Natural Metal Finishes by Boyd Waechter History of Natural Metal Finishes Floquil Bright Silver and Old Silver, Pactra Flat Aluminum - all enamels, none produce a true, realistic metal finish, pigments too coarse Liqua-A- Plate

slide-1
SLIDE 1

Natural Metal Finishes

by Boyd Waechter

slide-2
SLIDE 2

History of Natural Metal Finishes

Floquil Bright Silver and Old Silver, Pactra Flat Aluminum - all enamels, none produce a true, realistic metal finish, pigments too coarse “Liqua-A-Plate” – produced by Bob Moore in the mid 1970’s, very fragile and hard to use, came in multiple shades, very toxic odor “Spray ‘N’ Plate” - produced by Advance Products in the late 70’s, easier to use, but still very fragile and could not be masked over without difficulty, one shade only

slide-3
SLIDE 3

Monogram 1/48th SNJ-5 Texan – Built in 1980 and painted with Spray N Plate

slide-4
SLIDE 4
slide-5
SLIDE 5

History of Natural Metal Finishes

SNJ Spray Metal – produced by SNJ Metal Products in liquid form and powder (dangerous to use), can not mask over it – no longer available. Alclad – a derivative of Spray N Plate, based on similar formula, but pigments ground finer. Lacquer based, so must put down barrier between plastic and paint. Very extensive range of colors, easiest to use. Humbrol, Xtracolor, Gunze Sanyo, Testors, etc. all now produce metalizer paints to some degree.

slide-6
SLIDE 6

ICM 1/48th P-51B Mustang – Painted with SNJ Spray Metal

slide-7
SLIDE 7

Silver Pastes

  • Rub ‘n Buff
  • Treasure Gold
  • Both available at Hobby Lobby
slide-8
SLIDE 8

Tamiya 1/32nd Spitfire Mk.IX – Finished with Treasure Gold

slide-9
SLIDE 9

Tamiya TS-17 Gloss Aluminum

Rattle Can Silver Paint

Dupli-Color Metallic Silver (GM)

slide-10
SLIDE 10

Lone Star Models 1/48th XB-42 painted with Dupli-Color Silver Paint

slide-11
SLIDE 11

Building NM Finished Models

  • Must have large amount of patience. If not, DON’T build

natural metal models!

  • Start with a good quality kit that has good fit (Tamiya, Hase-

gawa, AFV Club, Revell/Germany, etc.).

  • Spending time test fitting parts to minimize or eliminate use
  • f fillers will pay dividends later on.
  • Assemble as much of model with super glue, or liquid glues like

Texnax 7R or Testors Liquid Cement as you can.

  • Use gap filling super glue or kit plastic in lieu of putty when-

ever possible .

slide-12
SLIDE 12
  • To minimize deep scratches in the plastic, NEVER use any

sandpaper or a sanding stick heavier than 600 grit.

  • ALL imperfections in the plastic and seams must be

repaired before painting begins – use super glue or primer.

  • Putty must be over coated with super glue and sanded
  • smooth. Putty is NOT your friend when using metalizers.
  • Prior to painting, polish all seams with Blue Magic or

Novus polishing creams, then wipe model down w/ alcohol.

  • Use pin light and magnifier to check all seams.
  • Prime all seams with Testor’s Non-Buffing Aluminum.
  • Repair any imperfections before continuing.
slide-13
SLIDE 13

Heller 1/72nd EC-121 polished prior to priming seams

slide-14
SLIDE 14

EC-121 after wing seams and engines have been primed with Testor’s Aluminum

slide-15
SLIDE 15

Which One To Use?

slide-16
SLIDE 16

Testors Metalizers

Not as difficult to use as some report No primer necessary Mix 1:1 with lacquer thinner (do not use straight out of the bottle) All colors must be painted first and then masked off Mist on in 2 to 3 coats, 18-20 psi Easily repairable, blends in nicely Can be masked over with care Extensive range of colors, widely available, less expensive ($5.00)

Alclad II Metalizers

Most durable Can be masked over after model is painted Model must be primed in either gloss gray or gloss black paints, so additional step is necessary Primer will help fill any minute scratches or imperfections Limited availability locally Expensive ($7.99 per bottle via Sprue Brothers) 23 basic colors

slide-17
SLIDE 17

Always wash your hands after using metalizer paints.

slide-18
SLIDE 18

Hobbycraft 1/48th F-94B Starfire painted using Testors Metalizers

slide-19
SLIDE 19

Paneling affect on Trumpeter 1/32nd F-105B (Conv) using Alclad II paints.

slide-20
SLIDE 20
slide-21
SLIDE 21

Fisher 1/32nd Hawker Sea Fury T.20 Racer using Alclad II paints

slide-22
SLIDE 22

Paneling affect on Airfix 1/48th E.E. Lightning using Alclad II paints

slide-23
SLIDE 23

Paneling affect with various shades of Testors metalizer paints

slide-24
SLIDE 24

Using Floquil Silver Paints

  • These are NOT metalizers, but lacquer based paints
  • Three basic colors - Old Silver, Bright Silver, Platinum Mist
  • Very hard and durable once dry
  • Pigments are coarse, so best to use a medium tip and needle
  • Pigments will settle in color cup, so best to use in gravity

feed airbrush or using spray jar

  • Some people polish these paints after application with Brasso
slide-25
SLIDE 25

Accurate Miniatures 1/48th SBD-5 using Floquil Old Silver

For old, weathered look

slide-26
SLIDE 26

Other Finishes

slide-27
SLIDE 27

Testors Non-Buffing Aluminum oversprayed with Dullcote

slide-28
SLIDE 28

Testor’s Non-Buffing Aluminum over sprayed with Metalizer sealer

RAF/Royal Navy High Speed Finish

slide-29
SLIDE 29

Examples of Natural Metal Models

slide-30
SLIDE 30

Classic Airframes 1/48th B-57B Canberra, Edwards AFB

slide-31
SLIDE 31

Trumpeter 1/32nd F-105B Conversion

slide-32
SLIDE 32

Hobbycraft 1/48th F-94B Starfire (kit decals)

slide-33
SLIDE 33

Williams Brothers 1/72nd C-46 Commando Painted using automotive silver paint

slide-34
SLIDE 34

Tamiya 1/48th P-51D Mustang Painted using ModelMaster Non-Buffing Aluminum

slide-35
SLIDE 35

Kinetic 1/32nd F-86F-25 Sabre

slide-36
SLIDE 36

Hasegawa 1/72nd Avro Lancaster Mk.III RCAF

slide-37
SLIDE 37

Italeri 1/72nd C-119G Flying Boxcar

slide-38
SLIDE 38

Matchbox 1/72nd Consolidated RY3 Privateer

slide-39
SLIDE 39

Messerschmitt Me-262

slide-40
SLIDE 40

Hasegawa 1/72nd B-25J Mitchell RCAF

slide-41
SLIDE 41

Summary

Always start with the best fitting kit available of the subject you want to build. Natural metal finishes require a lot of extra time. Must plan ahead on application of colors, shades of metalizers, etc. Although a bit more expensive and it is a two step process, Alclad II is recommended for someone just beginning to do natural metal finishes. www.alclad2.com

slide-42
SLIDE 42

Bye Bye Boys!
