NEURO-OPHTHALMIC DIAGNOSES NOT TO MISS Nailyn Rasool Assistant Professor of Neurology and Ophthalmology University of California, San Francisco OBJECTIVES Become comfortable with the neuro-ophthalmic examination Identify and manage

slide-1
SLIDE 1

NEURO-OPHTHALMIC DIAGNOSES NOT TO MISS

Nailyn Rasool Assistant Professor of Neurology and Ophthalmology University of California, San Francisco

slide-2
SLIDE 2

OBJECTIVES

  • Become comfortable with the

neuro-ophthalmic examination

  • Identify and manage neuro-
  • phthalmic emergencies
  • Have fun!!
slide-3
SLIDE 3
  • Not all Optic Neuritis is made equal
  • Transient Monocular Vision loss is a TIA
  • Don’t forget GCA! (This is neuro-op after all!)
  • Think twice about a young 6th
  • If the MRI doesn’t match the patient – check again
  • A Temporal Visual Field Defect = Optic Chiasm until proven otherwise
  • Even if it’s just in one eye

Take Home Points

slide-4
SLIDE 4

NEURO-OPHTHALMOLOGY: X MARKS THE SPOT!

Divided into Afferent and Efferent Systems

ALL ABOUT LOCALIZATION!

slide-5
SLIDE 5

Neuro-Op in a Nutshell

LOCALIZATION OF AFFERENT DYSFUNCTION

  • Globe / Retina
  • Optic Nerve
  • Chiasm
  • Optic Tract
  • Optic Radiations
slide-6
SLIDE 6

LOCALIZATION EFFERENT DYSFUNCTION

Muscle Junction Nerve ­ Orbit ­ Orbital Apex ­ Cavernous sinus ­ Subarachnoid space Brainstem

  • Nucleus
  • Internuclear

Supranuclear

slide-7
SLIDE 7
slide-8
SLIDE 8

ACUTE VISION LOSS

slide-9
SLIDE 9

HISTORY OF PRESENT ILLNESS

  • 32 year old Asian woman
  • “For the past 2 days it looks like I’m

looking through a dirty glass in my right eye”

  • “I have some discomfort when I move my

eye"

slide-10
SLIDE 10

Right Left Visual acuity (cc) 20/800 20/20-1 Color (HRR) 3/6 6/6 Pupils Right RAPD External Examination Normal Neuro-exam Normal Normal

EXAMINATION

slide-11
SLIDE 11

VISUAL FIELDS

slide-12
SLIDE 12
slide-13
SLIDE 13
slide-14
SLIDE 14
slide-15
SLIDE 15

2 DECADES SINCE THE ONTT

What Has Changed?

slide-16
SLIDE 16

LET’S CHANGE THE STORY

slide-17
SLIDE 17
slide-18
SLIDE 18
slide-19
SLIDE 19

DOES ANY OF THIS MATTER?

MS disease-modifying therapies aggravate NMOSD and can result in relapses and worse outcomes Includes IFN-beta, natalizumab, fingolimod and alemtuzumab Early appropriate therapy results in reduced disability and recurrences

slide-20
SLIDE 20
slide-21
SLIDE 21

HISTORY OF PRESENT ILLNESS

  • 45 year old East Asian woman
  • “I was working on my computer

yesterday and things became dark in my left eye – like a shade. It lasted around two minutes and then slowly resolved. There was no pain.”

  • I’m fine now
slide-22
SLIDE 22

Right Left Visual acuity (cc) 20/20-2 20/20-1 Color 6/6 6/6 Pupils Normal Visual Fields Normal Neuro-Exam Normal Optic nerves Normal

EXAMINATION

Alright, you can go. Please get a CT head and carotid ultrasound done later this week!

slide-23
SLIDE 23

Right Left Visual acuity (cc) 20/20-2 Count Fingers Color 6/6 Unable Pupils Left RAPD Visual Fields Normal Diffuse loss Neuro-Exam Normal

NEXT DAY

slide-24
SLIDE 24
slide-25
SLIDE 25
slide-26
SLIDE 26

TRANSIENT MONOCULAR VISION LOSS

slide-27
SLIDE 27
slide-28
SLIDE 28
slide-29
SLIDE 29
slide-30
SLIDE 30
slide-31
SLIDE 31
slide-32
SLIDE 32
slide-33
SLIDE 33
slide-34
SLIDE 34
slide-35
SLIDE 35
slide-36
SLIDE 36

