NOAA Solar Irradiance Data and Rescue (SIDAR) Program Dan Mamula NOAA SIDAR Program Manager April 30, 2015 Page: 1 SIDAR Mission SIDAR Program is 3 different projects Continue measurement of the Suns Direct and Indirect Effects on

slide-1
SLIDE 1

NOAA

Solar Irradiance Data and Rescue (SIDAR) Program

April 30, 2015 Dan Mamula NOAA SIDAR Program Manager

Page: 1

slide-2
SLIDE 2

SIDAR Mission

  • SIDAR Program is 3 different projects
  • Continue measurement of the Sun’s Direct and Indirect Effects on Climate
  • Continue the operation of the Argos Data Collection System obtaining a

wide variety of data from platforms used for both environmental study and non-environmental uses

  • Continue the operation of the SAR instruments as part of the international

COSPAS-SARSAT system designed to detect and locate Emergency Locator Transmitters (ELTs), Emergency Position-Indicating Radio Beacons (EPIRBs) and Personal Locator Beacons (PLBs)

Page: 2

slide-3
SLIDE 3

SIDAR Instruments

  • Total & Spectral Solar Irradiance Sensor (TSIS)
  • NASA / Laboratory for Atmospheric and Space Studies (LASP) at

the University of Colorado

  • Advanced Data Collection System (A-DCS)
  • Centre National d’Etudes Spatiales (CNES) {France} / Thales
  • Search and Rescue Processor (SARP)
  • Centre National d’Etudes Spatiales (CNES) {France} / Thales
  • Search and Rescue Repeater (SARR)
  • Department of National Defence (DND) {Canada} / Com Dev

Page: 3

slide-4
SLIDE 4

Program Status

  • SIDAR became a program with the FY 2015 appropriation
  • Included “$7.3M to support activities associated with accommodating TSIS-1

instrument on ISS and to maintain international partnerships related to SARSAT and A-DCS”

  • President’s FY 2016 budget
  • “Transfers TSIS-1 to NASA consistent with the Administration's decision to

move solar irradiance measurements to NASA”

  • “NOAA to plan the accommodation for A-DCS and SARSAT for launch”

Page: 4

slide-5
SLIDE 5

TSIS

Page: 5

slide-6
SLIDE 6

TSIS Status

  • TIM and SSI sensors are in storage at Laboratory for

Atmospheric and Space Physics (LASP) at the University of Colorado.

  • TIM and SIM sensors successfully completed pre-ship review in December

2013

  • Total solar irradiance (TSI) calibration transfer experiment

(TCTE) operating on Air Force space test program satellite (STP- Sat3), collecting TSI data weekly.

  • TCTE measurements will be used to calibrate TSIS/ISS with SORCE

(operating since 2003) TSI measurements

  • Program accepted for integration on International Space Station

(ISS)

  • LASP is developing a thermal pointing system
  • Manifest candidate on SpaceX 15
  • Sep 2017 Launch Readiness Date (LRD)

Page: 6

slide-7
SLIDE 7

TSIS Elements on ISS

Launch Towers With Sep Nuts Two Axis Gimbal Third Axis Deployment System (TADS) Main Baseplate to ExPa Flexures Main Baseplate Thermal Pointing System Instrument S/C I/F Electronics (TPS ISIE) SIM SIM Generic Channel I/F (GCI) Electronics TIM TIM Generic Channel I/F (GCI) Electronics (TADS) Latch High Rate Fine Sun Sensor (HFSS) Fine Sun Sensor (FSS)

*green denotes completed hardware currently in storage

Optical Bench Microprocessor Unit (MU)

FRAM provided by ISS

Page: 7

slide-8
SLIDE 8

** TCTE ** must be flown at the same time (calibrated) with TSIS in order to continue the Climate Data Record.

78 80 82 84 86 88 90 92 94 96 98 00 02 04 06 08 10 12 14 16 18 20 22 24 26 28 30

Total and Spectral Solar Irradiance

Operational Provide CDRs =USA Experimental dark green=Foreign Partner

ERB

Operating beyond design life

ACRIM1 NOAA9

SOVA2

ACRIM2 VIRGO ACRIM3

PREMOS

SORCE TCTE

** **

NOAA10

SORCE ISS/TSIS-1 NASA/TSIS-2 ISS/TSIS-1 NASA/TSIS-2 Glory (launch Failed) Possible Gap

Page: 8

slide-9
SLIDE 9

Argos A-DCS and SARSAT

  • A-DCS supports global tracking and

environmental data collection applications

  • A-DCS heritage sensors fly on NOAA (POES), and

EUMETSAT (MetOp) satellites.

  • )
  • SARSAT collects distress beacon signals at the

satellite

  • SARSAT heritage sensors fly on NOAA (POES),

and EUMETSAT (MetOp) satellites.

