New Water Sources Projects New Water Sources Projects

• f the
• f the

Metropolitan Waterworks and Metropolitan Waterworks and Sewerage System (MWSS) Sewerage System (MWSS)

• Mr. Ramon B. Alikpala

Chairman, Board Of Trustees Metropolitan Waterworks and Sewerage System (MWSS)

MWSS Priorities MWSS Priorities For The Next Six (6) Years For The Next Six (6) Years

Development of New Water Sources Development of Replacement Source for Irrigation

Development of New Water Sources: Development of New Water Sources:

Angat Dam - the only present source of water supply for the MWSS service area serving a total of 13 million population out of the total service population of 15 million, or only 87% total service coverage. Angat Dam provides a supply volume of 4,000 million liters per day (4,000 mld) out of the present demand of 4,395 mld, or a deficit of 395 mld. By 2015, the projected demand is expected to reach 5,054 mld, thus requiring the development

• f

supplementary sources

• f

water to address the increasing demand.

Supply Supply – – Demand Projection Demand Projection

Year Supply (mld) Demand (mld) Deficit (mld) Supply Source 2009 4,000 Angat Dam = 4000mld 2010 4,100 4,395 295 + Laguna Lake = 100mld 2011 4,250 4,532 282 + Laguna Lake = 150mld 2012 4,600 4,605 5 + Laguna Lake = 150mld + Sumag River = 200mld 2015 4,600 5,054 454 2020 4,600 5,680 1,080

NOTE: Laguna Lake and NOTE: Laguna Lake and Sumag Sumag River will be implemented by the MWSS’ Concessionaires River will be implemented by the MWSS’ Concessionaires

Development of New Water Sources: Development of New Water Sources:

Based on the Supply-Demand Projection, potential new water sources were identified to fill the gap starting 2015 (these are enumerated in the succeeding slides) MWSS will hire consultant:

• to validate water demand study,
• to

undertake the necessary updating, comparative evaluation and prioritization of the various new water sources identified, in order to come up with a new road map;

• to prepare the first priority project biddable by 2012.

POTENTIAL NEW WATER SOURCES PROJECTS POTENTIAL NEW WATER SOURCES PROJECTS

Project Description Potential Supply Volume Project Cost

(Estimate)

Status/Remarks

1) Kaliwa Low Dam Project Construction of a low dam (height=30m) and appurtenant structures such as conveyance tunnels/pipelines and treatment plant Location: Kaliwa River, Barangay Daraitan, Tanay, Rizal 550 MLD US$ 510 M (PhP 23 B)

• Pre-Feasibility study of this

Project was completed in 2003. 2) Laiban Dam Project Construction of a 113-meters high rockfill dam and other appurtenant structures such as conveyance tunnels/pipelines, treatment plant & reservoirs. Location: Kaliwa River, Brgy. Laiban, Tanay, Rizal 1,900 MLD US$ 1.45 B (PhP 65 B)

• Feasibility Study and Detailed

Design of this Project was completed & updated in 2007;

• About 4,000 Affected Families

in 8 barangays will be resettled;

• New Environmental

Compliance Certificate (ECC) is in process.

MLD = million liters per day; US$1.00 = PhP45.00 MLD = million liters per day; US$1.00 = PhP45.00

POTENTIAL NEW WATER SOURCES PROJECTS POTENTIAL NEW WATER SOURCES PROJECTS

Project Description Supply Volume Project Cost Status/Remarks

3) Kanan Dam Project Construction of a dam and a transbasin tunnel to the Laiban Dam reservoir Location: Kanan River General Nakar, Quezon 3,270 MLD US$ 1.30 B (PhP 60 B)

• Pre-Feasibility study of

this Project was completed in 2003.

• May be considered as

a next stage development after the Laiban Dam Project

MLD = million liters per day MLD = million liters per day US$1.00 = PhP45.00 US$1.00 = PhP45.00

POTENTIAL NEW WATER SOURCES PROJECTS POTENTIAL NEW WATER SOURCES PROJECTS

Project Description Supply Volume Project Cost Status/Remarks

7 Rivers of Laguna 300 MLD+ N/A

• Feasibility study

unavailable Wawa River 50 MLD US$ 100 M (PhP 4.5 B)

• Feasibility study

completed in 2006 Laguna Lake 500 MLD N/A

• Feasibility study

unavailable

MLD = million liters per day MLD = million liters per day US$1.00 = PhP45.00 US$1.00 = PhP45.00

Project Location

13km transbasin tunnel

Laiban Dam

Angat Reservoir

ANGAT DAM Kaliwa Low Dam Kanan Dam

Development of Replacement Source Development of Replacement Source for Irrigation: for Irrigation:

Angat Dam is a multi-purpose facility serving domestic water supply, power supply and irrigation water. MWSS’ present water allocation in the Angat Reservoir:

Original Allocation = 22.0 cms Conditional Allocation from Irrigation water rights = 15.0 cms Umiray-Angat Transbasin Tunnel = 9.0 cms TOTAL = 46.0 cms

• r

4,000 mld

cms cms = cubic meters per second = cubic meters per second mld mld = million liters per day = million liters per day

Development of Replacement Source Development of Replacement Source for Irrigation: for Irrigation:

In 1988, the National Water Resources Board (NWRB) granted a conditional allocation of 15 cubic meter per second (15cms) to MWSS

• ut
• f

the unutilized allocation of the National Irrigation Administration (NIA) irrigation requirement; MWSS is proposing to develop an alternative source to replace/substitute the 15cms of NIA’s allocation from Angat Reservoir.

cms cms = cubic meters per second = cubic meters per second

Alternative Sources Alternative Sources To Replace The 15 CMS Conditional Allocation To Replace The 15 CMS Conditional Allocation

Project Description Potential Supply Volume Project Cost

(Estimate)

1) Apalit-Pampanga River Construction of a diversion/intake structures to utilize the irrigation return flows and the normal flow available from the Pampanga River Location: Apalit, Pampanga 20 CMS US$ 110 M (PhP 5 B) 2) Pampanga River Diversion Construction of a diversion/intake structures to utilize the normal flow available from the Bagabag River Location: Calumpit, Bulacan 20 CMS US$ 110 M (PhP 5 B)

CMS = cubic meters per second , US$1.00 = PhP45.00 CMS = cubic meters per second , US$1.00 = PhP45.00

Alternative Sources Alternative Sources To Replace The 15 CMS Conditional Allocation To Replace The 15 CMS Conditional Allocation

Project Description Supply Volume Project Cost

3) Candaba Water Resource Project A 1,000 hectares water impounding dam project at the Candaba Swamp Location: Candaba, Pampanga 15 CMS US$ 220 M (PhP10 B) 4) Balintingon Multi-Purpose Dam Project A multi-purpose high-head dam project by NIA intended for power and irrigation Location: General Tinio, Nueva Ecija 17 CMS US$ 440 M (PhP20 B)

CMS = cubic meters per second CMS = cubic meters per second US$1.00 = PhP45.00 US$1.00 = PhP45.00

Development of Replacement Source Development of Replacement Source for Irrigation: for Irrigation:

Technical Working Group (TWG) composed of MWSS, NIA and the Concessionaires (Maynilad and Manila Water) is preparing a Memorandum of Understanding (MOU) for the joint undertaking of the Project (re: 15 CMS Water Source Development Project); The TWG will hire consultant:

• to

evaluate the most viable and best alternative replacement source;

• to prepare the selected source biddable by 2012.

CMS = cubic meters per second CMS = cubic meters per second

THANK YOU… THANK YOU…