MANAGE AS A TRANSIENT ISCHEMIC ATTACK OR MINOR STROKE

  • Neuroimaging
  • Vascular imaging
  • Cardiac evaluation
  • Risk Factor Management
  • Anti-platelet therapy
  • Hypercoaguable work-up

TRANSIENT MONOCULAR VISION LOSS

slide-37
SLIDE 37

DOUBLE VISION

slide-38
SLIDE 38

HISTORY OF PRESENT ILLNESS

  • 42 year old Caucasian Male
  • “2 weeks ago I began to see double side-

by-side. Its worse looking far away and to the right. But its better now. Now I only notice it when i’m really looking in the

  • distance. Up close is much better.”
  • Some headaches when I lay flat
  • Ya, I guess when I sleep I hear my heart

beating– but that’s been going on a while

slide-39
SLIDE 39

Right Left Visual acuity (cc) 20/20 20/20-1 Color (HRR) 6/6 6/6 Pupils Normal External Examination Normal

EXAMINATION

  • 0.5

RIGHT LEFT

slide-40
SLIDE 40

DISCUSSION

  • Isolated 6th nerve palsy
  • No brainstem / long tract signs
  • No adjacent CN affected
  • No Horners
  • No optic nerve swelling
  • No Diabetes or vasculopathy
  • Young
  • No Trauma
  • Young 6th’s (<50)
  • 33% Intracranial Tumor
  • 24% Demyelinating
  • 9% Post-viral
  • 7% IIH
  • 7% Meningitis
  • Older 6th’s (>50) + Vascular RF
  • Microvascular most common!!
  • Don’t forget GCA!
  • Should resolve over 3 months
  • Follow closely to ensure

improvement

  • Not BILATERAL
slide-41
SLIDE 41

Courtesy of M. Amans MD.

slide-42
SLIDE 42

THINK TWICE ABOUT A YOUNG 6TH

slide-43
SLIDE 43
slide-44
SLIDE 44

60 yo F diagnosed with left sided Bell’s palsy and sinusitis 4 days prior PmHx: Alcohol abuse Treated with 1 week course of steroids and antibiotics . HbA1c 10.7% Starts to develop numbness on her left cheek and develops double vision 2 days later, loses vision in the left eye

HISTORY OF PRESENT ILLNESS

Courtesy of Z. Haq, MD.

slide-45
SLIDE 45

EXAMINATION

Right Left Visual acuity (cc) 20/20 NLP Color 6/6 None Visual Fields Full None Pupils Left RAPD Motility Normal Ptosis and Ophthalmoplegia Cranial Nerves Normal Decreased sensation in V1, V2 Left LMN 7th Poor hearing

slide-46
SLIDE 46

3 days prior 2 days prior 1 day prior

Courtesy of Z. Haq, MD.

slide-47
SLIDE 47

MR BRAIN + MRA WWO

Axial T1 Fat Suppression Relatively diminished enhancement of left orbital contents Axial T2 FLAIR Signal abnormality involving the left ifrontal lobe

slide-48
SLIDE 48
slide-49
SLIDE 49

POD#1

POD#2

Dusky gray tissue Web-like mold

Pupil OD 3 mm and non- reactive + Right-sided hemiplegia ↓ Complete occlusion of left internal carotid artery 2/2 infectious thrombophlebitis Multifocal MCA/PCA watershed infarcts

Courtesy of Z. Haq, MD.

slide-50
SLIDE 50

Courtesy of J. Crawford, MD.

H&E High magnification

Filaments Non-septate hyphae Wide angle branching

MUCORMYCOSIS

slide-51
SLIDE 51

Courtesy of J. Crawford, MD.

