SLIDE 1

Network Flows Upper bounds on flow

Network Flows

Math 482, Lecture 23 Misha Lavrov March 30, 2020

SLIDE 2

Network Flows Upper bounds on flow

Definition of a network

s 1 2 3 4 t

1 2 3 2 2 1 3 2

A set N of nodes. Here, N = {s, 1, 2, 3, 4, t}. Node s is the source and node t is the sink.

SLIDE 3

Network Flows Upper bounds on flow

Definition of a network

s 1 2 3 4 t

1 2 3 2 2 1 3 2

A set N of nodes. Here, N = {s, 1, 2, 3, 4, t}. Node s is the source and node t is the sink. A set A of arcs: pairs of nodes. In this example,

A = {(s, 1), (s, 2), (1, 2), (2, 3), (3, 1), (3, 4), (3, t), (4, 1)}.

SLIDE 4

Network Flows Upper bounds on flow

Definition of a network

s 1 2 3 4 t

1 2 3 2 2 1 3 2

A set N of nodes. Here, N = {s, 1, 2, 3, 4, t}. Node s is the source and node t is the sink. A set A of arcs: pairs of nodes. In this example,

A = {(s, 1), (s, 2), (1, 2), (2, 3), (3, 1), (3, 4), (3, t), (4, 1)}.

A nonnegative real capacity cij on each arc (i, j). Here, cs1 = 1, c12 = 3, and so on.

SLIDE 5

Network Flows Upper bounds on flow

Definition of a network

s 1 2 3 4 t

1 2 3 2 2 1 3 2

A set N of nodes. Here, N = {s, 1, 2, 3, 4, t}. Node s is the source and node t is the sink. A set A of arcs: pairs of nodes. In this example,

A = {(s, 1), (s, 2), (1, 2), (2, 3), (3, 1), (3, 4), (3, t), (4, 1)}.

A nonnegative real capacity cij on each arc (i, j). Here, cs1 = 1, c12 = 3, and so on.

SLIDE 6

Network Flows Upper bounds on flow

Definition of a network flow, I

A flow x assigns a number xij to each arc (i, j) ∈ A. s 1 2 3 4 t

1/1 1/2 1/3 2/2 0/2 0/1 2/3 0/2

We write “p/q” on an arc (i, j) with flow xij = p and capacity cij = q.

SLIDE 7

Network Flows Upper bounds on flow

Definition of a network flow, I

A flow x assigns a number xij to each arc (i, j) ∈ A. s 1 2 3 4 t

1/1 1/2 1/3 2/2 0/2 0/1 2/3 0/2

We write “p/q” on an arc (i, j) with flow xij = p and capacity cij = q. A flow represents stuff moving from s to t; xij is the amount

f stuff moving along arc (i, j).

SLIDE 8

Network Flows Upper bounds on flow

Definition of a network flow, I

A flow x assigns a number xij to each arc (i, j) ∈ A. s 1 2 3 4 t

1/1 1/2 1/3 2/2 0/2 0/1 2/3 0/2

We write “p/q” on an arc (i, j) with flow xij = p and capacity cij = q. A flow represents stuff moving from s to t; xij is the amount

f stuff moving along arc (i, j).

For this to make sense, we want to add some constraints on x for it to be a feasible flow.

SLIDE 9

Network Flows Upper bounds on flow

Definition of a network flow, II

Constraints on a feasible flow: Capacity constraints: for every arc (i, j) ∈ A, xij ≤ cij.

SLIDE 10

Network Flows Upper bounds on flow

Definition of a network flow, II

Constraints on a feasible flow: Capacity constraints: for every arc (i, j) ∈ A, xij ≤ cij. Nonnegativity constraints: x ≥ 0.

SLIDE 11

Network Flows Upper bounds on flow

Definition of a network flow, II

Constraints on a feasible flow: Capacity constraints: for every arc (i, j) ∈ A, xij ≤ cij. Nonnegativity constraints: x ≥ 0. Flow conservation: at every node k ∈ N except for s and t, the total flow going in is equal to the total flow going out. s 1 2 3

1/2 1/3 2/2

At node k = 2, we must have xs2 + x12 = x23. Here, 1 + 1 = 2.

