01/07/2015 1 29 / Non-crossing polymers and the KPZ equation Andrea De Luca in collaboration with P. Le Doussal arXiv:1505.04802 01/07/2015 KPZ equation PRL 56 889 (1986), Kardar, Parisi, Zhang relaxation lowest order Gaussian noise
SLIDE 2
SLIDE 3
Concrete examples 3 29 / 01/07/2015
Turbulent liquid crystals - PRL 104 230601
Tracy-Widom distribution
SLIDE 4
Cole-Hopf mapping 4 29 / 01/07/2015
diffusion equation in a random potential: directed polymer partition function
SLIDE 5
Quantum mechanics and replica 5 29 / 01/07/2015
Path integral representation (Feynman - Kac)
SLIDE 6
High-temperature and Lieb-Liniger 6 29 / 01/07/2015
Rescaling of variables We end up with the attractive Lieb-Liniger Hamiltonian which is integrable in 1dimension!
SLIDE 7
Bethe-ansatz approach 7 29 / 01/07/2015
Hard to treat: it contains space-time correlation of the KPZ height
decomposition in eigenstates
If we can compute the spectrum, we can find arbitrary moments...
SLIDE 8
Bethe-ansatz equations 8 29 / 01/07/2015
The initial condition is symmetric: the dynamics lies in the bosonic sector of the Hamiltonian The coefficient implements the scattering matrix How to fix the values of rapidities?
superposition of plane waves in each sector
SLIDE 9
Periodic boundary condition 9 29 / 01/07/2015
The values of rapidities are fixed by boundary
- conditions. In the symplest case
Bethe-Ansatz equations for the LL model Solutions at finite L are not easy... But in the thermodynamic limit?
SLIDE 10
String ansatz 10 29 / 01/07/2015
If for large L, we have a divergence in the LHS, which must be compensated by a pole in the RHS
bound states (strings) 5-string
1-string
SLIDE 11
String features 11 29 / 01/07/2015
5-string energy momentum
SLIDE 12
Needed ingredients 12 29 / 01/07/2015
Norm WF
SLIDE 13
General expression for moments 13 29 / 01/07/2015
The sum over eigenstates becomes the sum
- ver the possible partitioning of the n particles
into strings
sum over partitions
It is exact... but how to deal with it?
SLIDE 14
Partition function at fixed string number 14 29 / 01/07/2015
Use the grancanonical partition function: In this way we can recover the free energy distribution
SLIDE 15
Fredholm determinant 15 29 / 01/07/2015
Exchanging the two sums, we obtain In the large time limit, one obtains
Tracy-Widom GUE distribution EPL 90 2 (2010) Calabrese, Le Doussal, Rosso
SLIDE 16
Non-crossing polymers 16 29 / 01/07/2015
Can we use replica approach to treat non-crossing polymers? Simplest example of interaction, together with disorder...!
SLIDE 17
Karlin-McGregor formula 17 29 / 01/07/2015
Similar formulas for more than two polymers
SLIDE 18
Coinciding points 18 29 / 01/07/2015
SLIDE 19
Replica for non-crossing polymers 19 29 / 01/07/2015
The expression is analogous to the one for single polymer. But the bosonic sector gives a vanishing contribution! How to build wave functions with different symmetries?
SLIDE 20
Wave function and Young tableau 20 29 / 01/07/2015
We look for eigen functions antisymmetric in the first two variables...
symmetric antisymmetric
More general ansatz...
SLIDE 21
Nested Bethe Ansatz 21 29 / 01/07/2015
The auxliary variable implement the symmetry
- f the wave function.
In general, one auxiliary variable for every doubled column
SLIDE 22
String ansatz? 22 29 / 01/07/2015
For large L, the first equation suggests again the presence of strings What about the auxiliary variable?
SLIDE 23
Contour integral 23 29 / 01/07/2015
The solution of the second equation are non trivial... But we are only interested on the sum
SLIDE 24
Comparison with bosonic case 24 29 / 01/07/2015
After summing over the auxiliary variable, we get an expression very similar to the bosonic case Norm is unchanged
conserved quantities
- f the LL
SLIDE 25
Generalized Gibbs Ensemble 25 29 / 01/07/2015
we replace time evolution with a generalized evolution with multiples times
The average non-crossing probability is not affected by disorder!
SLIDE 26
Comparison with numerics 26 29 / 01/07/2015
Two-lines derivation
SLIDE 27
Recipe for higher moments 27 29 / 01/07/2015
In order to compute higher moments
- symmetrize the polynomial in terms of
conserved charges
- write the result as a set of derivatives
applied to the generalized moments
SLIDE 28
Results for higher moments 28 29 / 01/07/2015
Leading order
Physical picture:
- for most of the realization:
p is exponentially small
- for a fraction 1/t
- f the realization, p is O(c^2)
SLIDE 29
Conclusions 29 29 / 01/07/2015
- We developed a framework based on the Nested Bethe ansatz
to deal with non-crossing polymers in random media;
- We computed exactly the large times asymptotics
for the moments of the non-crossing probability for two polymers;
- Agreement with numerical lattice simulations:
the crossing probability is most of the time exponentially small Open questions:
- generalization to multi-polymers
- higher order large time asymptotics: connection with