Page: 9

slide-10
SLIDE 10

Argos A-DCS and SARSAT Instrument Status

  • Advanced Data Collection System (A-DCS) @ CNES France
  • Instrument complete and in storage in France
  • Search and Rescue Processor (SARP-3) @ CNES France
  • Instrument complete and in storage in France
  • Search and Rescue Repeater (SARR) @ Canada DND
  • SARR CDR completed January 2015

Page: 10

A-DCS SARP SARR

slide-11
SLIDE 11

05 06 07 08 09 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30

Metop-B (Argos-3*) NOAA-19 (Argos-3*)

Operational Design Life (Blue=USA; Green=EUMETSAT; Orange=Other)

Metop-C (Argos-3)

Early AM orbit Mid AM orbit PM orbit

Operating On Side B * Platform Interrogation Off Operating On Side B Partial AHRPT Coverage Combined Receive Antenna Issue * Platform Interrogation Off

Predicted Extended Mission Life

New “Circular Buffer” (improved timeliness)

Metop-SG B1 (Argos-4) “SIDAR” (Argos-4)

Early AM = ~05:30/17:30 Local Mid AM = ~09:30/21:30 Local PM = ~13:30/01:30 Local

Note There are no current plans to decommission NOAA-15,18,19

“Future NOAA” (Argos-4)

Secondary (Operating Beyond Mission Life)

Drifting Towards Early AM Orbit To Be Followed By Metop-SG B2 (~2029)

Calendar Year (20xx)

Metop-A (Argos-3) SARAL Follow-on?? (Argos-4)

Argos DCS Space Segment

SARAL (Argos-3) NOAA-18 (Argos-2) NOAA-15 (Argos-2) NOAA-18 (Argos-2) NOAA-15 (Argos-2)

Page: 11

slide-12
SLIDE 12

98 99 00 01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24

MetOp-A N18 MetOp-B N19

Operational (purple=USA; green=EUMETSAT; gold=Russia)

Early AM

  • rbit

Mid AM

  • rbit

PM

  • rbit

N15 SIDAR/HoPS

Combined Receive Antenna Anomaly (minor degradation)

Operational beyond design life

C-11 Failure On Launch C-12 Failure On Launch

COSPAS ??

M E O S A R

Possible SARSAT gap

SARSAT LEO Space Segment

Drifting Towards Early AM Orbit

Possible SARSAT gap

Page: 12

Early AM = ~05:30/17:30 Local Mid AM = ~09:30/21:30 Local PM = ~13:30/01:30 Local

slide-13
SLIDE 13

Accommodation Planning for A-DCS, SARP and SARR

  • NOAA is planning to use the USAF Hosted Payload

Solutions (HoPS) contract

  • Released an RFI in August 2014 to HoPS contractors and

received RFI responses that meet user requirements

  • SIDAR presented at the September 2014 HoPS kickoff meeting for

contractors for potential accommodation of A-DCS, SARR & SARP and held half-hour one-on-one meetings with host companies

  • Project presented at the March 2015 HoPS vendor workshop and

held half-hour one-on-one meetings with host companies

  • SIDAR is working with the USAF to establish an interagency

agreement

  • Planning for a FY 2017 Delivery Order

Page: 13

slide-14
SLIDE 14

UNCLASSIFIED

USAF SMC HoPS Contract Overview

Contract Summary

  • FAR 12 Commercial Procurement (supply

contract)

  • Multiple Award IDIQ w/ Firm Fixed Price DO
  • Access to 8 prime LEO/MEO contractors

and 12 GEO contractors providing HP

  • pportunities
  • 5-Year Ordering Period; 10-Year Max DO PoP
  • IDIQ Contract Ceiling value: $495M
  • IDIQ deliverables
  • Hosting opportunities list
  • Host spacecraft compatibility requirements
  • CLIN Structure
  • Hosted Payload Flight System
  • Hosted Payload Ground System
  • Operations Support

LEO IDIQ Contract Awardees

  • Astrium Services Government, Inc.
  • The Boeing Co.
  • Exoterra Resources, LLC.
  • Harris Corp. - Government Communications

Systems Business Unit

  • Millennium Engineering & Integration

Company

  • Orbital Sciences Corp.
  • Space Systems/Loral, LLC.
  • Surrey Satellite Technology

IDIQ Awarded July 2014

Page: 14

slide-15
SLIDE 15

Summary

  • SIDAR became a program with the FY 2015

appropriation

  • The FY 2016 President’s Budget transfers TSIS to

NASA

  • NOAA is working with the USAF to establish an

Interagency Agreement to use the HoPS contract vehicle for hosting the Argos A-DCS and SARSAT instruments

  • Delivery order planned for FY 2017

Page: 15