SLIDE 12

Network Flows Upper bounds on flow

More on flow conservation

The excess at a node k is the difference between the total flow into k and the total flow out of k: ∆k(x) :=

i:(i,k)∈A

xik −

j:(k,j)∈A

xkj.

SLIDE 13

Network Flows Upper bounds on flow

More on flow conservation

The excess at a node k is the difference between the total flow into k and the total flow out of k: ∆k(x) :=

i:(i,k)∈A

xik −

j:(k,j)∈A

xkj. Flow conservation: at every node k = s, t, ∆k(x) = 0.

SLIDE 14

Network Flows Upper bounds on flow

More on flow conservation

The excess at a node k is the difference between the total flow into k and the total flow out of k: ∆k(x) :=

i:(i,k)∈A

xik −

j:(k,j)∈A

xkj. Flow conservation: at every node k = s, t, ∆k(x) = 0. At the sink t, the excess ∆t(x) represents the amount of stuff we’ve successfully brought to t from s. This is called the value of x.

SLIDE 15

Network Flows Upper bounds on flow

More on flow conservation

The excess at a node k is the difference between the total flow into k and the total flow out of k: ∆k(x) :=

i:(i,k)∈A

xik −

j:(k,j)∈A

xkj. Flow conservation: at every node k = s, t, ∆k(x) = 0. At the sink t, the excess ∆t(x) represents the amount of stuff we’ve successfully brought to t from s. This is called the value of x. We can prove that ∆s(x) = −∆t(x): the amount of gain at t is equal to the amount of loss at s. (This should follow from flow conservation.)

SLIDE 16

Network Flows Upper bounds on flow

The maximum flow LP

The maximum flow problem to find the feasible flow in a network with the maximum value can be written as a linear program: maximize

x∈R|A|

i:(i,t)∈A

xit −

j:(t,j)∈A

xtj subject to

i:(i,k)∈A

xik −

j:(k,j)∈A

xkj = 0 (k ∈ N, k = s, t) xij ≤ cij (i, j) ∈ A x ≥ 0

SLIDE 17

Network Flows Upper bounds on flow

The maximum flow LP

The maximum flow problem to find the feasible flow in a network with the maximum value can be written as a linear program: maximize

x∈R|A|

i:(i,t)∈A

xit −

j:(t,j)∈A

xtj subject to

i:(i,k)∈A

xik −

j:(k,j)∈A

xkj = 0 (k ∈ N, k = s, t) xij ≤ cij (i, j) ∈ A x ≥ 0 We can assume there are no arcs into s or out of t. In that case, value of x =

i:(i,t)∈A

xit =

j:(s,j)∈A

xsj.

SLIDE 18

Network Flows Upper bounds on flow

How can we tell if a flow is optimal?

The flow in the example below has a value of 7. Can we do better? s a b t

3/3 4/4 1/5 2/2 5/7

SLIDE 19

Network Flows Upper bounds on flow

How can we tell if a flow is optimal?

The flow in the example below has a value of 7. Can we do better? s a b t

3/3 4/4 1/5 2/2 5/7

No; the arcs out of s are all at their maximum capacity. We can’t send more than 7 flow out of s.

SLIDE 20

Network Flows Upper bounds on flow

How can we tell if a flow is optimal?

The flow in the example below has a value of 7. Can we do better? s a b t

3/3 4/7 0/3 3/5 4/4

SLIDE 21

Network Flows Upper bounds on flow

How can we tell if a flow is optimal?

The flow in the example below has a value of 7. Can we do better? s a b t

3/3 4/7 0/3 3/5 4/4

No: the arcs from {s, b} to {a, t} are all at their maximum capacity, and the arcs from {a, t} to {s, b} are all at capacity 0. We can’t send more than 7 flow from {s, b} to {a, t}.

SLIDE 22

Network Flows Upper bounds on flow

Cuts

Definition An cut in a network is a partition of the node set N into two sets S and T, such that s ∈ S and t ∈ T.

SLIDE 23

Network Flows Upper bounds on flow

Cuts

Definition An cut in a network is a partition of the node set N into two sets S and T, such that s ∈ S and t ∈ T. The capacity of a cut (S, T) is the sum

i∈S
j∈T

cij. (If (i, j) / ∈ A, we say that cij = 0.)

