01/26/2017 Node Pole Examples AGL Summit - Seattle Proprietary & AGL Summit | 1 Confidential What is a Small Cell? There is not a universal definition of small cell 1. A small cell is a single, low power, optically fed


slide-1
SLIDE 1

| 1 AGL Summit

Proprietary & Confidential

Node Pole Examples

AGL Summit - Seattle 01/26/2017

slide-2
SLIDE 2

| 2 AGL Summit

Proprietary & Confidential

What is a “Small Cell”?

There is not a universal definition of “small cell”

  • 1. A small cell is a single, low power, optically fed unit (often part of a bigger

network) designed to augment macro coverage and provide capacity relief in densely populated areas.

  • 2. Small cells are generally placed on existing structures in the Public Right-of-

Way.

  • 3. In underground districts (new) stand alone poles are needed
  • 4. Existing wooden power poles are the fastest and most desirable method to

deploy small cell networks – lowest impact to neighborhoods. Street lamps

  • ffer clean alternatives to power poles
  • 5. Power and Fiber are as much a part of the network as radios and antennas
  • 6. Before Small Cell Networks can be developed, Right of Way agreements and

Pole Attachment Agreements are needed

slide-3
SLIDE 3

| 3 AGL Summit

Proprietary & Confidential

Components of SCS

SCS Networks typically are comprised of these components

slide-4
SLIDE 4

| 4 AGL Summit

Proprietary & Confidential

Street Lamp Replacement

Oakland, CA – Equipment inside base

slide-5
SLIDE 5

| 5 AGL Summit

Proprietary & Confidential

Street Lamp Replacement

Equipment concealed inside pole

slide-6
SLIDE 6

| 6 AGL Summit

Proprietary & Confidential

Traffic Signal Replacement

slide-7
SLIDE 7

| 7 AGL Summit

Proprietary & Confidential

Street Lamp Replacement

Ground Mounted Equipment Cabinets

slide-8
SLIDE 8

| 8 AGL Summit

Proprietary & Confidential

Street Lamp Replacement

Ground Mounted Equipment Cabinets cont…

slide-9
SLIDE 9

| 9 AGL Summit

Proprietary & Confidential

Street Lamp Replacement

Ground Mounted Equipment Cabinets cont…

slide-10
SLIDE 10

| 10 AGL Summit

Proprietary & Confidential

Street Lamp Replacement

Ground Mounted Equipment Cabinets cont…

slide-11
SLIDE 11

| 11 AGL Summit

Proprietary & Confidential

Wooden Utility Poles

slide-12
SLIDE 12

| 12 AGL Summit

Proprietary & Confidential

Custom Solutions

  • Flat rate Power – no meter
  • Equipment & Antennas hidden

inside structure

  • Battery backup partially buried

under “faux’ rock Limited only by our imagination (and budget!)

slide-13
SLIDE 13

| 13 AGL Summit

Proprietary & Confidential

Strand Mounted RRHs

Low power, small coverage area

slide-14
SLIDE 14

| 14 AGL Summit

Proprietary & Confidential

Equipment Examples cont…

Ericsson cabinet – RB6501 & mRRUS12

slide-15
SLIDE 15

| 15 AGL Summit

Proprietary & Confidential

Antennas

No Shroud

Custom Shroud Cylindrical with multi carriers

slide-16
SLIDE 16

| 16 AGL Summit

Proprietary & Confidential

Cabling Schematic

2100 LTE & 1900 LTE + UMTS

slide-17
SLIDE 17

| 17 AGL Summit

Proprietary & Confidential
