Nano Star Tracker AZDK-1 M.K. Abubekerov, M.E. Prokhorov, A.I. Zakharov, M.S. Tuchin, O.Yu. Stekolshchikov Moscow 2018 Nano Star Tracker AZDK-1 Parameters: Dimensions 566093 mm Total mass 193 g Power 0.3 W (Peak

slide-1
SLIDE 1

Nano Star Tracker AZDK-1

M.K. Abubekerov, M.E. Prokhorov, A.I. Zakharov, M.S. Tuchin, O.Yu. Stekolshchikov

Moscow 2018

slide-2
SLIDE 2

Nano Star Tracker AZDK-1

Parameters:

Dimensions – 56×60×93 mm

  • Total mass – 193 g
  • Power – 0.3 W (Peak – 1.25 W)
  • Accuracy – 5 arc sec
  • Accuracy – 5 arc sec
  • Maximum slew rate – 3°/ sec
  • Output Solution – 5 Hz
  • FOV – 20°
  • Detector – 1024×1280 CMOS
  • Stars – till 5,8m

Catalog – 2400 stars

slide-3
SLIDE 3

Well-pack Nano Star Tracker AZDK-1

3

slide-4
SLIDE 4

Flex-rigid PCB

4

slide-5
SLIDE 5

5

slide-6
SLIDE 6

6

slide-7
SLIDE 7

The appearance of the Nano star tracker AZDK-1

slide-8
SLIDE 8

Tests on the starry sky

Ultimate magnitude (at exposure 0.1 sec) is 5.8 m

slide-9
SLIDE 9

Vibrodynamic tests

Impacts:

  • Sinusoidal vibrations
  • Random vibrations
  • Shock vibration
slide-10
SLIDE 10

Vibrodynamic tests

slide-11
SLIDE 11

Vibrodynamic tests

Relative change in focal length is - 2.9 •10-6

slide-12
SLIDE 12

Vibrodynamic tests MEMS-gyroscope

slide-13
SLIDE 13

Thermal Vacuum Tests

Impacts :

  • from minus 27°С till + 57°С
  • rate of change 1°С per minute
  • retention in extreme points of temperature for 2

hours

slide-14
SLIDE 14

Thermal Vacuum Tests

slide-15
SLIDE 15

Thermal Vacuum Tests

slide-16
SLIDE 16

Flight tests 3U nanosatellite of the company "Sputnix" in end of 2019

slide-17
SLIDE 17

Nano Star Tracker AZDK-1 in container

17

We accept orders