SLIDE 24

Network Flows Upper bounds on flow

Cuts

Definition An cut in a network is a partition of the node set N into two sets S and T, such that s ∈ S and t ∈ T. The capacity of a cut (S, T) is the sum

i∈S
j∈T

cij. (If (i, j) / ∈ A, we say that cij = 0.) s a b t

3 7 3 5 4

Here, S = {s, b}, T = {a, t}, and the capacity is csa + cbt = 7.

SLIDE 25

Network Flows Upper bounds on flow

Cuts are upper bounds on flows

Theorem If a feasible flow x has value v(x), and a cut (S, T) has capacity c(S, T), then v(x) ≤ c(S, T).

SLIDE 26

Network Flows Upper bounds on flow

Cuts are upper bounds on flows

Theorem If a feasible flow x has value v(x), and a cut (S, T) has capacity c(S, T), then v(x) ≤ c(S, T). Proof idea: consider the sum

k∈S

 

j:(k,j)∈A

xkj −

i:(i,k)∈A

xik   By computing this sum in two ways, we show that it is equal to v(x), and also that it is at most c(S, T).

SLIDE 27

Network Flows Upper bounds on flow

Step 1

In the sum

k∈S

 

j:(k,j)∈A

xkj −

i:(i,k)∈A

xik   the difference (in orange) is the net flow out of k. When k = s, it is 0. When k = s, it is the value of the flow. Therefore

k∈S

 

j:(k,j)∈A

xkj −

i:(i,k)∈A

xik   =

j:(s,j)∈A

xsj −

i:(i,s)∈A

xis = v(x).

SLIDE 28

Network Flows Upper bounds on flow

Step 2

How many times, and with what sign, does xij appear in the sum

k∈S

 

j:(k,j)∈A

xkj −

i:(i,k)∈A

xik  ?

SLIDE 29

Network Flows Upper bounds on flow

Step 2

How many times, and with what sign, does xij appear in the sum

k∈S

 

j:(k,j)∈A

xkj −

i:(i,k)∈A

xik  ? Once, with + sign, if i ∈ S. Once, with − sign, if j ∈ S.

SLIDE 30

Network Flows Upper bounds on flow

Step 2

How many times, and with what sign, does xij appear in the sum

k∈S

 

j:(k,j)∈A

xkj −

i:(i,k)∈A

xik  ? Once, with + sign, if i ∈ S. Once, with − sign, if j ∈ S. Therefore

k∈S

 

j:(k,j)∈A

xkj −

i:(i,k)∈A

xik   =

i∈S
j∈T

xij −

i∈T
j∈S

xij.

SLIDE 31

Network Flows Upper bounds on flow

Step 2, continued

k∈S

 

j:(k,j)∈A

xkj −

i:(i,k)∈A

xik   =

i∈S
j∈T

xij −

i∈T
j∈S

xij.

SLIDE 32

Network Flows Upper bounds on flow

Step 2, continued

k∈S

 

j:(k,j)∈A

xkj −

i:(i,k)∈A

xik   =

i∈S
j∈T

xij −

i∈T
j∈S

xij. For the sum in red, use xij ≤ cij:

i∈S
j∈T

xij ≤

i∈S
j∈T

cij = c(S, T).

SLIDE 33

Network Flows Upper bounds on flow

Step 2, continued

k∈S

 

j:(k,j)∈A

xkj −

i:(i,k)∈A

xik   =

i∈S
j∈T

xij −

i∈T
j∈S

xij. For the sum in red, use xij ≤ cij:

i∈S
j∈T

xij ≤

i∈S
j∈T

cij = c(S, T). The sum in blue is ≥ 0, so for an upper bound, we can ignore it.

SLIDE 34

Network Flows Upper bounds on flow

Step 2, continued

k∈S

 

j:(k,j)∈A

xkj −

i:(i,k)∈A

xik   =

i∈S
j∈T

xij −

i∈T
j∈S

xij. For the sum in red, use xij ≤ cij:

i∈S
j∈T

xij ≤

i∈S
j∈T

cij = c(S, T). The sum in blue is ≥ 0, so for an upper bound, we can ignore it. We conclude that v(x) =

k∈S

 

j:(k,j)∈A

xkj −

i:(i,k)∈A