Angioinvasion

slide-52
SLIDE 52

INVASIVE FUNGAL SINUSITIS DIAGNOSTIC CONSIDERATIONS

Signs and symptoms overlap with many other processes

  • Maintain a high index of suspicion in immunocompromised patietns

Nasal endoscopy (NOT sensitive): pallor +/- frank necrosis +/- eschar Imaging: MRI is more sensitive than CT ↑ tissue contrast enhancement (CE): active infection with inflammation ↓ tissue contrast enhancement (LoCE): devitalization and necrosis Histology (frozen sections): PPV ~ 100%, NPV = 50 to 72% Culture (speciation): only positive in 55 to 67% of histology-positive IFS cases

Kalin-Hajdu et al. Invasive fungal sinusitis: treatment of the orbit. COO. 2017. 28:522-533.

slide-53
SLIDE 53

THERAPEUTIC CONSIDERATIONS

Kalin-Hajdu et al. Invasive fungal sinusitis: treatment of the orbit. COO. 2017. 28:522-533.

Initiation of systemic anti-fungal medication and consider intraorbital antifungals Zygomycetes: liposomal amphotericin-B Aspergillus: voriconazole Endoscopic debridement of necrotic sinonasal tissue Low-risk procedure that confers improved survival (large case series) ↓ fungal load and ↑ access for medication and host immune system Reduce immune suppression when feasible Readily reversed in DM with control of hyperglycemia Hyperbaric oxygen?

slide-54
SLIDE 54

PROGNOSIS

Mortality = 50.3% (based on largest review to date) Negative factors Advanced age Low absolute neutrophil count (< 500/𝛎l)* Zygomycetes* Orbital involvement (50 to 60%)* Intracranial extension Positive factors DM Early detection with disease isolated to the nasal cavity Sinus debridement

Kalin-Hajdu et al. Invasive fungal sinusitis: treatment of the orbit. COO. 2017. 28:522-533.

slide-55
SLIDE 55
slide-56
SLIDE 56

CASE

  • 65 yo Man
  • Acute onset headache, blurred vision, double vision
  • Labile blood pressure
slide-57
SLIDE 57
slide-58
SLIDE 58
slide-59
SLIDE 59
slide-60
SLIDE 60
slide-61
SLIDE 61

A UNILATERAL TEMPORAL VISUAL FIELD CUT = CHIASMAL LESION!

slide-62
SLIDE 62

FUNDI

slide-63
SLIDE 63
slide-64
SLIDE 64

CAVERNOUS SINUS SYNDROME

  • Cavernous sinus contains:
  • CN III, IV, V1, V2, VI
  • Sympathetic fibers to eye
  • Internal carotid artery
  • Signs & Symptoms:
  • Ocular motor palsies (single or multiple; uni or

bilateral)

  • Severe headache
  • Numbness in V1 and or V2
  • Disturbance of vision (optic nerve or chiasm

which run ABOVE the cavernous sinuses)

slide-65
SLIDE 65

DDX OF CAVERNOUS SINUS SYNDROME

  • Carotid-cavernous fistula
  • Cavernous Sinus Thrombosis
  • Infection (Fungus: Mucor, Rhizopus)
  • Pituitary tumor or apoplexy
  • Tolosa Hunt Syndrome
  • Nasopharyngeal ca (Southern China)
  • Metastatic ca, lymphoma
slide-66
SLIDE 66

PITUITARY APOPLEXY

slide-67
SLIDE 67

PITUITARY APOPLEXY

  • Headache/Neck Pain
  • Photophobia
  • Nausea/Vomit
  • Ophthalmoplegia
  • Bilateral vision loss
  • Alteration of

consciousness

slide-68
SLIDE 68

PITUITARY APOPLEXY

  • May be the initial presentation of a pituitary tumor
  • May be precipitated by:
  • Trauma
  • Radiation
  • Anticoagulation
slide-69
SLIDE 69

MANAGEMENT

  • Transfer patient to Neurosurgery & Neuro ICU
  • Initiate IV steroids (life saving)
  • Monitor electrolytes closely
slide-70
SLIDE 70
  • Not all Optic Neuritis is made equal
  • Consider NMO/MOG in atypical cases
  • Amaurosis Fugax and Ocular Ischemia should be managed as a minor stroke / TIA
  • Don’t forget GCA!
  • Think twice about a young 6th
  • If the MRI doesn’t match the ophthalmoplegic patient – check again
  • Think Fungus!
  • A Temporal Visual Field Defect = Optic Chiasm
  • Even if it’s just in one eye

Conclusions
