Ni-MH ENDURANCE range Benefits 2 ENDURANCE range- ARTS Energy proprietary & Confidential Dec. 2017 Why ENDURANCE? ENDURANCE range was developed to offer a complete battery solution with a 10 years life in extreme climates. 3 ENDURANCE

slide-1
SLIDE 1

Ni-MH ENDURANCE range

slide-2
SLIDE 2
  • Dec. 2017

2

Benefits

ENDURANCE range- ARTS Energy proprietary & Confidential

slide-3
SLIDE 3

Why ENDURANCE?

3

ENDURANCE range- ARTS Energy proprietary & Confidential

  • Dec. 2017

ENDURANCE range was developed to offer a complete battery solution with a 10 years life in extreme climates.

slide-4
SLIDE 4

Ni-MH ENDURANCE range

4

ENDURANCE range- ARTS Energy proprietary & Confidential

  • Dec. 2017

New casing for 10 years life

+ =

VHT F: 10 years life in warm countries

slide-5
SLIDE 5

Benefits of this new innovative battery casing

5

ENDURANCE range- ARTS Energy proprietary & Confidential

  • Dec. 2017

Features Benefits

New plastic design Improve robustness Space between sticks, space between layers Improve thermal homogeneity Flat shape Battery can be put under a solar panel or 1U / 19’’ configuration ENDURANCE L4 Bigger and compact batteries for bigger systems No electronics Improve reliability at the battery level Simple and rationalized design Cost effective

slide-6
SLIDE 6

Benefits of VHT technology

6

ENDURANCE range- ARTS Energy proprietary & Confidential

  • Dec. 2017
slide-7
SLIDE 7

The benefits of Ni-MH

7

ENDURANCE range- ARTS Energy proprietary & Confidential

  • Dec. 2017

Lead-acid Benefits of Ni-MH

Temperature range

  • 10°C / +45°C

0°C / +45°C

(+60°C under conditions)

  • 40°C / +85°C

Exceptional temperature range

Life duration @ 40°C 1 – 2 years 4 – 5 years 6 – 10 years Lower TCO Form factor Block Block or cylinders Cylinders A lot of flexibility Safety

Non-flammable (aqueus electrolyte)

Flammable

(organic electrolyte)

Non-flammable (aqueus electrolyte)

Safe

Transportation constraints none more and more severe none No constraints

slide-8
SLIDE 8
  • Dec. 2017

8

Performances

ENDURANCE range- ARTS Energy proprietary & Confidential

slide-9
SLIDE 9

Performances in back up applications

9

ENDURANCE range- ARTS Energy proprietary & Confidential

  • Dec. 2017

More than 10 years life @ 40°C permanent

slide-10
SLIDE 10

Performances in cycling applications

10

ENDURANCE range- ARTS Energy proprietary & Confidential

  • Dec. 2017

More than 10 000 cycles @ 50°C permanent

slide-11
SLIDE 11
  • Dec. 2017

11

Product range

ENDURANCE range- ARTS Energy proprietary & Confidential

slide-12
SLIDE 12

ENDURANCE Range

12

ENDURANCE range- ARTS Energy proprietary & Confidential

  • Dec. 2017

ENDURANCE L1 ENDURANCE L2 ENDURANCE L4

slide-13
SLIDE 13

ENDURANCE L1: Features

ENDURANCE range- ARTS Energy proprietary & Confidential

  • Dec. 2017

13

slide-14
SLIDE 14

ENDURANCE L1: Benefits

ENDURANCE range- ARTS Energy proprietary & Confidential

  • Dec. 2017

14

Solar Back Up

Slim battery that can be put under the solar panel 1U thickness Width compatible with 19’’ racks

slide-15
SLIDE 15

ENDURANCE L2: Features

ENDURANCE range- ARTS Energy proprietary & Confidential

  • Dec. 2017

15

slide-16
SLIDE 16

ENDURANCE L2: Benefits

ENDURANCE range- ARTS Energy proprietary & Confidential

  • Dec. 2017

16

Solar / cycling Back Up

Few kWh systems With the new MULTI P BMS 2U thickness Width compatible with 19’’ racks

slide-17
SLIDE 17

MULTI P + ENDURANCE: 12V or 24V

ENDURANCE range- ARTS Energy proprietary & Confidential

  • Dec. 2017

17

a centralised BMS to manage up to 10 strings in parallel = 100 Ah

slide-18
SLIDE 18

ENDURANCE L4: Features

ENDURANCE range- ARTS Energy proprietary & Confidential

  • Dec. 2017

18

slide-19
SLIDE 19

ENDURANCE L4: Benefits

ENDURANCE range- ARTS Energy proprietary & Confidential

  • Dec. 2017

19

Solar Back Up

Few kWh systems With the new MULTI P BMS Few kWh systems with

  • ur Ni-MH rectifier
slide-20
SLIDE 20
  • Dec. 2017

20

Charge controler Charger Rectifier BMS/EMS

ENDURANCE range- ARTS Energy proprietary & Confidential

slide-21
SLIDE 21

Battery interface

21

ENDURANCE range- ARTS Energy proprietary & Confidential

  • Dec. 2017

Battery Interface applications Controler/EMS Solar Rectifier Telecom - Back up

  • Railway

Charger Various (cycling) Multi P controler

Big solar systems Up to 3 kWh battery

ARTS Energy offers a large variety for battery & Load management

slide-22
SLIDE 22
  • Dec. 2017

22

Targeted markets

ENDURANCE range- ARTS Energy proprietary & Confidential

slide-23
SLIDE 23

Targeted markets

23

ENDURANCE range- ARTS Energy proprietary & Confidential

  • Dec. 2017

Solar Street Light Aviation Wind turbines

slide-24
SLIDE 24

Targeted markets

24

ENDURANCE range- ARTS Energy proprietary & Confidential

  • Dec. 2017

Telecom Railway Back Up Big solar (MULTI P)

slide-25
SLIDE 25

Back up & Telecom

25

ENDURANCE range- ARTS Energy proprietary & Confidential

  • Dec. 2017

The 1st Ni-MH Outdoor energy cabinet Introduced at GITEX 2017 (DUBAI)

slide-26
SLIDE 26
  • Dec. 2017

26

Product road map

ENDURANCE range- ARTS Energy proprietary & Confidential

slide-27
SLIDE 27

Product Road Map: VHT F 13 Ah

27

ENDURANCE range- ARTS Energy proprietary & Confidential

  • Dec. 2017

VHT F 10 Ah VHT F 13 Ah

04-2018

+30% volumetric energy +30% more energy!

slide-28
SLIDE 28

Thank you for your attention

  • Dr. Stéphane Sényarich

Business Development Stephane.senyarich@arts-energy.com

  • Tel. : +33 (0)6 73 22 80 45

www.arts-energy.com

Our Head Office / Manufacturing Site

ENDURANCE range- ARTS Energy proprietary & Confidential

ARTS Energy SAS 10 Rue Ampère Zone industrielle F-16440 Nersac

  • Tel. : +33 (0)5 45 90 35 52 / 53
  • Fax. : +33 (0)5 45 90 37 68

28

  • Dec. 2017
