.gov.au

$ $ $ $ $ $ $ $ $

slide-10
SLIDE 10

Petroleum Titleholder/contractor/geophysical company

NOPTA – Setting the scene

Wells and surveys data flow – submission and compliance

NOPTA

Titles application management and monitoring

National Offshore Petroleum Data and Core Repository (NOPDCR) Confidential data GSWA Repository (Perth) Confidential data

NEATS

NOPTA Data submission process

  • Activity reports, final data and physical samples
  • Metadata creation
  • Publication of activity
  • Program identification
  • Data receipt
  • Contents compliance
  • Stakeholder Liaison
  • 2/3 Core and cuttings
  • Sidewall cores
  • Thin sections – paly/paleo

NOPTA Quality Control (outsourced to NOPDCR/GA)

  • 1/3 core and field data receipt
  • Notification to NOPTA
  • Data storage and maintenance
  • Title application management
  • Title activity monitoring

www.nopta.gov.au

  • Well completion reports – basic/interpretative
  • Well logs and supporting raw data
  • Survey reports – acquisition/processing/ interpretative
  • Survey logs and supporting raw data

GA Repository (Canberra) Confidential data

slide-11
SLIDE 11

National Offshore Petroleum Data and Core Repository

Confidential Data

NOPDCR*

West Coast repository Geological Survey of Western Australian

NOPDCR

East Coast repository Geoscience Australia

ausgeodata@ga.gov.au Open File Data NOPTA

  • NOPTA authorises release
  • NOPTA advises NOPDCR that data confidentiality has expired
  • NOPDCR confirms data is available for delivery

NOPTA involvement ceases

*Physical samples only

  • NOPTA confirms all data and samples have been submitted
  • NOPTA checks regulations to ensure expiry of relevant confidentiality period
  • NOPTA confirms data is not subject to additional confidentiality provisions
  • NOPDCR advises former authority (where appropriate)
  • Data and/or physical samples moved to ‘open’ category
  • Data and/or physical samples made available to clients

NOPTA – Setting the scene

Wells and surveys data flow – release and availability

Viewing and sampling Open File Data NOPIMS Open File Data

  • Client requests data
  • Reports on physical sampling required by NOPDCR
  • Compliance activity related to sampling
  • Reports added to Commonwealth data collection

Legacy systems Open File Data www.nopta.gov.au

slide-12
SLIDE 12

NOPTA – Setting the scene

NOPDCR Repository consolidation

From this……..

www.nopta.gov.au

mapsnworld.com

To this……..

slide-13
SLIDE 13

NOPTA – Setting the scene

NOPDCR Repository consolidation

NOPDCR East Coast NOPDCR West Coast www.nopta.gov.au

slide-14
SLIDE 14

Geoscience Repositories and Digital Collections

NOPTA – Setting the scene

NOPDCR Repository consolidation

www.nopta.gov.au

Data relocation project schedule State/Territory Data type Moved to Date moved Volume Distance KM Northern Territory samples Perth NOPDCR Nov-12 130 pallets 4040 Northern Territory hard copy Canberra NOPDCR Mar-13 26 pallets 3140 Queensland samples Canberra NOPDCR Dec-13 1 pallet 1155 Queensland hard copy Canberra NOPDCR Dec-13 1 pallet 1155 New South Wales samples Canberra NOPDCR Feb-14 1 pallet 285 New South Wales hard copy Canberra NOPDCR Feb-14 1 pallet 285 Tasmania samples Perth NOPDCR Mar-14 70 pallets 4143 Tasmania hard copy n/a digital only n/a n/a n/a South Australia samples Perth NOPDCR Apr-14 35 pallets 2691 South Australia hard copy n/a digital only n/a n/a n/a Western Australia samples retained - NOPDCR n/a n/a n/a Western Australia hard copy Canberra NOPDCR Jul-14 85 pallets 3840 Victoria samples Perth NOPDCR by Mar-15 ~ 260 pallets 3420 Victoria hard copy Canberra NOPDCR by Jun-15 ~ 10 pallets 650 Totals ~ 620 pallets 24,804

slide-15
SLIDE 15

NOPTA and NOPDCR Next Steps

www.nopta.gov.au

The next 30 months ……

  • Digitisation and Integration
  • Regulation change and guideline

development

  • Embedding the QC function
  • New techniques and challenges
  • Standards implementation
  • NOPIMS online discovery, delivery – and submission

J W Waterhouse – The Crystal Ball

slide-16
SLIDE 16

NOPTA and NOPDCR Next Steps

Digitisation and Integration

www.nopta.gov.au

From this…….. To this……..

slide-17
SLIDE 17

NOPTA and NOPDCR Next Steps

Regulation change and guideline development

  • Clarification of obligations – reprocessed surveys, work overs
  • Stakeholder consultation and interest group surveys
  • Socialisation through peak bodies
  • Examples of ‘best practice’

Embedding the QC function

  • Complete contents – logs and analysis
  • Narrative supported by raw data
  • Digital Logs - DLIS InfoView and LAS Certify
  • Usability – Geoframe, GA in-house systems

New techniques and challenges

  • GeoStreamer, MAZ/RAZ, broadband, 4D, seabed surveys,
  • Production & reservoir performance, environmental studies
  • CO2 – injection, storage and sequestration

Standards Implementation

  • PPDM data modelling
  • Energistics WITSML

www.nopta.gov.au

GeoStreamer GS - http://pgs.com/en/Geophysical-Services/Seismic- Techniques/ DISCover Broadband - http://www.slb.com/services/seismic/seismic_acquis ition/services/marine/techniques/discover.aspx Multi-Azimuth - http://techlib.pgs.com/MediaFiles/67_TechLink16_M ulti-Azimuth

slide-18
SLIDE 18

NOPTA and NOPDCR Next Steps

NOPIMS online discovery and delivery – and submission

(National Offshore Petroleum Information Management System)

www.nopta.gov.au

NOPIMS development environment screenshot – courtesy GA

slide-19
SLIDE 19

Geoscience Repositories and Digital Collections

Offshore Statistics

Commonwealth offshore data holdings

www.nopta.gov.au

slide-20
SLIDE 20

Geoscience Australia National Data Repositories

Commonwealth Palaeontological Collection GA Rock Store Marine Core Collection GA Mineral Specimen Collection

Confidential Data

National Offshore Petroleum Data and Core Repository (NOPDCR) GA Onshore Survey Repository

National Offshore Petroleum Data and Core Repository

(Core, Digital, Fluids and Gas Stores)

Open File Data

Data moves from ‘Confidential’ to ‘Open File’

GA Cold Store www.nopta.gov.au

slide-21
SLIDE 21

Australian Oil and Gas Statistics

www.nopta.gov.au

50 100 150 200 250 300 350 2000 2001 2002 2003 2004 2005 2006 2007 2008 2009 2010 million barrels

Source: APPEA

Australian Crude Oil, Condensate & LPG Production

Crude Condensate LPG

200 400 600 800 1000 1200 1400 1600 1800 2000 2000 2001 2002 2003 2004 2005 2006 2007 2008 2009 2010

Australian Gas Production

LNG Conventional gas CSG

Source: APPEA

billions of cubic feet

slide-22
SLIDE 22

Australian Oil and Gas Statistics

www.nopta.gov.au

slide-23
SLIDE 23

Australian Oil and Gas Statistics

www.nopta.gov.au

Australian crude oil, condensate and LPG reserves

Source: GA

slide-24
SLIDE 24

Questions?

www.nopta.gov.au

www.dogonews.com

(Answers not guaranteed ………)

slide-25
SLIDE 25

Further Contacts:

http://www.nopta.gov.au/

  • General website for NOPTA, access to NEATS system, forms/publications

http://www.nopta.gov.au/data-mgmt/index.html

  • Data specific webpages – access to regulations, submission guidelines,

notices and updates data@nopta.gov.au

  • Requests for export approval, submission variations, general questions

reporting@nopta.gov.au

  • Submission of activity reports including Daily Drilling, Weekly Survey,

Monthly Production, Annual Title Assessment and Discovery Reports mark.ducksbury@nopta.gov.au

  • Information on NOPTA, NOPDCR, NOPIMS or national repository approach

andrew.owen@ga.gov.au

  • Information on Geoscience Australia or East and West NOPDCR repositories
